2134-5. Using the driving support systems
4
Driving
IS350/250_U (OM53C50U)
NOTICE
■To prevent damage to or incorrect operation of the LDA system
●Do not modify the headlights or attach stickers to the surface of the lights.
●Do not modify the suspension or replace it with non-genuine parts.
●Do not install or place anything on the hood or the grille. Also, do not install a grille
guard (bull bars, kangaroo bar etc.).
●If your windshield needs repairs, contact your Lexus dealer.
■Camera sensor
Observe the following to ensure that the LDA system functions correctly.
●Keep the windshield clean at all times.
Performance could be affected if the windshie ld is dirty, or if raindrops, condensation
or ice are adhering to the windshield.
●Do not spill liquid onto the camera sensor
●Do not attach window tinting to the windshield.
●Do not install an antenna in front of the camera lens.
●If the windshield is fogged up, use the wi ndshield defogger to remove fog from the
windshield.
When it is cold, using the he ater with air blowing to the feet may allow the upper part
of the windshield to fog up. This will have a negative effect on the images.
●Do not scratch the camera lens, or let it get dirty.
When cleaning the inside of the windshield , be careful not to get any glass cleaner
etc. on the lens. Also, do not touch the lens.
For lens repair, contact your Lexus dealer.
●Do not change the installation position or di rection of the camera sensor or remove it.
The direction of the camera se nsor is precisely adjusted.
●Do not subject the camera sensor to strong impact or force, and do not disassemble
the camera sensor.
●Do not replace windshield with non-genuine windshield.
Contact your Lexus dealer.
●Do not attach a sticker or other items to the
windshield near the camera sensor.

2494-5. Using the driving support systems
4
Driving
IS350/250_U (OM53C50U)
■Obstacles not detected
The sensor cannot detect plastic obstacles such as traffic cones. There may also be occa-
sions when the sensor cannot detect pedestrians, animals, bicycles, motorcycles, trees,
or snowdrifts.
■Situations in which the pre-collision system does not function properly
The system may not function effectively in situations such as the following:
●On roads with sharp bends or uneven surfaces
●If a vehicle suddenly moves in front of your vehicle, such as at an intersection
●If a vehicle suddenly cuts in front of your vehicle, such as when overtaking
●In inclement weather such as heavy rain, fog, snow or sand storms
●If the vehicle is skidding when VSC is not operating
●When an extreme change in vehicle height occurs
●When only part of your vehicle’s front end collides with, or contacts, a vehicle or object
in a frontal collision
●When the radar sensor moves off position due to its surrounding area being subjected
to a strong impact
■Automatic cancelation of the pre-collision system
When a malfunction occurs due to sensor cont amination, etc. that results in the sensors
being unable to detect obstacles, the pre-collision syst em will be automatically disabled.
In this case, the system will not activate even if there is a collision possibility.
■When there is a malfunction in the system
The pre-collision system warning light will flas h and warning messages will be displayed.
(  P. 4 6 7 , 4 76 )

4017-1. Maintenance and care
7
Maintenance and care
IS350/250_U (OM53C50U)
NOTICE
■Cleaning detergents
●Do not use the following types of detergent, as they may discolor the vehicle interior
or cause streaks or damage to painted surfaces:
• Non-seat portions: Organic substances such as benzene or gasoline, alkaline oracidic solutions, dye, and bleach
• Seats: Alkaline or acidic solutions, su ch as thinner, benzene, and alcohol
●Do not use polish wax or polish cleaner. The instrument panel’s or other interior part’s
painted surface may be damaged.
■Preventing damage to leather surfaces
Observe the following precautions to avoid damage to and deterioration of leather
surfaces:
●Remove any dust or dirt from leather surfaces immediately.
●Do not expose the vehicle to direct sunlight for extended periods of time. Park the
vehicle in the shade, especially during summer.
●Do not place items made of vinyl, plastic, or containing wax on the upholstery, as they
may stick to the leather su rface if the vehicle interior heats up significantly.
■Water on the floor
Do not wash the vehicle floor with water.
Vehicle systems such as the audio system may be damaged if water comes into contact
with electrical components such as the au dio system above or under the floor of the
vehicle. Water may also cause the body to rust.
■When cleaning the inside of the windshield (vehicles with LDA [Lane Departure
Alert])
Be careful not to touch the camera sensor ( P. 2 0 8 ) .
If the camera is accidentally scratched or hit, LDA may not operate properly or may
cause a malfunction.
■Cleaning the inside of the rear window
●Do not use glass cleaner to clean the rear window, as this may cause damage to the
rear window defogger heater wires or antenna. Use a cloth dampened with luke-
warm water to gently wipe the window cl ean. Wipe the window in strokes running
parallel to the heater wires or antenna.
●Be careful not to scratch or damage the heater wires or antenna.

