SECTION 1 – 2
15
INSTRUMENTS AND CONTROLS
Switches
Headlight switch16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlight dimmer and turn signal switch17 . . . . . . . . . . . . . . . . . . . . .
Fog light switch18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield wiper and washer switch19 . . . . . . . . . . . . . . . . . . . . . . . . .
Headlight cleaner switch19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window and outside rear view mirror defogger switch20 . . . . .
Power window switches21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flasher switch22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat heater switches23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SWITCHES
16
HEADLIGHT SWITCH
To turn the lights on, twist the knob on the end of the lever.
FIRST CLICKSTOP : Only the parking, tail, license plate, side
marker and instrument panel lights turn on.
SECOND CLICKSTOP : Headlights also turn on.
THIRD CLICKSTOP (“AUTO”) : The headlights and all other
lights automatically turn on depending on the darkness of the
surroundings.
When these lights are on, the indicator lights up in the
instrument cluster.
Manually twist the knob to the second clickstop to turn on
the headlights if they are needed immediately when
entering a dark tunnel, parking structure, etc.
The light control sensor is on top of the driver’s side instrument
panel.
Do not place anything on the instrument panel, and / or do not
affix anything on the windshield to block this sensor.
The lights automatically turn off when the driver’s door is
opened with the ignition turned off. To turn them on again, turn
the ignition key to the “ON” position or actuate the headlight
switch. If you are going to park for over one week, make sure
the headlight switch is off.
When the headlight switch is turned to the first or second
clickstop, the brightness of the instrument cluster will be
reduced slightly unless the instrument panel light control knob
is turned fully on.

SWITCHES
17 Daytime Running Light System (Canada only)
The headlights turn on when the parking brake is released with
the engine started, even with the light switch in the “OFF”
position. They will not go off until the ignition switch is turned
off.
To turn on the other exterior lights and instrument panel lights,
twist the knob to the first clickstop.
Under the daytime running light system, the headlights turn on
at reduced intensity. Twist the knob to the second clickstop to
turn to full intensity for driving at night.
When setting the knob to the third clickstop (“AUTO”), the
headlights will automatically adjust to full intensity and / or turn
on the other lights depending on the darkness of the
surroundings. Likewise, as the surroundings become brighter,
the headlights will turn to reduced intensity, ultimately turning
off the other lights.
NOTICE:
To prevent the battery from being discharged, do not
leave the lights on for a long period when the engine is
not running.
HEADLIGHT DIMMER AND TURN
SIGNAL SWITCH
For high beam, push the lever forward. Pull it back for low
beam. For the headlight flasher, pull it further back.
A blue light in the instrument cluster indicates high beam or
headlight flusher is on.
The headlight flasher works even when the headlight switch is
off.

SWITCHES
18
For signaling turns, move the lever up or down in the
conventional manner.
The ignition key must be in the “ON” position.
The turn signal is self-cancelling after a turn, but after a lane
change, you may have to cancel it by hand. You can also signal
a lane change by moving the turn signal lever partway and
holding it there. If the green light in the instrument cluster
flashes faster than normal, it indicates that the front or rear turn
signal bulb has burned out. If this indicator light does not come
on, the fuse or the indicator light itself has probably failed. You
may change headlight beam even while the turn signal lights
are flashing.
FOG LIGHT SWITCH
Fog light switch
To turn on the fog lights, turn the switch to the “ON”
position. The fog lights come on only when the headlights
are on low beam.
The headlights must be on.

SWITCHES
19
WINDSHIELD WIPER AND
WASHER SWITCH
Interval
adjuster
Washer on
Intermittent
operation
Slow speed
Fast speedMist wiper
operation
To turn the wipers on, move the lever down. To make the
washer squirt, push the button on the end of the lever.
The ignition key must be in the “ON” position.
For mist wiper operation (a single wipe), pull the lever toward
you and release it.
The wipers will operate at intervals when the lever is in the
“INT” position. With the lever in this position, the wipers can be
adjusted to operate at intervals of 2 to 11 seconds depending
on the interval adjuster setting between “S” and “F”.
Also, the wipers will automatically operate a couple of times
after the washer squirts even with the lever in the “OFF”
position.The low washer fluid reminder light in the instrument cluster
comes on when the fluid level in the tank becomes nearly
empty. For information on adding washer fluid, see “Adding
washer fluid” on page 230.
In cold weather, warm the windshield with the defroster before
using the washer. This will help prevent icing, which could
block your vision.
NOTICE:
Do not operate the wipers if the windshield is dry. It may
scratch the glass.
HEADLIGHT CLEANER SWITCH
(CANADA ONLY)
To spray fluid on the headlights, push the switch with the
headlights on.
The ignition key must be in the “ON” position.

