4607-3. Do-it-yourself maintenance
IS350/300/200t_U (OM53D18U)
■Rear turn signal lights Open the trunk, and remove the
2 covers and 2 screws.
When removing the cover, wrap the
tip of the screwdriver with tape to
protect the vehicle from damage.
Push and pull the light unit toward
the rear of the vehicle as shown in
the illustration to remove it.
Apply protective tape to the periph-
eral of the light un it installation sur-
face on the vehicle body, such as the
rear bumper, to protect the vehicle
from damage.
Pushing on the portion A in the illus-
tration toward the rear of the vehicle
will make disengagement of the tabs
easier.
Turn the bulb base counterclock-
wise.
Remove the light bulb.
1
2
3
4

4617-3. Do-it-yourself maintenance
7
Maintenance and care
IS350/300/200t_U (OM53D18U)
Install a new light bulb then install
the bulb base to the light unit by
inserting it and turning the bulb
base clockwise.
After installing the light bulb, turn on
the rear turn signal light to visually
check that there is no light leaking
from the bulb base.
Align the tabs and push the light
unit toward the front of the vehicle
to install it.
Remove the protective tape applied
to the peripheral of the light unit
installation surface on the vehicle
body.
Install the 2 screws and 2 covers.
5
6
7

4637-3. Do-it-yourself maintenance
7
Maintenance and care
IS350/300/200t_U (OM53D18U)
■Replacing the following bulbs
If any of the lights listed below has burnt out, have it replaced by your Lexus
dealer.
●Headlights
●Parking lights and daytime running lights
●Side marker lights
●Side turn signal lights
●Fog lights (if equipped)
●Outer foot lights
●Stop/tail lights
●Tail lights
●High mounted stoplight
●License plate lights
■Discharge headlights (if equipped)
If voltage to the discharge bulbs is insufficient, the bulbs may not come on, or may go out
temporarily. The discharge bulbs will come on when normal power is restored.
■LED Lights
The lights other than the discharge headlights (if equipped), front turn signal lights, rear
turn signal lights, back-up light and outer foot lights each consist of a number of LEDs. If
any of the LEDs burn out, take your vehicle to your Lexus dealer to have the light
replaced.
■Condensation build-up on the inside of the lens
Temporary condensation build-up on the inside of the headlight lens does not indicate a
malfunction. Contact your Lexus dealer for mo re information in the following situations:
●Large drops of water have built up on the inside of the lens.
●Wa t e r h a s b u i l t u p i nside the headlight.
■When replacing the front turn signal lights (vehicles with LED headlights)
When the washer fluid filler opening is removed with a large amount of washer fluid con-
tained in the washer tank, washer fluid ma y spill onto the vehicle and cleaning may be
required.
■When replacing light bulbs
 P. 4 5 4

466
IS350/300/200t_U (OM53D18U)8-1. Essential information
Press the switch.
All the turn signals will flash.
To turn them off, press the switch once
again.
■Emergency flashers
If the emergency flashers are used for a long time while the engine is not operating, the
battery may discharge.
Emergency flashers
The emergency flashers are used to warn other drivers when the vehicle has
to be stopped in the road due to a breakdown, etc.

5369-1. Specifications
IS350/300/200t_U (OM53D18U)
Light bulbs*1
Light bulbsBulb No.WTy p e
Exterior
Discharge headlights*235A
Front turn signal lights7444NA28 /8B
Rear turn signal lights21B
Back-up lights92116C
Outer foot lights5C
Interior
Door courtesy lights1685C
Vanity lights8C
Interior light8C
Pe r s o n a l l i g h t s8C
Footwell lights1943.8C
Trunk light5C
A: D4S discharge bulbs B: Wedge base bulbs (amber)
C: Wedge base bulbs (clear)
*1: Light bulbs not listed in this table are LED bulbs.
*2: If equipped

5579-2. Customization
9
Vehicle specifications
IS350/300/200t_U (OM53D18U)
■Moon roof* ( P. 144)
*:If equipped
■Tu r n s i g n a l l e v e r ( P. 1 7 5 )
*1: After flashing the turn signal lights when turn ing left or right while this function is off
and the turn signal lever is moved to the fi rst position in the direction of the flashing
light, the turn signal lights can be selected to be flashing or off.
*2: The turn signal lights keep flashing if the tu rn signal lever is moved to the first position
in the direction of flashing light.
*3: The turn signal lights will be off if the turn signal lever is moved to the first position in
the direction of flashing light.
FunctionDefault settingCustomized setting
Mechanical key linked oper-
ationOffOn——O
Linked operation of compo-
nents when mechanical key
is used (open only)
Slide onlyTilt only——O
Wireless remote control
linked operationOffOn (Open only)——O
Linked operation of compo-
nents when wireless remote
control is used
Slide onlyTilt only——O
Wireless remote control
linked operation signal
(buzzer)OnOff——O
123
FunctionDefault settingCustomized setting
The number of times the
turn signal lights flash auto-
matically when the turn sig-
nal lever is moved to the first
position during a lane
change
*1
3
5
——O7
Off*2
Off*3
123

