Lexus IS220d 2012 Owner's Manual

460
4-3. Do-it-yourself maintenance
IS250/220d/200d_EE
When replacing the front left headlight and front position light bulbs
Condensation build-up on the inside of the lens
Contact any authorized Lexus dealer or repairer, or another duly qualified
and equipped professional, for more information in the following situations.
Temporary condensation build-up on the inside of the headlight lens does
not indicate a malfunction.
Large drops of water are built up on the inside of the lens.
Water has built up inside the headlight.
Discharge headlights (if equipped)
If voltage to the discharge bulbs is insufficient, the bulbs may not come on,
or may go out temporarily. The discharge bulbs will come on when normal
power is restored.
LED side turn signal lights, tail lights, stop/tail lights, high mounted stop-
light, license plate lights and front position lights (vehicles with discharge
headlights)
The side turn signal lights, tail lights, stop/tail lights, high mounted stop-
light, license plate lights and front position lights (vehicles with discharge
headlights) consist of a number of LEDs. If any of the LEDs burn out, take
your vehicle to any authorized Lexus dealer or repairer, or another duly
qualified and equipped professional to have the light replaced.
Remove the securing bolt and move the
washer fluid filler opening to allow easy
access to the light bulbs.
After replacing the bulbs, make sure to
secure the washer fluid filler opening
with the bolt.

461
4-3. Do-it-yourself maintenance
4
Maintenance and care
IS250/220d/200d_EE
CAUTION
Replacing light bulbs
Turn off the headlights. Do not attempt to replace the bulb immediately
after turning off the headlights.
The bulbs become very hot and may cause burns.
Do not touch the glass portion of the light bulb with bare hands. Hold the
bulb by the plastic or metal portion.
If the bulb is scratched or dropped it may blow out or crack.
Fully install light bulbs and any parts used to secure them. Failing to do so
may result in heat damage, fire, or water entering the headlight unit. This
may damage the headlights or cause condensation to build up on the lens.
Discharge headlights (if equipped)
Contact any authorized Lexus dealer or repairer, or another duly qualified
and equipped professional, before replacing discharge headlights (includ-
ing light bulbs).
Do not touch the high-intensity discharge headlight’s high voltage socket
when the headlights are turned on.
An extremely high voltage of 20000 V will be discharged and could result
in serious injury or death by electric shock.
Do not attempt to take apart or repair the low beam discharge headlight
bulbs, connectors, power supply circuits, or related components.
Doing so could result in electric shock and serious injury or death.
To prevent damage or fire
Make sure bulbs are fully seated and locked.

5When trouble arises
457
5-1. Essential information
Emergency flashers .......... 458
If your vehicle needs to
be towed ......................... 459
If you think something is
wrong ............................. 465
Fuel pump shut off
system ............................ 466
5-2. Steps to take in an
emergency
If a warning light turns
on or a warning buzzer
sounds... ......................... 467
If a warning message is
displayed ........................ 473
If you have a flat tire
(vehicles with a spare
tire)................................. 485
If you have a flat tire
(vehicles with an
emergency tire
puncture repair kit) ........ 497
If the engine will not start 512
If the shift lever cannot
be shifted from P............ 514
If you lose your keys ........ 515If the electronic key
does not operate
properly.......................... 516
If the vehicle battery is
discharged ...................... 521
If your vehicle overheats . 525
If you run out of fuel
and the engine stalls....... 528
If the vehicle becomes
stuck............................... 529
If your vehicle has to
be stopped in an
emergency...................... 531

458
IS250/220d/200d_EE
5-1. Essential information
Emergency flashers
NOTICE
To prevent battery discharge
Do not leave the emergency flashers on longer than necessary when the
engine is not running.
Use the emergency flashers if the vehicle malfunctions or is involved
in an accident.
Press the switch to flash all
the turn signal lights. To turn
them off, press the switch
once again.