SWITCHES
20The low washer fluid reminder light in the instrument cluster
comes on when the fluid level in the tank becomes nearly
empty. For information on adding washer fluid, see “Adding
washer fluid” on page 230.
NOTICE:
Do not turn the headlight cleaner on with the tank empty.
It may cause the cleaner motor to overheat.
REAR WINDOW AND
OUTSIDE REAR VIEW MIRROR
DEFOGGER SWITCH
To turn the electric rear window defogger on, push the
switch.
The ignition key must be in the “ON” position.The thin heater wires on the inside of the rear window and the
heater panels in the outside rear view mirrors will quickly clear
the surface. Keep your hands off the mirror faces when the
switch is on. An indicator light is on when the defogger is
operating.
The system will automatically shut off when the defogger has
operated about 15 minutes.
If further defrosting or defogging is desired, simply actuate the
switch again. When the surface has cleared, push the switch
once again to turn the defogger off. Continuous use may cause
the battery to discharge, especially during stop-and-go driving.
The defogger is not designed to dry rain water or to melt snow.
If the outside rear view mirrors are heavily coated with ice, use
a spray de-icer before operating the switch.
NOTICE:
When cleaning the inside of the rear window, be careful
not to scratch or damage the heater wires.

SWITCHES
21
POWER WINDOW SWITCHES
For left rear window
For right rear window
For driver’s window
For front passenger’s window
To raise or lower the windows, use the switch on each
door. The passengers’ windows can also be controlled by
the switches on the driver’s door.
The ignition key must be in the “ON” position. However, even
if the ignition key is turned to “OFF” position, the window can
be operated until a front door is opened (or for about sixty
seconds).
Operating the driver’s switch
To lower the window, push the switch halfway down. Pull
it up to raise the window. The window glass moves as long
as the switch is operated.
To fully lower the driver’s window automatically, push the
switch fully down.
In automatic operation, the window will fully open even if you
let go of the switch. To stop the window partway, lightly pull the
switch up and then release it.
Operating the passengers’ switches
To lower the window, push the switch down. Pull it up to
raise the window. The window moves as long as the
switch is operated.

SWITCHES
22
Indicator light
With the “WINDOW LOCK” switch pressed in, only the
driver’s window can be raised or lowered.
The indicator lights on the switch tell you which of the switches
can be operated.
CAUTION:
To avoid serious personal injury, you must do the
following.

Always make sure the head, hands and other parts of
the body of you and your passengers are kept
completely inside the vehicle before you close the
power windows. If someone’s neck, head or hands gets
caught in a closing window, it could result in a serious
injury. When your passengers close the power
windows, be sure that they operate the windows safely.
When small children are in the vehicle, never let them
use the power window switches without supervision.
Use the “WINDOW LOCK” switch to prevent them from
making unexpected use of the switches.

Never leave small children alone in the vehicle,
especially with the ignition key still inserted. They
could use the power window switches and get trapped
in a window. Unattended children can become involved
in a serious accidents.
EMERGENCY FLASHER SWITCH
To turn on the emergency flashers, push the switch.
All the turn signal lights will flash. The emergency flashers will
work with the engine running or off and with or without the
ignition key.

SWITCHES
23 Turn on the emergency flashers to warn other drivers if you
must stop your vehicle where it might be a traffic hazard.
Always pull your vehicle as far off the road as possible.
The turn signal light switch will not work when the emergency
flashers are in operation.
NOTICE:
To prevent the battery from being discharged, do not
leave the switch on for a long period when the engine is
not running.
SEAT HEATER SWITCHES
The seat heater has two switches one marked “L” (for the
driver’s seat) and the other marked “R” (for the front
passenger’s seat). Push these switches to turn the
respective seat heater on, and push the switches again to
turn them off.The seat heater can only be used with the ignition key in the
“ON” position.
NOTICE:
To prevent the battery from being discharged, turn the
switch on only when the engine is running.
