AUDIO
214
Audio remote controls (steering switches)
The switches are installed on the left side of the steering wheel.
“MODE” switch: Use this switch to turn on or off the audio
system, or change the audio mode.
 To turn on the system, push the switch briefly. To turn off the
system, push and hold the switch until you hear a beep.
 To change the audio mode, turn on the system and push the
switch briefly. If a tape or compact disc is not inserted, the
“TAPE” or “CD” mode is skipped.
“+
” switch: Use this switch to adjust the volume.
To increase the volume, push the “+” side. To decrease the
volume, push the“–” side. The volume continues to increase
or decrease while the switch is being pressed. (a) When the radio mode is selected
“
” or “” switch:
Use this switch for seek tuning or to
select a preset station.
 To select a preset station, push this switch briefly. The
station you assigned to a switch on the audio system will be
selected.
 To seek a station, push and hold this switch until you hear
a beep. The radio will begin seeking up or down for a station,
and will stop on reception.
(b) When the “TAPE” mode is selected
“
” or “” switch: Use this switch to fast forward or rewind
the tape or for automatic program selection.
 To skip forward or reward for automatic program selection,
push this switch briefly. When automatically selecting a
program, you can skip up to 9 programs at a time. For
details, see page 207 for details.
 To fast forward or rewind the tape, push this switch until you
hear a beep. To stop fast forwarding or rewinding, push and
hold the same side on the switch until you hear a beep.
(c) When the “CD” mode is selected
“
” or “” switch: Use this switch to select a desired track
or disc.
 To select a desired track, push this switch briefly.
 To select a desired disc, push and hold this switch until the
desired number of the disc appears and you hear a beep.

AUDIO
223
(c) Controller holder
The controller can be stowed in the holder when it is not
in use. The holder can be hooked on the back of the
driver’s or front passenger’s seatback.
CAUTION
To reduce the chance of injury in case of an accident or
a sudden stop while driving, stow the controller in the
holder when it is not in use.
NOTICE
Do not leave the controller exposed to high
temperatures (such as on the instrument panel) for a
long time, otherwise the controller may be damaged.
Quick reference for your remote control
22PY112

1 DISC/CH/PROG buttons

2 TUNE/TRACK buttons

3 “ON/SOURCE” button

4 “OFF” button

AUDIO
237
(c) Controller holder
The controller can be stowed in the holder when it is not
in use. The holder can be hooked on the back of the
driver’s or front passenger’s seatback.
CAUTION
To reduce the chance of injury in case of an accident or
a sudden stop while driving, stow the controller in the
holder when it is not in use.
NOTICE
Do not leave the controller exposed to high
temperatures (such as on the instrument panel) for a
long time, otherwise the controller may be damaged.
Quick reference for your remote controller
22PY041

IN CASE OF AN EMERGENCY
385
Automatic notifications
If an airbag deploys, an emergency signal is sent
automatically to the Lexus Link Call Center. In your vehicle, the
system announces “Placing an emergency call to the Lexus
Link Center.” In response to the signal, Lexus Link Advisor will
attempt to communicate with you first. If the Advisor cannot get
any response from you, the Advisor will locate your vehicle
through the GPS, call the nearest emergency services
provider, describe the situation and your location. If necessary,
the Advisor will transfer your call to the emergency services
operator.
If the theft deterrent system on your vehicle is activated,
the Lexus Link System on your vehicle will automatically call
the Lexus Link Call Center. The Advisor will attempt to contact
you to determine whether the alarm is valid.
If you report to the Lexus Link Call Center that your vehicle has
been stolen, the Advisor will locate, track and provide location
information to the appropriate law enforcement authority. To
protect subscriber privacy, the Lexus Link Call Center will not
provide the location of a vehicle to anyone other than a law
enforcement authority.
If you accidentally activate the vehicle alarm, push the
“UNLOCK” button on the wireless remote control key within 55
seconds after the alarm was set off, or insert the key into the
door keyhole or ignition switch. The Lexus Link System will
cancel the theft call.NOTICE
 Once the emergency button is pushed, an emergency
call cannot be cancelled.
 This system is only operational in GPS and analog
cellular coverage areas. Upon subscription
expiration, all Lexus Link services (i.e. automatic
notification, emergency call functions, service call
functions, door locking/unlocking function) are
deactivated.

