Lexus GX470 2006 Gauges, Meters and Service Reminder Indicators / LEXUS 2006 GX470 OWNER'S MANUAL (OM60B99U)

AUDIO
320
Video CD/audio CD/CD text player operation
(a) Selecting the disc menu number (video CD only)
1Remote control button
2Screen switch
Push the “SEARCH” button on the remote control or the
“Sel. Number” switch on the screen, and the disc menu
number search screen will appear.
Enter the disc menu number by using the “ −”, “+” and “+10”
switches and push the “Enter” switch. The player starts playing
the disc from the entered disc menu number. The entered disc
menu number will appear on the screen.
Push the “Back” switch to return to the menu screen.
Move up and down the switches by pushing the “Shift keys” on
the screen.

AUDIO
321
(b) Operating the “
”, “
”, “\b\b ” and “ ”
switches/buttons
1Remote control button
2Screen switch
“
” switch/button: Push this switch/button to pause the
disc.
“  ” switch/button: Push this switch/button to cancel the
pause and return to normal playing.
“ \b\b ” and “ ” switches/buttons: Push this switch/button
to fast forward or reverse. If you want to return to the beginning
of the current track, release the switch/button.
Video CD only: Push the “ ” switch/button while pausing,
the video CD plays the slow −motion video replay. (c) Turning on the disc menu (video CD only)
1Remote control button
2Screen switch
Push the “RETURN” button on the remote control or the
“Return” switch on the screen to turn on the menu screen
for the disc.
For the operation of the menu screen, see the manual for the
video CD.

AUDIO
322(d) Changing menu page or track (video CD only)
Push
the “D. Menu Next” or “D. Menu Prev.” s witch while
the disc menu is displayed. The next or previous page will
appear on the screen.
Push the “D. Menu Next” or “D. Menu Prev.” s witch while
the player is playing video. The next or previous track will
be searched and played. (e) Changing a multiplex transmission (video CD only)Push the “Main/Sub” switch to change a multiplex
transmission.
The mode changes from Main/Sub to Main
to Sub and back to Main/Sub by pushing the “Main/Sub”
switch.

AUDIO
323
(f) Changing the initial setting (video CD only)
1Remote control button
2Screen switch
Push the “SET UP” button on the remote control or the
“Set Up” switch on the screen, and the initial setting
screen will appear. You can change the initial setting. (See
“(k) Changing the initial setting” on page 308 for details.)
After the setting is done, the player plays from the beginning
of the chapter or the track. (g) Using the control screen
22PY095
1For video CD2For audio CD
3For CD text

AUDIO
324When
playing a disc, push the “DVD” button on the remote
control. The control screen will appear on the screen.
CD text only — The CD title and track title will appear on the
screen when pushing the “DVD” button.
Details of the specific switches, controls and features are
described below.
“PICTURE” switch (video CD only): Push the “PICTURE”
switch to turn off the control screen and return to the picture
previously displayed.
“RPT” switch (audio CD and CD text): Push the “RPT”
switch while the track is playing. When the track ends, it will
automatically replay. To turn off the repeat feature, push this
switch again.
“RAND” switch (audio CD and CD text): Push the “RAND”
switch. The player will play the tracks on the CD in random
order. To turn off the random feature, push this switch again.
“SCAN” switch (audio CD and CD text): Push the “SCAN”
switch. The player will scan all the tracks on the CD. To stop
scanning, push this switch again. When the player has
scanned all the tracks on the CD, it will stop scanning.
“
” and “” switches: Push the “” or “” switch
to fast forward or reverse the disc. When you push the switch
again, the DVD player will resume playing. (h) Error messages
If the player malfunctions, your audio system will display
following error messages.
If “DISC CHECK” appears on the screen:
It indicates that the
disc is dirty, damaged or it was inserted upside down. Clean
the disc or insert it correctly.
If “REGION CODE ERROR” appears on the screen: It
indicates that the DVD region code is not set properly.
If “DVD ERROR” appears on the screen: There is a problem
inside the player. Eject the disc. Set the disc again.
If the malfunction still exists, take your vehicle to your Lexus
dealer.

AUDIO
325
Screen adjustment
You can adjust the color, contrast, tone and brightness of
the screen.
Push the “DISPLAY” button on the remote control (1)
and then the “Display” screen (2) will appear.
The screen may turn purple to deflect the sunlight. This is not
a malfunction.
Each time you push the “+” or “ −” switch, you can adjust the
color, contrast, tone and brightness of the screen.
“+” or “GREEN”“ − ” or “RED”
COLORStrengthens the
green colorStrengthens the
red color
CONTRASTStrengthens the
contrastWeakens the
contrast
TONEStrengthens the
toneWeakens the tone
BRIGHTNESSBrightensDarkens
After adjusting the screen, push the “OK” switch to return to the
previous screen.

