audio Lexus IS220d 2012 Owner's Guide

273
3-2. Using the audio system
3
Interior features
IS250/220d/200d_EE
Using the CD player
The illustration below is for left-hand drive vehicles.
The button positions and shapes may differ slightly for right-hand
drive vehicles.
Powe Vol-
Track
selectionCD ejectPlayback
CD loadCD selection
Random play-RepeatPlayback/Displays text mes-

274
3-2. Using the audio system
IS250/220d/200d_EE
Loading CDs
Loading a CD
Press .
“WAIT” is shown on the display.
Insert a CD when the indicator on the slot turns from amber
to green.
The display changes from “WAIT” to “LOAD”.
Loading multiple CDs
Press and hold until you hear a beep.
“WAIT” is shown on the display.
Insert a CD when the indicator on the slot turns from amber
to green.
The display changes from “WAIT” to “LOAD”.
The indicator on the slot turns to amber when the CD is inserted.
Insert the next CD when the indicator on the slot turns from
amber to green again.
Repeat the procedure for the remaining CDs.
To stop the operation, press .
Ejecting CDs
Ejecting a CD
To select the CD to be ejected,
press “” or “” on .
The number of the CD selected
is shown on the display.
Press and remove the CD.
STEP1
STEP2
STEP1
STEP2
STEP3
STEP1
STEP2

275
3-2. Using the audio system
3
Interior features
IS250/220d/200d_EEEjecting all the CDs
Press and hold until you hear a beep, and then remove the
CDs.
Selecting, fast-forwarding and reversing tracks
Selecting a track
Press “” to move up and “” to move down using until
the desired track number is displayed.
To fast forward or reverse, press and hold “” or “” on until
you hear a beep.
Selecting a CD
To select a CD to play
To select the desired CD, press “” or “” on .
Random playback
Current CD
Press (RAND).
All CDs
Press and hold (RAND) until you hear a beep.

276
3-2. Using the audio system
IS250/220d/200d_EE
Repeat play
To repeat a track
Press (RPT).
To repeat all of the tracks on a CD
Press and hold (RPT) until you hear a beep.
Playing and pausing tracks
To play or pause a track, press ( ).
Switching the display
Press .
Each time is pressed, the display changes in the order of Track
no./Elapsed timeCD titleTrack title.
Display
Up to 12 characters can be displayed at a time.
If there are 13 characters or more, pressing and holding until you
hear a beep will display the remaining characters.
A maximum of 24 characters can be displayed.
If is pressed until you hear a beep again or has not been pressed for 6
seconds or more, the display will return to the first 12 characters.
Depending on the contents recorded, the characters may not be displayed
properly or may not be displayed at all.
Canceling random and repeat playback
Press (RAND) or (RPT) again.

277
3-2. Using the audio system
3
Interior features
IS250/220d/200d_EE
When “LOAD”, “ERROR” or “WAIT” is shown on the display
“LOAD”: This indicates that the CD player has completed loading the CD.
“ERROR”:This indicates a trouble either in the CD or inside the player. The
CD may be dirty, damaged, or inserted up-side down.
“WAIT”: Operation is stopped due to a high temperature inside the player.
Wait for a while and then press . Contact any authorized
Lexus dealer or repairer, or another duly qualified and equipped
professional, if the CD still cannot be played back.
Discs that can be used
Discs with the marks shown below can be used.
Playback may not be possible depending on recording format or disc fea-
tures, or due to scratches, dirt or deterioration.
CDs with copy-protection features may not play correctly.
CD player protection feature
To protect the internal components, playback is automatically stopped when
a problem is detected.
If CDs are left inside the CD player or in the ejected position for extended
periods
CDs may be damaged and may not play properly.
Lens cleaners
Do not use lens cleaners. Doing so may damage the CD player.

278
3-2. Using the audio system
IS250/220d/200d_EE
NOTICE
CDs and adapters that cannot be used
Do not use the following types of CDs, 8 cm (3 in.) CD adapters or Dual
Disc.
Doing so may damage the CD player and/or the CD insert/eject function.
CDs that have a diameter that is not 12
cm (4.7 in.).
Low-quality and deformed CDs.
CDs with a transparent or translucent
recording area.
CDs that have had tape, stickers or CD-
R labels attached to them, or that have
had the label peeled off.

279
3-2. Using the audio system
3
Interior features
IS250/220d/200d_EE
NOTICE
CD player precautions
Failure to follow the precautions below may result in serious damage to the
CDs or the player itself.
Do not insert anything other than CDs into the CD slot.
Do not apply oil to the CD player.
Store CDs away from direct sunlight.
Never try to disassemble any part of the CD player.
Do not insert more than one CD at a
time.

280
3-2. Using the audio system
IS250/220d/200d_EE
Playing back MP3 and WMA discs
Loading and ejecting MP3 and WMA discs
P. 274
Selecting MP3 and WMA discs
P. 275
Selecting a folder
Selecting folders one at a time
Press () or () to select the desired folder.
Returning to the first folder
Press and hold () until you hear a beep.
The illustration below is for left-hand drive vehicles.
The button positions and shapes may differ slightly for right-hand
drive vehicles.
Powe Vol-
CD ejectPlayback
CD loadCD selectionFile selection Random play-Repeat
Displays
text
Folder selection
File selection
Playback/Pause

281
3-2. Using the audio system
3
Interior features
IS250/220d/200d_EE
Fast-forwarding and reversing files
To fast-forward or reverse, press and hold “” or “” on
until you hear a beep.
Selecting files
Selecting one file at a time
Turn or press “” or “” on to select the desired file.
Repeat play
Repeating a file
Press (RPT).
Repeating all of the files in a folder
Press and hold (RPT) until you hear a beep.
Random playback
To play files from a particular folder in random order
Press (RAND).
To play all of the files on a disc in random order
Press and hold (RAND) until you hear a beep.
Playing and pausing files
To play or pause a file, press ( ).

282
3-2. Using the audio system
IS250/220d/200d_EE
Switching the display
Press .
Each time is pressed, the display changes in the order of
Folder no./File no./Elapsed timeFolder nameFile nameAlbum
title (MP3 only)Track titleArtist name.
Display
Up to 12 characters can be displayed at a time.
If there are 13 characters or more, pressing and holding until you
hear a beep will display the remaining characters.
A maximum of 24 characters can be displayed.
If is pressed until you hear a beep again or has not been pressed for 6
seconds or more, the display will return to the first 12 characters.
Depending on the contents recorded, the characters may not be displayed
properly or may not be displayed at all.
Canceling random and repeat playback
Press (RAND) or (RPT) again.
When “LOAD”, “ERROR”, “WAIT” or “NO MUSIC” is shown on the dis-
play
“LOAD”: This indicates that the CD player has completed loading the CD.
“ERROR”:This indicates a trouble either in the CD or inside the player. The
CD may be dirty, damaged, or inserted up-side down.
“WAIT”: Operation is stopped due to a high temperature inside the player.
Wait for a while and then press . Contact any authorized
Lexus dealer or repairer, or another duly qualified and equipped
professional, if the CD still cannot be played back.
“NO MUSIC”: This indicates that the MP3/WMA file is not included in the
CD.
