4-3. Do-it-yourself maintenance
4
Maintenance and care
IS F_EE
Checking and replacing fuses
If any of the electrical components do not operate, a fuse may have
blown. If this happens, check and replace the fuses as necessary.
Turn the “ENGINE START STOP” switch to OFF.
Engine compartment (type B fuse box): Remove the
engine compartment cover. (P. 367)
Open the fuse box cover.
Engine compartment (Left-hand drive vehicles on type A fuse
box)
Push the tabs in and lift the
lid off.
Engine compartment (Right-hand drive vehicles on type A
fuse box)
Push the tabs in and lift the
lid off.STEP1
STEP2
STEP3

403
4-3. Do-it-yourself maintenance
4
Maintenance and care
IS F_EE
14RR DOOR LH20 APower windows
15FR DOOR LH20 APower windows, outside rear view
mirror (left)
16SECURITY7.5 ASmart entry & start system
17H-LP LVL7.5 AAutomatic headlight leveling sys-
tem
18LH-IG10 A
Charging system, headlight
cleaner, rear window defogger,
electric cooling fans, emergency
flashers, turn signal lights, back-up
lights, stop lights, outside rear
view mirror defoggers, seat belts,
Lexus parking assist-sensor, air
conditioning system
19FR WIP30 AWindshield wipers
FuseAmpereCircuit

404
4-3. Do-it-yourself maintenance
IS F_EERight side instrument panel
FuseAmpereCircuit
1FR P/SEAT RH30 APower seat
2DOOR DL15 APower door lock system
3OBD7.5 AOn-board diagnosis system
4STOP SW7.5 A
Stop lights, VDIM, shift lock sys-
tem,
multiport fuel injection system/
sequential multiport fuel injection
system,
smart entry & start system
5TI & TE20 AElectric tilt and telescopic steering
column
6RAD NO. 310 AAudio system
7GAUGE7.5 AMeters and gauges
8IGN10 ASRS airbag system, stop lights,
steering lock system, fuel system
9ACC7.5 A
Clock, air conditioning system,
audio system, navigation system,
display, outside rear view mirrors,
smart entry & start system, Lexus
parking assist monitor, glove box
light, console box light
10CIG15 ACigarette lighter
11PWR OUTLET15 APower outlet
12RR DOOR RH20 APower windows

5When trouble arises
415
IS F_EE
5-1. Essential information
Emergency flashers .......... 416
If your vehicle needs to be
towed.............................. 417
If you think something is
wrong ............................. 423
Fuel pump shut off
system ............................ 4245-2. Steps to take in an
emergency
If a warning light turns
on or a warning buzzer
sounds... ........................ 425
If a warning message is
displayed ........................ 431
If you have a flat tire........ 444
If the engine will not start 454
If the shift lever cannot be
shifted from P ................ 456
If you lose your keys ....... 457
If the electronic key does
not operate properly....... 458
If the vehicle battery is
discharged ...................... 462
If your vehicle overheats . 465
If the vehicle becomes
stuck............................... 468
If your vehicle has to
be stopped in an
emergency...................... 469

418
5-1. Essential information
IS F_EETowing eyelet
Emergency towing procedure
Release the parking brake.
Shift the shift lever to N.
Put the “ENGINE START STOP” switch in ACCESSORY mode
(engine off) or IGNITION ON mode (engine running).
CAUTION
Caution while towing
Use extreme caution when towing the vehicle.
Avoid sudden starts or erratic driving maneuvers which place excessive
stress on the emergency towing eyelet and the cables or chains. Always be
cautious of the surroundings and other vehicles while towing.
If the engine is not running, the power assist for the brakes and steering
will not function, making steering and braking more difficult.
NOTICE
To prevent causing serious damage to the transmission
Never tow this vehicle from the rear with four wheels on the ground. This
may cause serious damage to the transmission.
STEP1
STEP2
STEP3

5
421
5-1. Essential information
When trouble arises
IS F_EE
Towing with a wheel lift-type truck
From the front
Use a towing dolly under the
rear wheels.
From the rear
Turn the “ENGINE START
STOP” switch to the ACCES-
SORY mode so that the steering
wheel is unlocked.
NOTICE
To prevent causing serious damage to the transmission
Never tow this vehicle from the front with the rear wheels on the ground.
To prevent damaging the vehicle
Do not tow the vehicle from the rear with the “ENGINE START STOP”
switch OFF.
The steering lock mechanism is not strong enough to hold the front wheels
straight.
When raising the vehicle from the rear, ensure adequate ground clearance
for towing at the opposite end of the raised vehicle. Without adequate
clearance, the vehicle could be damaged while being towed from the rear.

424
5-1. Essential information
IS F_EE
Fuel pump shut off system
NOTICE
Before starting the engine
Inspect the ground under the vehicle.
If you find that fuel has leaked on to the ground, the fuel system has been
damaged and is in need of repair. Do not restart the engine.
To minimize the risk of fuel leakage when the engine stalls or an air-
bag inflates upon collision, the fuel pump shut off system stops sup-
plying fuel to the engine.
Follow the procedure below to restart the engine after the system
is activated.
Turn the “ENGINE START STOP” switch to ACCES-
SORY mode or OFF.
Restart the engine.
STEP1
STEP2

436
5-2. Steps to take in an emergency
IS F_EE
Indicates that the trunk
is not fully closed.
flashes and a
buzzer sounds to indi-
cate that trunk is not
fully closed (with the
vehicle having reached
a speed of 5 km/h [3
mph]).
Close the trunk.
(Flashing)
(If equipped)
Indicates that the moon
roof is not fully closed
(with the “ENGINE
START STOP” switch
OFF and the driver's
door opened).
Close the moon roof.
Indicates that the park-
ing brake is still
engaged.
flashes and a
buzzer sounds to indi-
cate that the parking
brake is still engaged
(with the vehicle hav-
ing reached a speed of
5 km/h [3 mph]).
Release the parking
brake.
Warning messageDetailsCorrection procedure

440
5-2. Steps to take in an emergency
IS F_EE
Follow the correction procedures.
After taking the specified steps to correct the suspected problem,
check that the warning light turns off.
Inte-
rior
buzzerExte-
rior
buzzer
Warning messageDetailsCorrection
procedure
Once
(Comes on for 10 sec-
onds.)
Indicates that an
attempt was
made to start the
engine without
the electronic
key being pres-
ent, or the elec-
tronic key was
not functioning
normally.
Start the engine
with the elec-
tronic key
present.
*
Once3
times
(Flashing)
Indicates that a
door other than
the driver’s door
has been opened
and closed with
the “ENGINE
START STOP”
switch in any
mode other than
OFF and the
electronic key
has been taken
out of the detec-
tion area.
Confirm the
location of the
electronic key.

5
441
5-2. Steps to take in an emergency
When trouble arises
IS F_EE
Once3
times
Indicates that
the driver’s door
has been opened
and closed with
the shift lever in
P, the “ENGINE
START STOP”
switch in any
mode other than
OFF and the
electronic key
has been taken
out of the detec-
tion area.
Turn the
“ENGINE
START STOP”
switch OFF or
confirm the
location of the
electronic key.
Con-
tinu-
ousCon-
tinu-
ous
(Displayed alter-
nately)
(Flashing)
Indicates that
the driver’s door
has been opened
and closed with
the shift lever
out of in P, the
“ENGINE
START STOP”
switch in any
mode other than
OFF and the
electronic key
has been taken
out of the detec-
tion area.
• Shift the shift
lever to P.
• Confirm the
location of the
electronic key.
Inte-
rior
buzzerExte-
rior
buzzer
Warning messageDetailsCorrection
procedure
