steering lexus LS400 2000 Engine / LEXUS 2000 LS400 OWNER'S MANUAL (OM50533U)

00L054a
PICTORIAL INDEX
xiv
SEAT AND STEERING WHEEL
Page
1 Tilt and telescopicsteering adjustmentswitch 134 . . . . . . . . . . . . . .
2 Seat position, seat
cushionangle and height control
switch 126, 128 . . . . . . . . . .
3 Seatback angle and head
restraint control switch . . 127, 129
4 Lumbar support control
switch 129 . . . . . . . . . . . . . .
For detailed information, refer to the description givenin each section.

BASIC OPERATION
1
QUICK REFERENCE
Driver's seat2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering wheel 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic transmission 5
. . . . . . . . . . . . . . . . . . . . . . . . . .
Headlight and turn signal switch 7
. . . . . . . . . . . . . . . . . .
Wiper switch 8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

BASIC OPERATION ± QUICK REFERENCE
3
2. STEERING WHEEL

TILT STEERING WHEEL
00L009a
To tilt the steering wheel up or down to the desired
angle, push the control switch in the required
direction and release the button when the steering
wheel reaches the desired angle.

TELESCOPIC STEERING WHEEL

BASIC OPERATION ± QUICK REFERENCE
4
00L010a
To move the steering wheel to the desired position,
push the control switch away from you or pull it
toward you until the steering wheel reaches the
desired position.

SECTION 1 ± 6
122
INSTRUMENTS AND CONTROLS
Comfort adjustment
Front seats122
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Head restraints 129
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tilt and telescopic steering wheel 134
. . . . . . . . . . . . . . .
Outside rear view mirrors 136
. . . . . . . . . . . . . . . . . . . . . .
Inside rear view mirror 141
. . . . . . . . . . . . . . . . . . . . . . . . .
Seat belts 143
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SRS airbags 161
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Child restraint 184
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving position memory system 210
. . . . . . . . . . . . . . . .
FRONT SEATS
Front seat precautions

COMFORT ADJUSTMENT
124
Seat adjustment precautions
Adjust the driver's seat so that the foot pedals, steering
wheel and instrument panel controls are within easy
reach of the driver.
CAUTION
Do not adjust the seat while the vehicle is moving as
the seat may unexpectedly move and cause the
driver to lose control of the vehicle.
 Be careful not to hit the seat against a passenger,
luggage or the rear seat.
NOTICE
Do not operate the control switch in more than
one dimension at a time. It may cause electricaloverload.
Adjusting front seats

COMFORT ADJUSTMENT
134
TILT AND TELESCOPICSTEERING WHEEL
Adjustment of steering wheel tilt
16L010a
To adjust the tilt of the steering wheel, push the
control switch upward or downward to set it to the
desired position.
CAUTION
Do not adjust the steering wheel while the vehicle is
moving.

COMFORT ADJUSTMENT
135
Adjustment of telescopic steering
column
16L011a
To adjust the steering column length, push the
control switch forward or backward to set the
steering wheel to the desired position.
CAUTION
Do not adjust the steering column while the vehicle is
moving.

COMFORT ADJUSTMENT
136
Auto tilt away*
16L012b
When the ignition key is removed, the steering
column moves forward away from the driver and
also tilts up for easy exit and entry.
When the key is inserted in the ignition switch, the
steering column returns to the previously set position.
NOTE: *This feature can be set inoperative. Ask your
Lexus dealer for details.
OUTSIDE REAR VIEW MIRRORS
16L016

COMFORT ADJUSTMENT
161
SRS AIRBAGS
The SRS (Supplemental Restraint System) airbags
are designed to provide further protection for the
driver and front passenger in addition to the primary
safety protection provided by the seat belts.
16L118c

Driver and front passenger airbags
In response to a severe frontal impact, the driver and
front passenger airbags work together with the seat
belts to help reduce injury by inflating. The driver
and front passenger airbags help to reduce injuries
mainly to the driver's or front passenger's head or
chest directly hitting the steering wheel or
dashboard.
The front passenger airbag is activated even with no
passenger in the front seat.
Be sure to wear your seat belt.
