Page 4 of 648
TABLE OF CONTENTS4
IS350/300/200t_U (OM53D76U)
5-1. Basic Operations Lexus Display Audio system..........................................300
Steering wheel audio switches ...................................... 306
Mobile Assistant ........................ 307
USB/AUX ports ........................ 309
5-2. Setup Setup menu ....................................312
General settings...........................313
Voice settings................................316
Display settings ............................. 317
5-3. Using the audio system Selecting the au dio source ..... 318
Optimal use of the audio system............................................319
Audio settings ............................. 320
Audio menu screen operation .................................... 323
5-4. Using the radio Radio operation.......................... 326 5-5. Playing an audio CD and
MP3/WMA/AAC discs
CD player operation ................ 332
5-6. Using an external device Listening to an iPod .................. 339
Using USB memory device .......................................... 343
Using the AUX port .....................47
5-7. Connecting Bluetooth
®
Steps for using Bluetooth®
devices ........................................ 348
Registering a Bluetooth
®
device .......................................... 350
Selecting a Bluetooth
®
device ............................................351
Connecting a Bluetooth
®
audio player .............................. 352
Connecting a Bluetooth
®
phone ........................................... 353
Displaying a Bluetooth
®
device details ............................ 354
Detailed Bluetooth
®
settings ........................................ 355
5-8. Bluetooth
® Audio
Listening to Bluetooth
®
Audio ...........................................358
5Lexus Display Audio system
Page 298 of 648
298
IS350/300/200t_U (OM53D76U)
5-1. Basic Operations Lexus Display Audio system ......................................... 300
Steering wheel audio switches.......................................306
Mobile Assistant......................... 307
USB/AUX ports ........................309
5-2. Setup Setup menu ................................... 312
General settings .......................... 313
Voice settings ............................... 316
Display settings .............................317
5-3. Using the audio system Selecting the au dio source ..... 318
Optimal use of the audio system ........................................... 319
Audio settings .............................320
Audio menu screen operation .................................... 323
5-4. Using the radio Radio operation.......................... 326
Lexus DisplayAudio system
5
Page 299 of 648
299
Lexus DisplayAudio system
5
IS350/300/200t_U (OM53D76U)
5-5. Playing an audio CD and MP3/WMA/AAC discs
CD player operation ................332
5-6. Using an external device Listening to an iPod ...................339
Using USB memory device...........................................343
Using the AUX port ................. 347
5-7. Connecting Bluetooth
®
Steps for using Bluetooth®
devices ........................................ 348
Registering a Bluetooth
®
device.......................................... 350
Selecting a Bluetooth
®
device............................................ 351
Connecting a Bluetooth
®
audio player ...............................352
Connecting a Bluetooth
®
phone .......................................... 353
Displaying a Bluetooth
®
device details ............................354
Detailed Bluetooth
®
settings........................................ 355
5-8. Bluetooth
® Audio
Listening to Bluetooth
®
Audio........................................... 358 5-9. Bluetooth
® Phone
Using a Bluetooth
®
Phone ...........................................359
Making a call ................................. 361
Receiving a call ........................... 364
Speaking on the phone............365
Using a Bluetooth
®
phone message........................ 367
Using the steering wheel switches....................................... 369
Bluetooth
® phone
settings ........................................ 370
5-10. Phonebook Contact settings ......................... 372
Messaging setting...................... 375
5-11. Bluetooth
®
What to do if... (Troubleshooting)................... 376
Bluetooth
®.................................. 380
5-12. Other function “Information” screen.................385
USB photo .................................... 387
Weather information................389
Voice command system .........390
Page 309 of 648
3095-1. Basic Operations
5
Lexus Display Audio system
IS350/300/200t_U (OM53D76U)
■iPod
Open the cover and connect an
iPod using an iPod cable.
Turn on the power of the iPod if it is
not turned on.
■USB memory
Open the cover and connect the USB memory device.
Turn on the power, if applicable, of the USB memory device if it is not turned on.
■Portable audio player
Open the cover and connect the portable audio player.
Turn on the power of the portable audio player if it is not turned on.
USB/AUX ports
Connect an iPod, USB memory device or portable audio player to the USB/
AUX port as indicated below. Select “iPod”, “USB”, “AUX” or “External” on
the audio source selection screen and the device can be operated via Lexus
Display Audio system.
Connecting using the USB/AUX port
Page 310 of 648
3105-1. Basic Operations
IS350/300/200t_U (OM53D76U)
To view a video on an iPod video or VTR, it is necessary to use a 4-pole AUX
cable to connect the portable audio device.
When connecting a portable audio devi ce to the AUX port, use a 4-pole AUX
cable with a plug that matches the ex act layout shown in the illustration.
Connected device (portable audio
device, etc.)
Left audio
Right audio
Ground
Video
When using an iPod video, a cable
that has a 4-pole AUX plug and a
USB connector is necessary. Con-
nect the plug and connector to the
AUX and USB ports.
