5
When trouble arises
453
5-1. Essential information
Installing towing eyeletsRemove the eyelet cover using a
flathead screwdriver.
To protect the bodywork, place a
rag between the screwdriver and
the vehicle body, as shown in the
illustration.
Insert the towing eyelet into the
hole and tighten partially by hand.
Tighten down the towing eyelet
securely using a wheel nut wrench.
STEP1
STEP2
STEP3
■Location of the emergency towing eyelet
P. 4 8 1

454
5-1. Essential information
Towing with a sling-type truck
CAUTION
■Installing towing eyelets to the vehicle
Make sure that towing eyelets are installed securely.
If not securely installed, towing eyelets may come loose during towing. This may
lead to accidents that cause serious injury or even death.
NOTICE
■To prevent body damage
Do not tow with a sling type truck, either from the front or rear.

5
When trouble arises
455
5-1. Essential information
Towing with a wheel lift-type truckFrom the front Vehicles with an automatic trans-
mission: Use a towing dolly under
the rear wheels.
Vehicles with a manual transmis-
sion: We recommend to use a tow-
ing dolly under the rear wheels.
When not using a towing dolly,
release the parking brake and shift
the shift lever to N.
From the rear (2WD models)Switch to ACCESSORY mode so
that the steering wheel is
unlocked.
From the rear (AWD models) Use a towing dolly under the front
wheels.

456
5-1. Essential information
Using a flat bed truckIf your Lexus is transported by a
flat bed truck, it should be tied
down at the locations shown in the
illustration.
If you use chains or cables to tie
down your vehicle, the angles
shaded in black must be 45 .
Do not overly tighten the tie downs
or the vehicle may be damaged.
NOTICE
■To prevent causing serious damage to the transmission
(vehicles with an automatic transmission)
Never tow this vehicle from the front with the rear wheels on the ground.
■To prevent damaging the vehicle
●Do not tow the vehicle from the rear with the “ENGINE START STOP” switch
OFF.
The steering lock mechanism is not st rong enough to hold the front wheels
straight.
●When raising the vehicle from the rear, ensure adequate ground clearance for
towing at the opposite end of the raised vehicle. Without adequate clearance, the
vehicle could be damaged while being towed from the rear.

5
When trouble arises
481
5-2. Steps to take in an emergency
If you have a flat tire
Remove the flat tire and replace it with the spare provided.
■Before jacking up the vehicle
●Stop the vehicle on a hard, flat surface.
● Set the parking brake.
● Shift the shift lever to P (vehicle s with an automatic transmission)
or R (vehicles with a manual transmission).
● Stop the engine.
● Turn on the emergency flashers.
■ Location of the spare tire, jack and tools
Tool bag
(including towing eyelet) Jack
Jack handle
Spare tire
Ti g h t e nLoosen

5
When trouble arises
485
5-2. Steps to take in an emergency
Install the spare tire and loosely
tighten each nut by hand to
approximately the same amount.
Tighten the wheel nuts until the
tapered portion comes into loose
contact with the disc wheel seat.
Lower the vehicle.
Firmly tighten each nut two or
three times in the order shown in
the illustration.
Tightening torque:
76 ft•lbf (103 N•m, 10.5 kgf•m)
Stow the flat tire, tire jack and all tools.
STEP2
Disc wheel
seat
Tapered portion
STEP3
STEP4
STEP5

5
When trouble arises
505
5-2. Steps to take in an emergency
NOTICE
■To avoid damaging the transmission and other components
●Avoid spinning the wheels and do not rev the engine.
●If the vehicle remains stuck after trying these procedures, the vehicle may require
towing to be freed.

566
Alphabetical index
Cruise control ......................................... 175
Cup holder .............................................. 322
Curtain shield airbags............................ 93
Customizable features ...................... 540
Daytime running light system ........... 166
DefoggerRear window .......................................... 214
Side mirror .............................................. 214
Dimension ............................................... 508
Dinghy towing ............................. 200, 201
Display Satellite switch mode ....................... 329
Trip information ..................................... 161
Warning message............................. 470
Do-it-yourself maintenance ............ 380
Door courtesy lights Door courtesy lights...........................315
Wattage.................................................. 524
Door pockets.......................................... 324
Doors Door lock................................ 28, 40, 43
Door windows ....................................... 75
Side mirrors .............................................. 72
Driver's seat belt reminder light .....463
Driving Correct posture ...................................... 91
Procedures ............................................. 124
Driving position memory ...................... 53 Electric power steering....................... 185
Electronic key
If the electronic key does not operate properly............................ 494
Emergency, in case of If the engine will not start ............... 490
If the shift lever cannot be shifted from P....................................492
If the vehicle has a discharged battery ................................................. 498
If the warning buzzer sounds........ 461
If the warning light turns on............ 461
If a warning message is displayed ............................................ 470
If you have a flat tire .......................... 481
If you lose your keys ........................ 493
If you think something is wrong ...................................................457
If the electronic key does not operate properly............................ 494
If your vehicle becomes stuck .... 504
If your vehicle has to be stopped in an emergency ............................ 506
If your vehicle needs to be towed ..................................................... 451
If your vehicle overheats..................501
Emergency flashers Switch ...................................................... 450
Engine Compartment ..................................... 386
Engine switch ........................................ 134
Hood ....................................................... 383
How to start the engine ................... 134
Identification number ...................... 509
If the engine will not start ............... 490
Ignition switch ....................................... 134
Overheating ..........................................501
D
E

572
Alphabetical index
TachometerTacho indicator...................................... 151
Tachometer ............................................. 151
Tail lights Switch ....................................................... 165
Talk switch ...............................................289
Telephone switch ................................. 288
Theft deterrent system Alarm .......................................................... 87
Engine immobilizer system ............. 85
Theft prevention labels ..........................90
Tire inflation pressure .......................... 412
Tire information Glossary................................................. 533
Size ...........................................................530
Tire identification number .............530
Uniform tire quality grading ...........531
Tires Chains ...................................................... 195
Checking .............................................. 400
If you have a flat tire ........................... 481
Inflation pressure.................................. 412
Inflation pressure sensor................ 402
Information............................................528
Replacing ................................................ 481
Rotating tires ....................................... 400
Size ............................................................ 519
Snow tires ............................................... 195
Tools ............................................................ 481
Total load capacity ................................ 194 Towing
Dinghy towing ......................... 200, 201
Emergency towing ............................. 451
Trailer towing ........................................ 199
TRAC ......................................................... 185
Traction control...................................... 185
Transmission shift switches.................142
Trip meter ................................................... 151
Trunk Extending trunk space.....................344
Opener ...................................................... 47
Trunk light Trunk light ................................................ 48
Wattage ................................................. 524
Turn signal lights Replacing light bulbs ....................... 439
Switch ........................................................ 147
Wattage ................................................. 524
USB port ...................................................... 250
Vanity lights Vanity lights........................................... 327
Wattage ................................................. 524
Vanity mirrors ........................................ 327
VDIM.......................................................... 185
Vehicle dynamics integrated management ........................................ 185
Vehicle identification number.........509
Vehicle stability control ...................... 185
Ventilators ............................................... 338
Voice command switch .....................288
VSC ............................................................ 185T
U
V
