high beam Lexus IS300 2017 Owner's Manual / LEXUS 2017 IS200T,IS300,IS350 OWNER'S MANUAL (OM53D76U)

3
1
9 8
7 5 4
3
2
10
IS350/300/200t_U (OM53D76U)
6
4-1. Before driving Driving the vehicle ..................... 158
Cargo and luggage ....................166
Vehicle load limits .......................169
Trailer towing ................................170
Dinghy towing ................................ 171
4-2. Driving procedures Engine (ign ition) switch ............. 172
Automatic transmission ............ 177
Turn signal lever .......................... 184
Parking brake ............................... 186
ASC (Active Sound Control) .........187
4-3. Operating the lights and wipers
Headlight switch ......................... 188
Automatic High Beam...............192
Windshield wipers and washer ...........................................196
4-4. Refueling Opening the fuel tank cap ..... 203 4-5. Using the driving support
systems
Lexus Safety System+ .............. 207
PCS (Pre-Collision System) ........... 214
LDA (Lane Departure Alert with steering co ntrol) .............227
Dynamic radar cruise control ......................................... 236
Intuitive parking assist.............. 248
Lexus parking assist monitor........................................ 257
BSM (Blind Spot Monitor) ............. 273
• BSM function.......................... 277
• RCTA function......................280
Driving mode select switch ... 285
Driving assist systems .............. 289
4-6. Driving tips Winter driving tips..................... 294
4Driving

18Pictorial index
IS350/300/200t_U (OM53D76U)
■Switches
Automatic high beam switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 192
Windshield wiper de-icer switch
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 406
ASC (Active Sound Control) switch
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 187
Odometer/trip meter and trip meter reset button . . . . . . . . . . . . . . . . . . P. 88
Instrument panel light control swit ches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 82
Rear sunshade switch
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 423
Intuitive parking assist switch
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 248
BSM (Blind Spot Monitor) main switch
*. . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 273
1
2
3
4
5
6
7
8

762. Instrument cluster
IS350/300/200t_U (OM53D76U)
*1: These lights turn on when the engine switch is turned to IGNITION ON mode to indicate that a system check is being performed. They will turn off after the engine is
started, or after a few seconds. There may be a malfunction in a system if a light does
not come on, or turn off. Have the ve hicle inspected by your Lexus dealer.
*2: The light flashes to indicate a malfunction.
*3: This light illuminates on the center panel.
The indicators inform the driver of the op erating state of the vehicle’s various sys-
tems.
*1Tire pressure warning light
( → P. 518)
Indicators
Turn signal indicator
(→ P. 184) LDA (Lane Departure
Alert) indicator (
→P. 227)
(U.S.A.)
Headlight indicator
(→ P. 188) LDA (Lane Departure
Alert) indicator (
→P. 227)
(Canada)
Tail light indicator
(→ P. 188) *2LDA (Lane Departure
Alert) indicator ( →P. 227)
Headlight high beam indi-
cator (→ P. 189)
(if equipped)
Intuitive parkin g assist indi-
cator ( →P. 248)
*1Automatic High Beam indi-
cator (→ P. 192)*1, 2
Slip indicator ( →P. 290)
Cruise control indicator
( → P. 236)
*1VSC OFF indicator
(→ P. 291)
Dynamic radar cruise con-
trol indicator ( →P. 236)
*1, 3PCS warning light
(→ P. 218)
Cruise control “SET” indica-
tor (→ P. 236)
*1
(if equipped)
“AFS OFF” indicator
(→ P. 189)