5609-2. Customization
IS350/300/200t_U (OM53D18U)
■Vehicle customization
●When the smart access system with push-but ton start is off, the entry unlock function
cannot be customized.
●When the doors remain closed after unlocking the doors and the timer activated auto-
matic door lock function activates, signals will be generated in accordance with the
operation buzzer volume and operational si gnal (Emergency flashers) function set-
tings.
●Some settings can be changed using a switch or the audio system screen. If a setting is
changed using a switch, the changed setting will not be reflected on the audio system
screen until the engine switch is turn ed off and then to IGNITION ON mode.
■When customizing using the Remote Touch or Lexus Display Audio controller
Stop the vehicle in a safe place, apply the parking brake, and shift the shift lever to P. Also,
to prevent battery discharge, leave the engi ne running while customizing the features.
CAUTION
■During customization
As the engine needs to be running during customization, ensure that the vehicle is
parked in a place with adequate ventilation. In a closed area such as a garage, exhaust
gases including harmful carbon monoxide (CO) may collect and enter the vehicle. This
may lead to death or a serious health hazard.
NOTICE
■During customization
To prevent battery discharge, ensure that the engine is running while customizing fea-
tures.

587Alphabetical index
IS350/300/200t_U (OM53D18U)
Front turn signal lights .......................... 175Replacing light bulbs ........... 457, 459
Turn signal lever .................................. 175
Wattage ................................................. 536
Fuel ...............................................................194 Capacity .................................................526
Fuel gauge ................................................. 81
Fuel pump shut off system............. 475
Information ............................................537
Refueling.................................................. 194
Type ............................................... 194, 526
Warning light ....................................... 477
Fuel consumption Average fuel economy ...................... 87
Current fuel consumption ................ 87
Fuel filler door ..........................................194 If the fuel filler door cannot be opened .......................... 196
Refueling.................................................. 194
Fuel gauge ....................................................81
Fuel pump shut off system................. 475
Fuses .......................................................... 452
Garage door opener .......................... 392
Gauges ..........................................................81
Gear positions ......................................... 173
Glove box ................................................ 382
Glove box light ...................................... 382 Hands-free system
(for cellular phone)........................... 330
HD Radio
® system .............................. 300
Head restraints......................................... 131
Headlights ................................................. 178 Discharge headlights precautions ....................................... 464
Light switch.............................................178
Replacing light bulbs ....................... 463
Wattage .................................................536
Headlights cleaner ................................ 187
Heaters Air conditioning system .................368
Heated steering wheel ................... 376
Outside rear view mirrors .............372
Seat heaters ...........................................377
Hill-start assist control ........................249
Hood ........................................................... 421 Open ......................................................... 421
Hooks Cargo hooks .......................................385
Coat hooks .............................................391
Retaining hooks (floor mat)............. 26
Horn............................................................. 135
G
H

589Alphabetical index
IS350/300/200t_U (OM53D18U)
Lane Departure Alert (LDA) ............ 217
Language (multi-information display) ............... 89
LATCH anchors ...................................... 59
LDA (Lane Departure Alert) ............ 217
Lever Auxiliary catch lever ...........................421
Hood lock release lever ...................421
Internal trunk release lever............... 113
Shift lever ................................................. 169
Tilt and telescopic steering lock release lever............................. 134
Turn signal lever .................................. 175
Wiper lever ............................................ 187
Lexus Display Audio controller...... 278
Lexus Display Audio system ............ 276
Lexus Enform
*
Lexus Enform Remote*.................... 365
Lexus Enform Safety Connect........400
Lexus parking assist monitor
*........ 230
License plate lights.................................178 Light switch ............................................ 178
Replacing light bulbs ........................463 Light bulbs
Replacing ............................................... 457
Wattage .................................................536
Lights Fog light switch .................................... 186
Headlight switch ..................................178
Illuminated entry system................. 379
Interior light........................................... 379
Interior lights list.................................. 378
Personal lights ..................................... 379
Replacing light bulbs ....................... 457
Trunk light..................................................113
Turn signal lever ................................... 175
Vanity lights .......................................... 387
Wattage .................................................536
Lock steering column........................... 166
Low profile tire ...................................... 438
Luggage security system ......................112
L
*: For vehicles with a navigation system, refer to the
“NAVIGATION SYSTEM OWNER’S MANUAL”.

592Alphabetical index
IS350/300/200t_U (OM53D18U)
Radar cruise control (dynamic radar cruise control) ........................ 202
Radiator .................................................... 429
Radio..........................................................300
Rear personal lights............................. 379 Wattage ................................................. 536
Rear seats .................................................. 124 Fold down the seatback ...................124
Luggage security system .................. 112
Rear sunshade ....................................... 389 Operation ............................................. 389
Reverse operation feature............ 389
Rear turn signal lights ........................... 175 Replacing light bulbs ....................... 460
Turn signal lever .................................. 175
Wattage ................................................. 536
Rear view mirror Inside rear view mirror ..................... 136
Outside rear view mirrors .............. 138 Rear window defoggers ..................... 372
Refueling.................................................... 194
Capacity ................................................. 526
Fuel types............................................... 526
If the fuel filler door cannot be opened ...........................196
Opening the fuel tank cap ..............196
Remote Touch
*
Replacing Electronic key battery .....................450
Fuses ........................................................ 452
Light bulbs.............................................455
Tires .......................................................... 496
Reporting safety defects for U.S. owners .................................. 564
Reset the maintenance data .............. 413
Rev indicator ............................................. 89
Rev peak ..................................................... 89
R
