Lexus IS300 2004 Electrical Components / LEXUS 2004 IS300 (OM53461U) Repair Manual

GAUGES, METERS AND SERVICE REMINDER INDICATORS
46
VOLTMETER
SV13021

1Discharge warning light 2Normal range
The voltmeter tells whether the battery is charged or
discharged. Check it while the engine is running - the
needle should always indicate as shown above.
If the needle reads below or above the normal range while the
engine is running, it indicates that the charging system needs
immediate repair.
However, it is normal for the needle to drop below the normal
range during engine starting.
MOMENTARY FUEL CONSUMPTIONMETER
SV13018

Vehicles sold in U.S.A.
SV13020

Vehicles sold in Canada
03 07.09

GAUGES, METERS AND SERVICE REMINDER INDICATORS
47
The momentary fuel consumption is calculated and
indicated based on the driving distance and the fuel
consumption with the engine running.
If you are driving at low speeds just before stopping, the
accurate figure may not be shown.
TACHOMETER
SV13016
The tachometer indicates engine speed in thousands of
rpm (revolutions per minute). Use it while driving to
prevent engine over-revving.
Driving with the engine running too fast causes excessive
engine wear and poor fuel economy. Remember, in most
cases the slower the engine speed, the greater the fuel
economy.
NOTICE
Do not let the indicator needle get into the red zone. This
may cause severe engine damage.
03 07.09

GAUGES, METERS AND SERVICE REMINDER INDICATORS
48
ODOMETER AND TRIP METER
SV13015
This meter displays the odometer and two trip meters. To
change the mode indication, push the ºODO/TRIPº knob
briefly. Each time you push the knob, the mode changes
in order from the odometer to trip meter A to trip meter B,
then back to the odometer, etc.
The odometer records the total distance the vehicle has
been driven. The twin trip meter records two different
distances independently.
For example, you can use one meter to calculate the fuel
economy and the other to measure the distance on each trip.
To set A trip meter to zero, display the A meter reading,
push the knob and hold it. The same applies for the B trip
meter.
The data of trip meters will be cancelled if the electrical power
source is disconnected.
SERVICE REMINDER INDICATORS AND WARNING BUZZERS
IF THIS INDICATOR OR
BUZZER COMES ON ...DO THIS.
(a)or
(Indicator and buzzer)
If parking brake is off,
stop immediately and
contact Lexus dealer.
(b)
(Indicator and buzzer)
Fasten driver's seat
belt
(c)Fasten front
passenger's seat belt.
(d)Take vehicle to Lexus
dealer immediately.
(e)Stop and check.
03 07.09

GAUGES, METERS AND SERVICE REMINDER INDICATORS
49
IF THIS INDICATOR OR
BUZZER COMES ON ...
DO THIS.
(f)Stop and check.
(g)Add engine oil.
(h)Replace engine oil.
(i)or
Take vehicle to Lexus
dealer.
(j)or
Take vehicle to Lexus
dealer.
If brake system
warning light is also
on, stop immediately
and contact Lexus
dealer.
(k)Close all doors.
IF THIS INDICATOR ORBUZZER COMES ON ...DO THIS.
(l)Replace bulb.
(m)Low fuel level
warning lightFill up tank.
(n)Take vehicle to Lexus
dealer.
(o)Take vehicle to Lexus
dealer.
(p)Take vehicle to Lexus
dealer.
(q)Key reminder buzzerRemove key.
03 07.09

GAUGES, METERS AND SERVICE REMINDER INDICATORS
50
(a) Brake System Warning Light and Buzzer
This light comes on in the following cases when the ignition key
is in the ºONº position.
 When the parking brake is applied ...
This light comes on for a few seconds when the ignition key is
turned to the ºONº position even after the parking brake is
released.
If you drive your vehicle without releasing the parking brake,
the buzzer sounds.
 When the brake fluid level is low ...
CAUTION
It is dangerous to continue driving normally when the
brake fluid level is low.
Have your vehicle checked at your Lexus dealer in the
following cases:
The light does not come on even if the parking brake is
applied when the ignition key is in the ºONº position.
 The light does not come on even if the ignition key is turned
on with the parking brake released.
A warning light turning on briefly during operation does not
indicate a problem.
CAUTION
If either of the following conditions occurs, immediately
stop your vehicle at a safe place and contact your Lexus
dealer.
 The light does not turn off even after the parking
brake is released while the engine is running.
In the case, the brakes may not work properly and
your stopping distance will become longer. Depress
the brake pedal firmly and bring the vehicle to an
immediate stop.
 The brake system warning light remains on together
with the ºABSº warning light.
In this case, not only the anti-lock brake system will
fail but also the vehicle will become extremely
unstable during braking.
03 07.09