4527-3. Do-it-yourself maintenance
IS350/250_U (OM53C50U)
■Replacing the following bulbs
If any of the lights listed below has burnt out, have it replaced by your Lexus
dealer.
●Headlights
●Parking lights and daytime running lights
●Side marker lights
●Side turn signal lights
●Fog lights (if equipped)
●Outer foot lights
●Stop/tail lights
●Tail lights
●High mounted stoplight
●License plate lights
■Discharge headlights (if equipped)
If voltage to the discharge bulb s is insufficient, the bulbs may not come on, or may go out
temporarily. The discharge bulbs will come on when normal power is restored.
■LED Lights
The lights other than the discharge headlights (if equipped), front turn signal lights, rear
turn signal lights, back-up light and outer foot lights each consist of a number of LEDs. If
any of the LEDs burn out, take your vehicle to your Lexus dealer to have the light
replaced.
■Condensation build-up on the inside of the lens
Temporary condensation build-up on the inside of the headlight lens does not indicate a
malfunction. Contact your Lexus dealer for mo re information in the following situations:
●Large drops of water have built up on the inside of the lens.
●Wa t e r h a s b u i l t u p i nside the headlight.
■When replacing the front turn signal lights (vehicles with LED headlights)
When the washer fluid filler opening is removed with a large amount of washer fluid con-
tained in the washer tank, washer fluid ma y spill onto the vehicle and cleaning may be
required.
■When replacing light bulbs
 P. 443

568Alphabetical index
IS350/250_U (OM53C50U)
Daytime running light system ............ 174
DefoggerFront windshield .................................362
Outside rear view mirrors .............362
Rear window ........................................362
Differential Front differential ................................... 517
Rear differential .................................... 517
Dimension .................................................512
Dinghy towing......................................... 158
Display Drive information .................................. 87
Dynamic radar cruise control....... 196
LDA (Lane Departure Alert) ...... 209
Multi-information display ..................86
Warning message ............................. 472
Distance ...................................................... 88
Do-it-yourself maintenance ............. 409
Door courtesy lights Location ................................................. 368
Wattage ................................................... 521 Doors ..........................................................103
Automatic door locking and unlocking system ................... 106
Door glasses ......................................... 138
Door lock................................................ 105
Open door warning buzzer ..........104
Open door warning light .............. 467
Outside rear view mirrors ..............135
Rear door child-protector ............. 106
Drive information .....................................87
Drive info 1/Drive info 2 ....................... 88
Driver’s seat position memory.......... 123
Driving ........................................................ 146 Break-in tips ........................................... 147
Correct driving posture .................... 28
Driving mode select switch ...........237
Procedures .............................................146
Winter drive tips ................................ 260
Dynamic radar cruise control ........... 196
D

570Alphabetical index
IS350/250_U (OM53C50U)
Emergency flashers ............................. 456
Engine .........................................................514ACCESSORY mode....................... 160
Compartment....................................... 413
Engine switch ........................................ 159
Hood ........................................................... 411
How to start the engine ................... 159
Identification number ........................ 513
If the engine will not start............... 496
Ignition switch (engine switch)..... 159
Overheating ........................................ 506
Engine coolant......................................... 417 Capacity .................................................. 516
Checking..................................................417
Preparing and checking before winter ................................... 260
Engine coolant temperature gauge ..........................................................81
Engine immobilizer system ................. 69
Engine oil ...................................................414 Capacity .................................................. 514
Checking................................................. 414
Preparing and checking before winter ................................... 260
Engine switch .......................................... 159
Enhanced VSC ..................................... 240
EPS (Electronic Power Steering) ..........241 Function ....................................................241
Warning light ....................................... 467
Event data recorder (EDR) ...................10 First-aid kit storage belt......................374
Flat tire ...................................................... 486
Floor mats....................................................26
Fluid
Automatic transmission .................... 517
Brake......................................................... 518
Washer ................................................... 422
Fog lights..................................................... 181 Replacing light bulbs ....................... 452
Switch ......................................................... 181
Wattage ................................................... 521
Footwell light .......................................... 368 Wattage ................................................... 521
Front passenger occupant classification system ............................ 47
Front personal lights ........................... 369 Wattage ................................................... 521
Front seats ................................................. 120 Adjustment..............................................120
Cleaning................................................. 399
Correct driving posture .................... 28
Driving position memory................. 123
Head restraints .....................................128
Power easy access system ............. 123
Seat heaters .......................................... 367
Seat position memory ....................... 123
Seat ventilators.................................... 367F

