DRIVING TIPS
456Check the condition of the battery and cables.
Cold temperatures reduce the capacity of any battery, so it
must be in top shape to provide enough power for winter
starting. Page 611
tells you how to visually inspect the battery.
Your Lexus dealer and most service stations will be pleased to
check the battery charge level.
Make sure the engine oil viscosity is suitable for the cold
weather.
See page 565 for recommended viscosity. Leaving a heavy
summer oil in your vehicle during winter months may cause
harder starting. If you are not sure about which oil to use, call
your Lexus dealer Ð they will be pleased to help. Check the electronic ignition system for loose
connections or obvious damage.
Keep the door locks from freezing.
Squirt
lock de-icer or glycerine into the locks to keep them from
freezing.
Use a washer fluid containing an antifreeze solution.
This product is available at your Lexus dealer and most auto
parts stores. Follow the manufacturer's directions for how
much to mix with water.
NOTICE
Do not use engine antifreeze or any other substitute because it may damage your vehicle's paint.

DRIVING TIPS
468
Connecting a trailer
Stop your vehicle and a trailer in line and perform the following:
1. Put the rear height control air suspension in the LOº (low)
mode. Turn the ignition switch off or push the HEIGHT
CONTROL OFFº switch to turn off the rear height control air
suspension.
2. Connect a trailer.
3. Turn the ignition switch on or push the HEIGHT CONTROL
OFFº switch to turn on the rear height control air suspension.
Select the Nº (normal) mode with the height select switch.
Disconnecting a trailer
Stop your vehicle and a trailer in line and perform the following:
1. Put the rear height control air suspension in the LOº (low)
mode. (Make sure the vehicle height is in the LOº (low) mode
by pushing the height select switch on the  º side.)
2. Turn the ignition switch off or push the HEIGHT CONTROL
OFFº switch to turn off the rear height control air suspension.
3. Set the supporting leg of a trailer on the ground and raise the
hitch by 100 mm (4 in.).
4. Turn the ignition switch on or push the HEIGHT CONTROL
OFFº switch to turn on the rear height control air suspension. 5. Wait for about 20 seconds until the rear vehicle height is
lowered by the automatic leveling function.
6. Make sure the hitch is disconnected. If not, raise the hitch
higher and repeat steps 2 through 5.
7. Move the vehicle forward in the LOº (low) mode where the
hitch does not touch anything in the Nº (normal) mode.
8. Put the rear height control air suspension in the Nº (normal)
mode.
Pre-towing safety check

Check that your vehicle remains level when a loaded or
unloaded trailer is hitched. Do not drive if the vehicle has an
abnormal nose-up or nose-down condition, and check for
improper tongue load, overload, worn suspension or other
possible causes.
 Make sure the trailer cargo is securely loaded so that it
cannot shift.
 Check that your rear view mirrors conform to any federal,
state/provincial or local regulations. If they do not, install
required rear view mirrors appropriate for towing purposes.

IN CASE OF AN EMERGENCY
480
IF YOUR ENGINE STALLS WHILEDRIVING
If your engine stalls while driving...
1. Reduce your speed gradually, keeping a straight line. Move
cautiously off the road to a safe place.
2. Turn on your emergency flashers.
3. Turn the ignition key to ACCº or LOCKº, and try starting the
engine again.
If the engine will not start, see If your vehicle will not startº.
CAUTION
If the engine is not running, the power assist for the
brakes and steering will not work, so steering and
braking will be much harder than usual.
IF YOUR VEHICLE WILL NOT START
(a) Simple checks
Before making these checks, make sure you have followed the
correct starting procedure instructions in How to start the
engineº on page 391 and that you have sufficient fuel. Since
your vehicle is equipped with the engine immobilizer system,
also check whether the other keys w ill start the engine. If they
work, your key may be broken. Have the key checked at your
Lexus dealer. If none of your keys work, there may be a
malfunction in the i mmobilizer system. Call your Lexus dealer.
See Keysº on page 8.
If the engine is not turning over or is turning over too
slowly Ð
1. Check that the battery terminals are tight and clean.
2. If the battery terminals are O.K., switch on the interior light.
3. If the light is out, dim or goes out when the starter is cranked,
the battery is discharged. You may try jump starting. See (c)
Jump startingº for further instruction.
If the light is O.K., but the engine still will not start, it needs
adjustment or repair. Call a Lexus dealer, Roadside
Assistance or Customer Service Assistance. (See
Forewordº.)

