IN CASE OF AN EMERGENCY
358B: If no steam is coming from your engine:
Leave the engine running and turn off the air
conditioning. Check the following.

Is the cooling fan operating?
 Is the coolant in the acceptable range?
 Is the engine drive belt O.K.?
CAUTION
When the engine is running, keep hands and clothing
away from the moving fan and engine drive belt.
 Do not attempt to remove the radiator cap when the
engine and radiator are hot. Serious injury could
result from scalding hot fluid and steam blown out
under pressure.
If the cooling fan is not operating or the coolant is not in
the acceptable range, turn off the engine and call your
Lexus dealer.
If both conditions are O.K., after the engine coolant
temperature has cooled to normal, continue driving your
vehicle.
If the engine coolant temperature does not cool down, or
your vehicle overheats again, have it checked as soon
as possible by your Lexus dealer.IF YOU HAVE A FLAT TIRE
1. Reduce your speed gradually, keeping a straight line.
Move cautiously off the road to a safe place ± well away
from the traffic. Avoid stopping on the center divider of
a highway. Park on a level spot with firm ground.
2. Stop the engine and turn on your emergency flashers.
3. Firmly set the pa rking brake and put the transmission
in ºPº.
4. Have everyone get out of the vehicle on the side away

MAINTENANCE
390
GENERAL MAINTENANCE
Listed below are the general maintenance items that
should be performed at the intervals specified. It is
recommended that any problem you notice be brought
to the attention of your Lexus dealer or qualified service
shop for their advice.
CAUTION
Make these checks only where adequate ventilation can
be obtained if you run the engine.
Vehicle exterior
Items listed below should be performed from time to
time, unless otherwise specified.
Tire pressure
Check the pressure with a gauge every two weeks, or at
least once a month and adjust as shown on the tire
pressure label. See page 431 for a dditional information.
Tire surface
Check the tires carefully for cuts, damage or excessive
wear. See page 435 for additional information.
Wheel nuts
When checking the tires, make sure to check the nuts for
looseness. Tighten them if necessary. Tire rotation
Rotate
the tires every 12000 km (7500 miles). See page
433 for additional information.
Fluid leaks
Check underneath for leaking fuel, oil, water or other
fluid after the vehicle has been parked for a while. If you
smell fuel fumes or notice any leak, have the cause
found and corrected immediately.
Doors and engine hood
Check that all doors, including trunk lid, operate
smoothly and all latches lock securely. Make sure the
engine hood secondary latch secures the hood when the
primary latch is released.

MAINTENANCE
392Parking brake
Check that the pedal has the proper travel and that, on
a safe incline, your vehicle is held securely with only the
parking brake applied.
Automatic transmission ºParkº mechanism
On a safe incline, check that your vehicle is held
securely with the selector lever in ºPº position and all
brakes released.
Engine compartment
Items listed below should be checked from time to
time, e.g. each time when refueling.
Washer fluid
Make sure there is sufficient fluid in the tank. See page
464 for additional information.
Engine coolant level
Make sure the coolant level is between the Upper and
Lower lines on the see±through reservoir when the
engine is cold. See page 417
for additional information.
Battery
Your Lexus has a maintenance free battery. You do not
have to add distilled water. For longer life of the battery,
however, see page 453 for additional information.
Brake fluid level
Make sure the brake fluid level is correct. See page 427
for additional information.

MAINTENANCE
393
Engine oil level
Check
the level on the dipstick with the engine turned off
and the vehicle parked on a level spot. See page 413 for
additional information.
Power steering fluid level
Check the level on the dipstick. The level should be in
the ºHOTº or ºCOLDº range depending on the fluid
temperature. See page 428 for additional information.
Exhaust system
If you notice any change in the sound of the exhaust or
smell exhaust fumes, have the cause located and
corrected immediately. (See engine exhaust cautions in
Section 3±1.)
DOES YOUR VEHICLE NEED REPAIRING?
Be on the alert for changes in performance and sounds,
and visual tip±offs that indicate service is needed. Some
important clues are:

Engine missing, stumbling, or pinging

Appreciable loss of power

Strange engine noises

A fluid leak under the vehicle (However, water
dripping from the air conditioning after use is normal.)

Change in exhaust sound (This may indicate a
dangerous carbon monoxide leak. Drive with the
windows open and have the exhaust system checked
immediately.)

