LEXUS IS250 2016 Owners Manual

Topic 4
Rain and Night Driving
33
IS_U (L/O_0808)
Headlights
The instrument panel, side marker, parking, tail
and license plate lights turn on.
The headlights and all lights listed above turn on.
The headlights and parking lights turn on/off
automatically in accordance with ambient light
levels.
To engage the high beams, push the lever forward.
To flash the high beams, pull the lever and hold.
nAFS (Adaptive Front-lighting System) (if equipped)
AFS improves visibility on curves by automatically adjusting the horizontal orientation of the
headlights in accordance with vehicle speed and the degree of the tire angle that are con-
trolled by steering input.
The system can be turned on and off using the satellite switch. (→P. 2 5 )
1
2
3

Topic 4
Rain and Night Driving
34

Entering and Exiting
Before Driving
Before Driving
When Driving
Rain and
Night Driving
Rain and
Night Driving
Driving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
IS_U (L/O_0808)
Fog Lights
The fog lights can be used only when the head-
lights (low beam) are on.

Topic 4
Rain and Night Driving
35
IS_U (L/O_0808)
Windshield Wipers and Washer
nIntermittent wiper with interval adjuster (if equipped)
Intermittent operation
Low speed
High speed
Single wipe
Intermittent operation: Wiper interval can be
adjusted by turning the band.
To spray washer fluid, pull the lever. The wipers
will operate automatically.
1
2
3
4

Topic 4
Rain and Night Driving
36

Entering and Exiting
Before Driving
Before Driving
When Driving
Rain and
Night Driving
Rain and
Night Driving
Driving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
IS_U (L/O_0808)
nRain-sensing windshield wipers (if equipped)
Automatic operation
Low speed
High speed
Single wipe
Automatic operation: Sensitivity can be adjusted
by turning the band.
To spray washer fluid, pull the lever. The wipers
will operate automatically.
1
2
3
4

Topic 4
Rain and Night Driving
37
IS_U (L/O_0808)
Headlight Cleaner (If Equipped)
The headlight cleaner can be used only when the
“ENGINE START STOP” switch is in IGNITION
ON mode and the headlights are on.
Rear Window and Outside Rear View
Mirror Defoggers
To defog the rear window and the outside rear
view mirrors, press the button.
Press again to cancel.

Instrument Panel Light Control
To d i m : turn the dial counterclockwise.
To b r i g h t e n : turn the dial clockwise.
The system turns off automatically after 15 minutes.
1
2

Topic 5
Driving Comfort
39
IS_U (L/O_0808)
Audio System (without navigation system)
Owners of models equipped with a navigation system should refer to the “Navigation System
Owner's Manual”.
nBasic operation
Sound quality modes
Listening position (if equipped)
Automatic Sound Levelizer (ASL)
Audio sources
Po w e r/ Vo l u m e
nAudio sources
AM⋅SAT: AM radio/Satellite Radio*
FM: FM radio
DISC⋅AUX: CD player/Auxiliary audio device
*: The optional Lexus genuine satellite tuner and antenna allows you to receive and play
XM® Satellite Radio broadcasts. (Subscription is required. For detailed information,
see the Owner’s Manual.)
nRadio
Traffic information
Station presets
Te x t m e s s a g e s
Radio tuner
RDS genre select
Scan
All radio stations: press
Preset radio stations: press and hold
Seek
nEntering station presets
Select the desired station by using the tune, the seek or the scan function.
Press and hold one of the preset buttons (1-6) until you hear a beep, indicating that the
station is set.
1
2
3
4
5
1
2
3
4
5
6
7

Topic 5
Driving Comfort
40

Entering and Exiting
When Driving
Rain and
Night Driving
Driving Comfort
Driving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
Before Driving
IS_U (L/O_0808)
nCD player
nPlaying an audio CD
Random playback
Current CD: press
All CDs: press and hold
Repeat
Current track: press
Current CD: press and hold
Text information
CD select
CD load
Scan
All tracks in current disc: press
First track of each disc: press and hold
Eject
Track select/rewind/fast-forward
nPlaying a CD with MP3/WMA files
Random playback
Current folder: press
All folders: press and hold
Repeat
Current file: press
All files in current folder: press and hold
Folder select
Text information
File select
CD select
CD load
Scan
All files in current folder: press
First file of each folder: press and hold
Eject
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
9

Topic 5
Driving Comfort
41
IS_U (L/O_0808)
nLoading a CD
Press the LOAD button.
WAIT is shown on the display.
Insert a CD when the indicators on the slot turn from amber to green.
The display changes from WAIT to LOAD.
nLoading multiple CDs
Press and hold the LOAD button until you hear a beep.
WAIT is shown on the display.
Insert a CD when the indicators on the slot turn from amber to green.
The display changes from WAIT to LOAD.
The indicators on the slot turn to amber when the CD is inserted.
Insert the next CD when the indicators on the slot turn from amber to green again.
Repeat the procedure for the remaining CDs.
To stop the operation, press the DISC

Topic 5
Driving Comfort
42

Entering and Exiting
When Driving
Rain and
Night Driving
Driving Comfort
Driving Comfort
Opening and Closing
What to do if ...
Customizing
Yo u r L e x u s
Before Driving
IS_U (L/O_0808)
Air Conditioning System (wit hout navigation system)
Owners of models equipped with a navigation system should refer to the “Navigation System
Owner's Manual”.
nUsing the automatic mode
Press the AUTO button.
Adjust the temperature using the TEMP but-
tons.
nAdjusting the temperature in DUAL mode
In DUAL mode, driver and passenger side tem-
perature settings can be adjusted separately.
Press the DUAL button.
Adjust the driver side temperature using the
TEMP buttons, and the passenger side temper-
ature using the PASSENGER TEMP buttons.
Driver side temperature control
Switch to automatic mode
Driver side temperature display
OFF button
Fan speed controls
Air flow controls
Passenger side temperature display
Micro dust and pollen filter
Passenger side temperature control
Windshield defog/defrost
Outside air/recirculated air mode switch
A/C switch
Dual mode switch
1
2
3
4
5
6
7
8
9
10
11
12
13

Topic 5
Driving Comfort
43
IS_U (L/O_0808)
Garage Door Opener
The garage door opener (HomeLink® Universal Transceiver) is manufactured under license
from HomeLink®.
The HomeLink® compatible transceiver in your
vehicle has 3 buttons which can be programmed
to operate 3 different devices.
nProgramming HomeLink®
Hold your hand-held transmitter within 3
inches of the HomeLink® buttons.
Press and hold down the desired HomeLink®
button.
For U.S.A. owners:
While pressing the HomeLink® button,
press and hold down the button on the hand-
held transmitter until the indicator light
changes from a slow to a rapid flash.
For Canadian owners:
While pressing the HomeLink® button,
repeatedly press and release (cycle) the but-
ton on the hand-held transmitter every 2
seconds until the indicator light changes
from a slow to a rapid flash.
If your garage door is of the rolling code type:
Press the training button on the motor-head unit
in your garage.
Press and hold the vehicle’s programmed
HomeLink® button for 2 seconds and release
it. Repeat this step once again.
If the door does not open, press and release
the same button once again.
The garage door opener can be programmed to operate garage doors, gates, entry
doors, door locks, home lighting systems, security systems, and other devices.
