Lexus GX470 2004 Engine / LEXUS 2004 GX470 FROM JAN. 2004 THROUGH JUL. 2004 PROD. (OM60A87U) Owner's Guide

KEYS AND DOORS
12

When starting the engine, do not use the key inproximity with other transponder keys (including theflat key and keys of other vehicles), and do not press
other key plates against the key grip. Doing so may prevent the engine from starting, or may cause theengine to stop soon after it starts. If this happens,remove the key once and then insert it again after
removing other transponder keys (including the flatkey and keys of other vehicles) from the ring or whilegripping or covering them with your hand to start theengine.

KEYS AND DOORS
13

Do not bend the key grip or flat key.

Do not cover the key grip or flat key with any materialthat cuts off electromagnetic waves.

Do not knock the key or flat key hard against otherobjects.

Do not leave the key or flat key exposed to hightemperatures for a long period, such as on the
dashboard or hood under direct sunlight.

Do not put the key or flat key in water or wash it in anultrasonic washer.

Do not use the key or flat key with electromagneticmaterials.

This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
FCC ID: MOZRI-20BTY
MADE IN JAPAN
KEYS AND DOORS
14
ENGINE IMMOBILIZER SYSTEM
The engine immobilizer system is a theft prevention
system. When you insert the key in the ignition switch, the
transponder chip in the key's head transmits an electronic
code to the vehicle. The engine will start only when the
electronic code in the chip corresponds to the registered
ID code for the vehicle.
The system is automatically set when the key is removed from
the ignition switch. At this time, the security indicator light
flashes. When you insert the key in the ignition switch, the
security indicator light goes out and the system is canceled
automatically, which enables the engine to start.
The transponder chip of the flat key is in its key case. You can
cancel the engine immobilizer system using the flat key. (For
details, see Flat keyº on page 9.)For your Lexus dealer to make you a new key with built-in
transponder chip, your dealer will need your key number and
master key. However, there is a limit to the number of
additional keys your Lexus dealer can make for you.
If you make your own duplicate key, you will not be able to
cancel the system or start the engine.
For vehicles sold in U.S.A.

KEYS AND DOORS
15
CAUTION
Changes or modifications not expressly approved by
the party responsible for compliance could void the
user's authority to operate the equipment.
For vehicles sold in Canada
This device complies with RSS- 210 of Industry
Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2)
this device must accept any interference, including
interference that may cause undesired operation of
the device.
WIRELESS REMOTE CONTROL*
1Locking the doors
2Unlocking the doors
3Indicator light
4Sounding an alarm
NOTE: * This feature can be set inoperative as vehicle theftdeterrent measure in case of the loss of the wireless remote
control key.
Ask your Lexus dealer for details.
When you operate any button on the key, push it slowly and
surely. At this time, the indicator light on the key grip flashes
once.

KEYS AND DOORS
16The operational range of the wireless remote control is
approximately 1 meter (3 ft.). The effective range may vary
with different conditions. To activate the wireless remote
control
without fail, do it approximately 1 meter (3 ft.) from your
Lexus.
In the following cases, the battery in the key may be
discharged. If this is the case, replace it using a special
screwdriver.
 The remote control does not work.
 The operational range of wireless remote control becomes
extremely short.
 The indicator light on the key is dimmed or does not come
on.
For the replacement of the battery, see Replacing the batteryº
on page 20. You can also have the battery of the key replaced
by your Lexus dealer.
If you lose the wireless key, contact your Lexus dealer as soon
as possible to avoid the possibility of theft, or an accident.
You can use up to 4 wireless remote control keys for the same
vehicle. Contact your Lexus dealer for detailed information. The wireless remote control key is an electronic
component. Observe the following instructions in order
not to cause damage to the key.

Do not leave the wireless remote control key in places
where the temperature becomes high such as on the
dashboard.
 Do not disassemble it.
 Avoid knocking it hard against other objects or dropping it.
 Avoid putting it in water.

