PICTORIAL INDEX
xii
SEAT AND STEERING WHEEL
Page
1 Tilt and telescopic steering adjustment
switch 76
. . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Seat position, seat cushion
angle and height control
switch 71, 72
. . . . . . . . . . . . . . . . . . . . . . . .
3 Seatback angle and head
restraint control switch 72, 73
. . . . . . . . . .
4 Lumbar support control switch 73 . . . . . . .
For detailed information, refer to the
description given in each section.

00L05700L056
Seat adjustment
Seat
position
Seat
cushion
angle
Seat cushion
height
Head restraint
height
Seatback
angle
Lumbar
support
Head restraint
angleSeat adjustment
Seat
position
Seat
cushion
angle
Seat cushion
height
Head restraint
height Seatback
angle
Lumbar
support
Head restraint
angle
BASIC OPERATION QUICK REFERENCE
2
1. DRIVER’S SEAT
Power head restraint type Manual head restraint type

SECTION 1 6
69
INSTRUMENTS AND CONTROLS
Comfort adjustment
Front seats 70. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Head restraints 73. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tilt and telescopic steering wheel 76. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside rear view mirrors 77. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside rear view mirror 79. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat belts 80. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Supplemental restraint system (SRS) 86. . . . . . . . . . . . . . . . . . . . . . . . . . .
Child restraint 98. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving position memory system 113. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

COMFORT ADJUSTMENT
70
FRONT SEATS
Front seat precautions
CAUTION
The SRS side airbags are installed in the driver and front
passenger seats. Observe the following precautions.
Do not lean over the front door when the vehicle is in use.
The side airbag inflates with considerable speed and force;
you may be killed or severely injured.
Do not modify or replace the seats or the surface of the seats
with side airbags. Such changes may disable the system, or
cause the side airbags to inflate, resulting in death or
serious injury. Consult your Lexus dealer.
Do not use accessories for the seats which cover the parts
where the side airbags should inflate. Such accessories may
prevent the side airbags from activating correctly, causing
death or serious injury.
Seat adjustment precautions
Adjust the driver’s seat so that the foot pedals, steering wheel and
instrument panel controls are within easy reach of the driver.
CAUTION
Do not adjust the seat while the vehicle is moving as the seat
may unexpectedly move and cause the driver to lose control
of the vehicle.
Be careful not to hit the seat against a passenger, luggage or
the rear seat.
NOTICE
Do not operate the control switch in more than one dimension
at a time. It may cause electrical overload.

COMFORT ADJUSTMENT
71
Adjusting front seats
16L1341
1
Seat position control switch, seat cushion angle and
height control switch
2
Seatback angle and head restraint control switch
3
Lumbar support control switch
Adjusting seat position
16L111
Move the control switch in the desired direction.
Releasing the switch will stop the seat in that position. Do not place
anything under the seat. It might interfere with the seat movement.

COMFORT ADJUSTMENT
72
Adjusting seatback angle
16L112
Move the control switch in the desired direction.
Releasing the switch will stop the seatback in that position.
CAUTION
To reduce the risk of sliding under the lap belt during a
collision, avoid reclining the seatback any more than needed.
The seat belts provide maximum protection in a frontal or rear
collision when the driver and the passenger are sitting up
straight and well back in the seats. If you are reclined, the lap
belt may slide past your hips and apply restraint forces
directly to the abdomen. Therefore, in the event of a frontal
collision, the risk of personal injury may increase with
increasing recline of the seatback.
Adjusting seat cushion angle and height
16L113
Move the control switch in the desired direction.
Releasing the switch will stop the seat cushion in that position.

COMFORT ADJUSTMENT
73
Adjusting lumbar support
16L114
Push the control switch on either side.
The amount of lumbar support will change as long as the switch is
pushed.
HEAD RESTRAINTS
Front seats (power type)
16L007
Move the control switch in the desired direction.
Releasing the switch will stop the head restraint in that position.

COMFORT ADJUSTMENT
74
16L008
To move the head restraint forward or rearward, pull or push on
the top.
The head restraint is most effective when it is close to your head.
Therefore, using a cushion on the seatback is not recommended.
CAUTION
Adjust the top of the head restraint so that it is closest to the
top of your ears.
Front and outside rear seats (manual type)
16L006-1
To raise the head restraint, pull it up. To lower it, press the lock
release button and push the head restraint down. To move the
head restraint forward or rearward, pull or push on the top.
The head restraint is most effective when it is close to your head.
Therefore, using a cushion on the seatback is not recommended.

COMFORT ADJUSTMENT
75
CAUTION
Adjust the top of the head restraint so that it is closest to the
top of your ears.
After adjusting the head restraint, make sure it is locked in
position.
Do not drive with the head restraints removed.
Center rear seat
16L192
To move the head restraint forward, pull on the top.
Pulling the top of the head restraint forward as far as it can go will
return it to the original position.
CAUTION
After adjusting the head restraint, make sure it is locked in
position.

COMFORT ADJUSTMENT
80
SEAT BELTS
Seat belt precautions
Lexus strongly urges that the driver and passengers in the vehicle be
properly restrained at all times with the seat belts provided. Failure
to do so could increase the chance of injury and/or the severity of
injury in accidents.
Child. Use a child restraint system appropriate for the child until the
child becomes large enough to properly wear the vehicle’s seat belts.
See ”Child restraint” for details.
If a child is too large for a child restraint system, the child should sit
in the rear seat and must be restrained using the vehicle’s seat belt.
According to accident statistics, the child is safer when properly
restrained in the rear seat than in the front seat.
If a child must sit in the front seat, the seat belts should be worn
properly. Do not let the child sit on your lap. It does not provide
sufficient restraint. If an accident occurs and the seat belts are not
worn properly, the force of the rapid inflation of the airbag may cause
severe injury to the child.
Do not allow the child to stand up or kneel on either rear or front
seats. An unrestrained child could suffer serious injury during
emergency braking or a collision.Pregnant woman. Lexus recommends the use of a seat belt. Ask
your doctor for specific recommendations. The lap belt should be
worn securely and as low as possible over the hips and not on the
waist.
Injured person. Lexus recommends the use of a seat belt.
Depending on the injury, first check with your doctor for specific
recommendations.
CAUTION
Persons should ride in their seats properly wearing their seat
belts whenever the vehicle is moving. Otherwise, they are
much more likely to suffer serious bodily injury in the event
of sudden braking or a collision.
When using the seat belts, observe the following:
Use the belt for only one person at a time. Do not use a
single belt for two or more people even children.
Avoid reclining the seatbacks too much. The seat belts
provide maximum protection when the seatbacks are in the
upright position. (See ”Adjusting seatback angle”.)
Be careful not to damage the belt webbing or hardware.
Take care that they do not get caught or pinched in the seat
or doors.
Inspect the belt system periodically. Check for cuts,
fraying, and loose parts. Damaged parts should be
replaced. Do not disassemble or modify the system.
