400
5-2. Steps to take in an emergency
If your vehicle overheats
If your engine overheats:
Stop the vehicle in a safe place and turn off the automatic air
conditioning system.
Check to see if steam is coming out from under the hood.
If you see steam: Stop the engine and car efully lift the hood.
If you do not see steam: Leave the engine running and carefully lift the hood.
Remove the engine compartment cover. ( P. 2 9 4 )
Check to see if the cooling fan is operating.
If the fan is operating: Wait until the temperature of the engine (shown on the
instrument cluster) begins to fall and then stop the engine.
If the fan is not operating: Stop the engine immediately and call your local Lexus
dealer.
After the engine has cooled
down sufficiently, check the
engine coolant level and inspect
the radiator core (radiator) for
any leaks.STEP1
STEP2
STEP3
STEP4
STEP5

5
When trouble arises
401
5-2. Steps to take in an emergency
■Overheating
If you observe the following, your vehicle may be overheating.
●The engine coolant temperature gauge enters the red zone or a loss of power is
experienced.
●Steam is coming from under the hood.
CAUTION
■To prevent an accident or injury when in specting under the hood of your vehicle
●Keep hands and clothing away from the fan and other belts while the engine is
running.
●Do not loosen the radiator cap while the engine and radiator are hot.
Serious injury, such as burns, may result from hot coolant and steam released
under pressure.
NOTICE
■When adding engine coolant
Wait until the engine has cooled do wn before adding engine coolant.
When adding coolant, do so slowly. Adding cool coolant to a hot engine too quickly
can cause damage to the engine.
Add engine coolant if required.
Water can be used in an emer-
gency measure if engine coolant
is unavailable. ( P. 411)
Have the vehicle checked at your nearest Lexus dealer as soon as pos-
sible.
STEP6

411
6-1. Specifications
6
Vehicle specifications
Cooling system
Ignition system
Capacity9.6 q t .
(9.1 L, 8.0 lmp.qt.)
Coolant type
Use either of the following.• “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-based non-sili- cate, non-amine, non-nitrite, and non-borate cool-
ant with long-life hybrid organic acid technology
Do not use plain water alone.
Spark plug
Make
GapDENSO FK20HBR11
0.043 in. (1.1 mm)
NOTICE
■Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust gap when tuning engine.

429
6-1. Specifications
6
Vehicle specifications
■Temperature A, B, C
The temperature grades are A (the hi ghest), B, and C, representing
the tire's resistance to the generation of heat and its ability to dissipate
heat when tested under controlled conditions on a specified indoor
laboratory test wheel.
Sustained high temperature can cause the material of the tire to degenerate
and reduce tire life, and excessive temperature can lead to sudden tire fail-
ure.
The grade C corresponds to a level of performance which all passenger car
tires must meet under the Federal Mo tor Vehicle Safety Standard No. 109.
Grades B and A represent higher levels of performance on the laboratory
test wheel than the minimum required by law.
Warning: The temperature grades for this tire are established for a tire that
is properly inflated and not overloaded.
Excessive speed, underinflation, or excess ive loading, either separately or in
combination, can cause heat build up and possible tire failure.
Glossary of tire terminology
Tire related termMeaning
Accessory weight
The combined weight (in excess of those standard
items which may be replaced) of automatic transmis-
sion, power steering, power brakes, power windows,
power seats, radio and heater, to the extent that these
items are available as factory-installed equipment
(whether installed or not)
Cold tire inflation pres-
sureTire pressure when the vehicle has been parked for
three hours or more, or has not been driven more
than 1 mile or 1.5 km under that condition
Curb weight
The weight of a motor vehicle with standard equip-
ment, including the maximum capacity of fuel, oil and
coolant, and if so equipped, air conditioning and
additional weight optional engine

453
Alphabetical index
Electric power steering ....................... 170
Electronic keyIf the electronic key does not operate properly ............................ 394
Emergency, in case of If the engine will not start ................. 391
If the shift lever cannot be shifted from P ................................... 392
If the vehicle has discharged battery.................................................. 397
If the warning buzzer sounds...... 360
If the warning light turns on .......... 360
If the warning message is displayed ............................................ 369
If you have a flat tire ........................ 382
If you lose your keys ........................ 393
If you think something is wrong................................................... 356
If the electronic key does not operate properly ............................ 394
If your vehicle becomes stuck .... 402
If your vehicle needs to be towed ...................................................350
If your vehicle overheats................400 Engine
Compartment...................................... 292
Engine switch .......................................... 117
Hood ....................................................... 289
How to start the engine ..................... 117
Identification number .......................407
If the engine will not start................. 391
Ignition switch ......................................... 117
Overheating ........................................ 400
Engine compartment cover ............. 294
Engine coolant Capacity .................................................... 411
Checking ...............................................299
Preparing and checking before winter ..................................... 183
Engine coolant temperature gauge....................................................... 130
Engine immobilizer system.................. 72
Engine oil Capacity .................................................. 410
Checking ...............................................295
Preparing and checking before winter ..................................... 183
Engine oil maintenance data............298
EPS .............................................................. 170
Event data recorder ........................... 358E

462
What to do if...
What to do if...
A tire puncturesP. 3 8 2If you have a flat tire
The engine does not start
P. 3 9 1If the engine will not start
P. 7 2Engine immobilizer system
P. 3 9 4If the vehicle battery is discharged
The shift lever cannot be
moved outP. 3 9 2If the shift lever cannot be shifted
from P
The engine coolant temperature
gauge enters the red zone
Steam can be seen coming
from under the hood
P. 4 0 0If your vehicle overheats
The key is lostP. 3 9 3If you lose your keys
The battery runs outP. 3 9 7If the vehicle battery is discharged
The doors cannot be lockedP. 3 7Doors
The horn begins to soundP. 74Alarm
The vehicle is stuck in mud or
sandP. 4 0 2If the vehicle becomes stuck
