Page 168 of 609
159
2-1. Driving procedures
2
When driving
IS250/220d/200d_EE
If the engine does not start
The engine immobilizer system may not have been deactivated. (P. 9 6 )
When the steering lock cannot be released
When the “ENGINE START STOP” switch indicator flashes in amber
The system may be malfunctioning. Have the vehicle inspected by any
authorized Lexus dealer or repairer, or another duly qualified and equipped
professional, immediately.
Auto power off function
If the vehicle is left in ACCESSORY mode for more than an hour with the
shift lever in P (vehicles with an automatic transmission), the “ENGINE
START STOP” switch will automatically turn OFF.
Electronic key battery depletion
P. 4 4
When the electronic key battery is discharged
P. 4 3 1
Conditions affecting operation
P. 4 2
Note for the entry function
P. 4 6
The “ENGINE START STOP” switch
indicator will flash in green and a mes-
sage will be shown on the multi-informa-
tion display. Press the “ENGINE START
STOP” switch again while turning the
steering wheel left and right.
Page 169 of 609
160
2-1. Driving procedures
IS250/220d/200d_EE
CAUTION
When starting the engine
Always start the engine while sitting in the driver's seat. Do not press the
accelerator while starting the engine under any circumstances.
Doing so may cause an accident resulting in death or serious injury.
Stopping the engine in an emergency
If you want to stop the engine in an emergency while driving the vehicle,
push and hold the “ENGINE START STOP” switch for more than 3 sec-
onds.
However, do not touch the “ENGINE START STOP” switch while driving
except in an emergency. Turning the engine off while driving will not cause
loss of steering or braking control, but the power assist to these systems will
be lost. This will make it more difficult to steer and brake, so you should
pull over and stop the vehicle as soon as it is safe to do so.
NOTICE
To prevent battery discharge
Do not leave the “ENGINE START STOP” switch in ACCESSORY or
IGNITION ON mode for long periods without the engine running.
When starting the engine
Do not race a cold engine.
If the engine becomes difficult to start or stalls frequently, have the engine
checked immediately.
Page 170 of 609
161
2-1. Driving procedures
2
When driving
IS250/220d/200d_EE
Automatic transmission
Select a shift position appropriate for the driving conditions.
Shifting the shift lever
While the “ENGINE START STOP” switch is in IGNI-
TION ON mode, depress the brake pedal and move the
shift lever.
Shift position uses
*: To improve fuel consumption and reduce noises, set the shift lever
Shift positionFunction
PParking the vehicle or starting the engine
RReversing
NNeutral
DNormal driving*
SS mode driving (P. 165)
: If equipped
Page 172 of 609
163
2-1. Driving procedures
2
When driving
IS250/220d/200d_EE
Selecting shift ranges in the D position (if equipped)
To drive using temporary shift range selection, operate the “-” shift
paddle switch. The shift range can then be selected by operating
the “-” and “+” shift paddle switches. Changing the shift range
allows restriction of the upper limit of the gears to be used, pre-
venting unnecessary upshifting and enabling the level of engine
braking force to be selected.
Higher shift range
Lower shift range
The selected shift range, from 1
to 6, will be displayed in the
meter cluster.
To return to normal D position
driving, the “+” shift paddle
switch must be held down for a
period of time.
Page 173 of 609
164
2-1. Driving procedures
IS250/220d/200d_EEShift ranges and their functions
A lower shift range will provide greater engine braking force than a
higher shift range.
Shift rangeFunction
6Automatically selecting gears between 1 and 6
according to vehicle speed and driving conditions.
5Automatically selecting gears between 1 and 5
according to vehicle speed and driving conditions.
4Automatically selecting gears between 1 and 4
according to vehicle speed and driving conditions.
3Automatically selecting gears between 1 and 3
according to vehicle speed and driving conditions.
2Automatically selecting gears between 1 and 2
according to vehicle speed and driving conditions.
1Setting the gear at 1.
Page 174 of 609
165
2-1. Driving procedures
2
When driving
IS250/220d/200d_EE
Changing shift ranges in S mode
To enter S mode, shift the shift lever to the S position. The shift
range can then be selected by operating the “-” and “+” shift pad-
dle switches (if equipped) or the shift lever. Changing the shift
range allows restriction of the upper limit of the gears to be used,
preventing unnecessary upshifting and enabling the level of engine
braking force to be selected.
Higher shift range
Lower shift range
The selected shift range, from 1
to 6, will be displayed in the
meter cluster.
The initial shift range in S mode is automatically set to 5 or 4
according to vehicle speed. However, the initial shift range may be
set to 3 or 2 if the AI-SHIFT has operated while the shift lever was
in the D position.
(P. 167)
Shift ranges and their functions
P. 164
Page 175 of 609
166
2-1. Driving procedures
IS250/220d/200d_EE
When the “-” shift paddle switch is operated in the D position
When the “-” shift paddle switch is operated in the D position, a shift range
will be automatically selected. The highest gear of the first shift range will
be one gear lower than the gear in use during normal D position driving.
Automatic deactivation of shift range selection in the D position
Shift range selection in the D position will be deactivated in the following
situations:
When the vehicle comes to a stop
When range 6 is selected and the accelerator pedal is depressed
If the accelerator pedal is depressed for more than a certain period of
time
To protect automatic transmission
A function is adopted that automatically selects a higher shift range when
the fluid temperature is high.
Gear range display when driving
The current gear is displayed on the multi-information display. (P. 184)
Downshifting restrictions warning buzzer
To help ensure safety and driving performance, downshifting operation may
sometimes be restricted. In some circumstances, downshifting may not be
possible even when the shift lever or shift paddle switch is operated. (The
warning buzzer will sound twice.)
When driving with the cruise control system or dynamic radar cruise control
system
Engine braking will not occur during shift range selection in the D position
or S mode, even when downshifting to range 5 or 4. (P. 198, 202)
Snow mode automatic deactivation
Snow mode is automatically deactivated if the “ENGINE START STOP”
switch is turned off after driving in snow mode.
If the shift lever cannot be shifted from P
P. 5 1 4
Page 178 of 609
169
2-1. Driving procedures
2
When driving
IS250/220d/200d_EE
Maximum downshifting speed
Adhere to the downshifting speeds in the following table in order to prevent
over-revving the engine.
km/h (mph)
Shift positionMaximum speed
146 (28)
291 (56)
3151 (93)
4198 (122)
Page 179 of 609
170
2-1. Driving procedures
IS250/220d/200d_EE
Turn signal lever
Turn signals can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode.
If the indicators flash faster than usual
Check that a light bulb in the front or rear turn signal lights has not burned
out.
Right turn
Left turn
Move and hold the lever
partway to signal a lane
change
The right hand signal will
flash until you release the
lever.
Move and hold the lever
partway to signal a lane
change
The left hand signal will flash
until you release the lever.
Page 183 of 609
171
2
When driving
IS250/220d/200d_EE
2-2. Instrument cluster
Gauges and meters
The units used on the speedometer, tachometer and fuel gauge display
may differ depending on the model/type.
The following gauges, meters and display illuminate when the
“ENGINE START STOP” switch is in IGNITION ON mode.
Speedometer
Displays the vehicle speed.
Multi-information display
P. 181
Tachometer
Displays the engine speed in revolutions per minute.
Tacho indicator
When the set engine speed is reached, this ring-shaped indicator
comes on in yellow. The indicator comes on in red when the engine
speed reaches a dangerous range.
Engine coolant temperature gauge
Displays the engine coolant temperature.