GAUGES, METERS AND SERVICE REMINDER INDICATORS
51
(b) Driver's Seat Belt Reminder Light andBuzzer
This light and buzzer remind you to buckle up the driver's seat
belt.
Once the ignition key is turned to ºONº or ºSTARTº, the
reminder light flashes and buzzer sounds if the driver's seat
belt is not fastened. Unless the driver fastens the belt, the light
stays flashing and the buzzer stops after about 4 to 8 seconds.
(c) Front Passenger's Seat Belt Reminder Light
This light reminds you to buckle up the front passenger's seat
belt.
Once the ignition key is turned to ºONº or ºSTARTº, the
reminder light flashes if a passenger sits in the front passenger
seat and does not fasten the seat belt. Unless the front
passenger fastens the belt, the light stays flashing. However,
if a front passenger uses an additional seat cushion, the light
may not flash even when the seat belt is not buckled up.
If luggage or other load is placed on the front passenger seat,
depending on its weight and how it is placed on the seat,
built-in sensors in the seat cushion may detect the pressure,
causing the reminder light to come on.
(d) SRS Warning Light
The indicator comes on when the ignition key is turned to
the ºACCº or ºONº position. It goes off after about 6
seconds. This means the SRS airbags and front seat belt
pretensioners are operating properly.
The SRS warning light system monitors the airbag sensor
assembly, front airbag sensors, side and curtain shield airbag
sensors, front seat belt pretensioner assemblies, inflators,
warning light, interconnecting wiring and power sources.
If either of the following conditions occurs, this indicates a
malfunction somewhere in the components monitored by the
warning light system. Contact your Lexus dealer as soon as
possible to service the vehicle.
 When the ignition key is turned to the ºACCº or ºONº
position, the light does not come on, remains on or flashes.
 The light comes on or starts flashing while driving.
If the light stays on, it indicates that the driver and front
passenger airbags fail. If the light flashes, the side and curtain
shield airbags and/or seat belt pretensioners fail.
03 07.09

GAUGES, METERS AND SERVICE REMINDER INDICATORS
52
(e) Discharge Warning Light
This light warns that the battery is being discharged.
If it comes on while you are driving, stop the vehicle, turn off the
engine, and check for the cause. Look first at the engine drive
belt.
 If it is loose or broken, the generator will not charge the
battery properly.
 If the belt is O.K., there is a problem somewhere in the
charging system.
The engine ignition will continue to operate, however, until the
battery is discharged. Turn off the air conditioning, blower,
radio, etc., and drive directly to the nearest Lexus dealer or
repair shop.
NOTICE
Do not continue driving if the engine drive belt is broken or loose.
(f) Low Engine Oil Pressure Warning Light
This light warns that the engine oil pressure is too low.
If it flickers or stays on while you are driving, pull off the road
to a safe place and stop the engine immediately. Call a Lexus
dealer or qualified repair shop for assistance.
The light may occasionally flicker when the engine is idling or
it may come on briefly after a hard stop. There is no cause for
concern if it then goes out when the engine is accelerated
slightly.
The light may come on when the oil level is extremely low. It
is not designed to indicate low oil level, and the oil level must
be checked using the oil level dipstick.
NOTICE
Do not drive the vehicle with the warning light on - evenfor one block. It may ruin the engine.
03 07.09

GAUGES, METERS AND SERVICE REMINDER INDICATORS
53
(g) Low Engine Oil Level Warning Light
This light warns that the engine oil level is too low. Add oil as
soon as possible. (For instructions, see ºChecking the engine
oil levelº on page 333.)
While driving on steep inclines or rough roads which causes
the vehicle to substantially sway or on curves, this light may
come on due to the movement of engine oil in the engine.
In normal conditions, due to engine oil consumption, this light
may come on earlier than the specified service interval of the
scheduled maintenance. This is because the engine oil is
consumed to the low level within the scheduled maintenance
interval and does not indicate a problem. (For detailed
information, see ºFacts about engine oil consumptionº on page
331.)
NOTICE
Continued engine operation with low engine oil will damage the engine.
(h) Engine Oil Replacement Reminder Light (for vehicles sold in U.S.A.)
This light reminds you when to replace the engine oil.
This light will come on when the ignition key is turned to the
ºONº position and will go off after about a few seconds. When you drive for about 7200 km (4500 miles) after the
engine oil replacement, this light illuminates for about 3
seconds and then flashes for about 12 seconds with the
ignition key turned to the ºONº position. If you continue driving
without replacing the engine oil, and if the distance driven
exceeds 8000 km (5
000 miles), the light will come on after the
ignition key is turned to the ºONº position. The light will remain
on thereafter.
If the light is flashing, we recommend that you replace the
engine oil at an early opportunity depending on the driving and
road conditions. If the light comes on, replace it as soon as
possible.
The system must be reset after the engine oil replacement.
Reset the system by the following procedure:
1. Turn the ignition key to the ºOFFº position with the odometer
reading shown. (For details, see ºOdometer and trip meterº on
page 48.)
2. Turn the ignition key to the ºONº position while holding down
the ºODO/TRIPº button.
Hold down the button for at least 5 seconds. The odometer
indicates º000000º and the light goes off.
If the system fails to reset, the system will revert to the state
before resetting operation. In this case, return to step 1 and try
again.
03 07.09

