sensor Lexus IS250 2007 Basic Functions / LEXUS 2007 IS350/250 (OM53578U) Service Manual

346
5-2. Steps to take in an emergency
Wa r n i n g m e s s a g eDetails
(If equipped)
Indicates a malfunction in the pre-collision system.
(If equipped)
Indicates Lexus parking assist-sensor malfunction.
The malfunctioning assist-sensor is shown flashing on
the display.
(If equipped)
(Flashing)
Indicates a malfunction in the radar cruise control
system.
Stop the vehicle in a safe place. Switch the engine
switch to OFF and then to IG-ON mode again to
reset the cruise control system.

5
When trouble arises
347
5-2. Steps to take in an emergency
■If the tire pressure warning system is inoperative
The tire pressure warning system may become inoperative in the following circum-
stances:
●The vehicle’s wheels have not been equipped with tire pressure sensors.
●The sensor batteries are dead.
●If wireless frequencies the same as those used by the sensors are being used by
other facilities or equipment in the vicinity of the vehicle.
●If snow or ice has collected on or around the wheel or wheelhouse.
●If non-genuine wheels are used on the vehicle.
●When driving with tire chains.
●If wireless devices or other equipment that operate on similar frequencies to
those used by the sensors are being used
●If the select switch is used to select the wrong set of sensors (wheels)
●If the tire pressure was not set to the specified level when the system was initial-
ized
NOTICE
■Precaution when installing a different tire
When a tire of a different specification or maker is installed, the tire pressure warn-
ing system may not operate properly.

352
5-2. Steps to take in an emergency
Wa r n i n g m e s s a g eDetailsCorrection procedure
Indicates low tire pres-
sure.Check the tire pressure,
and adjust to the appropri-
ate level.
(Flashing)
(If equipped)
Indicates that the pre-
collision system is not
currently functional.
Clean the grille and the
sensor.
This message appears
when the pre-collision
system is hot. In this case,
wait until the system
cools down.
(If equipped)
Indicates that Lexus
parking assist-sensor is
dirty or covered with ice.
Clean the sensor.
(If equipped)
(Flashing)
Indicates that the radar
cruise control sensor is
dirty or covered with ice.
Clean the sensor.

409
6-2. Customization
6
Vehicle specifications
ItemFunctionDefault settingCustomized
setting
Po w e r w i n -
dows
(
P. 4 5 )
Linked door lock opera-
tionONOFF
Linked door key opera-
tionOpen and closeOpen only
Close only
Wireless remote control
linked operationONOFF
Moon roof
(
P. 4 8 )
Linked door lock opera-
tionONOFF
Linked door key opera-
tionOpen and closeOpen only
Close only
Linked operation of com-
ponents when door key is
used
Slide onlyTilt only
Wireless remote control
linked operationONOFF
Linked operation of com-
ponents when wireless
remote control used
Slide onlyTilt only
Automatic
light control
system
(
P. 122)
Light sensor sensitivityLevel 3Level 1 to 5
Time elapsed before
headlights automatically
turn off after doors are
closed
30 seconds
0 seconds
60 seconds
90 seconds

410
6-2. Customization
ItemFunctionDefault settingCustomized
setting
Windshield
wipers and
washer
(
P. 1 2 6 )
Switching operation when
the vehicle is stationaryONOFF
Drip prevention functionONOFF
Ti m e e l a p s e d b e f o r e t h e
drip prevention function
operatesVa r i a b l e
depending on
the vehicle
speed
3 seconds
Lexus parking
assist-sensor
(
P. 1 4 2 )
Back sensor operation
display and buzzerONOFF
Buzzer volumeLevel 3Level 1 to 5
Distance which a sensor
detects150 cm (4.9 ft.)60 cm (2.0 ft.)
Illumination
(
P. 2 0 9 )
Time elapsed before lights
turn off15 seconds7. 5 s e c o n d s
30 seconds
Operation when the
doors are unlockedONOFF
Operation after the
engine switch turned OFFONOFF
Front foot well lightingONOFF
Shift lever lightingONOFF
Outer foot lightONOFF

411
6
Vehicle specifications
6-3. Initialization
Items to initialize
ItemWhen to initializeReference
Po w e r w i n d o w
• After reconnecting or changing the
battery
• After changing a fuse
P. 4 5
Engine oil maintenance
dataAfter changing engine oilP. 2 7 2
Tire inflation pressure
warning system
• When the standard tire pressure
changes by replacing tires or wheels
• When tires are rotated
• When tire pressure sensors are
replaced
• When driving with the tires inflated to
a higher than standard tire pressure
P. 2 8 4
The following item must be initialized for normal system operation in cases
such as after the battery is reconnected, or maintenance is performed on
the vehicle.

