9
Anti-glare inside rear view
mirror
P. 42
Power outlet
P. 214
Bottle holder P. 211
USB port , *
AUX port , *
Tilt sensor cancel
switch
P. 56
Interior lights
Down light
“SOS” button
*, 
P. 207
P. 207
P. 219
Vanity mirror
Sun visors P. 213
P. 213
Tire pressure gauge
P. 278
Penlight P. 211
: If equipped
*: Refer to the “Navigation System Owner’s Manual”.

10
Pictorial index
With navigation system
Without navigation system
Navigation
system
*
Rear view monitor
system
P. 163
Talk switch
*P. 191
Emergency flasher
switch
P. 302
Air conditioning
system
P. 186
Audio system
*P. 202
Emergency flasher
switch
P. 302
Interior
Air conditioning
system
P. 194
Air conditioning
system
P. 194
Air conditioning
system
P. 186

11
: If equipped
*: Refer to the “Navigation System Owner’s Manual”.
Rear window and outside rear view
mirror defoggers
P. 201
Door lock switch
P. 25
Remote Touch 

*P. 187
Power window switches
P. 46
Air conditioning system P. 186, 194

12
Pictorial index
Gauges and
meters
P. 116, 124
Paddle shift switches P. 102
“ENGINE START” switch P. 98
Glove box P. 210
Floor mats P. 215
Parking brake switch P. 113
Tilt and telescopic steering
lock release lever
P. 41
Horn P. 115
Instrument panel
Control pad P. 125

13
Driving mode selector switch P. 105
AUTO driving mode button P. 105
Shift speed selector P. 107
Intermittent wiper interval adjuster
P. 160
Windshield wiper and washer lever
P. 160
Ignition switch P. 98
Headlight switch P. 158
Reverse selector switch P. 103
Turn signal lever
Headlights low/high beam selectorP. 112
P. 158

14
Pictorial indexInstrument panel
Fuel filler door openerswitch
P. 49
Hood lock release lever P. 250
VSC off switch P. 167
Rear hatch opener switch P. 29
Outside rear view mirror switches
P. 43

15
For your information
Main Owner’s Manual
Please note that this manual applies to all models and explains all equipment, includ-
ing options. Therefore, you may find some explanations for equipment not installed
on your vehicle.
All specifications provided in this manual are current at the time of printing. How-
ever, because of the Lexus policy of continual product improvement, we reserve the
right to make changes at any time without notice.
Depending on specifications, the vehicle sh own in the illustration may differ from
your vehicle in terms of color and equipment.
Noise from under vehicle after turning off the engine
Approximately five hours after the engine is turned off, you may hear sound coming
from under the vehicle for several minutes. This is the sound of a fuel evaporation
leakage check and, it does not indicate a malfunction.
Installation of a mobile two-way radio system
As the installation of a mobile two-way radio system in your vehicle could affect
electronic systems such as the multiport fuel injection system/sequential multiport
fuel injection system, anti-lock brake syst em, SRS airbag system and seat belt pre-
tensioner system, be sure to check with your Lexus dealer for precautionary mea-
sures or special instructions regarding installation.
Grounding of the LFA
Since the LFA is composed of CFRP (Carbo n Fiber Reinforced Plastics) body parts,
the body cannot be used as a ground terminal. As such, this vehicle has specialized
ground terminals. Consult with your Lexus dealer for the locations of the special-
ized ground terminals available for this vehicle. Do not use any portion other than
the specialized ground terminals for grounding, as doing so may cause a fire hazard.

16
Accessories, spare parts and modification of your Lexus
A wide variety of non-genuine spare parts and accessories for Lexus vehicles are
currently available in the market. You should know that Toyota does not warrant
these products and is not responsible for their performance, repair, or replacement,
or for any damage they may cause to, or adverse effect they may have on, your
Lexus vehicle.
This vehicle should not be modified with non-genuine Lexus products. Modification
with non-genuine Lexus products could affect its performance, safety or durability,
and may even violate governmental regula tions. In addition, damage or perfor-
mance problems resulting from the modification may not be covered under war-
ranty.
Scrapping of your Lexus
The SRS airbag and seat belt pretensioner devices in your Lexus contain explosive
chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left
as they are, this may cause an accident such as fire. Be sure to have the systems of
the SRS airbag and seat belt pretensioner removed and disposed of by a qualified
service shop or by your Lexus deal er before you scrap your vehicle.
Perchlorate Material
Special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate.
Your vehicle has components that may contain perchlorate. These components may
include airbags, seat belt pretensioners, and wireless remote control batteries.

17
CAUTION
■General precautions while driving
Driving under the influence: Never drive your vehicle when under the influence of
alcohol or drugs that have impaired your ability to operate your vehicle. Alcohol
and certain drugs delay reaction time, impair judgment and reduce coordination,
which could lead to an accident that could result in death or serious injury.
Defensive driving: Always drive defensively. Anticipate mistakes that other drivers
or pedestrians might make and be ready to avoid accidents.
Driver distraction: Always give your full at tention to driving. Anything that distracts
the driver, such as adjusting controls, ta lking on a cellular phone or reading can
result in a collision with resulting death or serious injury to you, your occupants or
others.
Drive considerately: Drive carefully and gently when a pregnant woman or a per-
son suffering from heart disease or other illness that requires rest is on board.
■General precaution regarding children’s safety
Never leave children unattended in the vehi cle, and never allow children to have or
use the key.
Children may be able to start the vehicle or shift the vehicle into neutral. There is
also a danger that children may injure themselves by playing with the accessory
socket, the windows, or other features of the vehicle. In addition, heat build-up or
extremely cold temperatures inside the vehicle can be fatal to children.

18
Symbols used throughout this manual
Cautions & Notices
Symbols used in illustrations
CAUTION
This is a warning against something which, if ignored, may cause death or serious
injury to people. You are informed about what you must or must not do in order to
reduce the risk of death or serious injury to yourself and others.
NOTICE
This is a warning against something which, if ignored, may cause damage to the vehi-
cle or its equipment. You are informed about what you must or must not do in order to
avoid or reduce the risk of damage to your Lexus and its equipment.
Safety symbol
The symbol of a circle with a slash through it means “Do not”,
“Do not do this”, or “Do not let this happen.”
Arrows indicating operationsIndicates the action (pushing, turning, etc.)
used to operate switches and other
devices.
Indicates the outcome of an operation (e.g.
a lid opens).