GAUGES, METERS AND SERVICE REMINDER INDICATORS
54
(i) Malfunction Indicator Lamp
This lamp comes on when the ignition key is turned to the
ºONº position and goes off after the engine starts. This
means that the warning light system is operating properly.
If the lamp remains on, or the lamp comes on while
driving, first check the followings.
 Empty fuel tank
If the fuel tank is empty, refuel immediately.
 Loose fuel tank cap
If the fuel tank cap is loose, securely tighten it.
These cases are temporary malfunctions. The malfunction
indicator lamp will go off after taking several driving trips.
If the lamp will not go off even after the several trips, contact
your Lexus dealer as soon as possible.
If the fuel tank is not empty or the fuel tank cap is not
loose...
 There is a problem somewhere in the engine, emission
control system, electronic throttle control system, automatic
transmission electrical system or warning light system itself.
Contact your Lexus dealer as soon as possible to service the
vehicle.
If this lamp comes on and the engine speed does not increase
with the accelerator pedal depressed down to about the middle
position, there may be a problem somewhere in your electronic
throttle control system. At this time, if you depress the accelerator pedal more firmly
and slowly, you can drive your vehicle at low speeds. Have
your
Lexus checked by your Lexus dealer as soon as possible.
Even if the abnorma lity of the electronic throttle control system
is corrected during low speed driving, the system may not be
recovered until the engine is stopped and the ignition key is
turned to ºACCº or ºLOCKº position.
CAUTION
Be especially careful to prevent erroneous pedal
operation.
Emissions Inspection and Maintenance (I/M) programs
Your vehicle may not pass a state emission inspection if the
malfunction indicator lamp remains on. Contact your Lexus
dealer to check your vehicle's emission control system and
OBD (On-Board Diagnostics) system before taking your
vehicle for the inspection.
For details, see ºEmissions Inspection and Maintenance (I/M)
programsº on page 313.
(j) ºABSº Warning Light
The light comes on when the ignition key is turned to the ºONº
position. If the anti-lock brake system and the brake assist
system work properly, the light turns off after a few seconds.
Thereafter, if either of the systems malfunctions, the light
comes on again.
03 07.09

GAUGES, METERS AND SERVICE REMINDER INDICATORS
55
When the ºABSº warning light is on (and the brake system
warning light is off), the anti-lock brake system, the brake
assist system, the traction control system and/or the vehicle
stability control system do not operate, but the brake system
still operates conventionally.
When the ºABSº warning light is on (and the brake system
warning light is off), the anti-lock brake system and/or the
traction
control system do/does not operate so that the wheels
could lock up during a sudden braking or braking on slippery
road surfaces.
If either of the following conditions occurs, this indicates
a malfunction somewhere in the components monitored
by the warning light system. Contact your Lexus dealer
as soon as possible to service the vehicle.
 The light does not come on when the ignition key is turned
to the ºONº position, or remains on.
 The light comes on while you are driving.
A warning light turning on briefly during operation does not
indicate a problem.
CAUTION
If the ºABSº warning light remains on together with the
brake system warning light, immediately stop your
vehicle at a safe place and contact your Lexus dealer.
In this case, not only the anti-lock brake system will fail
but also the vehicle will become extremely unstable
during braking.
(k) Open Door Warning Light
This light remains on until all the doors are completely closed.
(l) Rear Light Failure Warning Light
If this light comes on when the headlight switch is turned on (at
the first or second clickstop), it indicates that one or more of the
tail lights are burned out.
If it comes on when the brake pedal is depressed, one or more
stop lights are burned out.
Have defective bulbs replaced as soon as possible.
(m) Low Fuel Level Warning Light
This light comes on when the fuel level in the tank becomes
nearly empty. Fill the tank as soon as possible.
On inclines or curves, due to the movement of fuel in the tank,
the low fuel level warning light may come on earlier than usual.
(n) ºTRAC OFFº Indicator / Warning Lights
This light comes on when the ignition key is turned to ºONº, and
will go off after a few seconds. This means that the system is
operating properly.
If one of the following conditions occurs, this indicates a
malfunction somewhere in the components monitored by the
warning light system. Contact your Lexus dealer as soon as
possible to service the vehicle.
 The light does not come on after the ignition key is turned
to ºONº.
03 07.09
