Page 66 of 529

61
1
Before driving
IS F_EE
1-3. Adjustable components (seats, mirrors, steering wheel)
Front seats
CAUTION
Seat adjustment
Do not recline the seat more than necessary when the vehicle is in motion to
reduce the risk of sliding under the lap belt.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen or your neck may contact the shoul-
der belt, increasing the risk of death or serious injury in the event of an acci-
dent.
Seat position switch
Seatback angle switch
Seat cushion (front) angle switch
Vertical height adjustment switch
Lumbar support switch
Page 70 of 529

65
1-3. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
IS F_EE
To cancel seat position recall
Perform any of the following operations.
Push the “SET” button.
Push button “1”, “2” or “3”.
Adjust the seat using the switches (only cancels seat position recall).
If the battery is disconnected
The memorized positions are erased when the battery is disconnected.
CAUTION
Seat adjustment caution
Take care during seat adjustment that the seat does not strike the rear pas-
senger or squeeze your body against the steering wheel.
Page 72 of 529

67
1-3. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
IS F_EE
Operating the seat position memory after turning the “ENGINE START
STOP” switch OFF
Memorized position can be activated up to 180 seconds after the front pas-
senger door is opened, even after turning the “ENGINE START STOP”
switch OFF.
To cancel seat position recall
Perform any of the following operations.
Push the “SET” button.
Push button “1”, “2” or “3”.
Adjust the seat position using the switches.
If the battery is disconnected
The memorized positions are erased when the battery is disconnected.
CAUTION
Seat adjustment caution
Take care during seat adjustment that the seat does not strike the rear pas-
senger.
Page 73 of 529

68
1-3. Adjustable components (seats, mirrors, steering wheel)
IS F_EE
Head restraints
Removing the head restraints (front seats)
Vertical adjustment (front
seats)
Up
Pull the head restraints up.
Down
Push the head restraint down
while pushing the lock
release button.
Folding operation (rear seats)
To stow the head restraint by
folding it forward, pull the
head restraint up while push-
ing the lock release button.
Only the button on the right
stay (when facing the front of
the vehicle) can be used to
Lock release but-
Lock release but-
Pull the head restraint up while pushing
the lock release button.
Page 82 of 529

77
1-3. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
IS F_EE
The steering wheel can be adjusted when
The “ENGINE START STOP” switch is in ACCESSORY or IGNITION
ON mode.
Automatic adjustment of the steering position
A desired steering position can be entered to memory and recalled automat-
ically by the driving position memory. (P. 6 2 )
Customization that can be configured at any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional
It is possible to deactivate the auto tilt-away function.
(Customizable features P. 484)
Page 87 of 529

82
1-3. Adjustable components (seats, mirrors, steering wheel)
IS F_EE
The mirrors can be operated when
The “ENGINE START STOP” switch is in ACCESSORY or IGNITION
ON mode.
When the mirrors are fogged up
Turn on the mirror defoggers to defog the mirrors. (P. 236)
One-touch adjustment of the mirror angle
A desired mirror face angle can be entered to memory and adjusted with the
touch of a button. (P. 6 2 )
Linked mirror function when reversing
The outside rear view mirrors will automatically angle downwards when the
vehicle is reversing in order to give a better view of the ground. However,
this function will not operate when the mirror select switch is in the neutral
position (between “L” and “R”).
Auto anti-glare function
When the anti-glare inside rear view mirror is set to automatic mode, the
outside rear view mirrors will activate in conjunction with the anti-glare
inside rear view mirror to reduce reflected light. (P. 7 9 )
Page 522 of 529

499
Alphabetical index
IS F_EE
Service reminder indicators ......164
Shift lever
If the shift lever cannot
be shifted from P ................456
Transmission ........................150
Shift lever light..........................320
Shift lock system .......................456
Shopping bag hooks ..................347
Side airbags ...............................105
Side mirrors
Adjusting and folding .............81
Mirror position memory .........62
Side turn signal lights
Wattage .................................481
Smart entry & start system
Entry function .........................36
Starting the engine ................146
Spare tire
Inflation pressure ..................480
Storage location ....................444
Spark plug .................................478
Specifications ............................472
Speedometer ..............................161Steering wheel
Adjustment............................. 76
Audio switches .................... 278
Steering wheel position
memory ............................... 62
Storage feature.......................... 324
Stuck
If your vehicle becomes stuck ...
468
Sun visors ................................. 330
Sunshade..................................... 86
Switch
Airbag manual ON/OFF ...... 135
Emergency flasher switch.... 416
Engine switch ...................... 146
Fog light switch ................... 175
F-sport mode total control
switch ........................ 153, 209
Hazard light switch .............. 416
Ignition switch ..................... 146
Light switches ...................... 172
Power door lock switch ......... 54
Power window switch............ 82
Satellite switches ................. 333
SNOW switch ...................... 152
Transmission shift
switches ..................... 153, 155
Window lock switch.............. 82
Wiper and washer switch..... 176
