radio lexus LS400 2000 Engine / LEXUS 2000 LS400 OWNER'S MANUAL (OM50533U)

iiiThis vehicle should not be modified with non±genuine
Lexus products. Modification with non±genuine Lexus
products could affect its performance, safety or
durability, and may even violate governmental
regulations. In addition, damage or performance
problems resulting from the modification may not be
covered under warranty.
Spark ignition system of your Lexus
The spark ignition system in your Lexus meets all
requirements of the Canadian Interference±Causing
Equipment Standard.
Installation of a mobile two±way radio
system
As the installation of a mobile two±way radio system in
your
vehicle could affect electronic systems such as the
multiport fuel injection system/sequential multiport fuel
injection system, cruise control system, anti±lock brake
system, SRS airbag system and seat belt pretensioner
system, be sure to check with your Lexus dealer for
precautionary measures or special instructions
regarding installation.
Scrapping of your Lexus
The SRS airbag and seat belt pretensioner devices in
your Lexus contain explosive chemicals. If the vehicle
is scrapped with the airbags and seat belt pretensioners
left as they are, this may cause an accident such as a
fire. Be sure to have the system of the SRS airbag and
seat belt pretensioner removed and disposed of by a
qualified service shop or by your Lexus dealer before
you scrap your vehicle.

KEYS AND DOORS
25
This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment
generates, uses and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures:
± Reorient or relocate the receiving antenna.
± Increase the separation between the
equipment and receiver.
± Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
± Consult the dealer or an experienced radio /
TV technician for help.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
67
(e) Discharge Warning Light
This light warns that the battery is being discharged.
If it comes on while you are driving, stop the vehicle, turn
off the engine, and check for the cause. Look first at the
engine drive belt.
If it is loose or broken, the generator will not charge
the battery properly.
 If the belt is O.K., there is a problem somewhere in the
charging system.
The engine ignition will continue to operate, however,
until the battery is discharged. Turn off the air
conditioning, blower, radio, etc., and drive directly to the
nearest Lexus dealer or repair shop.
NOTICE
Do not continue driving if the engine drive belt is broken or loose.
(f) Malfunction Indicator Lamp
This lamp comes on in the following cases.
a. The fuel tank is completely empty. (See ºFuel gaugeº
on page 57 for instructions.)
b. The fuel tank cap is not tightened securely. (See
ºFuel tank capº on page 114 for instructions.)
c. There is a problem somewhere in your engine
electrical system, automatic transmission electrical
system or electronic throttle control system.
If it comes on while you are driving in case ªc.º, have your
vehicle checked/repaired by your Lexus dealer as soon
as possible.
If this lamp comes on and the engine speed does not
increase with the accelerator pedal depressed down to
about the middle position, there may be a problem
somewhere in your electronic throttle control system.
At this time, if you depress the accelerator pedal more
firmly and slowly, you can drive your vehicle at low
speeds. Have your Lexus checked by your Lexus dealer
as soon as possible.
Even if the abnormality of the electronic throttle control
system is corrected during low speed driving, the system
may not be recovered until the engine is stopped and the
ignition key is turned to ªACCº or ªLOCKº position.

COMFORT ADJUSTMENT
159
NOTICE
Do not perform any of the following changeswithout consulting your Lexus dealer. Suchchanges can interfere with proper operation of the
seat belt pretensioners in some cases.
Installation of electronic devices such as a mobile two±way radio, cassette tape player orcompact disc player.
Repairs on or near the front seat belt retractorassemblies.
Modification of the suspension system.
Modification of the front end structure.
Attachment of a grille guard (bull bar, kangaroo
bar, etc.), snowplow, winches or any other equipment to the front end.
Repairs made on or near the front fenders, front
end structure or console.

