73
1-3. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
IS F_EE
Pregnant women
People suffering illness
Obtain medical advice and wear the seat belt in the proper way.
Child seat belt usage
The seat belts of your vehicle were principally designed for persons of adult
size.
Use a child restraint system appropriate for the child, until the child
becomes large enough to properly wear the vehicle's seat belt. (P. 1 1 6 )
When the child becomes large enough to properly wear the vehicle's seat
belt, follow the instructions on P. 70 regarding seat belt usage.
Replacing the belt after the pretensioner has been activated
If the vehicle is involved in multiple collisions, the pretensioner will acti-
vate for the first collision, but will not activate for the second or subsequent
collisions.
Seat belt regulations
If seat belt regulations exist in the country where you reside, please contact
any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional, for seat belt replacement or installation.
Obtain medical advice and wear the seat
belt in the proper way. (P. 70)
Women who are pregnant should position
the lap belt as low as possible over the
hips in the same manner as other occu-
pants. Extend the shoulder belt com-
pletely over the shoulder and position the
belt across the chest. Avoid belt contact
over the rounding of the abdominal area.
If the seat belt is not worn properly, not
only a pregnant woman, but also the fetus
could suffer death or serious injury as a
result of sudden braking or a collision.

212
2-4. Using other driving systems
IS F_EE
CAUTION
If the hill- start assist control does not operate effectively
Do not overly rely on the hill-start assist control. The hill-start assist control
may not operate effectively on steep inclines and roads covered in ice.
When the VSC is activated
The slip indicator light flashes. Always drive carefully. Reckless driving
may cause an accident, resulting in death or serious injury. Exercise particu-
lar care when the indicator light flashes.
When TRC and VSC are off
Be especially careful and drive at a speed appropriate to the road conditions.
As these are systems to help enhance vehicle stability and driving force, do
not turn off TRC and VSC unless necessary.
Replacing tires
Make sure that all tires are of the designated size and total load capacity, and
of the same brand and tread pattern. In addition, make sure that the tires are
inflated to the recommended tire pressure level.
The ABS, VSC and TRC systems will not function correctly if different
tires are fitted on the vehicle.
Contact any authorized Lexus dealer or repairer, or another duly qualified
and equipped professional, for further information when replacing tires or
wheels.
Handling of tires and suspension
Using tires with any kind of problem or modifying the suspension will
affect the driving assist systems, and may cause the system to malfunction.

222
2-5. Driving information
IS F_EE
Winter driving tips
Carry out the necessary preparations and inspections before driving
the vehicle in winter. Always drive the vehicle in a manner appropriate
to the prevailing weather conditions.
Pre-winter preparations
Use fluids that are appropriate to the prevailing outside
temperatures.
• Engine oil
• Engine coolant
• Washer fluid
Have a service technician inspect the level and specific
gravity of battery electrolyte.
Have the vehicle fitted with four snow tires.
Ensure that all tires are the specified size and the same brand.
Tire chains cannot be installed on 19-inch tires. Use the
specified type of tire chains and install them on the rear
tires only. Before installing the tire chains, change all four
tires and wheels to those of the specified size (tires: 225/
40R18, wheels: 18x8JJ +45 offset). For details, contact any
authorized Lexus dealer or repairer, or another duly quali-
fied and equipped professional.
Before driving the vehicle
Perform the following according to the driving conditions.
Do not try to forcibly open a window or move a wiper that
is frozen. Pour warm water over the frozen area to melt the
ice. Wipe away the water immediately to prevent it from
freezing.
To ensure proper operation of the climate control system
fan, remove any snow that has accumulated on the air inlet
vents in front of the windshield.
Remove any ice that has accumulated on the vehicle chas-
sis

223
2-5. Driving information
2
When driving
IS F_EE
Selecting tire chains
Tire chains can be mounted on 18-inch tires. They cannot be
mounted on 19-inch tires. Use the correct tire chain size when
mounting the snow chains.
Chain size is regulated for each tire size.
Side chain
(3 mm [0.12 in.] in diameter)
Cross chain
(4 mm [0.16 in.] in diameter)
Regulations on the use of snow chains
Regulations regarding the use of tire chains vary according to
location and type of road. Always check local regulations before
installing chains.
Install the chains on the rear tires.
Retighten the chains after driving 0.5 - 1.0 km (1/4 - 1/2 mile).
When driving the vehicle
Accelerate the vehicle slowly and drive at a reduced speed
suitable to road conditions.
When parking the vehicle
Park the vehicle and move the shift lever to P without setting
the parking brake. The parking brake may freeze up, prevent-
ing it from being released. If necessary, block the wheels to
prevent inadvertent sliding or creeping.

