STARTING AND DRIVING
370
TIRE PRESSURE WARNINGSYSTEM
The tire pressure warning system is designed to provide
warning using a message in the multiinformation
display, master warning light and warning tone when tire
inflation pressure is critically low while driving. This
message appears to inform you that such low tire
pressure may hamper driving.
As this system is not designed to operate when the vehicle is
stopped, check the tire inflation pressure regularly. The
recommended cold tire inflation pressure, tire size and the
vehicle capacity weight are on the tire and loading information
label. (For instructions, see “Checking tire inflation pressure”
on page 468.)
Installed tires should be of the specified size. They should be
of the same size and construction. If tires other than the
specified size are used, or if tires of different sizes or
constructions are mixed, the tire pressure warning system will
not function properly.
Low tire pressure warning message
w264
When the low tire inflation pressure is detected while
driving, the master warning light comes on, the above
message appears and a warning tone sounds.
If the above message appears and adjust the tire inflation
pressure to the specified level as soon as possible. Push the
tire pressure warning system reset switch for a few seconds
and make sure the warning message goes off. If the message
still remains on, have your vehicle checked by your Lexus
dealer as soon as possible.
The tire pressure warning system does not function
properly under certain circumstances. In the following
cases, the low tire pressure warning may not turn on even
if the tire inflation pressure is low, or it may turn on when
the tire inflation pressure is actually normal.
 A compact spare tire, snow tires, or tire chains are used.
 The tire inflation pressure is excessively higher than
specified, or tire inflation pressure suddenly drops due to
bursting or other causes.
 You are driving on slippery road surfaces such as rough or
frozen roads.
 You are driving under 30 km/h (19 mph) or above 100 km/h
(62 mph) for less than 5 minutes.
 The tires differ in tread pattern or manufacturer.
 The tires are not the specified size.

STARTING AND DRIVING
371

The degree of the tread wear is very different among the
installed tires.
 Rapid acceleration/deceleration or sharp turns are
continued.
 Towing a trailer.
 The loading is over the limit or unbalanced.
 Initialization was not performed correctly after replacing or
rotating tires or wheels.
 The outside temperature is below 0 C (32F) or above
40 C (104 F).
If the warning message appears again on the
multi−information display after adjusting tire inflation pressure,
the system may be malfunctioning. Have your vehicle
checked by your Lexus dealer as soon as possible.
CAUTION
When the tire pressure warning message appears,
observe the following instructions:
 Adjust the tire inflation pressure to the specified level
as soon as possible.
 Avoid abrupt steering wheel maneuvering and
braking. If the vehicle tires are deteriorated, you
could lose control of the steering wheel or the brakes,
causing death or serious injury.
Note: The tire pressure mon itoring system on your
vehicle will warn you when one of your tires is
significantly underinflated and when some
combinations of your tires are significantly
underinflated. However, there are other combinations
of significantly underinflated tires for which your tire
pressure warning system may not warn you. These
other combinations are relatively common, accounting
for approximately half the instances in which vehicles
have significantly underinflated tires. For example,
your system may not warn you when both tires on the
same side or on the same axle of your vehicle are
significantly underinflated. It is particularly important,
therefore, for you to check the tire inflation pressure in
all of your tires regularly and maintain proper pressure.

STARTING AND DRIVING
372
Tire pressure warning system reset switch
31L568b
The tire pressure warning system needs to be initialized
after tires or wheels are replaced or rotated.
To initialize the system, perform the following:
1. Park the vehicle at a safe place with the parking brake
applied and turn the ignition switch to “LOCK”.
2. Adjust the pressure of all the installed tires to the specified
level. (See “Tires and wheels” on pages 463 through 465.)
3. Turn the ignition switch to “ON”.
If the low tire pressure warning message “Low Tire” appears
in the multi−information display, push the reset switch for a few
seconds and make sure the warning message goes off.
4. With the vehicle stopped, push and hold the reset switch
until “Pressure Initial” appears in the multi−information display.
W266
Initialization is completed after driving at the speeds of 30
km/h (19 mph) or over for more than one hour. If the
following driving conditions are satisfied, initialization
will be completed in about one hour.
 The vehicle speeds is between 50 km/h (31 mph) and
100 km/h (62 mph).
 The roads are dry, smooth and straight.
 The number of passengers is one or two (including the
driver).
If you make a mistake in the middle of initialization, perform the
operation from the beginning again.
Do not push the reset switch without adjusting the tire inflation
pressure to the specified level. Otherwise, the low tire
pressure warning may not turn on even if the tire inflation
pressure is low, or it may turn on when the tire inflation
pressure is actually normal.
If you push the reset switch while driving, initialization is not
performed.
If “Pressure Initial”does not appear when the reset switch is
held down, the system may be malfunctioning. Have your
vehicle checked by your Lexus dealer as soon as possible.