COMFORT ADJUSTMENT
181
Do not use accessories for the seats which
cover the parts where the side airbags inflate.
Such accessories may prevent the side airbags
from activating correctly, causing death or
serious injury.
 Do not modify or remove any wiring. Do not
modify, remove, strike or open any
components, such as the steering wheel pad,
steering wheel, column cover, front passenger
airbag cover, front seats or airbag sensor
assembly. Doing any of these may cause
sudden SRS airbag inflation or disable the
system, which could result in death or serious
injury.
 Do not modify or replace the seats or
upholstery of the front seats with side airbags.
Such changes may disable the system or cause
the side airbags to inflate accidentally,
resulting in death or serious injury. Consult
your Lexus dealer if you consider
modifications of this kind.
Failure to follow these instructions can result in
death or serious injury.NOTICE
Do not perform any of the following changes without consulting your Lexus dealer. Suchchanges can interfere with proper operation of the
SRS in some cases.
Installation of electronic devices such as a mobile two±way radio, cassette tape player orcompact disc player.
Modification of the suspension system.
Modification of the front end structure and sidestructure of the passenger compartment.
Attachment of a grille guard (bull bar, k angaroo
bar, etc.), snowplow, winches or any other equipment to the front end.
Repairs made on or near the front fenders, front
end structure, console, steering column, steering wheel, dashboard near the frontpassenger airbag or front seats.

AUDIO
243
1Turning the system on and adjusting volume
(See page 244 for details.)
2Stopping and ejecting a cassette tape
(See page 255 for details.)
3Function buttons
1 ± 6: Station selector buttons
(See page 252 for details.)
SCAN: Scan tuning
(See page 255 for details.)
P. SCAN: Preset scan tuning (See page 255 for details.)
4Display of functions in TAPE mode

:
Side change
(See page 257 for details.)
: DOLBY NR
(See page 257 for details.)
 :Rewinding
(See page 258 for details.)


:Fast forwarding
(See page 258 for details.)
RPT: Automatic repeat
(See page 259 for details.)
SKIP: Automatic skip of blank portions of tape
(See page 259 for details.)
SCAN: Scan selection
(See page 260 for details.)
4
Display of functions in CD mode
:Disc selection
(See page 267 for details.)
 :Reversing
(See page 271 for details.)


:Fast forwarding
(See page 271 for details.)
RPT: Automatic repeat
(See page 272 for details.)
RAND: Random access
(See page 272 for details.)
SCAN: Scan selection
(See page 269 for details.)
5
Mode selectors
(See page 246 for details.)
6Cassette tape slot
(See page 255 for details.)
7Automatic sound levelizer
(Except Nakamichi model)
(See page 248 for details.)
8Tone and balance knobs
(See page 247 for details.)
9Radio mode: Frequency tuning
( S e e p a g e 251 o r 253 f o r
details.)
10TAPE mode: Direct access to a desired

AUDIO
249
(d) Your radio antenna
The wire antenna is mounted inside the rear window.
NOTICE
When
cleaning the inside of the rear window, be
careful not to scratch or damage the wire antenna.
Putting a window tint (especially, conductive ormetallic type) on the rear window may affect thereception of radio or m obile telephone. For the
installation of the window tint, consult with your Lexus dealer.
(e) Your cassette player
When you insert a cassette, the exposed tape should be
to the right.
NOTICE
Do not oil any part of the cassette player, and do not insert anything except a cassette tape into theslot.
(f) Your automatic changer

AUDIO
251
Radio operation
(a) Listening to the radio
20L045a
Push these buttons to choose either an AM or FM
station.
ºAMº, ºFM1º or ºFM2º appears on the display.

AUDIO
252
20L046±1
Push this button on the upper side to step up the
station band or on the lower side to step down.
Your radio automatically changes to stereo reception
when a stereo broadcast is received. ºSTº appears on
the display. If the signal becomes weak, the radio
reduces the amount of channel separation to prevent the
weak signal from creating noise. If the signal becomes
extremely weak, the radio switches from stereo to mono
reception. In this case, ºSTº disappears from the
display. (b) Presetting a station

AUDIO
253
20L047a
1. Tune in the desired station.
2. Push one of the station selector buttons ( 1±6 )
and hold it until a beep is heard. This sets the station
to the button and the button number ( 1±6 ) appears
on the display.
Each button can store one AM station and two FM
stations. To change the preset station to a different one,
follow the same procedure.
The preset station memory is cancelled when the power
source is interrupted by battery disconnection or a blown
fuse. (c) Selecting a station
Your Lexus has an electronic tuning radio ( ETR ). Tune
in the desired station using one of the following methods.
