4938-2. Steps to take in an emergency
8
When trouble arises
IS350/300/200t_U (OM53D18U)
9 times
An attempt was made to drive when
the electronic key was not inside the
vehicle.
Confirm that the electronic key
is inside the vehicle.
Con-
tinuous
An attempt was made to lock the
doors using the smart access system
with push-button start while the
electronic key was still inside the
vehicle.
Retrieve the electronic key
from the vehicle and lock the
doors again.
OnceCon-
tinuous
An attempt was made to lock either
front door by opening a door and
putting the inside lock button into
the lock position, then closing the
door with the electronic key still
inside the vehicle.
Retrieve the electronic key
from the vehicle and lock the
doors again.
Once
The electronic key has a low battery.
Replace the electronic key bat-
tery. ( P. 4 5 0 )
Once
The steering lock could not be
released within 3 seconds of the
engine switch being pressed.
 Press the engine switch while
depressing the brake pedal and
moving the steering wheel left
and right.
Once
Indicates a malfunction in the smart
access system with push-button
start
Have the vehicle inspected by
your Lexus dealer.
Interior
buzzerExteriorbuzzerWa r n i n g m e s s a g eDetails/Actions
(Flashes)
(Flashes)
(Flashes)
(Flashes)
(Flashes)

5058-2. Steps to take in an emergency
8
When trouble arises
IS350/300/200t_U (OM53D18U)
CAUTION
■When using the compact spare tire
●Remember that the compact spare tire provided is specifically designed for use with
your vehicle. Do not use your compact spare tire on another vehicle.
●Do not use more than one compact spare tires simultaneously.
●Replace the compact spare tire with a standard tire as soon as possible.
●Avoid sudden acceleration, ab rupt steering, sudden braking and shifting operations
that cause sudden engine braking.
■When the compact spare tire is attached
The vehicle speed may not be correctly detected, and the following systems may not
operate correctly:
Also, not only can the following system not be utilized fully, but it may even negatively
affect the drive-train components:
•AWD system
■Speed limit when using the compact spare tire
Do not drive at speeds in excess of 50 mph (80 km/h) when a compact spare tire is
installed on the vehicle.
The compact spare tire is not designed for driving at high speeds. Failure to observe
this precaution may lead to an accident causing death or serious injury.
■After using the tools and jack
Before driving, make sure all the tools and jack are securely in place in their storage
location to reduce the possibility of personal injury during a collision or sudden brak-
ing.
NOTICE
■Driving with tire chains and the compact spare tire
Do not fit tire chains to the compact spare tire.
Tire chains may damage the vehicle body and adversely affect driving performance.
■When replacing the tires
When removing or fitting the wheels, tires or the tire pressure warning valve and trans-
mitter, contact your Lexus dealer as the tire pressure warning valve and transmitter
may be damaged if not handled correctly.
• ABS & Brake assist
•VSC
•TRAC
• Cruise control (if equipped)
• Dynamic radar cruise control
(if equipped)
• PCS (if equipped)
•EPS • Adaptive Variable Suspension System
(if equipped)
• LDA (Lane Departure Alert)
(if equipped)
• VGRS (if equipped)
• Rear view monitor system (if equipped)
• Intuitive parking assist (if equipped)
• Navigation system (if equipped)

5078-2. Steps to take in an emergency
8
When trouble arises
IS350/300/200t_U (OM53D18U)
One of the following may be the cause of the problem:
●One or both of the battery terminals may be disconnected.
●The battery may be discharged. (P. 5 1 2 )
●There may be a malfunction in the steering lock system.
Contact your Lexus dealer if the problem cannot be repaired, or if repair procedures
are unknown.
When the engine does not start, the following steps can be used as an interim
measure to start the engine if the engine switch is functioning normally:
Set the parking brake.
Shift the shift lever to P.
Turn the engine switch to ACCESSORY mode.
Press and hold the engine switch for about 15 seconds while depressing the
brake pedal firmly.
Even if the engine can be started using the above steps, the system may be mal-
functioning. Have the vehicle inspected by your Lexus dealer.
The starter motor does not turn over, the interior lights and headlights
do not turn on, or the horn does not sound.
Emergency start function
1
2
3
4

