INTRODUCTION
495
Removing the engine compartment covers
Before checking the power steering fluid or fuses in the
engine compartment, remove the engine compartment
covers as follows:
61PY010
1Turn the plastic nuts counterclockwise and remove them.
2Push the core of the clips using a Phillips −head
screwdriver and remove the clips.
3Remove the covers.
Be careful not to lose the removed plastic nuts and clips.
After checking the items, install the engine compartment
covers and insert the plastic nuts and clips in their original
positions.
When inserting the clips, do as shown above.
NOTICE
After installing the engine compartment covers, make
sure the covers are securely in their original positions.

INTRODUCTION
497
Use eye protection whenever you work on or under
your vehicle where you may be exposed to flying or
falling material, fluid spray, etc.
 Be extremely cautious when working on the battery.
It contains poisonous and corrosive sulfuric acid.
NOTICE
Remember that battery and ignition cables carry high
currents or voltages. Be careful of accidentally
causing a short circuit.
 Add only “T oyota Super Long Life Coolant” or similar
high quality ethylene glycol based nonsilicate,
nonamine, nonnitrite, and nonborate coolant with
longlife hybrid organic acid technology to fill the
radiator. “Toyota Super Long Life Coolant” is a
mixture of 50% coolant and 50% deionized water (for
the U.S.A.) or 55% coolant and 45% deionized water
(for Canada).
 If you spill some of the coolant, be sure to wash it off
with water to prevent it from damaging the parts or
paint.
 Before closing the engine hood, check to see that you
have not forgotten any tools, rags, etc.
 Do not drive with the air cleaner removed, or
excessive engine wear could result. Also backfiring
could cause a fire in the engine compartment.
Do not overfill automatic transmission fluid and
power steering fluid, or the transmission and power
steering could be damaged.
 Be careful not to scratch the glass surface with the
wiper frame.

INTRODUCTION
498
PARTS AND TOOLS
Here is a list of parts and tools you will need to perform
do−it−yourself maintenance. Remember all Lexus parts are
designed in metric sizes, so your tools must be metric.
Checking the engine oil level
Parts (if level is low):
“Toyota Genuine Motor Oil” or equivalent
See page 513 for details about engine oil selection.
Tools:
 Rag or paper towel
 Funnel (only for adding oil)
Checking the engine coolant level
Parts (if level is low):
“Toyota Super Long Life Coolant” or similar high quality
ethylene glycol based non −silicate, non− amine, non−nitrite,
and non −borate coolant with long −life hybrid organic acid
technology (Coolant with long −life hybrid organic acid
technology is a combination of low phosphates and organic
acids.)
“Toyota Super Long Life Coolant” is a mixture of 50% coolant
and 50% deionized water (for the U.S.A.) or 55% coolant
and 45% deionized water (for Canada). This coolant
provides protection down to about −35C (− 31F).
Tools:
 Funnel (only for adding coolant)

SECTION 6 – 2
501
SERVICE PROCEDURES AND
SPECIFICATIONS
Engine
Specifications502
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Fuel 506
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . .
Fuel pump shut off system 508
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Facts about engine oil consumption 509
. . . . . . . . . . . . . . . . . . . . . . . .
Used engine oil 510
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Checking the engine oil level 511
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the engine coolant level 514
. . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the radiator and condenser 516
. . . . . . . . . . . . . . . . . . . . . . .
Spark plugs 516
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .

ENGINE
505
— IGNITION SYSTEM
Spark plug — Make DENSO
NGK
— Gap
SK20R11
IFR6A11
1.1 mm (0.043 in.)
— ELECTRICAL SYSTEM
Battery Open voltage at 20C (68F):
Charging rates
12.6 — 12.8 V Fully charged
12.2 — 12.4 V Half charged
11.8 — 12.0 V Discharged
[Voltage that is checked 20 minutes after the key is removed
with all the lights turned off]
5 A max.