KEYS AND DOORS
17
Locking/Unlocking the doors
When you push the LOCKº button on the key briefly, all
the side doors and back door can be locked from outside
the vehicle.
At this time, you can hear one beep* and the turn signal lights
flash.** However, when you push the LOCKº button with any
door not closed securely, the buzzer sounds for 10 seconds.***
To stop the buzzer, close all the side doors and back door
securely or push the UNLOCKº button. If the key is in the
ignition switch, locking cannot be done.
Make sure all the doors are locked when you leave the vehicle.
Push the LOCKº button once again. If they were already
locked, the turn signal lights will flash.
NOTE:
* The beep volume can be changed. ** The turn signal lights can be set not to flash. *** The buzzer can be set not to sound if a door is not closedsecurely.
Ask your Lexus dealer for details.
When you push the UNLOCKº button, the driver's door
is unlocked. Pushing that button once again within 3
seconds from the first push, all other side doors and back
door are also unlocked.*
NOTE: * The 2-step unlocking function can be changed. Ask your Lexus dealer for details.
At this time, you can hear two beeps* and the turn signal lights
flash twice.** Together with the activation of unlocking, the
personal lights and center interior light come on for 15 seconds
if the personal light switch and center interior light switch is in
the DOORº position and the running board lights come on for
15 seconds.*** However, this function does not work when the
ignition key is in the ONº position. For further information, see
Illuminated entry systemº on page 80.
You have 30 seconds to open a door after using the wireless
remote unlock feature.**** If a door is not opened by then, all
the doors will be automatically locked again.
Even if the LOCKº or UNLOCKº button is kept pressed in, the
locking or unlocking operation is not repeated. Release the
button and then push again.
NOTE: * The beep volume can be changed. ** The turn signal lights can be set not to flash. *** The personal lights, center interior light and runningboard lights can be set not to come on or the duration oflighting can be changed. **** The time before automatic re-locking can be changed.
Ask your Lexus dealer for details.

KEYS AND DOORS
18
Sounding an alarm*
When you push the PANICº button for about 1 second, an
alarm sounds to deter any person trying to break into or
damage your vehicle.
If you want to stop the alarm, push any button.
This function does not work when the ignition key is in the ONº
position.
NOTE: * The alarm can be set not to sound. Ask your Lexus dealer for details.
Operating the windows and moon roof
The windows and moon roof can be opened using a
wireless key from outside the vehicle.*
NOTE: * The windows and moon roof can be set inoperative. Ask your Lexus dealer for details.
Push the UNLOCKº button until the windows and moon roof
start to move. A beep sounds just before opening. When you
release the button, the windows and moon roof stop opening.
For vehicles sold in U.S.A.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.

KEYS AND DOORS
19
NOTICE:
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and
can radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which
can be determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
 Increase the separation between the equipment
and receiver.Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
 Consult the dealer or an experienced radio / TV
technician for help.
FCC WARNING:
Changes or modifications not expressly approved
by the party responsible for compliance could void
the user's authority to operate the equipment.
For vehicles sold in Canada
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2)
this device must accept any interference, including
interference that may cause undesired operation of
the device.

KEYS AND DOORS
20
Replacing the battery
When you replace the battery, prepare a lithium battery
CR1616 or equivalent and a special screwdriver.
CAUTION
Special care should be taken to prevent small children
from swallowing the removed battery or components.
NOTICE

When replacing the battery, be careful not to lose thecomponents, screws and O-ring.

Replace only with the same or equivalent typerecommended by a Lexus dealer.

Dispose of used batteries according to the local laws.
1. Remove the screw, and then the cover while pushing it in the
arrow direction.
2. Remove the module from the key frame.

KEYS AND DOORS
21
3. Remove the 2 screws to take out the lid of the module.
4. Take out the discharged battery and put in a new battery with
the positive side up.
