reset Lexus IS250 2015 Navigation Manual

77
3. OTHER SETTINGS
IS250/350_Navi_U
BASIC FUNCTION
21Select the desired part or component
screen button.
2Set the conditions.
3Select “OK” after entering the condi-
tions.
MAINTENANCE
INFORMATION SETTING
No.Function
Select to enter the next maintenance
date.
Select to enter the driving distance
until the next maintenance check.
Select to cancel the conditions which
have been entered.
Select to reset the conditions which
have expired.
INFORMATION
● For scheduled maintenance information,
refer to “Warranty and Services Guide/
Owner’s Manual Supplement/Scheduled
Maintenance”.
● Depending on driving or road conditions,
the actual date and distance that mainte-
nance should be performed may differ
from the stored date and distance in the
system.

80
IS250/350_Navi_U1. QUICK REFERENCE .............................. 82
MAP SCREEN............................................................. 82
NAVIGATION OPTIONS SCREEN ............. 84
2. MAP SCREEN OPERATION ............... 85
CURRENT POSITION DISPLAY..................... 85
MAP SCALE ............................................................... 86
ORIENTATION OF THE MAP.......................... 88
SWITCHING THE MAP MODE....................... 89
SCREEN SCROLL OPERATION...................... 91
ADJUSTING LOCATION IN SMALL
INCREMENTS......................................................... 92
3. MAP SCREEN INFORMATION ......... 93
DISPLAYING MAP INFORMATION ............ 93
DISPLAYING INFORMATION ABOUT THE ICON WHERE
THE CURSOR IS SET .......................................... 97
STANDARD MAP ICONS ................................... 99
4. TRAFFIC INFORMATION .................. 100
DISPLAYING TRAFFIC INFORMATION ON THE MAP .................. 103
1. DESTINATION SEARCH SCREEN.................................................... 105
2. SEARCH OPERATION ......................... 107
SELECTING SEARCH AREA.......................... 108
SETTING HOME AS DESTINATION........... 109
SETTING PRESET DESTINATIONS AS DESTINATION .............................................. 109
SEARCHING BY ADDRESS .............................. 110
SEARCHING BY POINT OF INTEREST ....... 111
DESTINATION SEARCH BY DESTINATION ASSIST ..................................... 116
SEARCHING FROM PREVIOUS DESTINATIONS.................................................... 116
SEARCHING BY ADDRESS BOOK .............. 117
SEARCHING BY EMERGENCY ..................... 117
SEARCHING BY INTERSECTION AND FREEWAY.................................................... 118
SEARCHING BY MAP.......................................... 119
SEARCHING BY COORDINATES .............. 120
3. STARTING ROUTE GUIDANCE ....... 121
STARTING ROUTE GUIDANCE..................... 121
PAUSING GUIDANCE....................................... 124
1BASIC OPERATION2DESTINATION SEARCH

3
81
IS250/350_Navi_U
2
3
4
5
6
7
8
9
1
1. ROUTE GUIDANCE SCREEN .......... 125
SCREEN FOR ROUTE GUIDANCE ............ 125
ROUTE OVERVIEW ............................................. 127
DURING FREEWAY DRIVING....................... 128
WHEN APPROACHING INTERSECTION ................................................... 130
TURN LIST SCREEN.............................................. 130
TURN-BY-TURN ARROW SCREEN ............ 131
2. TYPICAL VOICE GUIDANCE PROMPTS ............................................... 132
3. EDITING ROUTE..................................... 133
ADDING DESTINATIONS ................................ 134
REORDERING DESTINATIONS.................... 135
DELETING DESTINATIONS ............................ 135
SETTING ROUTE PREFERENCES................ 136
SELECTING ROUTE TYPE ............................... 136
DETOUR SETTING ................................................ 137
STARTING FROM ADJACENT ROAD...... 138
1. MEMORY POINTS SETTINGS.......... 139
SETTING UP HOME ............................................. 140
SETTING UP PRESET DESTINATIONS...... 142
SETTING UP ADDRESS BOOK ..................... 144
SETTING UP AREAS TO AVOID .................. 147
DELETING PREVIOUS DESTINATIONS................................................... 150
1. DETAILED NAVIGATION SETTINGS ................................................. 151
SCREENS FOR NAVIGATION
SETTINGS ................................................................ 152
2. TRAFFIC SETTINGS ............................... 157
SCREEN FOR TRAFFIC SETTINGS ............. 158
AUTO AVOID TRAFFIC ..................................... 159
1. GPS (GLOBAL POSITIONING SYSTEM) .................................................. 160
LIMITATIONS OF THE NAVIGATION
SYSTEM .................................................................... 160
2. MAP DATABASE VERSION AND COVERED AREA................................. 163
MAP INFORMATION .......................................... 163
ABOUT THE MAP DATA ................................... 164
3ROUTE GUIDANCE
4MEMORY POINTS
5SETUP
6TIPS FOR THE NAVIGATION
SYSTEM
NAVIGATION SYSTEM

