Page 299 of 420
297
4-3. Do-it-yourself maintenance
4
Maintenance and care
■ Luggage compartment
FuseAmpereCircuit
1VSSR 5 A Electric power control system
2RR-IG110 AActive rear wing, electric cooling fans,
electronic parking brake, electroni-
cally controlled brake system, seat
belts, navigation system, rear window
defogger, back-up lights
3WASH
20 A Windshield washer
4F/OPN 10 A Fuel filler door opener
5TA I L 1 0 AParking lights, front side marker lights,
rear side marker lights, license plate
lights, stop/tail lights
6RR FOG 7.5 A
7AMP RH 30 A Audio system
8AMP LH 30 A Audio system
9OIL PMP 25 AASG (Automated Sequential Gear-
box)
10RR ECU-B 7.5 AActive rear wing, electronic parking
brake
11ASG-IG2 7.5 AASG (Automated Sequential Gear-
box)
Page 401 of 420
