9
LC500_QG_OM11518U_(U)
Meter control switches .......................................................................................... P.32
Paddle shift switches ........................................................................................ P.26, 27
Telephone switch...................................................................................................... P.66
LKA (Lane-Keeping Assist) switch ...................................................................... P.41
Vehicle-to-vehicle distance switch ..................................................................... P.44
Cruise control switches
Dynamic radar cruise control with full-speed range .............................................P.42
Audio remote control switches ............................................................................ P.68
Talk switch .................................................................................................................. P.66A
B
C
D
E
F
G
H

10
LC500_QG_OM11518U_(U)
Audio control switches ........................................................................................... P.67
Remote Touch ........................................................................................................... P.55
Roof switch ................................................................................................................. P.54
All window control switch
*
P position switch........................................................................................................ P.25
Brake hold switch ...................................................................................................... P.31
*: Refer to the “OWNER’S MANUAL”.
A
B
C
D
E
F

14
LC500_QG_OM11518U_(U)
●Smart access system with push-button
start ( P.16)
● Wireless remote control
To take out the mechanical key, push the
release button and take the key out.
The mechanical key can only be inserted in
one direction, as the key only has grooves
on one side. If the key cannot be inserted in
a lock cylinder, turn it over and re-attempt
to insert it.
After using the mechani cal key, store it in
the electronic key. Carry the mechanical
key together with the electronic key. If the
electronic key battery is depleted or the
entry function does not operate properly,
you will need the mechanical key.
Keys
Electronic key
Mechanical key

15
LC500_QG_OM11518U_(U)
Locks the doors
Unlocks the doors
Opens the windows (press and hold)
*
Opens the trunk
Sounds the alarm
*: This setting must be customized at yourLexus dealer.
Wireless remote control
A
B
C
D
E

17
LC500_QG_OM11518U_(U)
Press the button.
When both side doors are unlocked using
one of the following methods, the trunk can
be opened without the electronic key:
• Entry function
• Wireless remote control
• Door lock switches
• Automatic door unlocking system
• Mechanical key
Opening the trunk
For details on what to do when the electronic key does not operate properly, see page 101.

56
LC500_QG_OM11518U_(U)
Press the “MENU” button on the Remote Touch to display the menu screen.
Menu screen
SwitchFunction
Select to display the destination screen. (P.61)
Select to display the audio control screen. ( P.71, 72, 73)
Select to display the hand s-free control screen. (P.65)
Select to display the “Apps” screen.*1, 2
/
/When an Apple CarPlay/Android Auto connection is established and this
button displays “Apple CarPlay”/”An droid Auto”, select to display the
home screen of Apple CarPlay/Android Auto.
*1, 2
Select to display the information screen. ( P.59)
Select to display the setup screen.*2, 3
Select to display the air co nditioning control screen. ( P.76)

67
LC500_QG_OM11518U_(U)
The audio control screen can be reached by the following methods:
Using the audio control switch
Press the “RADIO” or “MEDIA” button.
 Using the Remote Touch
Press the “MENU” button on the Remote Touch, then select “Audio”.
 Using the audio control switch
1Press the “RADIO” or “MEDIA” button.
2“RADIO” button: Press to change
radio modes.
“MEDIA” button: Press to change
media modes.
Each time the “RADIO” or “MEDIA”
button is pressed, the audio source
changes.
 From the audio source selection screen
1Display the audio control screen.
2Select “Source” on the sub menu.
3Select the desired source.
Audio System
Audio control screen
Selecting an audio source

74
LC500_QG_OM11518U_(U)
Press the “MENU” button on the Remote Touch and select “Climate” to display the air con-
ditioning control screen. Then, select on the sub menu to display the Lexus Climate
Concierge control screen.
Select .
The indicator on the Lexus Climate Con-
cierge control screen illuminates and all of
the following systems operate in automatic
mode.
●Air conditioning system
● Seat heaters and ventilators
● Heated steering wheel (if equipped)
● Neck heaters (if equipped)
If any of the system is operated manually, the indicator turns off. However, all other functions
continue to operate in automatic mode.
Lexus Climate Concierge
The seat heaters, seat ventilators and, heated steering wheel (if equipped) and neck heat-
ers (if equipped) are each automatically controlled according to the set temperature of
the air conditioning system, the outside and cabin temperature, etc. Lexus Climate Con-
cierge allows a comfortable condition to be maintained without adjusting each system.
Displaying the Lexus Climate Concierge
Turning on Lexus Climate Concierge

75
LC500_QG_OM11518U_(U)
Automatic mode switch
Off switch
Left-hand side temperature control switch
Fan speed control switch
Outside/recirculated air mode switch
Right-hand side temperature control switch
Windshield defogger switch
Rear window and outside rear view mirror defoggers switch
■Adjusting the temperature
Operate the temperature control switch upwards to increase the temperature and down-
wards to decrease the temperature.
If the “A/C” indicator is turned off, the system will blow ambient temperature air or heated
air.
■Setting the fan speed
Operate the fan speed control switch upwards to increase the fan speed and downwards
to decrease the fan speed.
Press the off switch to turn the fan off.
■Changing the air flow mode
P.76
Air Conditioning System
Press the “MENU” button on the Remote Touch, then select “Climate” to display the air
conditioning control screen.
Control panel
A
B
C
D
E
F
G
H

76
LC500_QG_OM11518U_(U)
■Main control screen
Using the touchpad of the Remote Touch, select the button on the screen. to can be adjusted by performing the following operations.
Flick operation: Move the poin ter to the desired item and flick the touchpad up or down.
The item can be adjusted by one level.
Trace operation: After selecting the desired item, trace the pad surface.
The item can be adjusted by the amount that you trace.
Trace operation cannot be used while driving.
Sub menu
Selecting the sub menu item to switch
the main screen.
: Display the air conditioning con-
trol screen
: Display the heated steering
wheel (if equipped)/seat heater/seat
ventilator control screen
: Display the neck heater control
screen (if equipped)
: Display the Lexus Climate Con-
cierge control screen
: Display the option control
screen
Adjust the left-hand side temperature setting
Adjust the fan speed setting
Select the air flow mode
: Air flows to the upper body
: Air flows to the upper body and feet
: Air flows to the feet
: Air flows to the feet and the windshield defogger operates
Air conditioning control screen
BE
A
B
C
D
