fold seats Lexus IS350 2021 Owner's Manual / LEXUS 2021 IS 300, IS 350 OWNER'S MANUAL (OM53E98U)

1063-3. Adjusting the seats
3-3.Adjusting the seats
Seat position adjustment
Seatback angle adjustment
Seat cushion (front) angle adjust-
ment
Seat cushion (rear) angle adjust-
ment
Lumbar support adjustment (if
equipped)
■Power easy access system (if equipped)
The driver’s seat and steering wheel move
in accordance with engine switch mode and
the driver’s seat belt condition. ( P.108)
■When adjusting the seat
●Take care when adjusting the seat so that
the head restraint does not touch the ceil-
ing.
●When folding down a rear seatback, if it
interferes with a front seatback, adjust the
front seat position so that the seats no
longer interfere with each other. How-
ever, if adjusting the front seat position
causes the correct driving posture to not
be maintained, return the rear seatback
to its original position. ( P.107)
Front seats
WARNING
■When adjusting the seat position
●Take care when ad justing the seat
position to ensure that other passen-
gers are not injured by the moving
seat.
●Do not put your hands under the seat
or near the moving parts to avoid
injury.
Fingers or hands may become
jammed in the se at mechanism.
●Make sure to leave enough space
around the feet so they do not get
stuck.
■Seat adjustment
To reduce the risk of sliding under the lap
belt during a collision, do not recline the
seat more than necessary.
If the seat is too reclined, the lap belt may
slide past the hips and apply restraint
forces directly to the abdomen, or your
neck may contact the shoulder belt,
increasing the risk of death or serious
injury in the event of an accident.
Adjustments should not be made while
driving as the seat may unexpectedly
move and cause the driver to lose control
of the vehicle.
Adjustment procedure
A
B
C
D
E

1073-3. Adjusting the seats
3
Before driving
1Check that the luggage security
system lever in the trunk is in the
unlock position.
2 Pull the seatback lock release lever
and fold the seatback down.
To return the rear seatbacks to their origi-
nal position, lift them up until they lock.
P.98
Rear seats
The rear seatbacks can be folded
down.
WARNING
Observe the following precautions. Fail-
ure to do so may result in death or seri-
ous injury.
■When folding the rear seatbacks
down
●Do not fold the seatbacks down while
driving.
●Stop the vehicle on level ground, set
the parking brake and shift the shift
lever to P.
●Do not allow anyone to sit on a folded
seatback or in the trunk while driving.
●Do not allow children to enter the
trunk.
■After returning the rear seatback to
the upright position
●Make sure that the seatback is
securely locked in position by lightly
pushing it back and forth.
If the seatback is not securely locked,
the red marking will be visible on the
seatback lock release knob. Make sure
that the red marking is not visible.
●Check that the seat belts are not
twisted or caught in the seatback.
Folding down the rear seatbacks
Luggage security system

1314-1. Before driving
4
Driving
*3: C =Available cargo and luggage load
In this condition, if 3 more passengers with
the combined weight of D lb. (kg) get on,
the available cargo and luggage load will
be reduced E lb. (kg) as follows:
C lb. (kg) - D*4 lb. (kg) = E*5 lb. (kg)
*4: D =Additional weight of people
*5: E =Available cargo and luggage load
As shown in the example above, if the
number of occupants increases, the
cargo and luggage load will be
reduced by an amount that equals the
increased weight due to the additional
occupants. In other words, if an
increase in the number of occupants
causes an excess of the total load
capacity (combined weight of occu-
pants plus cargo and luggage load),
you must reduce the cargo and lug-
gage on your vehicle.
WARNING
■Things that must not be carried in the
trunk
The following things may cause a fire if
loaded in the trunk:
●Receptacles containing gasoline
●Aerosol cans
■Storage precautions
Observe the following precautions.
Failure to do so may prevent the pedals
from being depressed properly, may
block the driver’s vision, or may result in
items hitting the driver or passengers,
possibly causing an accident.
●Stow cargo and luggage in the trunk
whenever possible.
●To prevent cargo and luggage from
sliding forward during braking, do not
stack anything in th e enlarged trunk.
Keep cargo and luggage low, as close
to the floor as possible.
●When you fold down the rear seats,
long items should not be placed
directly behind the front seats.
●Never allow anyone to ride in the
enlarged trunk. It is not designed for
passengers. They should ride in their
seats with thei r seat belts properly fas-
tened.
●Do not place cargo or luggage in or on
the following locations.
• At the feet of the driver
• On the front passenger or rear seats (when stacking items)
• On the package tray
• On the instrument panel
•On the dashboard
• In front of the Center Display
●Secure all items in the occupant com-
partment.
■Capacity and distribution
●Do not exceed the maximum axle
weight rating or the total vehicle
weight rating.
●Even if the total load of occupant’s
weight and the cargo load is less than
the total load capacity, do not apply the
load unevenly. Improper loading may
cause deterioration of steering or
braking control which may cause
death or serious injury.

429Alphabetical Index
Pregnant women, proper seat belt use.............................................................................24
Reminder light and buzzer ...................340
Seat belt extender ........................................ 25
Seat belt pretensioners ...............................27
SRS warning light ......................................338
Seat heaters ..................................................... 261
Seat position memory................................. 108
Seat ventilators ............................................... 261
Seating capacity.............................................132
Seats Adjustment..................................................... 106
Adjustment precautions .......................... 106
Child seats/child restraint system installa-tion ...................................................................... 41
Cleaning......................................................... 283
Driving position memory........................ 108
Head restraints ................................................ 111
Power easy access system .................... 108
Properly sitting in the seat .........................23
Seat heaters .................................................... 261
Seat position memory .............................. 108
Seat ventilators.............................................. 261
Sensor Automatic headlight system...................149
Automatic High Beam system............... 151
Inside rear view mirror............................... 115
Intuitive parking assist................................210
LTA (Lane Tracing Assist)..................... 180
Parking Support Brake function (rear-crossing vehicles)...................... 232
Parking Support Brake function (static objects).........................................................227
Radar sensor..................................... 164, 204
Rain-sensing windshield wipers.......... 159
RCTA ................................................................ 217
Service reminder message ..................... 286
Shift lever Automatic transmission ........................... 138
Side airbags ...................................................... 28
Side marker lights Light switch .....................................................149 Replacing light bulbs ................................ 322
Side mirrors Adjustment ....................................................... 116
BSM (Blind Sport Monitor)..................202
Folding................................................................ 117
Linked mirror functi on when reversing
............................................................................. 116
Mirror position memory ..........................108
RCTA function ..............................................216
Side turn signal lights Replacing light bulbs ................................ 322
Turn signal lever ...........................................142
Side windows ................................................... 118
Smart access system with push-button startAntenna location ........................................... 99
Entry functions ................................................ 92
Starting the engine ......................................134
Snow mode ..................................................... 140
Snow tires ....................................................... 243
Spare tire......................................................... 349 Storage location ........................................ 350
Spark plug ...................................................... 376
Specifications ................................................ 372
Speedometer .................................... 71, 72, 80
Steering lock Column lock release ..................................134
Steering lock system warning message............................................................................134
Steering wheel Adjustment ....................................................... 113
Heated steering wheel ..............................261
Meter control switches ...............................77
Power easy access system .................... 108
Steering wheel position memory........108
Stop lights Replacing light bulbs ................................ 322
Storage features .......................................... 266
Stuck If the vehicle becomes stuck ............... 368
Sun visors .......................................................... 271
