For detailed information, refer to the description given in each Section\
.
PICTORIAL INDEX
xiv
Page
1Automatic transmission second start indicator light 401 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Unengaged Parkº warning light 68
. . . . . . . . . . . . . . .
3Automatic transmission fluid temperature
warning light 69 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4Low washer fluid warning light 73
. . . . . . . . . . . . . . . . .
5Automatic transmission indicator lights 393 . . . . . .
6Driver's seat belt reminder light 65
. . . . . . . . . . . . . . . .
7Turn signal indicator light 36
. . . . . . . . . . . . . . . . . . . . .
8Brake system warning light 64
. . . . . . . . . . . . . . . . . . . .
9Headlight high beam indicator light 36
. . . . . . . . . . . .
10Anti-lock brake system warning light 67
. . . . . . . . . . .
11Open door warning light 68
. . . . . . . . . . . . . . . . . . . . . . .
12Tachometer 60
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13Headlight indicator light 33
. . . . . . . . . . . . . . . . . . . . . . .
14Cruise control indicator light 409
. . . . . . . . . . . . . . . .
15Engine oil replacement reminder light 72
. . . . . . . . . .
16Slip indicator light 421, 423, 426, 428
. . . . . . . . . . . . .
17Low engine oil pressure warning light 71
. . . . . . . . . .
18Discharge warning light 70
. . . . . . . . . . . . . . . . . . . . . . . Page
19Engine coolant temperature gauge
58
. . . . . . . . . . . . .
20Malfunction indicator lamp 66
. . . . . . . . . . . . . . . . . . . .
21Vehicle stability control system off
indicator light 423 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22Roll sensing of curtain shield airbags off
indicator light 193 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
23Kinetic dynamic suspension system
warning light 70 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
24Center differential lock indicator light 401
. . . . . . . .
25Vehicle stability control system and active
traction control system warning light 70 . . . . . . . . . . .
26Downhill assist control system
indicator light 425 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
27Rear height control indicator lights 418
. . . . . . . . . . .
28Security indicator light 14, 29
. . . . . . . . . . . . . . . . . . . .
29SRS warning light 66
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
30Trip meter reset knob 61
. . . . . . . . . . . . . . . . . . . . . . . . .
31Odometer and trip meter 61
. . . . . . . . . . . . . . . . . . . . . .
32Low fuel level warning light 72
. . . . . . . . . . . . . . . . . . . .
33Low tire pressure warning light 72
. . . . . . . . . . . . . . . .
34Fuel gauge 57
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