5
459
5-1. Essential information
When trouble arises
IS250/220d/200d_EE
If your vehicle needs to be towed
Before towing
The following may indicate a problem with your transmission.
Contact any authorized Lexus dealer or repairer, or another duly
qualified and equipped professional, before towing.
The engine is running, but the vehicle will not move.
The vehicle makes an abnormal sound.
Emergency towing
If a tow truck is not available, in an emergency your vehicle may
be temporarily towed using a cable or chain secured to the emer-
gency towing eyelet(s). This should only be attempted on hard,
surfaced roads for short distances at low speeds.
A driver must be in the vehicle to steer and operate the brakes. The
vehicle’s wheels, drive train, axles, steering and brakes must be in
good condition.
If towing is necessary, we recommend having your vehicle towed by
any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional, such as a commercial towing service, using a
lift-type truck or a flat bed truck.
Use a safety chain system for all towing, and abide by all state/provin-
cial and local laws.
If towing from the rear, the vehicle's front wheels and axles must be in
good condition. (P. 463)
If they are damaged, use a towing dolly or flat bed truck.

460
5-1. Essential information
IS250/220d/200d_EETowing eyelets
Emergency towing procedure
Release the parking brake.
Shift the shift lever to N.
Put the “ENGINE START STOP” switch in ACCESSORY mode
or IGNITION ON mode.
CAUTION
Caution while towing
Use extreme caution when towing the vehicle.
Avoid sudden starts or erratic driving maneuvers which place excessive
stress on the emergency towing eyelets and the cables or chains. Always
be cautious of the surroundings and other vehicles while towing.
If the engine is not running, the power assist for the brakes and steering
will not function, making steering and braking more difficult.
NOTICE
To prevent causing serious damage to the transmission
(vehicles with an automatic transmission)
Never tow this vehicle from the front with the rear wheels on the ground.
This may cause serious damage to the transmission.
When towing a vehicle without using a towing dolly
(vehicles with a manual transmission)
The “ENGINE START STOP” switch must not be OFF.
STEP1
STEP2
STEP3

5
461
5-1. Essential information
When trouble arises
IS250/220d/200d_EE
Installing towing eyelets
Remove the eyelet cover using
a flathead screwdriver.
To protect the bodywork, place
a rag between the screwdriver
and the vehicle body, as shown
in the illustration.
Insert the towing eyelet into the
hole and tighten partially by
hand.
Tighten down the towing eyelet
securely using a wheel nut
wrench.
STEP1
STEP2
STEP3
Location of the emergency towing eyelet
P. 4 8 5

462
5-1. Essential information
IS250/220d/200d_EE
Towing with a sling-type truck
CAUTION
Installing towing eyelets to the vehicle
Make sure that towing eyelets are installed securely.
If not securely installed, towing eyelets may come loose during towing. This
may lead to accidents that cause serious injury or even death.
NOTICE
To prevent body damage
Do not tow with a sling-type truck, either from the front or rear.

5
463
5-1. Essential information
When trouble arises
IS250/220d/200d_EE
Towing with a wheel lift-type truck
From the front
Vehicles with an automatic
transmission: Use a towing
dolly under the rear wheels.
Vehicles with a manual trans-
mission: We recommend to use
a towing dolly under the rear
wheels.
When not using a towing dolly,
release the parking brake and
shift the shift lever to N.
From the rear
Switch to ACCESSORY mode
so that the steering wheel is
unlocked.
NOTICE
To prevent causing serious damage to the transmission
(vehicles with an automatic transmission)
Never tow this vehicle from the front with the rear wheels on the ground.

464
5-1. Essential information
IS250/220d/200d_EE
Using a flat bed truck
If your Lexus is transported by
a flat bed truck, it should be
tied down at the locations
shown in the illustration.
If you use chains or cables to tie
down your vehicle, the angles
shaded in black must be 45.
Do not overly tighten the tie
downs or the vehicle may be
damaged.
NOTICE
To prevent damaging the vehicle
Do not tow the vehicle from the rear with the “ENGINE START STOP”
switch OFF.
The steering lock mechanism is not strong enough to hold the front wheels
straight.
When raising the vehicle, ensure adequate ground clearance for towing at
the opposite end of the raised vehicle. Without adequate clearance, the
vehicle could be damaged while being towed from the rear.