417
Alphabetical index
Care
Exterior ................................................... 252
Interior..................................................... 254
Seat belts ............................................... 255
Cargo capacity ....................................... 157
Cargo hooks .......................................... 238
CD changer .............................................189
CD player..................................................189
Chains.......................................................... 161
Child restraint system (CRS)
Booster seats, definition..................... 77
Booster seats, installation ................... 81
Convertible seats, definition ............ 77
Convertible seats, installation .......... 81
Front passenger occupant
classification system ......................... 72
Infant seats, definition .......................... 77
Infant seats, installation......................... 81
Installing CRS with lower
anchorages .......................................... 84
Installing CRS with seatbelts ............ 81
Installing CRS with top straps ........ 85
Child safety
Airbag precautions ..............................67
Battery precautions................ 281, 374
Child restraint system ......................... 77
Child-protectors................................... 20
How your child should wear
the seatbelt ............................................ 37
Installing child restraints .................... 80
Moon roof precautions ..................... 50
Power window lock switch ............. 45
Power window precautions............. 47
Removed electronic key battery
precautions ....................................... 303
Seat belt comfort guide..................... 35
Seat belt extender precautions ..... 39Seat belt precautions ..........................38
Seat heater precautions........229, 231
Trunk precautions................................. 25
Child-protectors ...................................... 20
Cigarette lighter.................................... 226
Cleaning
Exterior.................................................... 252
Interior ..................................................... 254
Seat belts ................................................255
Clock ...........................................................221
Coat hooks .............................................. 236
Compass .................................................. 246
Condenser .............................................. 278
Console box ............................................ 214
Cooling system
Engine overheating...........................375
Cornering assist sensors .................... 142
Cruise control
Cruise control....................................... 130
Dynamic radar cruise control....... 133
Cup holder ............................................... 216
Curtain shield airbags..............................61
Customizable features .......................406
Daytime running light system ........... 123
Defogger
Rear window ......................................... 178
Side mirror.............................................. 178
Dimension............................................... 380
Dinghy towing ................................166, 167
Display
Dynamic radar cruise control....... 133
Satellite switch mode ....................... 222
Trip information ..................................... 119
Warning message ............................. 344
Do-it-yourself maintenance ............. 263C
D

420
Alphabetical index
Keys
Electronic key ............................................. 2
Engine switch.......................................... 98
If you lose your keys.........................368
If your electronic key battery
is discharged .................................... 369
Key number ................................................. 2
Keys ................................................................. 2
Mechanical key.......................................... 2
Wireless remote control..................... 16
Light bulbs
Replacing .................................................319
Wattage.................................................. 394
Lights
Door courtesy lights.........................209
Fog light switch..................................... 125
Headlights switch ................................ 122
Interior light switch................................ 211
Outer foot lights ................................. 209
Overhead courtesy light................209
Personal light switch ............................211
Replacing light bulbs..........................319
Scuff lighting .........................................209
Shift lever lighting .............................. 209
Turn signal lever ................................... 107
Vanity lights .......................................... 220
Wattage.................................................. 394
Load capacity .......................................... 160
Maintenance
Do-it-yourself maintenance ......... 263
General maintenance ..................... 259
Maintenance data............................. 380
Maintenance requirements .......... 257
Manual transmission............................. 105Meter
Instrument panel light control .........110
Meters.......................................................109
Mirrors
Inside rear view mirror ....................... 42
Side mirror heater............................... 178
Side mirrors.............................................. 43
Vanity mirrors ..................................... 220
Moon roof................................................... 48
MP3 disc........................................................ 195
Multi-information display........................118
Odometer ................................................ 109
Oil
Engine oil................................................ 272
Opener
Fuel filler door .......................................... 51
Hood ....................................................... 266
Trunk............................................................ 23
Outer foot lights
Outer foot lights................................. 209
Wattage ................................................. 394
Outside rear view mirrors
Adjusting and folding .......................... 43
Driving position memory ..................28
Outside temperature display ............. 119
Overhead console .................................215
Overhead courtesy lights
Overhead courtesy lights ............. 209
Wattage ................................................. 394
Overheating, Engine..............................375
Parking assist sensors........................... 142
Parking brake.......................................... 108K
L
M
O
P