IN CASE OF AN EMERGENCY
390
Audible voice prompts
The following table shows the voice responses from the Lexus Link System\
.Voice phrase: Explanation about Lexus Link System
This is the Lexus Link system. Integrating
global positioning satellite and wireless
communication technology into your
Lexus and providing enhanced safety,
security, and convenience. At the touch of
a button, or automatically in the event of
an accident, you are connected to a Lexus
Link Advisor who will assist you − 24 hours
a day, 7 days a week where GPS and
cellular coverage is available. The Lexus
Link System also has an audio recorder
allowing you to record reminders to
yourself or information from a Lexus Link
Advisor.
To contact a Lexus Link Advisor, press the
“SERVICES” button. The Lexus Link
System will inform the advisor of your
vehicle’s current location and your
identity. The advisors can handle a wide
variety of services, such as giving
directions to shops, gas stations, ATMs,
restaurants and roadside assistance with
location. Services available will depend
on the service package you selected.In an emergency, press the emergency
services button on your Lexus Link
console. It is marked with a red
ambulance. Upon receiving your call, the
advisor will assess the situation and, if
necessary, alert the nearest emergency
services provider. The emergency button
should only be used in life threatening
situations.
If your Lexus detects that an airbag
deployment may have occurred, the
Lexus Link System will automatically send
an emergency message to the Lexus Link
Call Center.
The system will also automatically contact
the call center if the security system alarm
goes off. An advisor will first contact you
to determine if the alarm is valid. Upon
your confirmation, the advisor will then
provide the vehicle location to the police.If you accidentally set off the alarm, press
the remote door unlock, or insert your key
in the door lock or ignition within 55
seconds. This will prevent the Lexus Link
System from placing a theft call.
The volume control lets you adjust the
volume level for Lexus Link calls, system
prompts, and memos. Press the plus key
to increase volume and the minus key to
decrease it.
To record a memo or a call, press the key
labeled “REC”. When you are finished
recording, press the “REC” button again.
To listen to the memo, press the “PLAY”
button. You can record one message up
to five minutes long. When you record a
new memo, all of the previous memos will
be erased.
For more detailed information on the use,
features and limitations of this system,
please consult your Lexus Link Owner’s
Manual.

IN CASE OF AN EMERGENCY
392
Lexus Link transceiver antenna
The Lexus Link transceiver antenna is removable. Before
taking the vehicle to an automatic car wash, disconnect
the antenna by unscrewing it from the roof mount.
NOTICE
If you forget reattaching the Lexus Link transceiver
antenna, the Lexus Link System may not function
properly.
 To prevent damage to the antenna, make sure it is
removed before driving your vehicle through an
automatic car wash.
IF YOU LOSE YOUR KEYS OR
LOCK YOURSELF OUT
You can purchase a new key at your Lexus dealer if you
can give them the key number and master key.
Even if you lose only one key, contact your Lexus dealer to
make a new key. If you lose all your master keys, you cannot
make new keys; the whole engine immobiliser system must be
replaced.
See the suggestion given in “Keys” on page 8.
You can use the wireless remote control system with the new
key. Contact your Lexus dealer for detailed information.
If your keys are locked in the vehicle and you cannot get a
duplicate, many Lexus dealers can still open the door for you
using special tools. If your vehicle is equipped with Lexus Link
System, call the Lexus Link Call Center 1 −800−25−LEXUS
(Toll−Free) (1−800−255−3987). Once you provide the Lexus
Link Call Center Advisor with your Lexus Link PIN (Personal
Identification Number), or personal security word, they will
unlock your vehicle.

ELECTRICAL COMPONENTS
445
No.FUSEAMPERECIRCUIT
13 MIR
HEATER10Outside rear view mirror defog-
ger
14 STOP10
Stop lights, high m ounted
stoplight, shift lock control
system, vehicle skid control
system, electronic m odulated
suspension, rear height control
air suspension, multiport fuel
injection system/sequential
multiport fuel injection system
15 AC115V
INV15Power outlet (115 VAC)
16 FR FOG15Front fog lights
17 OBD7.5On −board diagnosis system
18 HEAD
(LO RH)10Right− hand headlight (low beam)
19 HEAD
(LO LH)10Left− hand headlight (low beam)
20 HEAD
(HI RH)10Right− hand headlight (high
beam)
21 HEAD
(HI LH)10Left− hand headlight (high beam)
22 EFI NO.210Multiport fuel injection system/
sequential multiport fuel injection
system
23 HEATER
NO.27.5Air conditioning system
24 DEFOG30Rear window defogger
No.FUSEAMPERECIRCUIT
25 AIRSUSNO.210Rear height control air suspen-
sion
26 SEAT
HEATER20Seat heaters
27 DOME10
Ignition switch light, interior
lights, personal lights, foot
lights, running board lights,
door courtesy lights, inside
door handle lights,
multi− information display
28 RADIO
NO.120Car audio system, navigation
system
29 ECUB10
Multiplex communication
system, vehicle skid control
system, wireless remote
control system, inside rear
view mirror, air conditioning
system, electronic modulated
suspension, driving position
memory system, power
windows, moon roof
30 ECUB NO.210Theft deterrent system
31 ABS
MTR40
Anti −lock brake system,
vehicle skid control system,
active traction control system,
brake assist system
32 AM230Starting system, all components
in “IGN”, “SRS”, “GAUGE” and
“ST2” fuses
