Lexus GX470 2004 Engine / LEXUS 2004 GX470 FROM JAN. 2004 THROUGH JUL. 2004 PROD. OWNER'S MANUAL (OM60A87U)

OCCUPANT RESTRAINT SYSTEMS
173


1Side and curtain shield airbag sensor assemblies
2Curtain shield airbag modules (airbag and inflator)
3Side airbag modules (airbag and inflator)
4Curtain shield airbag sensor assemblies
5SRS warning light and RSCA OFFº indicator light
6Roll sensing of curtain shield airbags off switch
7Airbag sensor assembly
The SRS side airbag and curtain shield airbag system consists
mainly of the above components, and their locations are shown
in the illustration.
The SRS side airbag and curtain shield airbag system is
controlled by the airbag sensor assembly. The airbag sensor
assembly consists of a safing sensor and airbag sensor.
In a severe side impact, the side and curtain shield airbag
sensor and/or the curtain shield airbag sensor trigger(s) the
side airbag inflators and/or the curtain shield airbag inflators.
At this time a chemical reaction in the inflators quickly fills the
airbags with non-toxic gas to help restrain the lateral motion
of the occupants.
In a vehicle rollover, the airbag sensor assembly triggers the
curtain shield airbag inflator. At this time, a chemical reaction
in the inflators quickly fills the airbags with non-toxic gas to
help restrain the lateral motion of the occupants.
When the airbags inflate, they produce a fairly loud noise and
release some smoke and residue along with non-toxic gas.
This
does not indicate a fire. This smoke may remain inside the
vehicle for some time, and may cause some minor irritation to
the eyes, skin or breathing. Be sure to wash off any residue as
soon as possible to prevent any potential skin irritation with
soap and water. If you can safely exit from the vehicle, you
should do so immediately.
Deployment of the airbags happens in a fraction of a second,
so the airbags must inflate with considerable force. While the
system is designed to reduce serious injuries, it may also
cause minor burns or abrasions and swelling.
Front seats as well as parts of the front and rear pillars, and roof
side rail may be hot for several minutes, but the airbags
themselves will not be hot. The airbags are designed to inflate
only once.
CAUTION
SRS side airbags and curtain shield airbags inflate with
considerable force. To reduce the possibility of death
or serious injury when they inflate, the driver, front
passenger and second outside passengers must:
 Wear their seat belts properly.
 Remain properly seated with their backs upright and
against the seats at all times.

OCCUPANT RESTRAINT SYSTEMS
174
Do not allow anyone to lean against the door when
the vehicle is in use, since the side airbag and curtain
shield airbag could inflate with considerable speed
and force. Otherwise, he/she may be killed or
seriously injured. Special care should be taken
especially when you have a small child in the vehicle.
 Sit up straight and well back in the seat, distributing
your weight evenly in the seat. Do not apply
excessive weight to the outer side of the seats with a
side airbag and to the front pillar, rear pillar and roof
side rail with a curtain shield airbag.
 Improper sitting and wearing of the seat belts may
not retain you inside the vehicle.

OCCUPANT RESTRAINT SYSTEMS
175
Make sure the RSCA OFFº indicator light is off. The
curtain shield airbags will not inflate in a vehicle
rollover if this indicator light is on and you may be
killed or seriously injured. For details, see Roll
sensing of curtain shield airbags off switchº on page
183. Do not get allow anyone to get his/her head closer to
the area where the side airbag and curtain shield
airbag inflate, since these airbags could inflate with
considerable speed and force. Otherwise, he/she
may be killed or seriously injured. Special care
should be taken especially when you have a small
child in the vehicle.
 Do not allow anyone to kneel on the passenger seat,
facing the passenger's side door, since the side
airbag and curtain shield airbag could inflate with
considerable speed and force. Otherwise, he/she
may be killed or seriously injured. Special care
should be taken especially when you have a small
child in the vehicle.

OCCUPANT RESTRAINT SYSTEMS
176
Do not allow anyone to get his/her head or hands out
of windows, since the curtain shield airbags could
inflate with considerable speed and force.
Otherwise, he/she may be killed or seriously injured.
Special care should be taken especially when you
have a small child in the vehicle.

OCCUPANT RESTRAINT SYSTEMS
177
Do not attach a cup holder or any other device or
object on or around the door. When the side airbag
and curtain shield airbag inflate, the cup holder or
any other device or object will be thrown with great
force, or the side airbag and curtain shield airbag
may not activate correctly, resulting in death or
serious injury. Likewise, the driver and front
passenger should not hold objects in their arms or on
their knees.

