Before driving
1-5.Refueling
Opening the fuel tank cap
Perform the following steps to open the fuel tank cap.
■Before refueling the vehicle
Turn the ignition switch to the “L OCK” position and ensure that both
side doors and windows are closed.
■ Opening the fuel tank cap
Press the opener switch.
Turn the fuel tank cap slowly to
open.
Hang the fuel tank cap on the back
of the fuel filler door.
STEP1
STEP2
STEP3

50
1-5. Refueling
Closing the fuel tank capAfter refueling, turn the fuel tank
cap until you hear a click. Once
the cap is released, it will turn
slightly in the opposite direction.
■When the fuel filler door opener switch is inoperable
The lever can be used to open the fuel filler door if the fuel filler door cannot be
opened using the inside switch because th e battery is discharged or for any other
reason.
Open the rear hatch. ( P. 2 9 )
STEP1
Remove the cover.
Pull the lever.STEP2
STEP3

51
1-5. Refueling
1
Before driving
CAUTION
■When refueling the vehicle
Observe the following precautions while refueling the vehicle.
Failure to do so may result in death or serious injury.
●Touch a metal surface (such as a static discharge plate if available) to discharge
any static electricity. As the vehicle body is made of resin touching the vehicle
body will not discharge static electricity.
Sparks resulting from discharging static electricity may cause the fuel vapors to
ignite.
●Always hold the grips on the fuel tank cap and turn it slowly to remove it.
A whooshing sound may be heard when the fuel tank cap is loosened. Wait until
the sound cannot be heard before fully removing the cap.
In hot weather, pressurized fuel may spra y out the filler neck and cause injury.
●Do not allow anyone that has not discharged static electricity from their bodies to
come close to an open fuel tank.
●Do not inhale vaporized fuel.
Fuel contains substances that are harmful if inhaled.
●Do not smoke while refueling the vehicle.
Doing so may cause the fuel to ignite and cause a fire.
●Do not return to the vehicle or touch an y person or object that is statically
charged.
This may cause static electricity to build up , resulting in a possible ignition hazard.
■When refueling
Securely insert the fuel nozzle into the fuel filler neck. When the fuel tank is filled to
the maximum level, the automatic shut of f function will engage. Do not continue
fueling once the automatic shut off function engages, as this may result in fuel over-
flowing from the tank.
■When replacing the fuel cap
Do not use anything but a genuine Lexus fuel tank cap designed for your vehicle.
Failure to do so may cause a fire or other incident which may result in death or seri-
ous injury.

52
1-5. Refueling
NOTICE
■Refueling
●Use only the specified premium-unleaded (unleaded high-octane) gasoline.
Never use regular unleaded gasoline, poor quality gasoline, diesel fuel, kerosene,
any type of alcohol-based fuel, or any type of fuel other than that specified for this
vehicle. Also, be careful not to mix up the fuel and washer fluid. Failure to follow
these precautions may cause damage to the vehicle.
●Do not spill fuel, as it may damage the vehicle's painted surface.

53
1
Before driving
1-6.Theft deterrent system
Engine immobilizer system
The vehicle's keys have built-in transponder chips that prevent the engine
from starting if the key has not been previously registered in the vehicle's on-
board computer.
Never leave the keys inside the vehicle when you leave the vehicle.
■ Setting and canceling the engine immobilizer system
U.S.A.
The system will set after the key has been removed from the ignition
switch.
The system will be canceled when the registered key is inserted into the
ignition switch.
Canada
The indicator light flashes after the
key has been removed from the
ignition switch to indicate that the
system is operating.
The indicator light stops flashing
after the registered key has been
inserted into the ignition switch to
indicate that the system has been
canceled.
■System maintenance
The vehicle has a maintenance-free type engine immobilizer system.
■Conditions that may cause the system to malfunction
●If the grip portion of the key is in contact with a metallic object
●If the key is in close proximity to or touching a key to the security system (key
with a built-in transponder chip) of another vehicle

54
1-6. Theft deterrent system
■Certifications for the engine immobilizer system For vehicles sold in the U.S.A.
FCC ID: MOZRI-33BTY
This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-
lowing two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
FCC WARNING:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
For vehicles sold in Canada
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interfer-
ence that may cause undesired operation of the device.
NOTICE
■To ensure the system operates correctly
Do not modify or remove the system. If mo dified or removed, the proper operation
of the system cannot be guaranteed.

