clock Lexus IS300 2020 / LEXUS 2020 IS300,IS350 (OM53F29U) User Guide

5087-3. Do-it-yourself maintenance
IS350 AWD/IS350/IS300 AWD/IS300_U
■Front turn signal lights (bulb type) For the left side only: Pinch the
clip to remove the washer fluid
filler opening.
Turn the bulb base counterclock-
wise.
Remove the light bulb.
Install a new light bulb then install
the bulb base to the light unit by
inserting it and turning the bulb
base clockwise.
After installing the light bulb, turn on
the front turn signal light to visually
check that there is no light leaking
from the bulb base.
After replacing the left side bulb, install the washer fluid filler opening to its
original position.
Replacing light bulbs
1
2
3
4
5

5097-3. Do-it-yourself maintenance
7
Maintenance and care
IS350 AWD/IS350/IS300 AWD/IS300_U
■Rear turn signal lightsOpen the trunk, and remove the
cover.
Remove the 2 screws.
Push and pull the light unit toward
the rear of the vehicle as shown in
the illustration to remove it.
Apply protective tape to the periph-
eral of the light un it installation sur-
face on the vehicle body, such as the
rear bumper, to protect the vehicle
from damage.
Pushing on the portion A in the illus-
tration toward the rear of the vehicle
will make disengagement of the tabs
easier.
Turn the bulb base counterclock-
wise.
1
2
3
4

5107-3. Do-it-yourself maintenance
IS350 AWD/IS350/IS300 AWD/IS300_U
Remove the light bulb.
Install a new light bulb then install
the bulb base to the light unit by
inserting it and turning the bulb
base clockwise.
After installing the light bulb, turn on
the rear turn signal light to visually
check that there is no light leaking
from the bulb base.
Align the tabs and push the light
unit toward the front of the vehicle
to install it.
Remove the protective tape applied
to the peripheral of the light unit
installation surface on the vehicle
body.
Install the 2 screws and cover.
5
6
7
8

5728-2. Steps to take in an emergency
IS350 AWD/IS350/IS300 AWD/IS300_U
■Doors
Use the mechanical key (P. 119) in
order to perform the following oper-
ations:
Locks all the doors
Closes the windows and moon
roof (turn and hold)
*
Unlocks the door
Turning the key rearward unlocks the
driver’s door. Turning the key once
again within 5 seconds unlocks the
other doors.
Opens the windows and moon roof (turn and hold)*
*
: This setting must be custom ized at your Lexus dealer.
■Trunk
Turn the mechanical key clockwise
to open. (P. 79)
If the electronic key does not operate properly
If communication between the electron ic key and vehicle is interrupted (P.
137) or the electronic key cannot be us ed because the battery is depleted, the
smart access system with push-button st art and wireless remote control can-
not be used. In such cases, the doors and trunk can be opened and the engine
can be started by follow ing the procedure below.
Locking and unlocking the doors, unlocking the trunk and key linked
functions
1
2
3
4

643Alphabetical index
IS350 AWD/IS350/IS300 AWD/IS300_U
Child safety ................................................ 52Airbag precautions ..............................38
Battery precautions ............. 483, 578
Child restraint system ......................... 53
How your child should wear the seat belt .......................................... 32
Installing child restraints..................... 57
Moon roof precautions.................... 169
Power window lock switch ............ 162
Power window precautions .......... 165
Rear door child-p rotectors ............ 127
Removed electronic key battery precautions.............. 503
Seat belt extender precautions ........................................... 35
Seat belt precautions ..........................56
Seat heater precautions..................426
Trunk precautions............................... 133
Child-protectors..................................... 127 Cleaning .......................................454, 458
Aluminum wheels ..............................455
Exterior ................................................... 454
Interior .....................................................458
Seat belts................................................ 459
Clock..........................................................437
Coat hooks ............................................... 441
Compass ..................................................449
Condenser.............................................. 480
Console box ............................................432
Cooling system ......................................478 Engine overheating .......................... 579
Cruise control Dynamic radar cruise control ..... 248
Cup holders............................................ 433
Current fuel consumption .................................. 112, 113
Curtain shield airbags ............................36
Customizable features ........................ 613