AUDIO
326
Selecting the video mode
The audio machine connected to the input terminal
adapter can be played in the video mode.
To select the video mode, push the “VIDEO” button on the
remote control (1). You can also select the video mode
on the mode selection screen (2) mentioned above.
DVD video disc information
(a) DVD player and DVD video discs
This DVD player conforms to NTSC color TV formats. DVD
video discs conforming to other formats such as PAL or
SECAM cannot be used.
Region codes: Some DVD video discs have a region code
indicating where you can use. If the DVD video disc is not
labeled “ALL” or “1”, you cannot use it in this DVD player. If you
attempt to play an inappropriate DVD video disc in this player,
“REGION CODE ERROR” appears on the screen. Even if the
DVD video disc does not have a region code, in some cases
you cannot use it.

AUDIO
327
Marks shown on DVD video discs:
Indicates NTSC format of color TV.
Indicates the number of audio
tracks.
Indicates the number of language
subtitles.
Indicates the number of angles.
Indicates the screen to be selected.
Wide screen: 16:9
Standard: 4:3
Indicates regions in which this video
disc can be played.
ALL: all countries
Number: region code
(b) DVD video disc glossary
DVD video discs: Digital V
ersatile Disc that holds video. DVD
video discs have adopted “MPEG2”, one of the world
standards of digital compression technologies. The picture
data is compressed by 1/40 on average and stored. Variable
rate encoded technology in which the volume of data assigned
to the picture is changed depending on the picture format has
also been adopted. Audio data is stored using PCM and Dolby
digital, which enables higher quality of sound. Furthermore,
multi−angle and multi −language features will also help you
enjoy the more advanced technology of DVD video.
Viewer restrictions: This feature limits what can be viewed in
conformity with the level of restrictions of the country. The level
of restrictions varies depending on the DVD video disc. Some
DVD video discs cannot be played at all, or violent scenes are
skipped or replaced with other scenes.
Level 1: DVD video discs for children can be played.
Level 2 — 7: DVD video discs for children and G −rated movies
can be played.
Level 8: All types of DVD video discs can be played.
Multiangle feature: You can enjoy the same scene at
different angles.
Multilanguage feature: You can select the language of the
subtitles and audio.

AUDIO
328Region codes:
Region codes are provided on DVD players
and DVD discs. If the DVD video disc does not have the same
region code as the DVD player, you cannot play the disc on the
DVD player. For region codes, see page 326.
Audio: This DVD player can play liner PCM, Dolby digital, dts
and MPEG audio format DVD. Other decoded type cannot be
played.
Title and chapter: Video and audio programs stored on DVD
video discs are divided in parts by title and chapter.
Title: The largest unit of the video and audio programs stored
on DVD video discs. Usually, one piece of a movie, one album,
or one audio program is assigned as a title.
Chapter: A unit smaller than a title. A title comprises plural
chapters. Manufactured under license from Dolby Laboratories.
“Dolby”,
“Pro Logic”, and “
” are trademarks of Dolby
Laboratories. Confidential unpublished works.
1992 — 1997 Dolby Laboratories. All rights reserved.
This product incorporates copyright protection
technology that is protected by method claims of certain
U.S. patents and other intellectual property rights owned
by Macrovision Corporation and other rights owners. Use
of this copyright protection technology must be
authorized by Macrovision Corporation, and is intended
for home and other limited viewing uses only unless
otherwise authorized by Macrovision Corporation.
Reverse engineering or disassembly is prohibited.
“dts” is a trademark of Digital Theater Systems, Inc.

AUDIO
329
A/V input adapter
The rear entertainment system plays videos and sound when
an audio−video equipment is connected to the A/V input
adapter. For details, refer to the manufacturer’s instructions.
To use the adapter, push the lid.
To use the adapter, open the cover.
The A/V input adapter is composed of 3 input adapters.
“VIDEO”: Image input adapter
“MONO L”: Audio input adapter (mono/left)
“R”: Audio input adapter (right)
NOTICE
Close the cover and lid when the A/V input adapter is
not in use. Inserting a foreign object other than the
appropriate plug may cause electrical failure or short
circuit.
 The input terminal lid must be closed before you fold
up the second seat.