For detailed information, refer to the description given in each Section\
.
PICTORIAL INDEX
xvi
Page
1Automatic transmission second start indicator light 401 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Unengaged Parkº warning light 68
. . . . . . . . . . . . . . .
3Automatic transmission fluid temperature
warning light 69 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4Low washer fluid warning light 73
. . . . . . . . . . . . . . . . .
5Automatic transmission indicator lights 393 . . . . . .
6Driver's seat belt reminder light 65
. . . . . . . . . . . . . . . .
7Turn signal indicator light 36
. . . . . . . . . . . . . . . . . . . . .
8Brake system warning light 64
. . . . . . . . . . . . . . . . . . . .
9Headlight high beam indicator light 36
. . . . . . . . . . . .
10Anti-lock brake system warning light 67
. . . . . . . . . . .
11Open door warning light 68
. . . . . . . . . . . . . . . . . . . . . . .
12Tachometer 60
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13Tail light indicator light 33
. . . . . . . . . . . . . . . . . . . . . . . .
14Cruise control indicator light 409
. . . . . . . . . . . . . . . .
15Slip indicator light 421, 423, 426, 428
. . . . . . . . . . . . .
16Low engine oil pressure warning light 71
. . . . . . . . . .
17Discharge warning light 70
. . . . . . . . . . . . . . . . . . . . . . .
18Engine coolant temperature gauge 58
. . . . . . . . . . . . . Page
19Malfunction indicator lamp
66
. . . . . . . . . . . . . . . . . . . .
20Vehicle stability control system off
indicator light 423 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
21Roll sensing of curtain shield airbags off
indicator light 193 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22Kinetic dynamic suspension system
warning light 70 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
23Center differential lock indicator light 401
. . . . . . . .
24Vehicle stability control system and active
traction control system warning light 70 . . . . . . . . . . .
25Downhill assist control system
indicator light 425 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
26Rear height control indicator lights 418
. . . . . . . . . . .
27Security indicator light 14, 29
. . . . . . . . . . . . . . . . . . . .
28SRS warning light 66
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
29Trip meter reset knob 61
. . . . . . . . . . . . . . . . . . . . . . . . .
30Odometer and trip meter 61
. . . . . . . . . . . . . . . . . . . . . .
31Low fuel level warning light 72
. . . . . . . . . . . . . . . . . . . .
32Low tire pressure warning light 72
. . . . . . . . . . . . . . . .
33Fuel gauge 57
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SWITCHES
38Twist the interval adjuster upward to increase the wiping
time
interval between sweeps, and downward to decrease
it.
The wiper lever must be in the INTº position.
The time interval between sweeps is shortened when the
vehicle speed increases. When the vehicle speed reaches
more than about 20 km/h (12 mph) with the interval adjuster in
the full upward position, the time interval becomes the shortest
1.5 seconds.
If you stop the vehicle with the wiper switch in the LOº position,
the wiper speed automatically changes from low speed to
intermittent operation speed.* This function does not work
when the interval adjuster is in the full upward position.
NOTE: * This feature can be deactivated. Ask your Lexus dealer for details.
To make the washer squirt, pull the lever toward you and
release it.
If the wiper lever is in the OFFº position, the wipers will
automatically make 3 wipes and then a single wipe later to
sweep the windshield completely.* The interval between the
3 wipes and the last wipe will depend on the vehicle speed. The
last sweep does not happen if the vehicle speed exceeds about
170 km/h (106 mph).
NOTE: * The last single wipe can be deactivated. Ask your Lexus dealer for details.
The low washer fluid warning light in the instrument cluster
comes on when the fluid level in the tank becomes nearly
empty. For information on adding washer fluid, see Adding
washer fluidº on page 622.
In cold weather, warm the windshield with the defroster before
using the washer. This will help prevent icing, which could
block your vision.

SWITCHES
42To make the washer squirt, pull the lever toward you and
release it.
If the wiper lever is in the OFFº position, the wipers will
automatically make 3 wipes and then a single wipe later to
sweep the windshield completely.* The interval between the
3 wipes and the last wipe will depend on the vehicle speed. The
last sweep does not happen if the vehicle speed exceeds about
170 km/h (106 mph).
NOTE:
* The last single wipe can be deactivated. Ask your Lexus dealer for details.
The low washer fluid warning light in the instrument cluster
comes on when the fluid level in the tank becomes nearly
empty. For information on adding washer fluid, see Adding
washer fluidº on page 622.
In cold weather, warm the windshield with the defroster before
using the washer. This will help prevent icing, which could
block your vision.
NOTICE
Do not operate the wipers if the windshield is dry. It mayscratch the glass.