106
2. DESTINATION SEARCH
IS250/350_Navi_U
Select to set a destination by home.109
Select to set a destination from preset destinations.109
Select to delete set destinations.135
No.FunctionPage

109
2. DESTINATION SEARCH
IS250/350_Navi_U
NAVIGATION SYSTEM
31Display the “Destination” screen.
(→ P. 107)
2Select “Go Home” .
zThe navigation system performs a search
for the route and the entire route map is
displayed. ( →P. 121)
1Display the “Destination” screen.
(→ P. 107)
2Select any of the preset destination but-
tons (1-5 ).
zThe navigation system performs a search
for the route and the entire route map is
displayed. ( →P. 1 2 1 )
SETTING HOME AS
DESTINATION
To use this function, it is necessary to
register a home address. ( →P. 140)
SETTING PRESET
DESTINATIONS AS
DESTINATION
To use this function, it is necessary to
register preset destinations to the preset
screen buttons (1-5). ( →P. 142)

139
IS250/350_Navi_U
NAVIGATION SYSTEM
3
4. MEMORY POINTS
1. MEMORY POINTS SETTINGS
1Press the “MENU” button on the
Remote Touch.
2Select “Setup”.
3Select “Navigation” .
4Select the desired item to be set.Home, preset destinations, address
book entries, areas to avoid can be set
as memory points. The registered points
can be used as the destinations.
(→ P. 105)
Registered areas to avoid, will be avoid-
ed when the system searches for a route.
No.FunctionPage
Select to set home.140
Select to set preset destina-
tions.142
Select to set the address
book.144
Select to set areas to avoid.147
Select to delete previous
destinations.150
Select to set detailed navi-
gation settings.151

142
4. MEMORY POINTS
IS250/350_Navi_U
1Display the “Navigation Settings”
screen. (→P. 139)
2Select “Preset Destinations” .
3Select the desired item.
1Select “Set”.
2Select the desired item to search for the
location. ( →P. 105)
3Select a position for this preset destina-
tion.
4Select “OK” when the editing preset
destination screen appears. ( →P. 143)
SETTING UP PRESET
DESTINATIONS
If a preset destination has been regis-
tered, that information can be recalled
by using preset destinations on the
“Destination” screen. ( →P. 109)
No.FunctionPage
Select to register a preset
destination.142
Select to edit a preset desti-
nation.143
Select to delete a preset
destination.143
REGISTERING PRESET
DESTINATIONS
INFORMATION
●Up to 5 preset destinations can be regis-
tered.

143
4. MEMORY POINTS
IS250/350_Navi_U
NAVIGATION SYSTEM
3
1Select “Edit”.
2Select the desired preset destination.
3Select the item to be edited.
4Select “OK”.
1Select “Delete”.
2Select the preset destination to be de-
leted and select “Delete”.
3Select “Yes” when the confirmation
screen appears.
EDITING PRESET
DESTINATIONS
No.FunctionPage
Select to edit the preset
destination name.146
Select to set display of the
preset destination name
on/off.

Select to edit location infor-
mation.146
Select to edit the phone
number.146
Select to change the icon to
be displayed on the map
screen.145
DELETING PRESET
DESTINATIONS

152
5. SETUP
IS250/350_Navi_U
SCREENS FOR NAVIGATION
SETTINGSNo.FunctionPage
Select to set display of pop-
up information on/off.
Select to set favorite POI
categories that are used for
POI selection to display on
the map screen.
153
Select to set display of low
fuel warning on/off.153
Select to set IPD road guid-
ance on/off.
Select to set the voice guid-
ance for the next street
name on/off.
Select to set display of the
3D city model map on/off.
Select to change the view-
ing angle of the 3D map.154
Select to adjust the current
position mark manually or
to adjust miscalculation of
the distance caused by tire
replacement.
155
Select to reset all setup
items.

158
5. SETUP
IS250/350_Navi_U
SCREEN FOR TRAFFIC
SETTINGSNo.Function
Select to set the avoid traffic function
auto/manual. (→P. 159)
Select to set the usage of traffic infor-
mation for the estimated arrival time
on/off.
Select to set the display of an arrow
of free flowing traffic on/off.
Select to set to on/off whether to
consider the predictive traffic infor-
mation (→ P. 102) with estimated ar-
rival time and detoured route search.
Select to set traffic incident voice
warning on/off.
Select to reset all setup items.
