For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
vi
Page
1Power door lock switch and power window switches 21, 33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Power rear view mirror control switches 103 . . . . . .
3Rear fog light switch 29
. . . . . . . . . . . . . . . . . . . . . . . . .
4Headlight cleaner switch 32
. . . . . . . . . . . . . . . . . . . . .
5Headlight, turn signal and fog light
switch 26, 29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6Transmission shift switches 229
. . . . . . . . . . . . . . . . .
7Instrument panel light control 51
. . . . . . . . . . . . . . . . .
8Cruise control switch 237
. . . . . . . . . . . . . . . . . . . . . . .
9Wiper and washer switches 30
. . . . . . . . . . . . . . . . . . .
10Ignition switch 223
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11Emergency flasher switch 35
. . . . . . . . . . . . . . . . . . . .
12Outside temperature display/Clock 57
. . . . . . . . . . . .
13Front passenger's seat belt reminder light 45 . . . . . Page
14Automatic air conditioning controls
176
. . . . . . . . . .
15Car audio 190
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
16Seat heater switches 36
. . . . . . . . . . . . . . . . . . . . . . . . .
17Glove box 60
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18Parking brake lever 224
. . . . . . . . . . . . . . . . . . . . . . . . .
19Driving pattern selector switch
(Automatic transmission) 226 . . . . . . . . . . . . . . . . . . . .
20Ashtray 58
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
.
21Cigarette lighter 58
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22Automatic transmission selector lever/Manual
transmission gear shift lever 226, 235 . . . . . . . . . . . . .
23Traction control system off/Snow mode switch
(Manual transmission) 240 . . . . . . . . . . . . . . . . . . . . . . .
24Hood lock release lever 80
. . . . . . . . . . . . . . . . . . . . . .

OPERATION OF SELECTOR LEVER
SELECTOR LEVER POSITION
P: Parking, engine starting and key removal position
R: Reverse position
N: Neutral position
D: Normal driving position (Shifting into overdrive
possible)
M: Position for manual shifting up or downshifting
(Shifting into overdrive possible)*
3, 2: Position for more powerful engine braking
L: Position for maximum engine braking
SVBA009
Shift while pressing the brake pedal. (Ignition
switch must be in the ºONº position.)
*:When the cruise control is being used, even if you downshift from º5º to º4º\
, engine braking will not be enabled because
the cruise control is not cancelled. For the operation to decrease the \
vehicle speed, see page 239.
SV31020
BASIC OPERATION ± QUICK REFERENCE
4
3. AUTOMATIC TRANSMISSION

BASIC OPERATION ± QUICK REFERENCE
5
4. HEADLIGHT AND TURN SIGNAL
SWITCH
SVBA013
SVBA013

HEADLIGHT SWITCHWith the ignition OFF
Parking, tail, license plate,
side marker and instrument
panel lights turn on.
Automatic light control
Headlights also turn on.
With the engine started and parking brake
released Parking, tail, license plate,
side marker and instrument
panel lights turn on.
Headlights also turn on
at full intensity.
Automatic light control
SVBA014
SSBA011b
Right or left turn
Lane change
(Right or left) High beam
Headlight flasher

TURN SIGNAL SWITCH

KEYS AND DOORS
9
Insert
your key plate in its key case as shown. We recommend
that you always carry this with you for emergency use. Do not
leave it in your vehicle.
Starting the engine using a flat key
SV11011
1. Remove the key plate from the key case.
2. Insert the key plate into the ignition switch. The indicator
light keeps flashing.
3. Bring the key case closer to the ignition switch within 10
seconds as indicated by the arrow head. The indicator light
goes out. This means the engine immobiliser system is
automatically cancelled. (For details, see ºEngine immobiliser
systemºon page 11.) You can put the key case away then. You
cannot cancel the engine immobiliser system if 10 seconds
have past after you inserted the key plate. You need to remove
the key plate from the ignition switch and try it again from the
step 2. 4. Start the engine within 20 seconds after the security
indicator light goes out. You cannot start the engine if 20
seconds have past after the security indicator went off. You
need to remove the key plate from the ignition switch and try
it again from the step 2.
NOTICE
Do not let the key case become bent as the key plate
may fall out or become bent also.
The flat key is designed for emergency use only. Sodo not use it regularly instead of other master keys.

