179
2-4. Using other driving systems
2
When driving
Intuitive parking assist
The distance to obstacles measured by the sensors is communicated via
the multi-information display and a buzzer when parallel parking or
maneuvering into a garage. Always check the surrounding area when
using this system.
With navigation system
For vehicles equipped with a navigation system, refer to the separate “Navi-
gation System Owner’s Manual” for further details.
Without navigation system
■ Types of sensors
Front corner sensors
Rear corner sensors
Back sensors
■ Multi-information display ( P. 1 6 0 )
Front corner sensor opera-
tion
Rear corner sensor operation
Back sensor operation

: If equipped

180
2-4. Using other driving systems
The distance display and buzzerWhen a sensor detects an obstacle, the direction of and the approximate
distance to the obstacle are di splayed and the buzzer sounds.
■ Front corner sensors
Multi-information
displayApproximate distance to obstacleBuzzer
1.6 to 1.3 ft.
(50 to 40 cm)Medium
1.3 to 1.0 ft.
(40 to 30 cm)Fast
1.0 ft. (30 cm) or lessContinuous
■ Intuitive parking assist switch ( P. 3 2 9 )
When on, an indicator is dis-
played to inform the driver that
the function is operational.

183
2-4. Using other driving systems
2
When driving
■Sensor detection information
●Certain vehicle conditions and the surrounding environment may affect the
ability of the sensor to correctly detect obstacles. Particular instances where this
may occur are listed below.
• There is dirt, snow or ice on the sensor.
• The sensor is frozen.
• The sensor is covered in any way.
• The vehicle is leaning considerably to one side.
• On an extremely bumpy road, on an incline, on gravel, or on grass.
• The vicinity of the vehicle is noisy due to vehicle horns, motorcycle engines,
air brakes of large vehicles, or other loud noises producing ultrasonic waves.
• There is another vehicle equipped with parking assist sensors in the vicinity.
• The sensor is coated with a sheet of spray or heavy rain.
• The vehicle is equipped with a fender pole or wireless antenna.
• Towing eyelets are installed.
• The bumper or sensor receives a strong impact.
• The vehicle is approaching a tall or curved curb.
• In harsh sunlight or intense cold weather.
In addition to the examples above, there are instances in which, because of their
shapes, signs and other object s may be judged by the sensor to be closer than they
are.
●The shape of the obstacle may prevent th e sensor from detecting it. Pay particu-
lar attention to the following obstacles.
• Wires, fences, ropes etc.
• Cotton, snow and other materials that absorb radio waves
• Sharply-angled objects
•Low obstacles
• Tall obstacles with upper sections projec ting outwards in the direction of your
vehicle
■When the display flashes and a message is displayed
 P. 4 7 0

565
Alphabetical index
Bluetooth® phone ............................... 284
Brake Fluid .......................................................... 394
Parking brake ........................................148
Brake assist ...............................................185
Care Exterior ................................................... 368
Interior....................................................... 371
Seat belts ................................................372
Cargo capacity ........................................ 191
Cargo hooks ...........................................347
CD changer ............................................ 227
CD player................................................. 227
Chains ......................................................... 195
Child restraint system Booster seats, definition...................109
Booster seats, installation ..................116
Convertible seats, definition ..........109
Convertible seats, installation .........116
Front passenger occupant classification system .......................104
Infant seats, definition ........................109
Infant seats, installation........................116
Installing CRS with LATCH anchors ................................................... 114
Installing CRS with seat belts ..........116
Installing CRS with top straps .........119 Child safety
Airbag precautions ..............................99
Battery precautions ............ 398, 500
Child restraint system ....................... 109
Child-protectors ................................... 44
How your child should wear the seat belt .......................................... 63
Installing child restraints..................... 113
Moon roof precautions....................... 81
Power window lock switch .............. 75
Power window precautions .............77
Removed electronic key battery precautions ....................... 422
Seat belt comfort guide .......................61
Seat belt extender precautions......65
Seat belt precautions .......................... 64
Seat heater precautions..... 337, 340
Trunk precautions................................. 49
Child-protectors ...................................... 44
Cigarette lighter....................................333
Cleaning Exterior................................................... 368
Interior .......................................................371
Seat belts ................................................ 372
Clock .........................................................328
Coat hooks ..............................................345
Compass ..................................................356
Condenser .............................................. 394
Console box ...........................................320
Cooling system Engine overheating............................ 501
Cornering assist sensors .....................179
C

570
Alphabetical index
Parking assist sensors .......................... 179
Parking brake .......................................... 148
Parking lightsReplacing light bulbs........................ 439
Switch ....................................................... 165
Wattage.................................................. 524
Personal lights Switch ........................................................ 317
Power outlet............................................334
Power windows ........................................ 75
Radiator ....................................................394
Radio ........................................................... 219
RDS ............................................................. 221
Rear sunshade ....................................... 342
Rear turn signal lights Replacing light bulbs........................ 439
Wattage.................................................. 524
Rear view mirror Compass ...............................................356
Rear window defogger........................ 214
Replacing Electronic key battery........................ 421
Fuses ........................................................ 423
Light bulbs............................................. 439
Reporting safety defects for U.S. owners ......................................... 548 Safety Connect ..................................... 360
Scuff lights................................................. 315
Seat belts
Adjusting the seat belt ......................... 61
Automatic locking retractor ............ 62
Child restraint system installation .............................................. 113
Cleaning and maintaining the seat belts ..................................... 372
Emergency locking retractor.......... 62
How to wear your seat belt ............ 60
How your child should wear the seat belt...........................................63
Pregnant women, proper seat belt use ......................... 62
Reminder light..................................... 463
Seat belt extenders...............................63
Seat belt pretensioners ....................... 61
Seat heaters ................................ 335, 338
Seat ventilators ...................................... 338
Seating capacity......................................194
Seats Adjustment ................................................ 51
Adjustment precautions ....................52
Child seats/child restraint system installation.............................. 113
Cleaning .................................................. 371
Driver’s seat position memory .......53
Head restraint ......................................... 57
Properly sitting in the seat.................. 91
Seat heaters .............................335, 338
Ventilated seats.................................. 338
Service reminder indicators .............157P