ENGINE
510
Importance of engine oil level check
One of the most important points in proper vehicle
maintenance is to keep the engine oil at the optimum level so
that oil function will not be impaired. Therefore, it is essential
that the oil level be checked regularly. Lexus recommends that
the oil level be checked every time you refuel the vehicle.
NOTICE
Failure to check the oil level regularly could lead to
serious engine trouble due to insufficient oil.
For detailed information on oil level check, see “Checking the
engine oil level” described below.
USED ENGINE OIL
CAUTION
 Used engine oil contains potentially harmful
contaminants which may cause skin disorders such
as inflammation or skin cancer, so care should be
taken to avoid prolonged and repeated contact with
it. To remove used engine oil from your skin, wash
thoroughly with soap and water.
 Dispose of used oil and used oil filters only in a safe
and acceptable manner. Do not dispose of used oil
and used oil filters in household trash, in sewers or
onto the ground. Call your Lexus dealer or a service
station for information concerning recycling or
disposal.
 Do not leave used oil within the reach of children.

ENGINE
511
CHECKING THE ENGINE OIL LEVEL
With the engine at operating temperature and turned off,
check the oil level on the dipstick.
1. To get a correct reading, the vehicle should be on level
ground. After turning off the engine, wait a few minutes for the
oil to drain back into the bottom of the engine.
2. Pull the dipstick out, hold a rag under the end and wipe it
clean.
3. Reinsert the dipstick and push it in as far as it will go, or the
reading will not be correct.
1Add oil2O.K.3Too full
4. Pull the dipstick out and look at the oil level while holding a
rag under the end. If it is between the low level mark (
4) and
the full level mark (5), it is O.K.
NOTICE
Be careful not to drop engine oil on the vehicle
components.

ENGINE
512
If the oil level is below or only slightly above the low line,
add engine oil of the same type as already in the engine.
Remove the oil filler cap and add engine oil a little at a time,
checking the dipstick. We recommend that you use a funnel
when adding oil. The approximate quantity of oil needed to
raise the level between low line and full line on the dipstick is
indicated as follows:1.5 L (1.6 qt., 1.3 Imp. qt.)
For the engine oil capacity, see “Specifications” on page 518.
When the level reaches within the correct range, return the filler
cap and turn the cap clockwise until you hear a click.
NOTICE
 Be careful not to spill engine oil on the vehicle
components.
 Avoid overfilling, or the engine could be damaged.
 Check the oil level on the dipstick once again after
adding the oil.

ENGINE
514
CHECKING THE ENGINE COOLANTLEVEL
1Reservoir cap2“F” (upper) line
3“L” (lower) line
Look at the seethrough coolant reservoir when the
engine is cold. The coolant level is satisfactory if it is
between the “F” and “L” lines on the reservoir. If the level
is low, add the coolant. (For the coolant type, see “Coolant
type selection” described below.)
The coolant level in the reservoir will vary with engine
temperature. However, if the level is on or below the “L” line,
add coolant. Bring the level up to the “F” line. If the coolant level drops within a short time after replenishing,
there
may be a leak in the system. Visually check the radiator,
hoses, engine coolant filler cap, radiator cap and drain cock
and water pump.
If you can find no leak, have your Lexus dealer test the radiator
cap pressure and check for leaks in the cooling system.
CAUTION
To prevent burning yourself, do not remove the radiator
cap when the engine is hot.

ENGINE
516
CHECKING THE RADIATOR ANDCONDENSER
If either of the above parts are extremely dirty or you are not
sure of their condition, take your vehicle to a Lexus dealer.
CAUTION
To prevent burning yourself, be careful not to touch the
radiator or condenser when the engine is hot.
NOTICE
To prevent damage to the radiator and condenser, do
not perform the work by yourself.
SPARK PLUGS
Your engine is fitted with iridiumtipped spark plugs.
NOTICE
Use only iridiumtipped spark plugs. Do not adjust
gaps for engine performance or smooth drivability.