IN CASE OF AN EMERGENCY
481
NOTICE
Do not pull- or push-start the vehicle. It may damagethe vehicle or cause a collision when the engine starts.Also the three-way catalytic converter may overheatand become a fire hazard.
If the engine turns over at its normal speed but will not
start Ð
1. Turn the ignition key to ACCº or LOCKº and try starting the
engine again.
2. The engine may be flooded because of repeated cranking.
See (b) Starting a flooded engineº for further instructions.
3. If the engine still will not start, it needs adjustment or repair.
Call a Lexus dealer, Roadside Assistance or Customer Service
Assistance. (See Forewordº.)(b) Starting a flooded engine
If the engine will not start, your engine may be flooded
because of repeated cranking.
If this happens, turn the ignition key to STARTº with the
accelerator pedal fully depressed, and hold the key at this
position for about 30 seconds. Then the cranking hold function
stops cranking automatically, and you can try starting the
engine with your foot off the accelerator pedal.
If the engine does not start, wait a few minutes and try again.
If the engine still will not start, it needs adjustment or repair.
Call a Lexus dealer, Roadside Assistance or Customer Service
Assistance. (See Forewordº.)
(c) Jump starting
To avoid serious personal injury and damage to your
vehicle which might result from battery explosion, acid
burns, electrical burns, or damaged electronic
components, these instructions must be followed
precisely.

IN CASE OF AN EMERGENCY
485
IF YOU CANNOT INCREASEENGINE SPEED
If engine speed does not increase when the accelerator pedal
is depressed, there may be a problem somewhere in the
electronic throttle control system.
At this time, vibration may occur. However, if you depress the
accelerator pedal more firmly and slowly, you can drive your
vehicle at low speeds. Have your vehicle checked by your
Lexus dealer as soon as possible.
Even if the abnormality of the electronic throttle control system
is corrected during low speed driving, the system may not be
recovered until the engine is stopped and the ignition key is
turned to ACCº or LOCKº position.
CAUTION
Be especially careful to prevent erroneous pedal
operation.
IF YOUR VEHICLE OVERHEATS
If your engine coolant temperature gauge indicates
overheating, if you experience a loss of power, or if you
hear a loud knocking or pinging noise, the engine has
probably overheated.
When the engine overheats
Pull safely off the road, stop the vehicle and turn on your
emergency flashers. Put the transmission in Pº and apply the
parking brake.
A: If steam is coming from your engine:
Turn off the engine. Leave the hood closed until there is no sign
of steam or coolant. Your engine could have been seriously
damaged already. Call your Lexus dealer for assistance.
CAUTION
To help avoid personal injury, keep the hood closed until
there is no steam. Escaping steam or coolant is sign of
very high pressure.

IN CASE OF AN EMERGENCY
511
A driver must be in the vehicle to steer it and operate the
brakes.
Towing in this manner may be done only on hard-surfaced
roads
for a short distance and at low speeds. Also, the wheels,
axles, drive train, steering and brakes must all be in good
condition.
CAUTION
Use extreme caution when towing the vehicle. Avoid
sudden starts or erratic driving maneuvers which would
place excessive stress on the emergency towing eyelet
and towing cable or chain. The eyelet and towing cable
or chain may break and cause serious injury or damage.
NOTICE
Use only a cable or chain specifically intended for use in towing vehicles. Securely fasten the cable or chainto the towing eyelet provided.
Before towing, check that the center differential is unlocked.
(The indicator light must be off with the ignition on.) Release
the parking brake and put the transmission in Nº. The ignition
key must be in ACCº (engine off) or ONº (engine running).CAUTION
If the engine is not running, the power assist for the
brakes and steering will not work so steering and
braking will be much harder than usual.
Emergency towing hook precautions:
 Before emergency towing, check that the eyelet is not
broken or damaged and that the installation bolts are not
loose.
 Fasten the towing cable or chain securely to the hook.
 Do not jerk the eyelet. Apply steady and even force.
 To avoid damaging the eyelet, do not pull from the side or at
a vertical angle. Always pull straight ahead.

IN CASE OF AN EMERGENCY
512
CAUTION
If the emergency towing eyelet is used to get out when
your vehicle becomes stuck in the mud, sand or other
condition from which the vehicle cannot be driven out
under its own power, make sure to observe the
precautions mentioned below. Otherwise, excessive
stress will be put on the eyelet and the towing cable or
chain may break, causing serious injury or damage.
If the towing vehicle can hardly move, do not forcibly
continue the towing. Contact your Lexus dealer or a
commercial tow truck service for assistance.
 Tow the vehicle as straight ahead as possible.
 Keep away from the vehicle during towing.
Tips for towing a stuck vehicle:
The following methods are effective to use when your
vehicle is stuck in the mud, sand or other condition from
which the vehicle cannot be driven out under its own
power. Use extreme caution when towing the vehicle. In
addition, keep away from the vehicles and towing cable or
chain when towing.
 Remove the sand and soil in the front and the back of the
tires.
 Place stones or wood under the tires.
IF YOU CANNOT SHIFT AUTOMATIC
TRANSMISSION SELECTOR LEVER
If you cannot shift the selector lever out of Pº position to
other positions even though the brake pedal is depressed,
use the shift lock override button as follows:
1Turn the ignition key to LOCKº. Make sure the parking
brake is applied.
2Pry up the cover with a flat-bladed screwdriver or
equivalent.

