TABLE OF CONTENTS2
IS350/250_U (OM53C50U)
For your information ................................... 8
Reading this manual................................... 12
How to search ..............................................13
Pictorial index ............................................... 14
1-1. For safe useBefore driving................................. 26
For safety drive............................... 28
Seat belts .......................................... 30
SRS airbags ..................................... 36
Front passenger occupant classification system...................47
Safety information for children ................................... 53
Child restraint systems ............... 54
Installing child restraints............. 58
Exhaust gas precautions ............ 68
1-2. Theft deterrent system Engine immobilizer system....... 69
Alarm ................................................... 71
Theft prevention labels ................73
2. Instrument cluster Warning lights and indicators........................................ 76
Gauges and meters .......................81
Multi-information display .......... 86
Fuel consumption information ................................... 92 3-1. Key information
Keys .................................................... 98
3-2. Opening, closing and locking the doors and trunk
Doors ............................................... 103
Trunk................................................. 109
Smart access system with push-button start ....................... 114
3-3. Adjusting the seats Front seats.......................................120
Rear seats......................................... 121
Driving position memory..........123
Head restraints .............................128
3-4. Adjusting the steering wheel and mirrors
Steering wheel ............................... 131
Inside rear view mirror ..............133
Outside rear view mirrors........135
3-5. Opening, closing the windows and moon roof
Power windows............................ 138
Moon roof ........................................ 141
1For safety and security
2Instrument cluster
3Operation of each
component

14
IS350/250_U (OM53C50U)Pictorial index
Pictorial index
■Exterior
The shape of the headlights may differ depending on the grade, etc. (
P. 4 4 5 )
Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 103
Locking/unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 103
Opening/closing the door glasses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 138
Locking/unlocking by using the mechanical key. . . . . . . . . . . . . . . . . . . . . . . . .P. 499
Warning lights/warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 467, 474
Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 109
Opening from inside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 1 09
Opening from outside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 109
Opening by using the mechanical key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 499
Warning lights/warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 467, 474
Outside rear view mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 135
Adjusting the mirror angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 135
Folding the mirrors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 1 3 5
Driving position memory
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 123
Defogging the mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 362
1
2
3

19Pictorial index
IS350/250_U (OM53C50U)
Driving position memory switches*1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 123
Outside rear view mirror switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 135
Door lock switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 105
Power window switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 138
Window lock switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 138
Tire pressure warning reset switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 425
PCS OFF switch
*1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 247
*1: If equipped
*2: For vehicles with a navigation system, refer to “NAVIGATION SYSTEM OWNER’S MANUAL”.
1
2
3
4
5
6
7

23Pictorial index
IS350/250_U (OM53C50U)
Inside rear view mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 133
Sun visors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 377
Vanity mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P . 377
Interior light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 369
Pe r s o n a l l i g h t s
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 369
Moon roof switches
*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 141
“SOS” button
*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 390
Garage door opener switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 382
*1: The illustration shows the front, but they are also equipped in the rear.
*2: If equipped
1
2
3
4
5
6
7

291-1. For safe use
1
For safety and security
IS350/250_U (OM53C50U)
Make sure that you can see backward clearly by adjusting the inside and outside
rear view mirrors properly. ( P. 133, 135)
Adjusting the mirrors
CAUTION
Observe the following precautions.
Failure to do so may result in death or serious injury.
●Do not adjust the position of the driver’s seat while driving.
Doing so could cause the driver to lose control of the vehicle.
●Do not place a cushion between the driver or passenger and the seatback.
A cushion may prevent correct posture from being achieved, and reduce the effec-
tiveness of the seat belt and head restraint.
●Do not place anything under the front seats.
Objects placed under the front seats may be come jammed in the seat tracks and stop
the seat from locking in place. This may lead to an accident and the adjustment mech-
anism may also be damaged.
●When driving over long distances, take regular breaks before you start to feel tired.
Also, if you feel tired or sleepy while drivin g, do not force yourself to continue driving
and take a break immediately.

782. Instrument cluster
IS350/250_U (OM53C50U)
*1: These lights turn on when the engine switch is turned to IGNITION ON mode to indicate that a system check is being perfor med. They will turn off after the engine is
on, or after a few seconds. There may be a ma lfunction in a system if the lights do not
come on, or turn off. Have the vehi cle inspected by your Lexus dealer.
*2: The light flashes to indicate a malfunction.
The indicators inform the driver of the operating state of the vehicle’s various sys-
tems.
Indicators
Turn signal indicator
( P. 1 7 0 )
(if equipped)
LDA (Lane Departure
Alert) indicator ( P. 2 0 8 )
(U.S.A.)
Headlight indicator
( P. 1 7 3 )