5339-1. Specifications
9
Vehicle specifications
IS350/300/200t_U (OM53D18U)
*1: Minimum pedal clearance when depressed with a force of 112.4 lbf (500 N, 51.0 kgf)
while the engine is running.
*2: Parking brake pedal travel when depressed with a force of 67.4 lbf (300 N, 30.6 kgf)
Brakes
Pe d a l c l e a r a n c e*12WD4.2 in. (107 mm) Min.
AW D4.7 in. (118 mm) Min.
Pedal free play0.04 — 0.08 in. (1.0 — 2.0 mm)
Brake pad wear limit0.04 in. (1.0 mm)
Parking brake lining wear limit0.04 in. (1.0 mm)
Parking brake pedal travel*27  10 clicks
Fluid typeSAE J1703 or FMVSS No. 116 DOT 3
Steering
Free playLess than 1.2 in. (30 mm)

5479-1. Specifications
9
Vehicle specifications
IS350/300/200t_U (OM53D18U)
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pressure
Tire pressure when the vehicle has been parked for
three hours or more, or has not been driven more than 1
mile or 1.5 km under that condition
Maximum inflation pres-
sureThe maximum cold inflated pressure to which a tire may
be inflated, shown on the sidewall of the tire
Recommended inflation
pressureCold tire inflation pressure recommended by a manu-
facturer
Accessory weight
The combined weight (in excess of those standard items
which may be replaced) of automatic transmission,
power steering, power brakes, power windows, power
seats, radio and heater, to the extent that these items are
available as factory-installed equipment (whether
installed or not)
Curb weight
The weight of a motor vehicle with standard equipment,
including the maximum capacity of fuel, oil and coolant,
and if so equipped, air co nditioning and additional
weight optional engine
Maximum loaded vehicle
weight
The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight
Normal occupant weight150 lb. (68 kg) times the numb er of occupants specified
in the second column of Table 1* that follows
Occupant distributionDistribution of occupants in a vehicle as specified in the
third column of Table 1
* below
Production options weight
The combined weight of installed regular production
options weighing over 5 lb. (2.3 kg) in excess of the
standard items which they replace, not previously con-
sidered in curb weight or accessory weight, including
heavy duty brakes, ride levelers, roof rack, heavy duty
battery, and special trim
RimA metal support for a tire or a tire and tube assembly
upon which the tire beads are seated

577What to do if... (Troubleshooting)
IS350/300/200t_U (OM53D18U)
●Did you press the engine switch while firmly depressing the brake pedal?
(P. 1 6 4 )
●Is the shift lever in P? ( P. 166)
●Is the electronic key anywhere detectable inside the vehicle? ( P. 1 1 6 )
●Is the steering wheel unlocked? ( P. 1 6 6 )
●Is the electronic key battery weak or depleted?
In this case, the engine can be started in a temporary way. (P. 5 1 0 )
●Is the battery discharged? ( P. 5 1 2 )
●Is the engine switch in IGNITION ON mode?
If you cannot release the shift lever by depressing the brake pedal with the
engine switch in IGNITION ON mode. ( P. 5 0 8 )
●It is locked automatically to prevent theft of the vehicle. ( P. 1 6 6 )
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be operated
if the window lock switch is pressed. ( P. 141)
●The auto power off function will be oper ated if the vehicle is left in ACCES-
SORY or IGNITION ON mode (the engine is not running) for a period of
time. ( P. 1 6 6 )
If you think something is wrong
The engine does not start
The shift lever cannot be shifted from P even if you depress the brake
pedal
The steering wheel cannot be turned after the engine is stopped
The windows do not open or close by operating the power window
switches
The engine switch is turned off automatically

581Alphabetical index
IS350/300/200t_U (OM53D18U)
Alarm .............................................................. 71
Anchor brackets ...................................... 58
Antennas (smart access system with push-button start) ....................... 116
Anti-lock Brake System (ABS)....... 249 Function ..................................................249
Warning light ....................................... 476
Approach warning (dynamic radar cruise control) ........................ 207
Armrest .................................................... 389
Assist grip ..................................................391
Audio input.............................................. 284
Audio system.......................................... 276 Audio input............................................284
AUX port/USB port........................284
Bluetooth
® audio.............................. 328
CD player ............................................. 306
iPod .............................................................312
MP3/WMA/AAC disc ................ 306
Optimal use ..........................................293
Portable music player ....................... 319
Radio ....................................................... 300
Steering wheel audio switch ......... 281
USB memory ........................................ 315 Automatic headlight leveling
system ...................................................... 179Warning light ........................................477
Automatic High Beam .......................... 181
Automatic light control system ...................................................... 178
Automatic transmission....................... 169 If the shift lever cannot be shifted from P ........... 508
M mode .................................................... 172
Paddle shift switches............................ 171
AUX port ................................................ 284
Average fuel economy ..........................87
Average vehicle speed..........................87

