SWITCHES
31
Daytime Running Light System
The headlights turn on at reduced intensity when the parking
brake is released with the engine started, even with the light
switch in the ºOFFº position. They will not go off until the
ignition switch is turned off.
To turn on the other exterior lights and instrument panel lights,
twist the knob to the first clickstop.
Twist
the knob to the second clickstop to turn on the headlights
to full intensity for driving at night.
When setting the knob to the third clickstop (ºAUTOº), the
headlights will automatically adjust to full intensity and/or turn
on the other lights depending on the darkness of the
surroundings. Likewise, as the surroundings become brighter,
the headlights will turn to reduced intensity, ultimately turning
off the other lights.
NOTICE
To prevent the battery from being discharged, do not leave the lights on longer than necessary when theengine is not running.
Automatic headlight leveling system
SV12022
The headlight beam level is always maintained automatically
at the proper level in all loading conditions so that your
headlights do not dazzle other road users.
If this system fails, the warning light in the instrument cluster
comes on. If this occurs, have your vehicle checked by Lexus
dealer.
03 07.09

GAUGES, METERS AND SERVICE REMINDER INDICATORS
46
VOLTMETER
SV13021

1Discharge warning light 2Normal range
The voltmeter tells whether the battery is charged or
discharged. Check it while the engine is running - the
needle should always indicate as shown above.
If the needle reads below or above the normal range while the
engine is running, it indicates that the charging system needs
immediate repair.
However, it is normal for the needle to drop below the normal
range during engine starting.
MOMENTARY FUEL CONSUMPTIONMETER
SV13018

Vehicles sold in U.S.A.
SV13020

Vehicles sold in Canada
03 07.09

GAUGES, METERS AND SERVICE REMINDER INDICATORS
49
IF THIS INDICATOR OR
BUZZER COMES ON ...
DO THIS.
(f)Stop and check.
(g)Add engine oil.
(h)Replace engine oil.
(i)or
Take vehicle to Lexus
dealer.
(j)or
Take vehicle to Lexus
dealer.
If brake system
warning light is also
on, stop immediately
and contact Lexus
dealer.
(k)Close all doors.
IF THIS INDICATOR ORBUZZER COMES ON ...DO THIS.
(l)Replace bulb.
(m)Low fuel level
warning lightFill up tank.
(n)Take vehicle to Lexus
dealer.
(o)Take vehicle to Lexus
dealer.
(p)Take vehicle to Lexus
dealer.
(q)Key reminder buzzerRemove key.
03 07.09

GAUGES, METERS AND SERVICE REMINDER INDICATORS
50
(a) Brake System Warning Light and Buzzer
This light comes on in the following cases when the ignition key
is in the ºONº position.
 When the parking brake is applied ...
This light comes on for a few seconds when the ignition key is
turned to the ºONº position even after the parking brake is
released.
If you drive your vehicle without releasing the parking brake,
the buzzer sounds.
 When the brake fluid level is low ...
CAUTION
It is dangerous to continue driving normally when the
brake fluid level is low.
Have your vehicle checked at your Lexus dealer in the
following cases:
The light does not come on even if the parking brake is
applied when the ignition key is in the ºONº position.
 The light does not come on even if the ignition key is turned
on with the parking brake released.
A warning light turning on briefly during operation does not
indicate a problem.
CAUTION
If either of the following conditions occurs, immediately
stop your vehicle at a safe place and contact your Lexus
dealer.
 The light does not turn off even after the parking
brake is released while the engine is running.
In the case, the brakes may not work properly and
your stopping distance will become longer. Depress
the brake pedal firmly and bring the vehicle to an
immediate stop.
 The brake system warning light remains on together
with the ºABSº warning light.
In this case, not only the anti-lock brake system will
fail but also the vehicle will become extremely
unstable during braking.
03 07.09