SWITCHES
43
REAR WINDOW WIPER ANDWASHER SWITCH

1Washer on during wiping
2Washer on
To turn the wipers on, twist the knob at the end of the lever.
The ignition key must be in the ONº position.
There are 2 settings:
INTº position: Intermittent operation
ONº position: Low speed operation
If you stop the vehicle with the rear window wiper switch in the
ONº position, the wiper speed automatically changes from low
speed to intermittent operation speed. To make the washer squirt, twist the knob downward to
position 2.
To make the washer squirt while operating in ONº
position, twist the knob upward to position 1.
The knob automatically returns from these positions after you
release it.
The low washer fluid warning light in the instrument cluster
comes on when the fluid level in the tank becomes nearly
empty. For information on adding washer fluid, see Adding
washer fluidº on page 622.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
63
IF THIS INDICATOR OR
BUZZER COMES ON...
DO THIS.
(k)Take vehicle to Lexus
dealer.
(l)Stop and check.
(m)Stop and check.
(n)Replace engine oil.
(o)
Adjust tire inflation
pressure. If light
remains, contact
Lexus dealer.
(p)Fill up tank.
IF THIS INDICATOR ORBUZZER COMES ON...DO THIS.
(q)Add washer fluid.
(r)Key reminder buzzerRemove key.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
73
(q) Low Washer Fluid Warning Light
This light comes on when the fluid level in the tank becomes
very low. Fill the tank as soon as possible.
(r) Key Reminder Buzzer
This buzzer reminds you to remove the key when you open the
driver's door with the ignition key in the ACCº or LOCKº
position.
How to check all the service reminder
indicators (except the low fuel level warning
light)
1. Apply the parking brake.
2. Open the door.
The following service reminder indicator should come on. It
goes off when you close the door completely.
3. Place the four-wheel drive control lever in Nº position and
the selector lever in Pº position and turn the ignition key to
ACCº.
The following service reminder indicator should come on. It
goes off when you place the four-wheel drive control lever in
Hº or Lº position.

DRIVING TIPS
457
Check the condition of the battery and cables.
Cold temperatures reduce the capacity of any battery, so it
must be in top shape to provide enough power for winter
starting. Page 612
tells you how to visually inspect the battery.
Your Lexus dealer and most service stations will be pleased to
check the battery charge level.
Make sure the engine oil viscosity is suitable for the cold
weather.
See page 566 for recommended viscosity. Leaving a heavy
summer oil in your vehicle during winter months may cause
harder starting. If you are not sure about which oil to use, call
your Lexus dealer Ð they will be pleased to help. Check the electronic ignition system for loose
connections or obvious damage.
Keep the door locks from freezing.
Squirt
lock de-icer or glycerine into the locks to keep them from
freezing.
Use a washer fluid containing an antifreeze solution.
This product is available at your Lexus dealer and most auto
parts stores. Follow the manufacturer's directions for how
much to mix with water.
NOTICE
Do not use engine antifreeze or any other substitute because it may damage your vehicle's paint.

MAINTENANCE
535
Your copy of the repair order is proof that all required
maintenance has been performed for warranty coverage. If
any problems should arise with your vehicle while under
warranty,
your Lexus dealer will promptly take care of it. Again,
be sure to keep a copy of the repair order for any service
performed on your Lexus.
What about do-it-yourself maintenance?
Many of the maintenance items are easy to do yourself, if you
have a little mechanical ability and a few basic automotive
tools. Simple instructions for how to perform them are
presented in Section 6.
If you are a skilled do-it-yourself mechanic, the Lexus service
manuals are recommended. Please be aware that
do-it-yourself maintenance can affect your warranty
coverage. See your Owner's Guideº, Owner's Manual
Supplementº or Warranty Bookletº for the details.
GENERAL MAINTENANCE
Listed below are the general maintenance items that should be
performed at the intervals specified. It is recommended that
any problem you notice be brought to the attention of your
Lexus dealer or qualified service shop for their advice.
CAUTION
Make these checks only with adequate ventilation if you
run the engine.
Engine compartment
Items listed below should be checked from time to time,
e.g. each time when refueling.
Washer fluid
Make sure there is sufficient fluid in the tank. See page 622 for
additional information.
Engine coolant level
Make sure the coolant level is between the Fº and Lº lines on
the see-through reservoir when the engine is cold. See page
567 for additional information.
Radiator, condenser and hoses
Check that the front of the radiator and condenser are clean
and not blocked with leaves, dirt, or insects. See page 569 for
additional information.

61PY004
INTRODUCTION
544
NOTICE
You should not attempt to remove the theft preventionlabels as it may violate certain state or federal laws.
ENGINE COMPARTMENT OVERVIEW
1Engine oil leveldipstick
2Engine oil filler cap
3Brake fluid reservoir
4Fuse box
5Battery
6Condenser
7Electric cooling fan
8Radiator
9Engine coolantreservoir
10Washer fluid tank
11Power steering fluidreservoir