(if equipped)
Intuitive parking assist indi-
cator ( P. 2 1 4 )
(Canada)
Tail light indicator
( P. 1 7 3 ) *1, 2 Slip indicator ( P. 2 4 1 )
Headlight high beam indi-
cator ( P. 1 74 )
*1VSC OFF indicator
( P. 2 4 2 )
(if equipped)
Automatic High Beam indi-
cator ( P. 1 76 )*1, 3
(if equipped)
Pre-collision system warn-
ing light
( P. 2 4 7 )
(if equipped)
Fog light indicator
( P. 1 8 1 )*4, 5
(if equipped)
BSM (Blind Spot Monitor)
outside rear view mirror
indicators ( P. 252)
Cruise control indicator
(  P. 192, 196)
*6Security indicator
( P. 6 9 , 7 1 )
(if equipped)
Dynamic radar cruise con-
trol indicator ( P. 1 9 6 )*7Low outside temperature
indicator ( P. 8 1 )
Cruise control “SET” indica-
tor ( P. 192, 196)
*1Eco Driving Indicator Light
( P. 9 0 )

792. Instrument cluster
2
Instrument cluster
IS350/250_U (OM53C50U)
*1: These lights turn on when the engine switch is turned to IGNITION ON mode toindicate that a system check is being perfor med. They will turn off after the engine is
on, or after a few seconds. There may be a ma lfunction in a system if the lights do not
come on, or turn off. Have the vehi cle inspected by your Lexus dealer.
*2: The light flashes to indicate that the system is operating.
*3: The light comes on when the system is turned off. The light flashes faster than usual to
indicate that the system is operating.
*4: In order to confirm operation, the BSM outside rear view mirror indicators illuminatein the following situations:
• When the engine switch is turned to IGNITION ON mode while the BSM main
switch is set to ON.
• When the BSM main switch is set to ON while the engine switch is in IGNITION
ON mode.
If the system is functioning correctly, the BSM outside rear view mirror indicators will
turn off after a few seconds.
If the BSM outside rear view mirror indica tors do not illuminate or do not turn off,
there may be a malfunction in the system.
If this occurs, have the vehicle inspected by your Lexus dealer.
*5: This light illuminates on the outside rear view mirrors.
*6: This light illuminates on the center panel.
*7: When the outside temperature is approximately 37 F (3 C) or lower, the indicator
will flash for approximately 10 seconds, then stay on.
*8:Except F SPORT models
*9:F SPORT models
*8Eco drive mode indicator
( P. 2 3 7 )*9
(if equipped)
“SPORT S+” indicator
( P. 2 3 7 )
*9Eco drive mode indicator
( P. 2 3 7 )*8Snow mode indicator
( P. 1 6 5 )
*8“SPORT” indicator
( P. 2 3 7 )*9Snow mode indicator
( P. 1 6 5 )
*9
(if equipped)
“SPORT” indicator
( P. 2 3 7 )*1, 6“AIR BAG ON/OFF”
indicator ( P. 4 7 )
*9
(if equipped)
“SPORT S” indicator
( P. 2 3 7 )

97
Operation of
each component
3
IS350/250_U (OM53C50U)
3-1. Key information
Keys ....................................................98
3-2. Opening, closing and locking the doors and trunk
Doors ............................................... 103
Trunk ................................................. 109
Smart access system with push-button start........................ 114
3-3. Adjusting the seats Front seats ...................................... 120
Rear seats ......................................... 121
Driving position memory ......... 123
Head restraints ............................ 128
3-4. Adjusting the steering wheel and mirrors
Steering wheel ............................... 131
Inside rear view mirror.............. 133
Outside rear view mirrors ....... 135
3-5. Opening, closing the windows and moon roof
Power windows ............................ 138
Moon roof ........................................ 141

1233-3. Adjusting the seats
3
Operation of each component
IS350/250_U (OM53C50U)
The seat and steering wheel are automatically adjusted to allow the driver to
enter and exit the vehicle easily.
When all of the following have been
performed, the driver’s seat and steer-
ing wheel are automatically adjusted to
a position that allows driver to enter
and exit the vehicle easily.• The shift lever has been shifted to P.
• The engine switch has been turned off.
• The driver’s seat belt has been unfas- tened.
When any of the following has been perf ormed, the driver’s seat and steering
wheel automatically return to their original positions. • The engine switch has been turn ed to ACCESSORY mode or IGNITION
ON mode.
• The driver’s seat belt has been fastened.
■Operation of the power easy access system
When exiting the vehicle, the power easy acc ess system may not operate if the seat is
already close to the rearmost position, etc.
■Customization
The seat movement amount settings of the power easy access system can be custom-
ized. (Customizable features: P. 5 3 7 )
Driving position memory

: If equipped
This feature automatically adjusts the driver’s seat, steering wheel and out-
side rear view mirrors to make enteri ng and exiting the vehicle easier or to
suit your preferences.
Power easy access system

1243-3. Adjusting the seats
IS350/250_U (OM53C50U)
Your preferred driving position (the posi tion of the driver’s seat, steering wheel
and outside rear view mirrors) can be recorded and recalled by pressing a but-
ton.
Three different driving positions can be recorded into memory.
■Recording procedure
Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Adjust the driver’s seat, steering wheel, and outside rear view mirrors to the
desired positions.
While pressing the “SET” button,
or within 3 seconds after the
“SET” button is pressed, press
button “1”, “2” or “3” until the
buzzer sounds.
If the selected button has already
been preset, the previously recorded
position will be overwritten.
■Recall procedure
Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Press one of the buttons for the
driving position you want to recall
until the buzzer sounds.
Driving position memory
1
2
3
4
1
2
3