GAUGES, METERS AND SERVICE REMINDER INDICATORS
52
(e) Discharge Warning Light
This light warns that the battery is being discharged.
If it comes on while you are driving, stop the vehicle, turn off the
engine, and check for the cause. Look first at the engine drive
belt.
 If it is loose or broken, the generator will not charge the
battery properly.
 If the belt is O.K., there is a problem somewhere in the
charging system.
The engine ignition will continue to operate, however, until the
battery is discharged. Turn off the air conditioning, blower,
radio, etc., and drive directly to the nearest Lexus dealer or
repair shop.
NOTICE
Do not continue driving if the engine drive belt is broken or loose.
(f) Low Engine Oil Pressure Warning Light
This light warns that the engine oil pressure is too low.
If it flickers or stays on while you are driving, pull off the road
to a safe place and stop the engine immediately. Call a Lexus
dealer or qualified repair shop for assistance.
The light may occasionally flicker when the engine is idling or
it may come on briefly after a hard stop. There is no cause for
concern if it then goes out when the engine is accelerated
slightly.
The light may come on when the oil level is extremely low. It
is not designed to indicate low oil level, and the oil level must
be checked using the oil level dipstick.
NOTICE
Do not drive the vehicle with the warning light on - evenfor one block. It may ruin the engine.
03 07.09

GAUGES, METERS AND SERVICE REMINDER INDICATORS
53
(g) Low Engine Oil Level Warning Light
This light warns that the engine oil level is too low. Add oil as
soon as possible. (For instructions, see ºChecking the engine
oil levelº on page 333.)
While driving on steep inclines or rough roads which causes
the vehicle to substantially sway or on curves, this light may
come on due to the movement of engine oil in the engine.
In normal conditions, due to engine oil consumption, this light
may come on earlier than the specified service interval of the
scheduled maintenance. This is because the engine oil is
consumed to the low level within the scheduled maintenance
interval and does not indicate a problem. (For detailed
information, see ºFacts about engine oil consumptionº on page
331.)
NOTICE
Continued engine operation with low engine oil will damage the engine.
(h) Engine Oil Replacement Reminder Light (for vehicles sold in U.S.A.)
This light reminds you when to replace the engine oil.
This light will come on when the ignition key is turned to the
ºONº position and will go off after about a few seconds. When you drive for about 7200 km (4500 miles) after the
engine oil replacement, this light illuminates for about 3
seconds and then flashes for about 12 seconds with the
ignition key turned to the ºONº position. If you continue driving
without replacing the engine oil, and if the distance driven
exceeds 8000 km (5
000 miles), the light will come on after the
ignition key is turned to the ºONº position. The light will remain
on thereafter.
If the light is flashing, we recommend that you replace the
engine oil at an early opportunity depending on the driving and
road conditions. If the light comes on, replace it as soon as
possible.
The system must be reset after the engine oil replacement.
Reset the system by the following procedure:
1. Turn the ignition key to the ºOFFº position with the odometer
reading shown. (For details, see ºOdometer and trip meterº on
page 48.)
2. Turn the ignition key to the ºONº position while holding down
the ºODO/TRIPº button.
Hold down the button for at least 5 seconds. The odometer
indicates º000000º and the light goes off.
If the system fails to reset, the system will revert to the state
before resetting operation. In this case, return to step 1 and try
again.
03 07.09

GAUGES, METERS AND SERVICE REMINDER INDICATORS
54
(i) Malfunction Indicator Lamp
This lamp comes on when the ignition key is turned to the
ºONº position and goes off after the engine starts. This
means that the warning light system is operating properly.
If the lamp remains on, or the lamp comes on while
driving, first check the followings.
 Empty fuel tank
If the fuel tank is empty, refuel immediately.
 Loose fuel tank cap
If the fuel tank cap is loose, securely tighten it.
These cases are temporary malfunctions. The malfunction
indicator lamp will go off after taking several driving trips.
If the lamp will not go off even after the several trips, contact
your Lexus dealer as soon as possible.
If the fuel tank is not empty or the fuel tank cap is not
loose...
 There is a problem somewhere in the engine, emission
control system, electronic throttle control system, automatic
transmission electrical system or warning light system itself.
Contact your Lexus dealer as soon as possible to service the
vehicle.
If this lamp comes on and the engine speed does not increase
with the accelerator pedal depressed down to about the middle
position, there may be a problem somewhere in your electronic
throttle control system. At this time, if you depress the accelerator pedal more firmly
and slowly, you can drive your vehicle at low speeds. Have
your
Lexus checked by your Lexus dealer as soon as possible.
Even if the abnorma lity of the electronic throttle control system
is corrected during low speed driving, the system may not be
recovered until the engine is stopped and the ignition key is
turned to ºACCº or ºLOCKº position.
CAUTION
Be especially careful to prevent erroneous pedal
operation.
Emissions Inspection and Maintenance (I/M) programs
Your vehicle may not pass a state emission inspection if the
malfunction indicator lamp remains on. Contact your Lexus
dealer to check your vehicle's emission control system and
OBD (On-Board Diagnostics) system before taking your
vehicle for the inspection.
For details, see ºEmissions Inspection and Maintenance (I/M)
programsº on page 313.
(j) ºABSº Warning Light
The light comes on when the ignition key is turned to the ºONº
position. If the anti-lock brake system and the brake assist
system work properly, the light turns off after a few seconds.
Thereafter, if either of the systems malfunctions, the light
comes on again.
03 07.09

