Lexus IS250 2007 Basic Functions / LEXUS 2007 IS350/250 OWNER'S MANUAL (OM53578U)

213
3
Interior features
3-4. Using the storage features
List of storage features
Glove box
Open (push button)
Lock with the mechanical key
Unlock with the mechanical key
Glove box
Console boxes
Cup holders
Bottle holders/door pockets
Overhead console
Glove box

214
3-4. Using the storage features
Console boxes
Front
Pull up the knob to release the
lock.
Slide armrest.
Pull up the knob to release the
lock.
Lift the armrest to open.
Rear (if equipped)
Press the button to release the
lock.
Lift the armrest to open.
■Glove box light
The glove box light turns on when the engine switch is in IG-ON mode.
■Trunk opener main switch
The trunk opener main switch located in the glove box. ( P. 2 3 )
CAUTION
■Caution while driving
Keep the glove box closed.
Injuries may result in the event of an accident or sudden braking.
Glove box and console boxes

215
3-4. Using the storage features
3
Interior features
Overhead console
The overhead console is useful for
temporarily storing sunglasses and
similar small items.
■Console box light (front)
The console box light turn on when the engine switch is in IG-ON mode.
■Using the front console box to store CD cases
CAUTION
■Caution while driving
Keep the console box closed.
Injuries may result in the event of an accident or sudden braking.
Store a CD case with the hinged portion fac-
ing either the front or back of the console
box.
Console boxes and overhead console

216
3-4. Using the storage features
Cup holders
Front (type A)
To open, press down and release
the front of the cup holder lid.
Front (type B)
Press the knob to release the
lock.
Slide armrest.
CAUTION
■Items that should not be left in the overhead console
Do not leave glasses or lighters in the console.
If the interior of the vehicle becomes hot, lighters may explode and glasses may
warp or become cracked.
■Caution while driving
Do not leave the overhead console open while driving.
Items may fall out and cause injury.
Overhead console and cup holders

217
3-4. Using the storage features
3
Interior features
Rear
To open, press in and release the
rear cup holder on the rear center
armrest.
■Using the front cup holder (type B) to store small items
CAUTION
■Items unsuitable for the cup holder
Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or sudden
braking and cause injury. If possible, cover hot drinks to prevent burns.
■When not in use
Keep the cup holders closed.
Injuries may result in the event of an accident or sudden braking.
Remove the cup holder insert holding the
base part.
Cup holders

218
3-4. Using the storage features
Bottle holders/door pockets
The door pocket can be opened
and closed.
When installing the bottle, close
the cap of the bottle.
CAUTION
■Caution while driving
Keep the door pockets closed.
Injuries may result in the event of an accident or sudden braking.
Bottle holders/door pockets

219
3
Interior features
3-5. Other interior features
Sun visors
Forward position:
Flip down.
Side position:
Flip down, unhook, and swing
to the side.

220
3-5. Other interior features
Vanity mirror
The light turns on when the
cover is opened.

221
3-5. Other interior features
3
Interior features
Clock
■The clock is displayed when
The engine switch is in ACC or IG-ON mode.
Adjusts the hour.
Adjusts the minutes.
Rounds to the nearest hour.
*
*: e.g. 1:00 to 1:29  1:00
1:30 to 1:59  2:00

222
3-5. Other interior features
Satellite switches
The satellite switches can be used to change the settings of various fea-
tures. Settings are shown on the multi-information display.
■Operating the satellite switches
Bring up the satellite switch
mode on the multi-information
display.
Press the left selector switch, the
main switch, or the right selector
switch.
Select the item whose setting is
to be changed.
Press either the left or right
selector switch to display the
item whose setting is to be
changed.
Change the settings.
Press the main switch to change
the settings (e.g. ON/OFF).
STEP1
STEP2
STEP3