55
1
1-6. Theft deterrent system
Before driving
Alarm
The system sounds the alarm and flashes the lights when forcible entry is
detected.
■ Triggering of the alarm
The alarm is triggered in the following situations when the alarm is set:
●A locked door is unlocked or op ened in any way other than using
the wireless remote control or key.
● The hood or rear hatch is opened.
● The tilt sensor detects a change of vehicle inclination.
■ Setting the alarm system
Close the doors, rear hatch and
hood, and lock both side doors.
The system will be set automati-
cally after 30 seconds.
The indicator light changes from
being on to flashing when the sys-
tem is set.
■Deactivating or stopping the alarm
Do one of the following to deactivate or stop the alarm.
●Unlock the doors.
● Start the engine. (The alarm will be deactivated or stopped after a
few seconds.)

56
1-6. Theft deterrent system
Tilt sensorThe tilt sensor detects changes in vehicle inclination, such as when the
vehicle is towed away.
This system is designed to deter and p revent vehicle theft but does not
guarantee absolute security against all tilts.
The tilt sensor can be canceled using the cancel switch.
Canceling the tilt sensor
Remove the key from the ignition
switch and press the tilt sensor
cancel switch in the glove box.
To set the alarm with the tilt sensor
disabled, the alarm must be set
within 5 minutes after canceling
the sensor.
The tilt sensor will revert to on each
time the ignition switch is turned to
the “ON” position.
To cancel the tilt sensor, perform the necessary procedure each time
canceling the sensors is desired.

57
1-6. Theft deterrent system
1
Before driving
■System maintenance
The vehicle has a maintenance-free type alarm system.
■Items to check before locking the vehicle
To prevent unexpected triggering of the alarm and vehicle theft, make sure of the
following.
●Nobody is in the vehicle.
●The windows are closed before the alarm is set.
●No valuables or other personal items are left in the vehicle.
■Tr i g g e r i n g o f t h e a l a r m
The alarm may be triggered in the following situations.
(Stopping the alarm deactivates the alarm system.)
■Alarm-operated door lock
●When the alarm is operating, the door s are locked automatically to prevent
intruders.
●Do not leave the key inside the vehicle when the alarm is operating, and make
sure the key is not inside the vehicle when recharging or replacing the battery.
●A person inside the vehicle opens a door,
rear hatch or hood.
●The battery is disconnected.

58
1-6. Theft deterrent system
■The alarm cannot be set when
In the following situations, the alarm cannot be set. Be careful if the vehicle will not
be used for an extended period of time.
●When a battery terminal is disconnected
●When the “D/C CUT” fuse is removed
■Canceling and automatic re-enabling of the tilt sensor
●The alarm will still be set even when the tilt sensor is canceled.
●After the tilt sensor is canceled, turning the ignition switch to the “ON” position
or unlocking the doors using the wireless remote control or key will re-enable
the tilt sensor.
●When the alarm system is set again, the intrusion sensor and tilt sensor will be
set.
■Tilt sensor detection considerations
The sensor may trigger the alarm in the fo llowing situations. Cancel the tilt sensor
as necessary.
●The vehicle is transported by a ferry, a flatbed track, train, etc.
●The vehicle is parked in a parking garage.
●Any of the tires loses air pressure.
●The vehicle is jacked up.
●An earthquake occurs or the road caves in.
NOTICE
■To ensure the system operates correctly
Do not modify or remove the system. If mo dified or removed, the proper operation
of the system cannot be guaranteed.
