Lexus GX470 2005 Pictorial Index / LEXUS 2005 GX470 OWNER'S MANUAL (OM60B11U)

DRIVING TIPS
460
When driving off±road or in rugged terrain, do not
drive at excessive speeds, jump, make sharp turns,
strike objects, etc. This may cause loss of control or
vehicle rollover causing death or serious injury. You
are also risking expensive damage to your vehicle's
suspension and chassis.
 Do not drive horizontally across steep slopes.
Driving straight up or straight down is preferred.
Your vehicle (or any similar off±road vehicle) can tip
over sideways much more easily than forward or
backward.BREAK±IN PERIOD
Drive gently and avoid high speeds.
You need not follow a break±in schedule with your new Lexus.
But following a few simple tips for the first 1600 km (1000 miles)
can add to the future economy and long life of your vehicle:
Avoid full throttle acceleration when starting and driving.
 Avoid racing the engine.
 Try to avoid hard stops during the first 300 km (200 miles).
 Do not drive for a long time at any single speed, either fast
or slow.
 Do not tow a trailer during the first 800 km (500 miles).

DRIVING TIPS
461
OPERATION IN FOREIGNCOUNTRIES
If you plan to drive your Lexus in another country...
First, comply with the vehicle registration laws.
Second, confirm the availability of the correct fuel (unleaded
and minimum octane rating).
TIPS FOR DRIVING IN VARIOUS CONDITIONS
Always slow down in gusty crosswinds. This will allow you
much better control.
 Drive slowly onto curbs and, if possible, at a right angle.
Avoid driving onto high, sharp±edged objects and other
road hazards. Failure to do so can lead to severe tire
damage such as a tire burst.
Drive slowly when passing over bumps or travelling on a
bumpy road. Otherwise, the impact could cause severe
damage to the tires and/or wheels.
 When parking on a hill, turn the front wheels until they touch
the curb so that the vehicle will not roll. Apply the parking
brake, and place the transmission in ªPº. If necessary, block
the wheels.
 Washing your vehicle or driving through deep water may get
the brakes wet. To see whether they are wet, check that
there is no traffic near you and then press the pedal lightly.
If you do not feel a normal braking force, the brakes are
probably w et. To dry them, drive the vehicle cautiously while
lightly pressing the brake pedal with the parking brake
applied. If they still do not work safely, pull to the side of the
road and call a Lexus dealer for assistance.

DRIVING TIPS
462
CAUTION
Before driving off, make sure the parking brake is
fully released and that the parking brake reminder
light is off.
 Do not leave your vehicle unattended while the
engine is running.
 Do not rest your foot on the brake pedal while driving.
It can cause dangerous overheating, needless wear,
and poor fuel economy.
 To drive down a long or steep hill, reduce your speed
and downshift. Remember, if you ride the brakes
excessively, they may overheat and not work
properly. See page 406.
 Be careful when accelerating, upshifting,
downshifting or braking on a slippery surface. The
abrupt change in engine speed, such as sudden
acceleration or engine braking, could cause the
vehicle to skid or spin.
 Do not drive in excess of the speed limit. Even if the
legal speed limit permits it, do not drive over 140 km/h
(85 mph) unless your vehicle has high±speed
capability tires. Driving over 140 km/h (85 mph) may
result in tire failure, loss of control and possible
injury. Be sure to consult a tire dealer to determine
whether the tires on your vehicle are high±speed
capability tires or not before driving at such speeds.

DRIVING TIPS
463
Do not continue normal driving when the brakes are
wet. If they are wet, your vehicle will require a longer
stopping distance, and it may pull to one side when
the brakes are applied. Also, the parking brake will
not hold the vehicle securely.
 If you drive through deep water over about 500 mm
(20 in.) in depth, put the vehicle height in the HI (High)
mode with the active height select switch and then
turn off the active height control suspension by
pushing the height control switch. Drive your vehicle
at 30 km/h (19 mph) or lower speed.