KEYS AND DOORS
11
SV11019
Do not bend the key grip or flat key.
Do not cover the key grip or flat key with any materialthat cuts off electromagnetic waves.
Do not knock the key or flat key hard against otherobjects.
Do not leave the key or flat key exposed to hightemperatures for a long period, such as on the
dashboard and hood under the direct sunlight.
Do not put the key or flat key in water or wash it in anultrasonic washer.
Do not use the key or flat key with electromagneticmaterials.
ENGINE IMMOBILISER SYSTEM
SV11007
The engine immobiliser system is a theft prevention
system. W hen you insert the key in the ignition switch, the
transponder chip in the key's head transmits an electronic
code to the vehicle. The engine will start, only when the
electronic code in the chip corresponds to the registered
ID code for the vehicle.
The system is automatically set when the key is removed from
the ignition switch. At this time, the security indicator light
flashes. When you insert the key in the ignition switch, the
security indicator light goes out and the system is canceled
automatically, which enables the engine to start.
For your Lexus dealer to make you a new key with built±in
transponder chip, your dealer will need your key number and
master key or the flat key. However, there is a limit to the
number of additional keys your Lexus dealer can make for you.

KEYS AND DOORS
14In the following cases, the battery in the key may be
discharged. If this is a case, replace it using a special
screwdriver.

The remote control does not work.
 The operational range of wireless remote control becomes
extremely short.
 The indicator light on the key is dimmed or does not come
on.
For the replacement of the battery, see ºReplacing the batteryº
on page 18. You can also have the battery of the key replaced
by your Lexus dealer.
If you lose the wireless key, contact your Lexus dealer as soon
as possible to avoid the possibility of theft, or an accident.
You can use up to 4 wireless remote control keys for the same
vehicle. Contact your Lexus dealer for detailed information.
The wireless remote control key is an electronic
component. Observe the following instructions in order
not to cause damage to the key.
 Do not leave the wireless remote control key on places
where the temperature becomes high such as on the
dashboard.
 Do not disassemble it.
 Avoid knocking it hard against other objects or dropping it.
 Avoid putting it in water.
Locking/Unlocking the doors
When you push the ºLOCKº button on the key briefly, all
the doors can be locked from outside the vehicle.
At this time, one beep sounds* and the emergency flashers
flash once.** However, when you push the ºLOCKº button with
any door not closed securely, the buzzer sounds for 10
seconds.*** To stop the buzzer, close all the doors securely or
push the ºUNLOCKº button. If the key is in the ignition switch,
locking cannot be done.
Make sure all the doors are locked when you leave the vehicle.
Push the ºLOCKº button once again. If they were already
locked, one beep sounds and the emergency flashers will
flash.
NOTE: *The beep sound can be set not to sound. **The emergency flasher can be set not to flash. ***The buzzercan be set not to sound if a door is not closed securely. Askyour Lexus dealer for details.
NOTICE
Sedan only: Do not push the ºLOCKº button any longerthan 2 to 3 seconds. Pushing the button longeractivates an alarm. For details, see page 16.
When you push the ºUNLOCKº button, the driver's door
is unlocked. Pushing that button once again within 3
seconds from the first push, all other doors are also
unlocked.*
NOTE: *The 2±step unlocking function can be changed.Ask your Lexus dealer for details.

KEYS AND DOORS
15
At this time, two beeps sound* and the emergency flashers
flash twice.** Together with the activation of unlocking, the
interior
light comes on for 15 seconds if the interior light switch
is in ºDOORº position.*** However, this function does not
work when the ignition key is in the ºONº position. For further
information, see ºInterior lightsº on page 55.
You have 30 seconds to open a door after using the wireless
remote unlock feature.**** If a door is not opened by then, all
the doors will be automatically locked again.
Even if the ºLOCKº or ºUNLOCKº switch is kept pressed in, the
locking or unlocking operation is not repeated. Release the
button and then push again.
NOTE: *The beep sound can be set not to sound. **The emergency flashers can be set not to flash. ***The interiorlight can be set not to come on or the duration of lighting can
be changed. ****The time before automatic re±locking can be changed. Ask your Lexus dealer for details.
Unlocking the trunk lid
SV11009
When you keep the button pushed for about 1 second, you
can unlock the trunk lid.* One beep sounds.
This function does not work when the key is in the ignition
switch.
NOTE: *The operation method can be changed. Ask your Lexus dealer for details.

