INTERIOR EQUIPMENT
58
TIE±DOWN HOOKS
SV14003
To secure your luggage, use the tie±down hooks as
shown above.
See ºLuggage stowage precautionsº on page 60 for
precautions to observe for loading luggage.
CAUTION
To avoid personal injury, keep the tie±down hooks
stored under the carpet when not in use.
FLOOR MAT
SS14019
Use a floor mat of the correct size.
If the floor carpet and floor mat have a hole, then it is designed
for use with a locking clip. Fix the floor mat with locking clip into
the hole in the floor carpet.

INTERIOR EQUIPMENT
59
SS14021a
CAUTION
Make sure the floor mat is properly placed on the floor
carpet. If the floor mat slips and interferes with the
movement of the pedals during driving, it may cause an
accident.
FIRST±AID KIT HOLDER
SS14022a

1To loosen 2To tighten
This belt is designed to hold the first±aid kit.
To loosen: Pull the buckle forward.
To tighten: Pull on the belt.
Make sure the first±aid kit is securely held.

INTERIOR EQUIPMENT
60
LUGGAGE STOWAGEPRECAUTIONS
When stowing luggage or cargo in the vehicle, observe
the following:
Put luggage or cargo in the trunk when at all possible. Be
sure all items are secured in place.
 Be careful to keep the vehicle level. Placing the weight as
far forward as possible helps maintain vehicle balance.
 For better fuel economy, do not carry unnecessary weight.
CAUTION
Do not place anything on the filler panel behind the
rear seatback. Such items may be thrown about and
possibly injure people in the vehicle during sudden
braking or in an accident.
 Do not drive with objects left on top of the instrument
panel. They may interfere with the driver's field of
view. Or they may move during sharp vehicle
acceleration or turning, and impair the driver's
control of the vehicle. In an accident they may injure
the vehicle occupants.
NOTICE
Do not load the vehicle beyond the vehicle capacity
weight specified on the tire pressure label.

SECTION 1 ± 5
61
INSTRUMENTS AND CONTROLS
Exterior equipment
Hood62
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . .
Trunk lid 63
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . .
Fuel tank cap 65
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .
Moon roof 67
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . .

EXTERIOR EQUIPMENT
62
HOOD
SS15001
1. To open the hood, pull the hood lock release lever
under the instrument panel. The hood will spring up
slightly.
SV15005
2. Insert your fingers under the hood, push up the
auxiliary catch lever and lift the hood.
SV15002
3. Hold the hood open by inserting the support rod into
the slot.
CAUTION
After inserting the support rod into the slot, make sure
the rod supports the hood securely from falling down on
to your head or body.
NOTICE
Be sure to return the support rod to its clip beforeclosing the hood. Closing the hood with the support rod
up could cause the hood to bend.

EXTERIOR EQUIPMENT
63
SS15021
In case of unlocking the support rod, lift up the hood a
little, move the support rod and unlock it as shown by the
arrow marks in the illustration.
Before closing the hood, check to see that you have not
forgotten any tools, rags, etc. and return the support rod to its
clips±this prevents rattles. Then lower the hood and make
sure it locks into place. If necessary, press down gently on the
front edge to lock it.
CAUTION
Before driving, be sure that the hood is securely locked.
Otherwise, the hood may open unexpectedly while
driving and an accident may occur.
TRUNK LID
SS15005c
To unlock the trunk lid, insert the master key and turn it
clockwise.
To close the trunk lid, lower it and press down on it. After
closing the trunk lid, try pulling it up to make sure it is securely
closed.
The trunk lid can be unlocked using the wireless remote control
key. For details, see page 13.
If the theft deterrent system is set, unlock the trunk lid with the
wireless remote control. (For details, see page 118.)

EXTERIOR EQUIPMENT
64
CAUTION
Keep the trunk lid closed while driving. This not only
keeps the luggage from being thrown out, but also
prevents exhaust gases from entering the vehicle.
 Always lock the trunk lid and all doors, and keep
away the vehicle keys out of children's reaches.
 Never leave children unattended in the vehicle.
Unsupervised children may lock themselves in the
vehicle or trunk and suffer serious injuries or death.
Lock release lever
SS15006
To open the trunk lid from the driver's seat, pull up on the
lock release lever.
Internal trunk release handle
SV15006
If a person is locked in the trunk, pull down the
phosphorescent handle (illuminated for a while) on the
inside of trunk lid in case of emergency to open the trunk
lid.
The handle illuminating time depends on the intensity of the
light thrown on the handle.

EXTERIOR EQUIPMENT
65
Luggage security system
SS15013
After closing the trunk lid, insert the master key and turn
it counterclockwise to deactivate the lock release lever.
At this time, the trunk lid can be opened only by the
phosphorescent handle lever inside the trunk.
FUEL TANK CAP
SS15008
1. To open the fuel filler door, pull the lever up.
When refueling, turn off the engine.
CAUTION
Do not smoke, cause sparks or allow open flames
when refueling. The fumes are flammable.
 When opening the cap, do not remove the cap
quickly. In hot weather, fuel under pressure could
cause injury by spraying out of the filler neck if the
cap is suddenly removed.

EXTERIOR EQUIPMENT
66
SV15007
2. To remove the fuel tank cap, turn the cap slowly
counterclockwise, then pause slightly before removing it.
After removing the cap, hang the tether as shown in the
illustration.
It is not unusual to hear a slight swoosh when the cap is
opened. When installing the cap, turn the cap clockwise until
you hear a click.
If the cap is not tightened securely, the malfunction indicator
lamp comes on. Make sure the cap is tightened securely.
The indicator lamp goes off after driving several times. If the
indicator lamp does not go off, contact your Lexus dealer as
soon as possible.
CAUTION
 Make sure the cap is tightened securely to prevent
fuel spillage in case of an accident.
 Use only a genuine Lexus fuel tank cap for
replacement. It is designed to regulate fuel tank
pressure.
Refueling the vehicle
As soon as the correctly operated nozzle switches off
automatically for the first time, the tank is full. Do not try
to add more fuel, because fuel may spill out.

EXTERIOR EQUIPMENT
67
MOON ROOF
SV15003

1Open 2Close
To slide open the moon roof, push the switch on the rear
side briefly. The moon roof will open and stop partway 30
mm (1.2 in.) from the fully opened position. When you
push the switch again, the moon roof will open fully. To
stop partway, push the same switch or ºTILTº switch
briefly while the moon roof is moving.
As driving with the moon roof opened fully will cause wind
throbs, we recommend you to drive with the moon roof partway
30 mm (1.2 in.) from the fully opened position.
To operate the moon roof, the ignition key must be in the ºONº
position.
The sun shade can be opened or closed manually. However,
if you open the moon roof, the sun shade will be opened with
the moon roof. To close the moon roof, push the switch on the front side.
The moon roof will fully close. To stop partway, push the
same switch or ºTILTº switch.
SS15012

1Tilt up 2Lower
To tilt up the rear end of the moon roof fully, push the
switch on the rear side or on the front side to lower it.
To operate the moon roof, the ignition key must be in the ºONº
position.
Key off operation:
Even if the ignition key is turned to the
ºACCº or ºLOCKº position, the moon roof can be operated until
either of the front doors is opened (or for about 45 seconds).