585Alphabetical index
IS350/300/200t_U (OM53D18U)
E-mail.........................................................338
Eco drive mode ..................................... 246
Eco Driving Indicator...............................91
Eco Driving Indicator Light ................. 89
EDR (Event data recorder) ...................10
Elapsed time .............................................. 87
Electric Power Steering (EPS) ....... 250Function ................................................. 250
Warning light ....................................... 477
Electronic key ......................................... 100 Battery-saving function ...................... 117
If the electronic key does not operate properly............................ 509
Replacing the battery ...................... 450 Emergency, in case of
If a warning message is displayed ........................................ 482
If the electronic key does not operate properly ....... 509
If the engine will not start .............. 506
If the shift lever cannot be shifted from P ........... 508
If the vehicle battery is discharged........................................... 512
If the warning buzzer sounds ................................................. 476
If the warning light turns on .......... 476
If you have a flat tire .......................... 496
If you think something is wrong .............................................. 474
If your vehicle becomes stuck......................................................520
If your vehicle has to be stopped in an emergency.......... 467
If your vehicle needs to be towed .......................................468
If your vehicle overheats ..................516
E

586Alphabetical index
IS350/300/200t_U (OM53D18U)
Emergency flashers ............................. 466
Engine ....................................................... 526ACCESSORY mode....................... 165
Compartment ...................................... 423
Engine switch ........................................ 164
Hood ..........................................................421
How to start the engine ................... 164
Identification number .......................526
If the engine will not start............... 506
Ignition switch (engine switch)..... 164
Overheating .......................................... 516
Engine coolant....................................... 428 Capacity .................................................. 531
Checking................................................428
Preparing and checking before winter ....................................270
Engine coolant temperature gauge ..........................................................81
Engine immobilizer system ................. 69
Engine oil ................................................. 425 Capacity ................................................. 527
Checking................................................425
Preparing and checking before winter ....................................270
Engine oil maintenance data ............427
Engine switch ...........................................164
Enhanced VSC ..................................... 249
EPS (Electronic Power Steering) ........ 250Function ................................................. 250
Warning light ....................................... 477
Event data recorder (EDR) ...................10 First-aid kit storage belt..................... 385
Flat tire .......................................................496
Floor mats....................................................26
Fluid
Automatic transmission .................. 532
Brake........................................................ 533
Washer ................................................... 433
Fog lights....................................................186 Replacing light bulbs ....................... 463
Switch ....................................................... 186
Wattage .................................................536
Footwell light .......................................... 378 Wattage .................................................536
Front passenger occupant classification system ............................ 47
Front personal lights ............................379 Wattage .................................................536
Front seats ................................................. 123 Adjustment.............................................. 123
Cleaning.................................................409
Correct driving posture .................... 28
Driving position memory................. 126
Head restraints .......................................131
Power easy access system ............. 126
Seat heaters ...........................................377
Seat position memory ....................... 126
Seat ventilators.....................................377F

587Alphabetical index
IS350/300/200t_U (OM53D18U)
Front turn signal lights .......................... 175Replacing light bulbs ........... 457, 459
Turn signal lever .................................. 175
Wattage ................................................. 536
Fuel ...............................................................194 Capacity .................................................526
Fuel gauge ................................................. 81
Fuel pump shut off system............. 475
Information ............................................537
Refueling.................................................. 194
Type ............................................... 194, 526
Warning light ....................................... 477
Fuel consumption Average fuel economy ...................... 87
Current fuel consumption ................ 87
Fuel filler door ..........................................194 If the fuel filler door cannot be opened .......................... 196
Refueling.................................................. 194
Fuel gauge ....................................................81
Fuel pump shut off system................. 475
Fuses .......................................................... 452
Garage door opener .......................... 392
Gauges ..........................................................81
Gear positions ......................................... 173
Glove box ................................................ 382
Glove box light ...................................... 382 Hands-free system
(for cellular phone)........................... 330
HD Radio
® system .............................. 300
Head restraints......................................... 131
Headlights ................................................. 178 Discharge headlights precautions ....................................... 464
Light switch.............................................178
Replacing light bulbs ....................... 463
Wattage .................................................536
Headlights cleaner ................................ 187
Heaters Air conditioning system .................368
Heated steering wheel ................... 376
Outside rear view mirrors .............372
Seat heaters ...........................................377
Hill-start assist control ........................249
Hood ........................................................... 421 Open ......................................................... 421
Hooks Cargo hooks .......................................385
Coat hooks .............................................391
Retaining hooks (floor mat)............. 26
Horn............................................................. 135
G
H