573Alphabetical index
IS350/250_U (OM53C50U)
Lane Departure Alert (LDA) ..........208
Language (multi-information display) ............... 88
LATCH anchors ...................................... 59
LDA (Lane Departure Alert) ..........208
Lever Auxiliary catch lever ............................ 411
Hood lock release lever .................... 411
Internal trunk release lever................. 111
Shift lever ................................................. 164
Tilt and telescopic steering lock release lever............................... 131
Turn signal lever .................................. 170
Wiper lever ............................................ 182
Lexus Display Audio system ............ 266
Lexus Display Audio controller...... 268
Lexus Enform
*
Lexus Enform Remote*.................... 354
Lexus Enform Safety Connect........ 390
Lexus parking assist monitor
*.......... 221
License plate lights................................. 173 Light switch .............................................173
Replacing light bulbs ........................452 Light bulbs
Replacing ............................................... 446
Wattage ................................................... 521
Lights Fog light switch ...................................... 181
Headlight switch .................................. 173
Illuminated entry system................. 369
Interior light........................................... 369
Interior lights list..................................368
Personal lights ..................................... 369
Replacing light bulbs ....................... 446
Trunk light................................................... 111
Turn signal lever ...................................170
Vanity lights ...........................................377
Wattage ................................................... 521
Lock steering column............................ 161
Low profile tire ....................................... 427
Luggage security system ..................... 110
L
*: For vehicles with a navigation system, refer to the
“NAVIGATION SYSTEM OWNER’S MANUAL”.

574Alphabetical index
IS350/250_U (OM53C50U)
MaintenanceDo-it-yourself maintenance......... 409
General maintenance .................... 405
Maintenance data ............................... 512
Maintenance requirements...........402
Maintenance system ..............................88
Malfunction indicator lamp .............. 466
Master warning light ........................... 467
Meter Changing the display..........................83
Indicators................................................... 78
Instrument panel light control .........84
Meters.......................................................... 81
Multi-information display ..................86
Warning lights ........................................ 77
Micro dust and pollen filter ................361
Mirrors Inside rear view mirror ..................... 133
Outside rear view mirror defoggers ...........................................362
Outside rear view mirrors .............. 135
Vanity mirrors ...................................... 377 MMS (Multimedia messaging
service)................................................... 327
Mobile Assistant .................................... 272
Moon roof ...................................................141 Door lock linked moon roof operation...................... 142
Jam protection function.................... 142
Operation..................................................141
MP3 disc ................................................. 295
Multi-information display..................... 86 Audio system-linked ........................... 86
Drive information.................................. 87
Dynamic radar cruise control .......196
LDA (Lane Departure Alert).......209
Navigation system-linked ................ 86
Settings ......................................................88
Switching the display .......................... 87
Warning message..............................472
Navigation system
*
Needle ......................................................... 88
Noise from under vehicle ........................8
M
N

575Alphabetical index
IS350/250_U (OM53C50U)
Odometer ....................................................81
OilEngine oil................................................. 514
Front differential oil............................. 517
Rear differential oil .............................. 517
Opener Hood ........................................................... 411
Trunk ......................................................... 109
Outer foot lights Location ................................................. 368
Replacing light bulbs ........................452
Wattage ................................................... 521
Outside rear view mirrors ................. 135 Adjusting and folding........................ 135
Blind spot monitor............................. 252
Linked mirror function when reversing ................................. 136
Mirror position memory ...................123
Outside rear view mirror defoggers ............................362
Outside temperature...............................81
Overheating, Engine .......................... 506 Paddle shift switches............................. 166
Parking assist sensors
(intuitive parking assist).................... 214
Parking brake .......................................... 172
Parking lights ........................................... 173 Light switch............................................. 173
Replacing light bulbs ....................... 452
PCS (Pre-Collision System).............246 Function .................................................. 246
PCS OFF switch .................................247
Warning light ....................................... 467
Personal lights ....................................... 369 Wattage ................................................... 521
Pop-up display ......................................... 88
Power easy access system ................. 123
Power outlet ........................................... 378
Power steering (Electric power steering system) .................................. 241 Warning light ....................................... 467
Power windows.......................................138 Door lock linked window operation ...........................140
Jam protection function....................139
Operation............................................... 138
Window lock switch ......................... 138
Pre-Collision System (PCS).............246 Function .................................................. 246
PCS OFF switch .................................247
Warning light ....................................... 467
OP
*: For vehicles with a navigation system, refer to the
“NAVIGATION SYSTEM OWNER’S MANUAL”.

576Alphabetical index
IS350/250_U (OM53C50U)
Radar cruise control (dynamic radar cruise control) ..........................196
Radiator ..................................................... 418
Radio.......................................................... 289
Rear personal lights............................. 369 Wattage ................................................... 521
Rear seats ................................................... 121 Fold down the seatback .................... 121
Luggage security system .................. 110
Rear sunshade ....................................... 379 Operation ..............................................379
Reverse operation feature.............379
Rear turn signal lights ...........................170 Replacing light bulbs ........................449
Turn signal lever .................................. 170
Wattage ................................................... 521
Rear view mirror Inside rear view mirror ..................... 133
Outside rear view mirrors .............. 135 Rear window defoggers .....................362
Refueling................................................... 188
Capacity...................................................514
Fuel types.................................................514
If the fuel filler door cannot be opened .......................... 190
Opening the fuel tank cap ............. 190
Remote Touch
*
Replacing Electronic key battery ..................... 439
Fuses .......................................................... 441
Light bulbs............................................. 444
Tires ..........................................................486
Reporting safety defects for U.S. owners .................................. 548
Reset the maintenance data ............ 403
Rev indicator ............................................. 88
Rev peak ..................................................... 88
R
