Lexus IS250 2014 Map database information and updates / LEXUS 2014 IS250,IS350 OWNERS MANUAL (OM53758U)

5309-2. Customization
IS350/250_U (OM53758U)
■Tu r n s i g n a l l e v e r ( P. 1 7 0 )
*1: After flashing the turn signal lights when turn ing left or right while this function is off
and the turn signal lever is moved to the fi rst position in the direction of the flashing
light, the turn signal lights can be selected to be flashing or off.
*2: The turn signal lights keep flashing if the tu rn signal lever is moved to the first position
in the direction of flashing light.
*3: The turn signal lights will be off if the turn signal lever is moved to the first position in
the direction of flashing light.
■Automatic light control system ( P. 1 7 3 )
FunctionDefault settingCustomized setting
The number of times the
turn signal lights flash auto-
matically when the turn sig-
nal lever is moved to the first
position during a lane
change
*1
3
5
——O7
Off*2
Off*3
123
FunctionDefault settingCustomized setting
Light sensor sensitivityStandard-2 to 2O—O
Time elapsed before head-
lights automatically turn off
after doors are closed
30 seconds
Off
O—O60 seconds
90 seconds
Welcome light illumination
controlOnOff——O
123

5319-2. Customization
9
Vehicle specifications
IS350/250_U (OM53758U)
■Lights (P. 1 7 3 )
*: U.S.A. only
■Intuitive parking assist*1 ( P. 2 1 4 )
*1: If equipped
*2: When intuitive parking assist is operating.
■Automatic air conditioning system ( P. 3 4 6 )
FunctionDefault settingCustomized setting
Daytime running light sys-
tem*OnOffO—O
123
FunctionDefault settingCustomized setting
Detection distance of the
front center sensorFarNearO—O
Detection distance of the
rear center sensorFarNearO—O
Buzzer volume31 to 5O—O
Display setting*2All sensors dis-
playedDisplay offO—O
123
FunctionDefault settingCustomized setting
A/C Auto switch operationOnOffO—O
123

5329-2. Customization
IS350/250_U (OM53758U)
■Illumination ( P. 3 5 6 )
■Seat belt reminder ( P. 4 5 6 )
FunctionDefault settingCustomized setting
Time elapsed before the
interior lights turn off15 seconds
Off
O—O7. 5 s e c o n d s
30 seconds
Operation after the engine
switch is turned offOnOff——O
Operation when the doors
are unlockedOnOff——O
Operation when you
approach the vehicle with
the electronic key on your
person
OnOff——O
Inside door handle lightsOnOff——O
Time elapsed before the
outer foot lights turn off15 seconds
Off
O—O7. 5 s e c o n d s
30 seconds
Operation of the outer foot
lights when you approach
the vehicle with the elec-
tronic key on your person
OnOff——O
Operation of the outer foot
lights when the doors are
unlocked with the power
door lock switch
OnOff——O
123
FunctionDefault settingCustomized setting
Vehicle speed linked seat
belt reminder buzzerOnOff——O
123

5339-2. Customization
9
Vehicle specifications
IS350/250_U (OM53758U)
■Vehicle customization
●When the smart access system with push-button start is off, the entry unlock function
cannot be customized.
●When the doors remain closed after unlocking the doors and the timer activated auto-
matic door lock function activates, signals will be generated in accordance with the
operation buzzer volume and operational si gnal (Emergency flashers) function set-
tings.
■When customizing using the Remote Touch or Lexus Display Audio controller
Stop the vehicle in a safe place, apply the parking brake, and shift the shift lever to P. Also,
to prevent battery discharge, leave the engi ne running while customizing the features.
CAUTION
■During customization
As the engine needs to be running during customization, ensure that the vehicle is
parked in a place with adequate ventilation. In a closed area such as a garage, exhaust
gases including harmful carbon monoxide (CO) may collect and enter the vehicle. This
may lead to death or a serious health hazard.
NOTICE
■During customization
To prevent battery discharge, ensure that the engine is running while customizing fea-
tures.