IN CASE OF AN EMERGENCY
514
Safety information for the Lexus Link System
Important!: Read this information before using the Lexus
Link System.
EXPOSURE TO RADIO FREQUENCY SIGNALS
The Lexus Link System to be installed in your vehicle a low
power radio transmitter and receiver. When the ignition is
turned to the ONº position, it receives and also sends out radio
frequency (RF) signals.
In August 1996, the Federal Communications Commission
(FCC) adopted RF exposure guidelines with safety levels for
mobile wireless phones. Those guidelines are consistent with
the safety standards previously set by both U.S. and
international standards bodies.
 ANSI C95.1 (1992)*
1
NCRP Report 86 (1986)*2
ICNIRP (1996)*3
*1: American National Standards Institute
*2: National Council on Radiation Protection and
Measurements
*
3: International Commission on Non-lonizing Radiation
Protection Those standards were based on comprehensive and periodic
evaluations of the relevant scientific literature. Over 120
scientists, engineers, and physicians from universities,
government health agencies, and industry reviewed the
available body of research to develop the ANSI Standard
(C95.1).
The design of the Lexus Link System complies with the FCC
guidelines in addition to those standards.

IN CASE OF AN EMERGENCY
515
Information for using the Lexus Link System
The Lexus Link System is a subscription-based service. To
obtain any of the Lexus Link services you must have enrolled
with the Lexus Link Call Center and have an active
subscription. It is important to be aware that an active
subscription is required to receive safety and security services. To learn more about your subscription status or how to renew
or extend your subscription, please push the SERVICESº
button
and speak to the Lexus Link Advisor, or you may dial toll
free 1-800-25 Lexus (Toll-Free) (1-800-255-3987) and
select the option for Lexus Link. If you are not enrolled, you will
hear the explanation about Lexus Link System. The actual
message is shown on Audible voice promptsº on page 525.
If you push the SERVICESº button again, the services
enrollment call will be announced. To cancel the enrollment
call, push the SERVICESº button one more time.
NOTICE
This system is only operational in GPS (Global Positioning System) and analog cellular coverageareas. Services may not be available in an area wherethe GPS and analog cellular phone signals cannot bereceived.
When the ignition is turned to the ONº position, The Lexus
Link System is activeº is announced to inform you that the
system is on. If your Lexus Link subscription expires, you will
hear The Lexus Link System is not active. To activate your
Lexus Link System, press the SERVICESº button nowº. To
learn more about your subscription status or how to renew or
extend your s ubscription, please push the SERVICESº button
to speak to a Lexus Link Advisor, or you may dial toll free
1-800-25 Lexus (Toll-Free) (1-800-255-3987) and select
the option for Lexus Link. If problems are detected in the Lexus
Link System, you will hear A Lexus Link System error has
been detected. Please contact your Lexus dealer.º If you hear
this message, take your vehicle to your Lexus dealer. In some cases, even if your subscription has expired, you may
hear The Lexus Link System is activeº. This is due to the time
delay required to process the deactivation of your Lexus Link
System. During this period, when you push the SERVICESº
button, your call will be forwarded to enrollment. Once the
deactivation process has been completed, you will hear The
Lexus Link System is not activeº.

IN CASE OF AN EMERGENCY
516
NOTICE
The voice prompt messages are the primary means tolet you know the status of your subscription. It isimportant to be aware that an active subscription isrequired to receive safety and security services. If these
voice prompt messages are disabled and you desire to have them re-activated, contact your Lexus dealer.
When you push the - VOL +º button on the -º side
immediately followed by the PLAYº button, you can hear an
explanation about the Lexus Link System. However, this
function is not available when you are recording or hearing a
playback. See Audible voice promptsº on page 525 for a
written version of this recorder message. The basic subscriber service package is available free of
charge for the first year.
NOTICE
Do not remove the Lexus Link fuse and wiring harness
with the ignition on, or an emergency call will be placed
to the Lexus Link Call Center.
