key lexus LS400 1994 Engine / 1994 LS400: COMFORT ADJUSTMENT

COMFORT ADJUSTMENT
55 Auto mode
When the tilt and telescopic steering wheel auto mode button
on the steering column is set to the “ON” position, the current
position of the steering column becomes the memorized
position.
On
Off
When the ignition key is removed with the auto mode button set
to the “ON” position, the steering column moves forward away
from the driver and also tilts up for easy exit and entry.
When the key is inserted in the ignition, the steering column
returns to the memorized position. This occurs regardless of
whether the auto mode button is ON or OFF.
Power tilt and manual telescopic type
ADJUSTMENT OF STEERING WHEEL TILT
To adjust the tilt of the steering wheel, push the control
switch upward or downward to set it to the desired
position.
CAUTION:
This adjustment should not be made while the vehicle is
moving.

COMFORT ADJUSTMENT
56ADJUSTMENT OF TELESCOPIC STEERING COLUMN
Lock
Unlock
To adjust the steering column length, push the lock
release lever down, push or pull the steering wheel to the
desired position, and pull the lever fully up until a click is
heard.
CAUTION:

This adjustment should not be made while the vehicle
is moving.

After adjusting the steering wheel, try moving it up and
down to make sure it is locked in position.
Auto mode
When the tilt steering wheel auto mode button on the steering
column is set to the “ON” position, the current position of the
steering column becomes the memorized position.
Off
On
When the ignition key is removed with the auto mode button set
to the “ON” position, the steering column tilts up for easy exit
and entry.
When the key is inserted in the ignition, the steering column
returns to the memorized position. This occurs regardless of
whether the auto mode button is ON or OFF.

COMFORT ADJUSTMENT
57
OUTSIDE REAR VIEW MIRRORS
Adjust the mirror so you can just see the side of your
vehicle in the mirror.
Be careful when judging the size or distance of any object seen
in the outside rear view mirror on the passenger’s side. It is a
convex mirror with a curved surface. Any object seen in a
convex mirror will look smaller and farther away than if seen in
a normal flat mirror.
Power rear view mirror control
Control switch
Master switch
To adjust the power rear view mirror, first place the master
switch at “R” (right) or “L” (left), and push the control
switch on the desired side.
If the engine is not running, the key must be in the “ACC”
position for operation of the power rear view mirror.
NOTICE:
If ice should jam the mirror, do not operate the control or
scrape the mirror face. Use a spray de-icer to free the
mirror.

COMFORT ADJUSTMENT
58
Folding rear view mirrors
To fold the rear view mirror, push backward.
The rear view mirrors can be folded backward for parking in
restricted areas.
INSIDE REAR VIEW MIRROR
The mirror surface is normal when switched to DAY, and
appears slightly darker when switched to NIGHT as its
reflectivity is reduced.
While driving at night, switching the inside rear view
mirror to NIGHT by pushing the button can reduce the
reflection of the headlights of following vehicles
When the ignition key is inserted or removed, the mirror is
always in DAY mode.
Each time the button is pushed, the mode is switched between
DAY and NIGHT.
Adjust it before driving so that the rear view is the best.
When the outside air temperature is low, switching between
DAY and NIGHT may be a little slower.

COMFORT ADJUSTMENT
67
SUPPLEMENTAL RESTRAINT
SYSTEM (SRS)
The Supplemental Restraint System (SRS) consists of
Airbags and Seat Belt Pretensioners. The combination of
these two systems provides further protection to the
driver and front passenger in a severe collision.
Airbags:
In response to a severe frontal impact, the airbags inflate
and reduce the likelihood of the driver and passenger’s
heads from directly hitting the steering wheel and
instrument panel.
Seat belt pretensioners:
In response to a severe frontal impact, the seat belts are
quickly drawn back in by the retractors so that the belts
snugly restrain the driver and front passenger.The passenger airbag is activated together with the driver
airbag, even with no passenger in the front seat.
The seat belt pretensioners are activated together with the
airbags, even with no passenger in the front seat.
This indicator comes on when the ignition key is turned to
the “ACC” or “ON” position. It goes off after about 6
seconds. This means the SRS is operating properly.
The SRS warning light system monitors the front airbag
sensors, center airbag sensor assembly, inflators, seat belt
pretensioners, warning light, interconnecting wiring and power
sources.

COMFORT ADJUSTMENT
71
NOTICE:
Do not perform any of the following changes without
consulting your Lexus dealer. Such changes can
interfere with proper operation of the SRS in some
cases.

Installation of electronic items such as a mobile
two-way radio or cassette tape player.

Modifications to the suspension system.

Repairs made on or near the front fenders, front
console, steering column, steering wheel or
instrument panel near front passenger airbag or seat
belt assembly.
This SRS has a warning light to indicate operating problems.
If either of the following conditions occurs, this indicates a
malfunction of the airbags and / or seat belt pretensioners.
Even if the seat belt pretensioners should fail, the seat belt will
operate conventionally. Contact your Lexus dealer as soon as
possible to service the vehicle.

The light does not come on when the ignition key is turned
to the “ACC” or “ON” position, or remains on.

The light comes on while driving.

COMFORT ADJUSTMENT
81
DRIVING POSITION MEMORY
SYSTEM
The micro computer can memorize the position of the driver’s
seat, the height of the shoulder belt anchor of the driver’s seat
belt, and the positions of the tilt and telescopic steering, and
outside rear view mirrors. Two different driving position profiles
can be entered into the computer’s memory.
Recording a driving position in the computer’s memory can
only be done when the ignition key is in the “ON” position and
the shift lever is in the “P” position.
Setting a driving position
1. Adjust the driver’s seat, driver’s shoulder belt anchor,
tilt and telescopic steering and outside rear view mirrors
to the desired position.2. While pushing the “SET” button, push button “1” or “2”
until the signal beeps.
The beep sound means that the positions are recorded in the
computer’s memory.
By repeating these two steps and pressing the remaining
button, the driving position for another driver can be recorded.
To set a new memorized position, select the desired position
and perform step 2. The previous memory will be erased and
the new position will be set.
To make only slight changes to an already memorized position,
the easiest way is to first activate the memorized position, then
make the desired changes and perform step 2 above.

COMFORT ADJUSTMENT
82
Activating a memorized position
When you push button “1” or “2”, the driving position will
be automatically adjusted to the position recorded for that
button.
Conditions for memorized position activation

Ignition key “ON” and shift lever in “P” position
All parts of the memorized positions can be activated.
However, if the brake pedal is being depressed, the seat
position will not change.

Key not in ignition switch and within 30 seconds of opening
driver’s door.
The memorized position can be activated, except for the tilt
and telescopic steering. This will be activated when the key
is inserted into the ignition switch.If any driving position memory switch is pushed while one of
the memorized driving position profiles is being activated, the
operation will stop.
To activate the system, push the desired button (“1” or “2”)
again.
The driving position memory control system cannot be
operated while the vehicle is moving.
If the vehicle’s battery is disconnected, the computer’s
memory will be erased and the memorized positions will have
to be set again.
CAUTION:

Do not start the vehicle while the adjustments are being
made.

Take care not to select the wrong button, or the seat
could strike the rear passenger or hit your body against
the steering wheel. If this happens, you can stop the
movement by pressing another driving position
memory switch, or depressing the brake pedal.