157
Driving4
IS350/300/200t_U (OM53D76U)
4-1. Before drivingDriving the vehicle ......................158
Cargo and luggage .................... 166
Vehicle load limits ....................... 169
Trailer towing ................................ 170
Dinghy towing ................................ 171
4-2. Driving procedures Engine (ignition) switch ............ 172
Automatic transmission.............177
Turn signal lever........................... 184
Parking brake ............................... 186
ASC (Active Sound Control)......... 187
4-3. Operating the lights and wipers
Headlight switch ..........................188
Automatic High Beam .............. 192
Windshield wipers and washer........................................... 196
4-4. Refueling Opening the fuel tank cap..... 203 4-5. Using the driving
support systems
Lexus Safety System+ .............. 207
PCS (Pre-Collision System) ...........214
LDA (Lane Departure Alert with steering
control)........................................ 227
Dynamic radar cruise control ......................................... 236
Intuitive parking assist .............. 248
Lexus parking assist monitor ........................................ 257
BSM (Blind Spot Monitor) ..... 273 • BSM function ..........................277
• RCTA function......................280
Driving mode select switch ...........................................285
Driving assist systems ..............289
4-6. Driving tips Winter driving tips ..................... 294

1894-3. Operating the lights and wipers
4
Driving
IS350/300/200t_U (OM53D76U)
With the headlights on, push the
lever away from you to turn on the
high beams.
Pull the lever toward you to the center
position to turn the high beams off.
Pull the lever toward you and release
it to flash the high beams once.
You can flash the high beams with the
headlights on or off.
AFS (Adaptive Front-lighting System) secures excellent visibility at intersections
and on curves by automatically adjusting the direction of the light axis of the
headlights according to vehicle speed and the degree of the tire’s angle as con-
trolled by steering input.
AFS operates at speeds of 6 mph (10 km/h) or higher.
■Deactivating AFS
Settings can be changed from on the multi-information display
(→ P. 84).
The indicator turns on when the AFS
is deactivated.
Turning on the high beam headlights
1
2
AFS (Adaptive Front-lighting System) (if equipped)

1924-3. Operating the lights and wipers
IS350/300/200t_U (OM53D76U)
Push the lever away from you with
the headlight switch in the or position.
Press the Automatic High Beam
switch.
The Automatic High Beam indicator will
come on when the system is operating.
Automatic High Beam
The Automatic High Beam uses a came ra sensor located behind the upper
portion of the windshield to assess the brightness of the lights of vehicles
ahead, streetlights, etc., and automatica lly turns the high beams on or off as
necessary.
WARNING
■Limitations of the Automatic High Beam
Do not overly rely on the Automatic High Beam. Always drive safely, taking care to
observe your surroundings and turning the hi gh beams on or off manually if necessary.
■To prevent incorrect operation of the Automatic High Beam system
Do not overload the vehicle.
Activating the Automatic High Beam
1
2

1934-3. Operating the lights and wipers
4
Driving
IS350/300/200t_U (OM53D76U)
■Switching to the low beams
Pull the lever to its original position.
The Automatic High Beam indicator
will turn off.
Push the lever away from you to acti-
vate the Automatic High Beam sys-
tem again.
■Switching to the high beams
Press the Automatic High Beam
switch.
The Automatic High Beam indicator
will turn off and the high beam indi-
cator will turn on.
Press the switch to activate the Auto-
matic High Beam system again.
Turning the high beams on/off manually

1944-3. Operating the lights and wipers
IS350/300/200t_U (OM53D76U)
■Conditions to turn the high beams on/off automatically
●When all of the following conditions are met, the high beams will be turned on automat-
ically (after approximately 1 second):
• The vehicle speed is approximately 21 mph (34 km/h) or more.
• The area ahead of the vehicle is dark.
• There are no vehicles ahead with headlights or tail lights turned on.
• There are few streetlights on the road ahead.
●If any of the following condit ions is met, the high beams will turn off automatically:
• The vehicle speed is below ap proximately 17 mph (27 km/h).
• The area ahead of the vehicle is not dark.
• Vehicles ahead have th eir headlights or tail lights turned on.
• There are many streetlights on the road ahead.
■Camera sensor detection information
●The high beams may not be automatically turned off in the following situations:
• When a vehicle suddenly appears from around a curve
• When the vehicle is cut in front of by another vehicle
• When vehicles ahead cannot be detected du e to repeated curves, road dividers or
roadside trees
• When vehicles ahead appear in a faraway lane on a wide road
• When the lights of vehicles ahead are not on
●The high beams may be turned off if a vehicl e ahead that is using fog lights without its
headlights turned on is detected.
●House lights, street lights, traffic signals, and illuminated billboards or signs and other
reflective objects may cause the high beams to change to the low beams, or the low
beams to remain on.
●The following factors may affect the amount of time taken for the high beams to turn on
or off:
• The brightness of the headlights, fog lights, and tail lights of vehicles ahead
• The movement and direction of vehicles ahead
• When a vehicle ahead only has operational lights on one side
• When a vehicle ahead is a two-wheeled vehicle
• The condition of the road (gradient, cu rve, condition of the road surface, etc.)
• The number of passengers and amount of luggage in the vehicle
●The high beams may turn on or off unexpectedly.