224
2-5. Driving information
IS F_EE
Tire chain installation
Observe the following precautions when installing and removing chains.
Install and remove tire chains in a safe location.
Install tire chains on the rear tires.
Install tire chains following the instructions provided in the accompany-
ing manual.
CAUTION
Driving with snow tires
Observe the following precautions to reduce the risk of accidents.
Failing to do so may result in a loss of vehicle control and cause death or
serious injury.
Use tires of the specified size.
Maintain the recommended level of air pressure.
Do not drive at speeds in excess of the speed limit or the speed limit spec-
ified for the snow tires being used.
Use snow tires on all, not just some wheels.
Driving with tire chains
Observe the following precautions to reduce the risk of accidents.
Failing to do so may result in the vehicle being unable to be driven safely,
and may cause death or serious injury.
Do not drive in excess of the speed limit specified for the tire chains being
used or 50 km/h (30 mph), whichever is lower.
Avoid driving on bumpy road surfaces or over potholes.
Avoid sudden turns and braking, as use of chains may adversely affect
vehicle handling.
Slow down sufficiently before entering a curve to ensure that vehicle con-
trol is maintained.

384
4-3. Do-it-yourself maintenance
IS F_EE
Wheels
If a wheel is bent, cracked or heavily corroded, it should be replaced.
Otherwise, the tire may separate from the wheel or cause loss of han-
dling control.
Wheel selection
When replacing wheels, care should be taken to ensure that
they are equivalent to those removed in load capacity, diame-
ter, rim width, and inset*.
Replacement wheels are available at any authorized Lexus
dealer or repairer, or another duly qualified and equipped pro-
fessional.
*: Conventionally referred to as “offset”.
Lexus does not recommend using:
Wheels of different sizes or types
Used wheels
Bent wheels that have been straightened
Aluminum wheel precautions
Use only Lexus wheel nuts and wrenches designed for use
with your aluminum wheels.
When repairing or changing your tires, check that the wheel
nuts are still tight after driving 1600 km (1000 miles).
Use only Lexus genuine balance weights or equivalent and

385
4-3. Do-it-yourself maintenance
4
Maintenance and care
IS F_EE
Tire and wheel replacement (if equipped)
CAUTION
When replacing wheels
Do not use wheels that are a different size from those recommended in the
Owner’s Manual, as this may result in loss of handling control.
Never use an inner tube in a leaking wheel which is designed for a tube-
less tire. Doing so may result in an accident, causing death or serious
injury.
Each tire and wheel is designed only for
its original position on the vehicle.
Therefore, when replacing tires and
wheels make sure that they are fitted in
the position indicated on the reverse side
of the wheel.
“FR”: Front right-hand side
“FL”: Front left-hand side
“RR”: Rear right-hand side
“RL”: Rear left-hand side

472
IS F_EE
6-1. Specifications
Maintenance data (fuel, oil level, etc.)
Dimensions and weight
*1:Unladen vehicle
*2:Vehicles with a rear wheel size of 19 × 9J
*3:Vehicles with a rear wheel size of 19 × 9 1/2J
Overall length4660 mm (183.4 in.)
Overall width1815 mm (71.4 in.)
Overall height*11415 mm (55.7 in.)
Wheelbase2730 mm (107.4 in.)
Tread
Front1560 mm (61.4 in.)
Rear1520 mm (59.8 in.)*2
1530 mm (60.2 in.)*3
Gross vehicle mass2120 kg (4673 lb.)
Maximum permissible axle
capacity1115 kg (2458 lb.)

480
6-1. Specifications
IS F_EE
Tires and wheels
Tire size
Front tires: 225/40R19 93Y
Rear tires: 255/35R19 96Y
Spare tire: T135/70R18 103M
Tire inflation pressure
(front and rear)
(Recommended cold tire
inflation pressure)
Vehicle
speedFront wheel
kPa (kgf/cm2
or bar, psi)
Rear wheel
kPa (kgf/cm2
or bar, psi)
More than
250 km/h
(155 mph)
320 (3.2, 46)320 (3.2, 46)
From 210
km/h (130
mph) to 250
km/h (155
mph)
300 (3.0, 44)300 (3.0, 44)
210 km/h
(130 mph) or
less
250 (2.5, 36)250 (2.5, 36)
Tire inflation pressure
(spare)
(Recommended cold tire
inflation pressure)
420 kPa (4.2 kgf/cm2 or bar, 60 psi)
Wheel size
Ty p e A
Front wheels: 19  8J
Rear wheels: 19  9J
Spare wheel: 18  4T
Ty p e B
Front wheels: 19  8 1/2 J
Rear wheels: 19  9 1/2 J
Spare wheel: 18  4T
Wheel nut torque103 N•m (10.5 kgf•m, 76 ft•lbf)