GAUGES, METERS AND SERVICE REMINDER INDICATORS
57
How to check all the service reminder
indicators
(except the low fuel level warning light):
1. Apply the parking brake.
2. Open the door.
The following service reminder indicator should come on. It
goes off when you close the door completely.
3. Turn the ignition key to ºACCº.
The following service reminder indicator should come on. It
goes off after about 6 seconds.
4. Turn the ignition key to ºONº.
The following service reminder indicators should come on.


or
or

or
The following service reminder indicators go off after a few
seconds.
or

The lights other than the slip indicator light may stay on for
about 60 seconds after the engine is started. It is normal if they
go out after a while.
If any service reminder indicator or warning buzzer does not
function as described above, have it checked by your Lexus
dealer as soon as possible.
03 07.09

STARTING AND DRIVING
237
HOW TO START THE ENGINE
Before cranking
1. Apply the parking brake firmly.
2. Turn off unnecessary lights and accessories.
3.Manual transmission : Press the clutch pedal to the floor
and shift the transmission into neutral. Hold the clutch pedal
to the floor until the engine is started. A starter safety device
will prevent the starter from operating if the clutch pedal is not
fully depressed.
Automatic transmission : Put the selector lever in ºPº. If you
need to restart the engine while the vehicle is moving, put the
selector lever in ºNº. A starter safety device will prevent the
starter from operating if the selector lever is in any drive
position.
4. For automatic transmission only :Depress the brake
pedal and hold it to the floor until driving off.
Starting the engine
Before starting the engine, be sure to follow the instructions in
ºBefore crankingº.
Normal starting procedure
The multiport fuel injection system/sequential multiport fuel
injection system in your engine automatically controls the
proper air-fuel mixture for starting. You can start a cold or hot
engine as follows:
With your foot off the accelerator pedal, crank the engine by
turning the key to ºSTARTº. Release it when the engine starts. Engine should be warmed up by driving, not in idle. For
warming up drive with smoothly turning engine until engine
coolant temperature is within normal range.
If the engine stalls ...
Simply restart it , using the correct procedure given in normal
starting.
If the engine will not start
See ºIf your vehicle will not startº on page 281.
NOTICE
Do not crank for more than 30 seconds at a time. This
may overheat the starter and wiring systems.
Do not race a cold engine.
If the engine becomes difficult to start or stallsfrequently, have the engine checked immediately.
03 07.09

STARTING AND DRIVING
252
TRACTION CONTROL SYSTEM
(With vehicle stability control system)
The traction control system automatically helps prevent
the spinning of rear wheels when the vehicle is started or
accelerated on slippery road surfaces.
When the ignition key is turned to ºONº, the system
automatically turns on.
CAUTION
Under certain slippery road conditions, full traction of
the vehicle and power against rear wheels cannot be
maintained, even though the traction control system is
in operation. Do not drive the vehicle under any speed
or maneuvering conditions which may cause the
vehicle to lose traction control. In situations where the
road surface is covered with ice or snow, your vehicle
should be fitted with snow tires or tire chains. Always
drive at an appropriate and cautious speed for the
present road conditions.
Normal driving mode
SV31037

Slip indicator light
Leave the system on during the ordinary driving so that it
can operate when needed.
You may hear a sound in the engine compartment for a few
seconds just after the vehicle begins to move. This means that
the traction control system is in the self-check mode, but does
not indicate a malfunction.
When the traction control system is operating, the following
conditions occur:
 The system controls the spinning of the rear wheels. At this
time, the slip indicator light blinks.
 You may feel vibration or noise in your vehicle, caused by
operation of the brakes. This indicates the system is functioning properly.
03 07.09