Using a 4-pole AUX cable
1
2
3
4
5
Page 346 of 648
3465-6. Using an external device
IS350/300/200t_U (OM53D76U)
●MP3, WMA and AAC playback
• When a device containing MP3, WMA or AA C files is connected, all files in the
USB memory device are checked. Once th e file check is finished, the first MP3,
WMA or AAC file is played. To make the file check finish more quickly, we recom-
mend that you do not include any files other than MP3, WMA or AAC files or cre-
ate any unnecessary folders.
• When a USB memory device is connected and the audio source is changed to USB memory mode, the USB memory device will st art playing the first file in the first
folder. If the same device is removed an d reconnected (and the contents have not
been changed), the USB memory device w ill resume play from the same point in
which it was last used.
●Extensions
If the file extensions .mp3, .wma and .m4a are used for files other than MP3, WMA
and AAC files, they will be skipped (not played).
●Playback
• To play MP3 files with steady sound quality, we recommend a fixed bit rate of at least 128 kbps and a sampling frequency of 44.1 kHz.
• There is a wide variety of freeware an d other encoding software for MP3, WMA
and AAC files on the market, and depending on the status of the encoding and the
file format, poor sound quality or noise at the start of playback may result. In some
cases, playback may not be possible at all.
• Microsoft, Windows, and Windows Media ar e the registered trademarks of Micro-
soft Corporation in the U.S.A. and other countries.
NOTICE
■To prevent damage to the USB me mory device or its terminals
●Depending on the size and shape of the USB memory that is connected to the sys-
tem, the console box may not close fully. In th is case, do not forcibly close the console
box as this may damage the USB memory or the terminal, etc.
●Do not leave the USB memory device in the vehicle. The temperature inside the vehi-
cle may become high.
●Do not push down on or apply unnecessary pressure to the USB memory device
while it is connected.
●Do not insert foreign objects into the port.
Page 385 of 648
385
5
Lexus Display Audio system
IS350/300/200t_U (OM53D76U)5-12. Other function
Go to “Information”: “MENU” button →
“Info”
Display the fuel consumption.
(→ P. 100)
Display the “USB Photo” screen.
(→ P. 387)
Display the Traffic Map picture.
Available when in a traffic supported
HD Radio coverage area
Display the weather information.
(→ P. 389)
Go to “Traffic Map”: “MENU” button → “Info” →“Traffic Incidents”
Current position of your car
Traffic information line
The line color means the following:
Red: Heavy congestion
Yellow: Moderate traffic
Green: Free flowing traffic
“Information” screen
Display “Information” screen
1
2
3
4
Traffic information map
1
2
Page 631 of 648
631Alphabetical index
IS350/300/200t_U (OM53D76U)
Alarm ............................................................ 70
Anchor brackets ...................................... 57
Antennas (smart access system with push-button start) ...................... 122
Anti-lock Brake System (ABS)....... 289 Warning light ........................................ 516
Approach warning (dynamic radar cruise control) ........................ 243
Armrest .................................................... 423
ASC (Active Sound Control) ...........187
Assist grip ................................................ 425
Audio input.............................................. 309
Audio system..........................................300 Audio input........................................... 309
AUX port/USB port....................... 309
Bluetooth
® audio.............................. 358
CD player .............................................. 332
iPod ...........................................................339
MP3/WMA/AAC disc ................. 332
Optimal use ........................................... 319
Portable music player ...................... 347
Radio ........................................................326
Steering wheel audio switch ....... 306
USB memory .......................................343 Automatic headlight leveling
system ......................................................190
Automatic High Beam ......................... 192
Automatic light control system ..................................................... 188
Automatic transmission....................... 177 If the shift lever cannot be shifted from P ..............182
M mode ................................................... 180
Paddle shift switches.......................... 179
AUX port ................................................ 309
Average fuel economy............................. 100, 101, 103
Average vehicle speed....................... 100
Page 646 of 648
646Alphabetical index
IS350/300/200t_U (OM53D76U)
Trip meters ..................................................79
Trunk............................................................. 117Internal trunk release lever............... 119
Luggage security system .................. 118
Smart access system with push-button start ..................... 117
Trunk features ....................................... 419
Trunk handle............................................ 118
Trunk light ................................................. 119
Trunk opener main switch................ 118
Trunk opener switch ........................... 117
Wireless remote control ................... 117
Trunk light ................................................... 119 Wattage ................................................. 586
Turn signal lights .................................... 184 Replacing light bulbs............................ 499, 500, 502
Turn signal lever .................................. 184
Wattage ................................................. 586
Units .............................................................. 92
USB device ..................................343, 387 Connecting .......................................... 309
USB audio .............................................343
USB photo ............................................387
USB port .................................................. 309 Vanity lights
Vanity lights ............................................ 421
Wattage ................................................ 586
Vanity mirrors.......................................... 421
VDIM (Vehicle Dynamics Integrated Management).............. 290
Vehicle data recordings...........................9
Vehicle Dynamics Integrated Management (VDIM)..................... 290
Vehicle identification number .........575
Vehicle Stability Control (VSC)..................................................... 289
Ventilators (seat ventilators) ...............411
Voice command system.................... 390
VSC (Vehicle Stability Control) ............ 289
U
V