KEYS AND DOORS
19
NOTICE
Make sure the positive side and negative side of thebattery should be faced correctly.
Do not replace the battery with wet hands. Water may
cause unexpected rust.
Do not touch or move any components inside of the transmitter, or it may interfere with proper operation.
Be careful not to bend the electrode of the batteryinsertion and that dust or oils do not adhere to theinside of the module.
Take care not to lose the screws and O±ring.
5. Install the lid with the 2 screws.
NOTICE
Take care not to damage or bend the O±ring wheninstalling.
6. Install the module into the key frame and secure the cover
with the screw.
7. When pushing any switch on the wireless key, make sure
the indicator light comes on.
DOORS
Locking with key
SS11007a

1Lock 2Unlock
Turn the key towards the front of the vehicle to lock and
towards the back to unlock.
Locking (or unlocking) the driver's door will lock (or unlock) all
the other doors simultaneously. In the driver's door lock,
turning the key once will unlock the driver's door and twice in
succession will unlock all doors simultaneously.*
Together with the activation of unlocking, the interior light will
turn on for 15 seconds if the interior light switch is in the
ºDOORº position.** However, this function does not work
when the ignition key is in the ºONº position. For further
information, see ºInterior lightº on page 55.

KEYS AND DOORS
20
NOTE: *The 2±step unlocking function can be changed.**The interior light can be set not to come on or the duration
of lighting can be changed. Ask your Lexus dealer for details.
Locking with inside lock button
SV11004

1Lock 2Unlock
Push in the lock button to lock and unlock the door.
When locked, the door cannot be opened with either the
outside or inside door handle.
Closing the door with the lock button pushed in will also lock
the door. Be careful not to lock your keys in the vehicle. The
door will not lock if the key is left in the ignition switch when
closing the front doors.
CAUTION
Before driving, make sure the doors are closed and
locked, especially when small children are in the
vehicle. Along with the proper use of seat belts, locking
the doors helps prevent the driver and passengers from
being thrown out from the vehicle during an accident.
It also helps prevent the doors from being opened
unintentionally.

SWITCHES
26
HEADLIGHT SWITCH
SS12002a
To turn the lights on, twist the knob on the end of the lever.
FIRST CLICKSTOP: Only the parking, tail, license plate, side
marker and instrument panel lights turn on.
SECOND CLICKSTOP: Headlights also turn on.
THIRD CLICKSTOP (ºAUTOº): The headlights and all other
lights automatically turn on depending on the darkness of the
surroundings.*
Manually twist the knob to the second clickstop to turn on
the headlights if they are needed immediately when
entering a dark tunnel, parking structure, etc.
When the headlight switch is turned to the first or second
clickstop, the brightness of the instrument cluster will be
reduced slightly unless the instrument panel light control knob
is turned fully on.
NOTE: *The operating condition or sensitivity can be changed. Ask your Lexus dealer for details.
SV12024
The automatic light control sensor is on top of the driver's side
instrument panel.
Do not place anything on the instrument panel, and/or do not
affix anything on the windshield to block this sensor.
When the headlights come on, the lights automatically turn off
about 30 seconds after any of the doors is opened and closed
with the ignition key turned to the ºACCº or ºLOCKº position\
.*
When only the taillights come on: The lights automatically turn
off with the driver's door opened and the ignition key turned to
the ºACCº or ºLOCKº position.
To turn them on again, turn the ignition key to the ºONº position,
or turn the headlight switch off and then twist the knob until the
first or second clickstop. If you are going to park for over one
week, make sure the headlight switch is off.
NOTE: *The time before turning off the lights can be changed. Ask your Lexus dealer for details.