422
Alphabetical index
Shift lever lighting .................................209
Shift lock system .................................... 367
Shopping bag hooks............................238
Side airbags................................................. 61
Side marker lights
Switch ........................................................ 122
Side mirror
Adjusting and folding ......................... 43
Driving position memory.................. 28
Smart access system with
push-button start
Entry function..............................................4
Starting the engine ............................... 98
Spare tire
Inflation pressure................................ 293
Spare tire................................................358
Spark plug ............................................... 385
Specifications ........................................ 380
Speedometer
Speed indicator ................................... 109
Speedometer........................................ 109
Steering wheel
Audio switches ................................... 207
Driving position memory.................. 28
Manual adjustment .............................. 40
Power adjustment .................................. 41
Storage feature....................................... 213
Stuck
If your vehicle becomes stuck......377
Sun visors .................................................. 219
Sunshade
Rear .......................................................... 233
Roof ............................................................. 49
Switch
ECT switch .............................................102
Engine switch.......................................... 98
ETCS switch.......................................... 105Fog light switch .................................... 125
Light switches.........................................122
Power door lock switch...................... 19
Power window switch ........................45
Satellite switches................................. 222
Transmission shift switches ............ 103
Window lock switch ............................45
Wipers and washer switch............. 126
Tachometer
Tacho indicator ....................................109
Tachometer............................................ 109
Tail lights
Switch .........................................................122
Theft deterrent system
Alarm.......................................................... 56
Engine immobilizer system ..............54
Theft prevention labels.......................... 58
Tire inflation pressure ......................... 293
Tire information
Glossary ................................................ 403
Size ........................................................... 400
Tire identification number ............. 399
Uniform tire quality grading........... 401
Tires
Chains......................................................... 161
Checking............................................... 283
If you have a flat tire ......................... 358
Inflation pressure ................................293
Inflation pressure sensor ............... 284
Information ........................................... 398
Replacing .............................................. 358
Rotating tires........................................ 283
Size ........................................................... 389
Snow tires.................................................. 161
Tools...........................................................358
T

423
Alphabetical index
Total load capacity................................. 160
Towing
Dinghy towing.............................166, 167
Emergency towing ........................... 328
Trailer towing.........................................165
TRAC (Traction control) .................... 148
Traction control (TRAC) .................... 148
Transmission shift switches..................103
Trip meter..................................................109
Trunk
Extending a space ............................ 235
Opener.......................................................23
Trunk light
Trunk light ................................................. 24
Wattage ................................................. 394
Turn signal lights
Replacing light bulbs ......................... 319
Switch ........................................................ 107
Wattage ................................................. 394
Vanity lights
Vanity lights .......................................... 220
Wattage ................................................. 394
Vanity mirrors........................................... 220
VDIM (Vehicle dynamics
integrated management)................. 148
Vehicle dynamics integrated
management (VDIM) ....................... 148
Vehicle identification number ..........381
Vehicle stability control (VSC) ........ 148
Ventilators............................................... 230
VSC (Vehicle stability control) ........ 148Warning buzzers
Brake system........................................339
Open door ............................................ 341
Seat belt reminder ............................ 340
Warning lights
Anti-lock brake system (ABS) ... 340
Brake assist system .......................... 340
Brake system........................................339
Charging system............................... 340
Electric power steering
warning light .................................... 340
Electronic engine control
system ................................................. 340
Low fuel level ........................................ 341
Low tire pressure warning
light ......................................................... 341
Master warning light.......................... 341
Open door ............................................. 341
Pre-collision system......................... 340
Pretensioners ...................................... 340
Seat belt reminder light.................... 341
SRS airbags.......................................... 340
Warning messages
AWD system .......................................345
Dynamic radar
cruise control....................... 345, 349
Engine oil level ....................................349
Engine oil maintenance ..................349
Engine oil pressure ...........................344
Hill-start assist control .................... 348
Hood ........................................................349
Lexus parking assist
sensor ...................................... 345, 349
Moon roof .............................................349
Open door ............................................349
Parking brake ......................................349
Pre-collision system............. 345, 349
V
W