Flat±looking tires, excessive tire squeal when
cornering, uneven tire wear

Vehicle pulls to one side when driving straight on a
level road

Strange noises related to suspension movement

Loss of brake effectiveness, spongy feeling brake
pedal, pedal almost touches floors, vehicle pulls to
one side when braking

Engine coolant temperature continually higher than
normal

INTRODUCTION
401
NOTICE

Remember that battery and ignition cablescarry high currents or voltages. Be careful ofaccidentally causing a short circuit.

Before closing the engine hood, check to seethat you have not forgotten any tools, rags, etc.

Do not drive with the air cleaner removed, or
excessive engine wear could result. Alsobackfiring could cause a fire in the enginecompartment.

Do not overfill automatic transmission fluid, orthe transmission could be damaged.

Be careful not to scratch the glass surface withthe wiper frame.
PARTS AND TOOLS
Here is a list of parts and tools you will need to perform
do±it±yourself maintenance. Remember all Lexus parts
are designed in metric sizes, so your tools must be
metric.
Checking the engine oil level
Parts (if level is low):

Use API grade SJ, ºEnergy±Conservingº multigrade
engine oil or ILSAC multigrade engine oil. For
recommended oil viscosity, see page 416.
Tools:

Rag or paper towel

Funnel (only for adding oil)
Checking the engine coolant level
Parts (if level is low):

ªToyota Long Life Coolantº or equivalent
See ºChecking the engine coolant levelº on page 417
for instructions.

Demineralized or distilled water
Tools:

Funnel (only for adding coolant)

SECTION 6 ± 2
403
SERVICE PROCEDURES AND
SPECIFICATIONS
Engine
Specifications404
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel 407
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Facts about engine oil consumption 409
. . . . . . . . . . . . .
Used engine oil 411
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the engine oil level 413
. . . . . . . . . . . . . . . . . . .
Checking the engine coolant level 417
. . . . . . . . . . . . . . .
Spark plugs 421
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ENGINE
406± COOLING SYSTEM
Capacity
Coolant type
10.8 L (11.4 qt., 9.5 lmp.qt.)
ºToyota Long Life Coolantº or equivalent
With ethylene±glycol type coolant for a proper
corrosion protection of aluminum components
Do not use alcohol type antifreeze or plain water
alone.
± FUELFuel type
Octane rating
Only UNLEADED
91 (Research octane number 96) or higher
± IGNITION SYSTEMSpark plug ± Make DENSO NGK
± Gap
SK20R11
IFR6A11
1.1 mm (0.043 in.)
± ELECTRICAL SYSTEM
Battery Open voltage at 20 C (68F):
Charging rates
12.7V Fully charged
12.3V Half charged
11.9V Discharged
[Voltage that is checked 20 minutes after the key is
removed with all the lights turned off]
5A max.

ENGINE
411
Importance of engine oil level check
One of the most important points in proper vehicle
maintenance is to keep the engine oil at the optimum
level so that oil function will not be impaired. Therefore,
it is essential that the oil level be checked regularly.
Lexus recommends that the oil level be checked every
time you refuel the vehicle.
NOTICE
Failure to check the oil level regularly could leadto serious engine trouble due to insufficient oil.
For detailed information on oil level check, see
ºChecking the engine oil levelº described below.
USED ENGINE OIL

ENGINE
413
CHECKING THE ENGINE OILLEVEL
62L004a
With the engine at operating temperature and turned
off, check the oil level on the dipstick.
1. To get a true reading, the vehicle should be on a level
spot. After turning off the engine, wait a few minutes for
the oil to drain back into the bottom of the engine.
2. Pull out the dipstick, and wipe it clean with a rag.
3. Reinsert the dipstick and push it in as far as it will go,
or the reading will not be correct.

ENGINE
415
If the oil level is below or only slightly above the low
line,
add engine oil of the same type as already in the
engine. Remove the oil filler cap and add engine oil a little at a
time,
checking the dipstick. The approximate quantity of
oil needed to fill between the low level line and the full
level line on the dipstick is indicated below for reference.
When the level reaches within the correct range, return
the filler cap and turn the cap clockwise until you hear a
click.
Oil quantity. L (qt., lmp. qt.) 1.5 (1.6, 1.3)
NOTICE
Avoid overfilling, or the engine could be
damaged. Ch eck the oil level on the dipstick once
again after adding the oil.
