KEYS AND DOORS
8
KEYS
11L025a
1Master key (black) ± The master key works in every
lock. For your Lexus dealer to make you a new key
with built±in transponder chip, your dealer will need
it.
2Sub key (gray) ± The sub key will not open the trunk
and the glove box.
3Key number plate ± Keep the plate in a safe place
such as your wallet, not in the vehicle.
A transponder chip for engine immobiliser system has been
filled in the head of the master and sub keys. These chips are
needed to enable the system to function correctly, so be careful
not to lose these keys. If you make your own duplicate key, you
will not be able to cancel the system or start the engine.
To protect things locked in the trunk or glove box when you
have your vehicle parked, leave the sub key with the attendant. Since the doors and trunk lid can be locked without a key, you
should always carry a spare master key in case you
accidentally lock your keys inside the vehicle.
If you should lose your keys or if you need additional keys,
duplicates can be made by a Lexus dealer using the key
number.
We recommend you to write down the key number and keep
it in safe place.
Flat key
SV11020
As a transponder chip is built in its key case, you can start
the engine with this key.
The flat key works in every lock.
A transponder chip for engine immobiliser system has been
filled in the key case of the flat key. This chip is needed to
enable the system to function correctly, so be careful not to
lose this key. If you make your own duplicate key, you will not
be able to cancel the system or start the engine.
Page 22 of 378
KEYS AND DOORS
9
Insert
your key plate in its key case as shown. We recommend
that you always carry this with you for emergency use. Do not
leave it in your vehicle.
Starting the engine using a flat key
SV11011
1. Remove the key plate from the key case.
2. Insert the key plate into the ignition switch. The indicator
light keeps flashing.
3. Bring the key case closer to the ignition switch within 10
seconds as indicated by the arrow head. The indicator light
goes out. This means the engine immobiliser system is
automatically cancelled. (For details, see ºEngine immobiliser
systemºon page 11.) You can put the key case away then. You
cannot cancel the engine immobiliser system if 10 seconds
have past after you inserted the key plate. You need to remove
the key plate from the ignition switch and try it again from the
step 2. 4. Start the engine within 20 seconds after the security
indicator light goes out. You cannot start the engine if 20
seconds have past after the security indicator went off. You
need to remove the key plate from the ignition switch and try
it again from the step 2.
NOTICE
Do not let the key case become bent as the key plate
may fall out or become bent also.
The flat key is designed for emergency use only. Sodo not use it regularly instead of other master keys.
Page 23 of 378
KEYS AND DOORS
10
11L021-2
When using a key containing a transponder chip,observe the following precautions:
When starting the engine, do not use the key with akey ring resting on the key grip and do not press thekey ring against the key grip. Otherwise the enginemay not start, or may stop soon after it starts.
11R055
When starting the engine, do not use the key withother transponder keys around (including the flat key
and keys of other vehicles) and do not press other key plates against the key grip. Otherwise the enginemay not start, or may stop soon after it starts. If thishappens, remove the key once and then insert itagain after taking off other transponder keys
(including the flat key and keys of other vehicles)from the ring or while gripping or covering them with
your hand to start the engine.
Page 24 of 378
KEYS AND DOORS
11
SV11019
Do not bend the key grip or flat key.
Do not cover the key grip or flat key with any materialthat cuts off electromagnetic waves.
Do not knock the key or flat key hard against otherobjects.
Do not leave the key or flat key exposed to hightemperatures for a long period, such as on the
dashboard and hood under the direct sunlight.
Do not put the key or flat key in water or wash it in anultrasonic washer.
Do not use the key or flat key with electromagneticmaterials.
ENGINE IMMOBILISER SYSTEM
SV11007
The engine immobiliser system is a theft prevention
system. W hen you insert the key in the ignition switch, the
transponder chip in the key's head transmits an electronic
code to the vehicle. The engine will start, only when the
electronic code in the chip corresponds to the registered
ID code for the vehicle.
The system is automatically set when the key is removed from
the ignition switch. At this time, the security indicator light
flashes. When you insert the key in the ignition switch, the
security indicator light goes out and the system is canceled
automatically, which enables the engine to start.
For your Lexus dealer to make you a new key with built±in
transponder chip, your dealer will need your key number and
master key or the flat key. However, there is a limit to the
number of additional keys your Lexus dealer can make for you.
Page 25 of 378
KEYS AND DOORS
12The transponder chip of the flat key is in its key case. You can
cancel the engine immobiliser system using the flat key. (For
details, see ºFlat keyº on page 8.)
If you make your own duplicate key, you will not be able
to cancel the system or start the engine.
For vehicles sold in U.S.A.
FCC ID: MOZ RI±4ATY
MADE IN JAPAN
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
CAUTION
Changes or modifications not expressly approved by
the party responsible for compliance could void the
user's authority to operate the equipment.
For vehicles sold in Canada
This device complies with RSS±210 of Industry
Canada.
Operation is subject to the following two conditions:
(1) This device may not cause interference, and (2)
this device must accept any interference, including
interference that may cause undesired operation of
the device.
