COMFORT ADJUSTMENT
106Pushing the ºAUTOº button for longer than 3 seconds
turns on or off the compass display.
The compass may not show the correct direction in the
following conditions:

The vehicle is stopped immediately after turning.
The compass does not adjust while the vehicle is stopped.
 The ignition switch is turned off immediately after turning.
 The vehicle is on an inclined surface.
 The vehicle is in a place where the earth's magnetic field is
subject to interference by artificial magnetic fields
(underground parking, under a steel tower, between
buildings, roof parking, near a crossing, near a large
vehicle, etc.).
 The vehicle is magnetized. (There is an magnet or a metal
object on or near the inside rear view mirror.)
 The battery has been disconnected.
 Any door is open.
The compass works to calibrate the direction automatically
while the vehicle is in motion, if deviation is small.
For obtaining additional precision or for complete calibrating,
see ºCALIBRATING THE COMPASSº below.
NOTICE
Do not put magnets or a metal object near the inside rear view mirror. Doing this may cause malfunction of thecompass sensor.
CALIBRATING THE COMPASS (deviation calibration)
The direction display on the compass deviates from the true
direction determined by the earth's magnetic field. The
amount of deviation varies according to the geographic
position of the vehicle.
To adjust for this deviation, stop the vehicle and push the
button for longer than about 6 seconds until the number (1±15)
appears on the display. Then push the button again, referring
to the following map to select the number of the zone where the
vehicle is.

STARTING AND DRIVING
222
To allow proper operation of your vehicle's
ventilation system, keep the inlet grilles in front of the
windshield clear of snow, leaves, or other
obstructions.
 If you smell exhaust fumes in the vehicle, drive with
the windows open and the trunk lid or back door
closed. Have the cause immediately located and
corrected.BEFORE STARTING THE ENGINE
1. Check the area around the vehicle before entering it.
2. Adjust seat position, seatback angle, head restraint height
and steering wheel angle.
3. Adjust the inside and outside rear view mirrors.
4. Lock all doors.
5. Fasten seat belts.
Remember to check that the service reminder indicators
function when turning the key to ºONº, and check the fuel
gauge to see that you have sufficient fuel.

ELECTRICAL COMPONENTS
336
No.FUSEAMPERECIRCUIT
1 D FR P/W20Power window system
2 TAIL10Tail lights, Side marker lights,
License plate lights,
Parking lights
3 GAUGE10
Back±up lights, Power window,
Gauges and meters,
Service reminder indicators and
buzzers,
Emergency flashers,
Windshield defogger,
Outside rear view mirror
defogger
4 DOOR20Door lock system
5 PANEL7.5
Instrument panel lights,
Seat heater, Cigarette lighter,
Automatic transmission system,
Traction control system,
Rear fog light, Ashtray light
6 WASHER15Windshield washer,
Headlight cleaner
7 STARTER7.5Starting system
8 FR DEF20Windshield wiper deicer
9 A/C10Air conditioning system
10 SEAT HTR15Seat heater
11 CIG15Cigarette lighter, Power outlet
12 S/ROOF30Moon roof
No.FUSEAMPERECIRCUIT
13 ECU±IG10
Radiator fan,
Anti±lock brake system,
Moon roof, Shift lock system,
Air conditioning system,
Door lock system,
Headlight beam level control,
Theft deterrent system
14 SRS±ACC10SRS system
15 STOP15Stop lights, Shift lock system,
Anti±lock brake system
16 WIPER25Windshield wipers
17 RADIONO.210Audio, Air conditioning,
Outside rear view mirror,
Shift lock system
18 DOOR DL15Power seat system
19 DOME7.5
Interior lights, Trunk light,
Vanity lights,
Ignition switch light, Map light,
Door courtesy lights
20 FR FOG15Fog lights
21 P FR P/W20Power window system
22 PWR
OUTLET15Power outlets
23 ECU±B27.5Theft deterrent system,
Door lock system
24 D RR P/W20Power window system
25 MIR HTR15Outside rear view mirror

BODY
360
RAIN CLEARING MIRRORS
The rear view mirrors have been coated to produce a ºrain
clearingº effect. This coating causes the raindrops to
spread, clearing the driver's rear view when it rains.
It is sufficient to wash the mirrors with water for day to day care.
The rain clearing effect is reduced in drizzle and light rain.
In the following cases, the rain clearing effect will be reduced
temporarily, but will gradually recover.

After wiping dirt off the mirrors

When the mirrors fog up

After waxing your vehicle in an automatic car wash

After your vehicle has been parked for a long period in
underground parking lots, etc. where there is no direct
sunlight.
If you would like to restore the rain clearing effect to its normal
level immediately in the above cases, wash the mirrors with
neutral detergent, then rinse thoroughly.
NOTICE
To maintain the rain clearing ability, and prevent the mirrors from being scratched, observe the followingprecautions.

Do not use any glass cleaners that containcompounds.

If ice should jam the mirror, do not scrape the mirror.Use a spray deicer to free the mirror.

Wash off any wax stuck to the mirrors with neutraldetergent and rinse thoroughly as any wax on thesurface of the mirrors can cause the rain clearingeffect to be lost.

Do not use any water repellents as they can destroythe rain clearing effect. If any repellent gets stuck onthe surface of the mirrors, wash it off with neutraldetergent, then rinse thoroughly.