1954-3. Operating the lights and wipers
4
Driving
IS350/300/200t_U (OM53D76U)
●Bicycles or similar vehicles may not be detected.
●In the following situations the system may not be able to correctly detect the surround-
ing brightness level. This may cause the low beams to remain on or the high beams to
flash or dazzle pedestrians or vehicles ahead. In such a case, it is necessary to manually
switch between the high and low beams.
• When driving in inclement weather (heavy rain, snow, fog, sandstorms, etc.)
• When the windshield is obscured by fog, mist, ice, dirt, etc.
• When the windshield is cracked or damaged
• When the camera sensor is deformed or dirty
• When the temperature of the camera sensor is extremely high
• When the surrounding brightness level is equal to that of headlights, tail lights or fog
lights
• When headlights or tail lights of vehicles ahead are turned off, dirty, changing color,
or not aimed properly
• When the vehicle is hit by water, snow, dust, etc. from a preceding vehicle
• When driving through an area of intermittently changing brightness and darkness
• When frequently and repeated ly driving ascending/descending roads, or roads with
rough, bumpy or uneven surfaces (such as stone-paved roads, gravel roads, etc.)
• When frequently and repeatedly taking curves or driving on a winding road
• When there is a highly reflective object ahea d of the vehicle, such as a sign or mirror
• When the back of a preceding vehicle is highly reflective, such as a container on a
truck
• When the vehicle's headlights are damaged or dirty, or are not aimed properly
• When the vehicle is listing or titling due to a flat tire, a trailer being towed, etc.
• When the headlights are changed between the high beams and low beams repeat- edly in an abnormal manner
• When the driver believes that the high beams may be flashing or dazzling pedestri-
ans or other drivers
■Temporarily lowering sensor sensitivity
The sensitivity of the sensor can be temporarily lowered.
Turn the engine switch off while the following conditions are met.
• The headlight switch is in or .
• The headlight switch lever is in high beam position.
• Automatic High Beam switch is on.
Turn the engine switch to IGNITION ON mode.
Within 30 seconds after , repeat pulling th e headlight switch lever to the original
position then pushing it to the high beam position quickly 10 times, then leave the lever
in high beam position.
If the sensitivity is changed, the Automatic High Beam indicator is turn on and off 3
times.
Automatic High Beam (head lights) may turn on even the vehicle is stopped.
1
2
32
4

207
4
Driving
IS350/300/200t_U (OM53D76U)4-5. Using the driving support systems
◆PCS (Pre-Collision System)
→
P. 214
◆LDA (Lane Departure Alert with steering control)
→P. 227
◆Automatic High Beam
→P. 192
◆Dynamic radar cruise control
→P. 236
Lexus Safety System+
The Lexus Safety System+ consists of the following drive assist systems and
contributes to a safe and comfo rtable driving experience:
WARNING
■Lexus Safety System+
The Lexus Safety System+ is designed to operate under the assumption that the driver
will drive safely, and is designed to help reduce the impact to the occupants and the
vehicle in the case of a collision or assist the driver in normal driving conditions.
As there is a limit to the degree of reco gnition accuracy and control performance that
this system can provide, do not overly rely on this system. The driver is always responsi-
ble for paying attention to the vehicle's surroundings and driving safely.