STARTING AND DRIVING
373
Tire pressure system warning message
w265
If there is a problem electrically in the tire pressure
warning system, the master warning light comes on, the
above message appears and a warning tone sounds. At
this time the multiinformation display indicates which
part causes an error.
Although it is no problem to continue driving with the above
message on the display, have your vehicle checked by your
Lexus dealer as soon as possible.
BRAKE PAD WEAR LIMITINDICATORS
13L338
 1Master warning light
2Brake pad wear warning message
When your brake pads are worn enough to require
replacement, the warning tone sounds, the master
warning light flashes and the brake pad wear warning
message in the multiinformation display appears.
If the warning message appears while driving, have the brake
pads checked and replaced by your nearest Lexus dealer
immediately.
Continuous driving without replacing the brake pads will cause
expensive rotor damage and increasing brake pedal effort to
get the same stopping distance.

ENGINE
454
327.Engine oil selection
“Toyota Genuine Motor Oil” is used in your Lexus vehicle. Use
Lexus approved “Toyota Genuine Motor Oil” or equivalent to
satisfy the following grade and viscosity.
Oil grade: API grade SL “Energy −Conserving” or ILSAC
multigrade engine oil.
Recommended viscosity (SAE): 5W −30
62L042
Outside temperature
SAE 5W30 is the best choice, for good fuel economy and
good starting in cold weather.
If SAE 5W30 is not available, SAE 10W30 may be used.
However, it should be replaced with SAE 5W30 at the next
oil change.
Oil identification marks
62L038
 API Service Symbol ILSAC Certification Mark
Either or both API registered marks are added to some oil
containers to help you select the oil you should use.
 The API Service Symbol is located anywhere on the outside
of the container.
The top portion of the label shows the oil quality by API
(American Petroleum Institut e) designation such as SL.
The center portion of the label shows the SAE viscosity
grade such as SAE 5W −30. “Energy− Conserving”, shown
in the lower portion, indicates that the oil has fuel −saving
capabilities.
 The ILSAC (International L ubricant Standardization and
Approval Committee) Certification Mark is displayed on the
front of the container.

ELECTRICAL COMPONENTS
492
64L206
Engine compartment
No.FUSEAMPERECIRCUIT
1 TI & TE20Tilt and telescopic steering
2 PANEL7.5
Lexus park assist system, Rear
seat heater, Rear climate
control seat, Multi− information
display, Audio system,
Cigarette lighter, Instrument
panel light, Coin box light, Rear
mirror light, Glove box light,
Power rear seat, Electronically
modulated air suspension
system, Turn signal lights,
Clock, Shift lock system,
Vehicle stability control system,
Sunshade, Power rear view
mirror control system, Console
box light, Fuel opener system,
Adaptive Front Lighting System
(AFS)
3 D P/SEAT30Power seat system
4 GAUGE7.5Gauges and meters, Lexus
park assist system, Shift lock
system
5 MPXIG7.5
Tilt and telescopic steering,
Power door lock system, Power
seat system, Engine
immobilizer system
6 D S/HTR15Seat heater, Climate control
seat system
7 AIR SUS20Electronically modulated air
suspension system
8 DACC7.5Shift lock system, Theft
deterrent system

ELECTRICAL COMPONENTS
493
No.FUSEAMPERECIRCUIT
9 PWR
OUTLET15Power outlet
10 DCIG15Rear cigarette lighter
11 OBD7.5On− board diagnosis system
12 AM17.5Starting system
13 ABSIG7.5Vehicle stability control system
14 D B/ANC5Seat belts
15 SECURITY7.5Theft deterrent system
16 A/C7.5Air conditioning system
17 STOP5Stop lights
18 D RRIG10Refreshing seat
19 IG230SRS airbag system, Engine
immobilizer system, Steering
lock system, Starting system
20 HAZ15Emergency flashers
21 STR LOCK7.5Steering lock system
22 AM27.5All components in “STA” and
“IG2”, Starting system
23 MPXB17.5
Power door lock system,
Engine immobilizer system,
Steering lock system, Front
power seat, Rear power seat
24 MPXB37.5
Tilt and telescopic steering,
Headlight switch, Windshield
wiper and washer switch, Turn
signal switch
No.FUSEAMPERECIRCUIT
25 DOME10
Vanity lights, Outer foot lights,
Ignition switch light, Clock,
Gauges and meters, Interior
lights, Personal lights
26 MPXB27.5Gauges and meters, Vehicle
stability control system,
Illuminated entry system, TEL
27 P RRIG10Refreshing seat
28 HLP LVL7.5Headlight leveling system,
Adaptive Front Lighting System
(AFS)
29 PIG7.5Rain sensor, Air conditioning
system, Moon roof,
Multi −information display, Clock
30 P S/HTR15Seat heater, Climate control
seat system
31 PACC7.5
Air conditioning system, Audio
system, Clock,
Multi −information display,
Illuminated entry system
32 PCIG15Front cigarette lighter
33 RADIO
NO.17.5Audio system
34 RR DOOR LH20Power door lock system, Power
window, Door closer system,
Door courtesy lights