OCCUPANT RESTRAINT SYSTEMS
178
Do not attach a microphone or any other device or
object around the area where the curtain shield
airbag activates such as on the windshield glass,
side door glass, front and rear pillars, roof side rail
and assist grips. When the curtain shield airbag
inflates, the microphone or other device or object will
be thrown away with great force or the curtain shield
airbag may not activate correctly, resulting in death
or serious injury.
 Do not hook a hanger, heavy or sharp pointed objects
on the coat hook. If the curtain shield airbag inflates,
those items will be thrown away with great force or
the curtain shield airbag may not activate correctly,
resulting in death or serious injury. When you hang
clothes, hang them on the coat hook directly.

OCCUPANT RESTRAINT SYSTEMS
179
Do not use seat accessories which cover the parts
where the side airbags inflate. Such accessories may
prevent the side airbags from activating correctly,
causing death or serious injury.
 Do not modify or replace the seats or upholstery of
the seats with side airbags. Such changes may
prevent the side airbag system form activating
correctly, disable the system or cause the side
airbags to inflate accidentally, resulting in death or
serious injury.
 Do not disassemble or repair the front and rear pillars
and roof side rails containing the curtain shield
airbags. Such changes may disable the system or
cause the curtain shield airbags to inflate
accidentally, resulting in death or serious injury.
 Do not modify or change the suspension system.
Such changes may cause the curtain shield airbags
to inflate accidentally, which could result in death or
serious injury. Consult your Lexus dealer about any
repair and modification.
 Do not use tires or wheels other than the
manufacture's recommended size. Such a use may
cause the curtain shield airbags and seat belt
pretensioners to inflate accidentally, which could
result in death or serious injury. For details, see
Checking and replacing tiresº on page 574.

OCCUPANT RESTRAINT SYSTEMS
180
Do not place luggage heavier than specified on the
roof luggage carrier. Such luggage may cause the
curtain shield airbags and seat belt pretensioners to
inflate accidentally, which could result in death or
serious injury. For details, see Roof luggage
carrierº on page 109.
Failure to follow these instructions can result in death
or serious injury. Consult your Lexus dealer about any
repair and modification.
NOTICE
Do not perform any of the following changes without consulting your Lexus dealer. Such changes caninterfere with proper operation of the SRS side airbagand curtain shield airbag system in some cases.
Installation of electronic devices such as a mobiletwo-way radio, cassette tape player or compact disc
player
Modification of the suspension system
Modification of the structure of the passenger compartment
Repairs made on or near the console or front seat

OCCUPANT RESTRAINT SYSTEMS
181
The indicator comes on when the ignition key is turned to
the ONº position. It goes off after about 6 seconds. This
means the SRS side airbags and curtain shield airbags are
operating properly.
This warning light system monitors the airbag sensor
assembly, front airbag sensors, side and curtain shield airbag
sensor assemblies, curtain shield airbag sensor assemblies,
driver's seat position sensor, driver's seat belt buckle switch,
front seat b elt pretensioner assemblies, inflators, warning light,
RSCA OFFº indicator light, interconnecting wiring and power
sources. (For details, see Service reminder indicators and
warning buzzersº on page 52 for instructions.) If any of the following conditions occurs, this indicates a
malfunction of the airbags or seat belt pretensioners. Contact
your Lexus dealer as soon as possible.

When the ignition key is turned to the ONº position, the light
does not come on, remains on or flashes.
 The light comes on or starts flashing while driving.
If the light stays on, it indicates that the SRS front airbags have
a problem. If the light flashes, the SRS side and curtain shield
airbags have a problem.

OCCUPANT RESTRAINT SYSTEMS
182
16PY153
In the following cases, contact your Lexus dealer as soon as
possible:
Any of the SRS side airbags and curtain shield airbags have
been inflated.
 The portion of the doors (shaded in the illustration) was
involved in an accident that was not severe enough to cause
the SRS side airbags and curtain shield airbags to inflate.
 The surface of the seats with the side airbag (shaded in the
illustration) is scratched, cracked, or otherwise damaged.
 The portion of the front pillars, rear pillars or roof side rail
garnishes (padding) containing the curtain shield airbags
inside (shaded in the illustration) is scratched, cracked, or
otherwise damaged.
NOTICE
Do not disconnect the battery cables before contacting
your Lexus dealer.