DRIVING TIPS
464
OFF±ROAD DRIVINGPRECAUTIONS
When driving your vehicle off±road, please observe the
following precautions to ensure your driving enjoyment and to
help prevent the closure of areas to off±road vehicles.
a. Drive your vehicle only in areas where off±road vehicles are
permitted to travel.
b. Respect private property. Get owner's permission before
entering private property.
c. Do not enter areas that are closed. Honor gates, barriers
and signs that restrict travel.
d. Stay on established roads. When conditions are wet,
driving techniques should be changed or travel delayed to
prevent damage to roads.
For owners in U.S. mainland, Hawaii and Puerto Rico:
To obtain additional information pertaining to driving your
vehicle off±road, consult the following organizations.
 State and Local Parks and Recreation Departments
 State Motor Vehicle Bureau
 Recreational Vehicle Clubs
 U.S. Forest Service and Bureau of Land Management
CAUTION
Always observe the following precautions to minimize
the risk of serious personal injury or damage to your
vehicle:
Drive carefully when off the road. Do not take
unnecessary risks by driving in dangerous places.
 Do not grip the steering wheel spokes when driving
off±road. A bad bump could jerk the wheel and injure
your hands. Keep both hands and especially your
thumbs on the outside of the rim.
 Always check your brakes for effectiveness
immediately after driving in sand, mud, water or
snow.
 After driving through tall grass, mud, rock, sand,
rivers, etc., check that there is no grass, bush, paper,
rags, stone, sand, etc. adhering or trapped on the
underbody. Clear off any such matter from the
underbody. If the vehicle is used with these materials
trapped or adhering to the underbody, a breakdown
or fire could occur.
 In a rollover crash, an unbelted person is
significantly more likely to die than a person wearing
a seat belt. Therefore, the driver and all passengers
should fasten their seat belts whenever the vehicle is
moving.

DRIVING TIPS
465
When driving off±road or in rugged terrain, do not
drive at excessive speeds, jump, make sharp turns,
strike objects, etc. This may cause loss of control or
vehicle rollover causing death or serious injury. You
are also risking expensive damage to your vehicle's
suspension and chassis.

DRIVING TIPS
466
NOTICE
If driving through water, such as when crossingshallow streams, first check the depth of the waterand the bottom of the river bed for firmness. Driveslowly and avoid deep water.
Take all necessary safety measures to ensure thatwater damage to the engine or other componentsdoes not occur.
Water entering the engine air intake will cause severe
engine damage.
Water can wash the grease from wheel bearings,causing rusting and premature failure, and may alsoenter the differentials, transmission and transfercase, reducing the gear oil's lubricating qualities.
Sand and mud that has accumulated in brake drumsand around brake discs may affect braking ef ficiency
and may damage brake system components.
Always perform a maintenance inspection after each day of off±road driving that has taken you throughrough terrain, sand, mud, or water. For scheduledmaintenance information, refer to the ªOwner'sManual Supplement/Scheduled Maintenanceº.

DRIVING TIPS
467
WINTER DRIVING TIPS
Make sure your coolant is properly protected against
freezing.
Only use ªToyota Super Long Life Coolantº or similar high
quality ethylene glycol based non±silicate, non±amine,
non±nitrite, and non±borate coolant with long±life hybrid
organic acid technology. (Coolant with long±life hybrid organic
acid technology is a combination of low phosphates and
organic acids.)
See ªChecking the engine coolant levelº on page 560 for
details of coolant type selection.
For the U.S.A. Ð ªToyota Super Long Life Coolantº is a mixture
of 50% coolant and 50% deionized water. This coolant
provides protection down to about ±35 C (±31F).
For Canada Ð ªToyota Super Long Life Coolantº is a mixture
of 55% coolant and 45% deionized water. This coolant
provides protection down to about ±42 C (±44F).
NOTICE
Do not use plain water alone.

DRIVING TIPS
468Check the condition of the battery and cables.
Cold temperatures reduce the capacity of any battery, so it
must be in top shape to provide enough power for winter
starting. Page 608
tells you how to visually inspect the battery.
Your Lexus dealer and most service stations will be pleased to
check the battery charge level.
Make sure the engine oil viscosity is suitable for the cold
weather.
See page 559 for recommended viscosity. Leaving a heavy
summer oil in your vehicle during winter months may cause
harder starting. If you are not sure about which oil to use, call
your Lexus dealer Ð they will be pleased to help. Check the electronic ignition system for loose
connections or obvious damage.
Keep the door locks from freezing.
Squirt
lock de±icer or glycerine into the locks to keep them from
freezing.
Use a washer fluid containing an antifreeze solution.
This product is available at your Lexus dealer and most auto
parts stores. Follow the manufacturer's directions for how
much to mix with water.
NOTICE
Do not use engine antifreeze or any other substitute because it may damage your vehicle's paint.

DRIVING TIPS
469
Do not use your parking brake when there is a possibility
it could freeze.
When
parking, put the transmission into ªPº and block the front
wheels. Do not use the parking brake, or snow or water
accumulated in and around the parking brake mechanism may
freeze the parking brake, making it hard to release.
Keep ice and snow from accumulating under the fenders.
Ice and snow built up under your fenders can make steering
difficult. During bad winter driving, stop and check under the
fenders occasionally.
Depending on where you are driving, we recommend you
carry some emergency equipment.
Some of the thi ngs you might put in the vehicle are tire chains,
window scraper, bag of sand or salt, flares, small shovel,
jumper cables, etc.
DINGHY TOWING
Your vehicle is not designed to be dinghy towed (with four
wheels on the ground) behind a motorhome.
NOTICE
Do not tow your vehicle with four wheels on the ground. This may cause serious damage to your vehicle.