534
IS350/250_U (OM53758U)9-3. Items to initialize
Items to initialize
The following items must be initialized for normal system operation after such
cases as the battery being reconnecte
d, or maintenance being performed on
the vehicle:
ItemWhen to initializeReference
Maintenance data• After the maintenance is per- formedP. 3 9 1
Tire pressure warning system
• When rotating the tires
• When changing the tire inflation
pressure by changing traveling
speed or load weight, etc.
P. 4 1 3

535
For owners10
IS350/250_U (OM53758U)
Reporting safety defects for U.S. owners ............................................ 536
Seat belt instructions for Canadian owners (in French) ........ 537
SRS airbag instructions for Canadian owners (in French) ........538

536
IS350/250_U (OM53758U)
Reporting safety defects for U.S. owners
If you believe that your vehicle has a defect which could cause a crash or could
cause injury or death, you should immediately inform the National Highway
Traffic Safety Administration (NHTSA) in addition to notifying the Lexus Divi-
sion of Toyota Motor Sales, U.S.A. , Inc. (Toll-free: 1-800-25-LEXUS).
If NHTSA receives similar complaints, it may open an investigation, and if it
finds that a safety defect exists in a gr oup of vehicles, it may order a recall and
remedy campaign. However, NHTSA cannot become involved in individual
problems between you, your dealer, or Lexus Division of Toyota Motor Sales,
U.S.A., Inc.
To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at
1-888-327-4236 (TTY: 1-800-424-9153); go to
http://www.safercar.gov ; or
write to: Administrator, NHTSA, 1200 New Jersey Ave, S.E., Washington, DC
20590. You can also obtain other information about motor vehicle safety from
http://www.safercar.gov.

537
For owners
IS350/250_U (OM53758U)
●Déroulez la sangle diagonale de
telle sorte qu’elle passe bien sur
l’épaule, sans pour autant être en
contact avec le cou ou glisser de
l’épaule.
●Placez la sangle abdominale le plus
bas possible sur les hanches.
●Réglez la position du dossier de
siège. Asseyez-vous le dos le plus
droit possible et calez-vous bien
dans le siège.
●Ne vrillez pas la ceinture de sécu-
rité.
■Ceintures de sécurité
Nettoyez avec un chiffon ou une éponge humectée d’eau savonneuse tiède.
Vérifiez régulièrement que les ceinture s ne sont pas effilochées, entaillées ou
exagérément usées.
Seat belt instructions for Canadian owners (in
French)
The following is a French explanation of seat belt instructions extracted from
the seat belt section in this manual.
See the seat belt section for more deta iled seat belt instructions in English.
Utilisation correcte des ceintures de sécurité
Entretien et soin
ATTENTION
■Détérioration et usure des ceintures de sécurité
Inspectez les ceintures de sécurité périod iquement. Contrôlez qu’elles ne sont pas
entaillées, effilochées et que leurs ancrages ne sont pas desserrés. N’utilisez pas une
ceinture de sécurité défectueuse avant qu’elle ne soit remplacée. Une ceinture de
sécurité défectueuse n’apporte aucune garant ie de protection de l’occupant en cas
d’accident.

538
IS350/250_U (OM53758U)
◆Airbags SRS frontaux
L’airbag SRS conducteur/l’airbag du passager avant
Participent à la protection de la tête et du thorax du conducteur et du passa-
ger avant contre les chocs contre les éléments de l’habitacle
Les airbags SRS de genoux
Participent à la protection du co nducteur et du passager avant
SRS airbag instructions for Canadian owners (in
French)
The following is a French explanation of SRS airbag instructions extracted
from the SRS airbag section in this manual.
See the SRS airbag section for more detailed SRS airbag instructions in
English.
1
2

539
For owners
IS350/250_U (OM53758U)
◆Airbags SRS latéraux et rideaux
Airbags SRS latéraux avant
Peuvent aider à protéger le torse des passagers avant
Airbags SRS latéraux arrière (sur modèles équipés)
Participent à la protection du haut du corps des occupants assis aux places
arrière extérieures
Airbags SRS rideaux
Participent principalement à la protection de la tête des occupants assis aux
places extérieures
3
4