Page 26 of 378
KEYS AND DOORS
13
WIRELESS REMOTE CONTROL*
SV11008
Sedan
1Locking the doors and sounding an alarm
2Unlocking the doors
3Indicator light
4Unlocking the trunk lid
SV11012
SportCross
1Locking the doors
2Unlocking the doors
3Indicator light
4Sounding an alarm
NOTE: *This feature can be set inoperative as vehicle theftdeterrent measure in case of the loss of the wireless remote
control key. Ask your Lexus dealer for details.
When you operate any button on the key, push it slowly and
surely. At this time, the indicator light on the key grip flashes
once.
The operational range of the wireless remote control is
approximately 1 meter (3 ft.). The effective range may vary
with different conditions. To activate the wireless remote
control w ithout fail, do it approximately 1 meter (3 ft.) from your
Lexus.
Page 27 of 378
KEYS AND DOORS
14In the following cases, the battery in the key may be
discharged. If this is a case, replace it using a special
screwdriver.
The remote control does not work.
The operational range of wireless remote control becomes
extremely short.
The indicator light on the key is dimmed or does not come
on.
For the replacement of the battery, see ºReplacing the batteryº
on page 18. You can also have the battery of the key replaced
by your Lexus dealer.
If you lose the wireless key, contact your Lexus dealer as soon
as possible to avoid the possibility of theft, or an accident.
You can use up to 4 wireless remote control keys for the same
vehicle. Contact your Lexus dealer for detailed information.
The wireless remote control key is an electronic
component. Observe the following instructions in order
not to cause damage to the key.
Do not leave the wireless remote control key on places
where the temperature becomes high such as on the
dashboard.
Do not disassemble it.
Avoid knocking it hard against other objects or dropping it.
Avoid putting it in water.
Locking/Unlocking the doors
When you push the ºLOCKº button on the key briefly, all
the doors can be locked from outside the vehicle.
At this time, one beep sounds* and the emergency flashers
flash once.** However, when you push the ºLOCKº button with
any door not closed securely, the buzzer sounds for 10
seconds.*** To stop the buzzer, close all the doors securely or
push the ºUNLOCKº button. If the key is in the ignition switch,
locking cannot be done.
Make sure all the doors are locked when you leave the vehicle.
Push the ºLOCKº button once again. If they were already
locked, one beep sounds and the emergency flashers will
flash.
NOTE: *The beep sound can be set not to sound. **The emergency flasher can be set not to flash. ***The buzzercan be set not to sound if a door is not closed securely. Askyour Lexus dealer for details.
NOTICE
Sedan only: Do not push the ºLOCKº button any longerthan 2 to 3 seconds. Pushing the button longeractivates an alarm. For details, see page 16.
When you push the ºUNLOCKº button, the driver's door
is unlocked. Pushing that button once again within 3
seconds from the first push, all other doors are also
unlocked.*
NOTE: *The 2±step unlocking function can be changed.Ask your Lexus dealer for details.
Page 28 of 378
KEYS AND DOORS
15
At this time, two beeps sound* and the emergency flashers
flash twice.** Together with the activation of unlocking, the
interior
light comes on for 15 seconds if the interior light switch
is in ºDOORº position.*** However, this function does not
work when the ignition key is in the ºONº position. For further
information, see ºInterior lightsº on page 55.
You have 30 seconds to open a door after using the wireless
remote unlock feature.**** If a door is not opened by then, all
the doors will be automatically locked again.
Even if the ºLOCKº or ºUNLOCKº switch is kept pressed in, the
locking or unlocking operation is not repeated. Release the
button and then push again.
NOTE: *The beep sound can be set not to sound. **The emergency flashers can be set not to flash. ***The interiorlight can be set not to come on or the duration of lighting can
be changed. ****The time before automatic re±locking can be changed. Ask your Lexus dealer for details.
Unlocking the trunk lid
SV11009
When you keep the button pushed for about 1 second, you
can unlock the trunk lid.* One beep sounds.
This function does not work when the key is in the ignition
switch.
NOTE: *The operation method can be changed. Ask your Lexus dealer for details.
Page 29 of 378
KEYS AND DOORS
16
Sounding an alarm*
SV11010
Sedan
When you push the ºPANICº button for about 2 to 3
seconds, an alarm sounds to deter any person trying to
break into or damage your vehicle.
If you want to stop the alarm, push any button.
This function does not work when the ignition key is in the ºONº
position.
NOTE: *The alarm can be set not to sound. Ask your Lexus
dealer for details.
SV11013
SportCross
When you push the ºPANICº button for about 1 second, an
alarm sounds to deter any person trying to break into or
damage your vehicle.
If you want to stop the alarm, push any button.
This function does not work when the ignition key is in the ºONº
position.
NOTE: *The alarm can be set not to sound. Ask your Lexus dealer for details.
Page 30 of 378
KEYS AND DOORS
17
For vehicles sold in U.S.A.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
NOTICE:
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off
and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
Consult the dealer or an experienced radio / TV
technician for help.
FCC WARNING:
Changes or modifications not expressly approved
by the party responsible for compliance could void
the user's authority to operate the equipment.
For vehicles sold in Canada
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this
device must accept any interference, including
interference that may cause undesired operation of
the device.
