GAUGES, METERS AND SERVICE REMINDER INDICATORS
82
ODOMETER AND TRIP METER
13L145
This meter displays the odometer and two trip meters. To
change the mode indication, push the “ODO/TRIP” button
briefly. Each time you push the button, the mode changes
in order from the odometer to trip meter A to trip meter B,
then to the odometer.
The odometer records the total distance the vehicle has
been driven. The twin trip meter records two different
distances independently.
For example, you can use one meter to calculate the fuel
economy and the other to measure the distance on each trip.
To change the trip meter indication from one trip to the
other, push the “ODO/TRIP” button. To set the trip meter
A to zero, display the meter A reading, then push the
“RESET” button. The same applies for the trip B meter.
The data of trip meters will be cancelled if the electrical power
source is disconnected.
SERVICE REMINDER INDICATORS AND WARNING BUZZERS
IF THIS INDICATOR OR
BUZZER COMES ON ...DO THIS.
(a)or
If parking brake is off,
stop immediately and
contact Lexus dealer.
(b)
(Indicator and buzzer)
Fasten driver’s seat
belt.
(c)Fasten front
passenger’s seat belt.
(d)Take vehicle to Lexus
dealer immediately.
(e)Stop and check.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
83
IF THIS INDICATOR OR
BUZZER COMES ON ...
DO THIS.
(f)orTake vehicle to Lexus
dealer.
(g)See multi− information
display.
(h)or
Take vehicle to Lexus
dealer.
If brake system
warning light is also
on, stop immediately
and contact Lexus
dealer
(i)Close all doors.
(j)Low fuel level
warning lightFill up tank.
IF THIS INDICATOR OR BUZZER COMES ON ...DO THIS.
(k)Key reminder
buzzerRemove key.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
87
At this time, vibration may occur. However, if you depress the
accelerator pedal more firmly and slowly, you can drive your
vehicle at low speeds. Have your Lexus checked by your
Lexus dealer as soon as possible.
Even if the abnormality of the electronic throttle control system
is corrected during low speed driving, the system may not be
recovered
until the engine is stopped and the ignition switch is
turned to “ACC” or “LOCK” position.
Emissions inspection and maintenance (I/M) programs
Your vehicle may not pass a state emission inspection if the
malfunction indicator lamp remains on. Contact your Lexus
dealer to check your vehicle’s emission control system and
OBD (On −Board Diagnostics) system before taking your
vehicle for the inspection.
For details, see “Emissions inspection and maintenance (I/M)
programs” on page 431.
(g) Master Warning Light
If any system malfunctions, this warning light comes on or
flashes together with a warning tone, and a warning message
appears in the multi−information display. When the cause of
the problem is eliminated, the warning tone and message on
the display will turn off.
(h) “ABS” Warning Light
The light comes on when the ignition switch is turned to the
“ON” position. If the anti−lock brake system and the brake
assist system work properly, the light turns off after a few
seconds. Thereafter, if either of the systems malfunctions, the
light comes on again.
When the “ABS” warning light is on (and the brake system
warning light is off), the anti −lock brake system, the brake
assist system, the traction control system and/or the vehicle
stability control system do/does not operate, but the brake
system still operates conventionally.
When the “ABS” warning light is on (and the brake system
warning light is off), the anti− lock brake system does not
operate so that the wheels could lock up during a sudden
braking or braking on slippery road surfaces.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
90
MULTIINFORMATION DISPLAY
13L146
The multiinformation display provides various
information, including your vehicle’s driving condition,
outside temperature, and warning messages if your
vehicle is in trouble.
During ordinary driving, cruise information and graphic
information are displayed. However, if any problem
occurs in your vehicle, a warning message appears above
the cruise information.
(a) Cruise information
13L197
 1 “DISP1” button 2“DISP2” button
3“RESET” button
The following information is shown with the ignition
switch turned on. Each time you push the “DISP1” button,
the displayed information is changed.
 Available driving distance
 Average fuel consumption
 Current fuel consumption
 Average fuel consumption after being refueled
 Driving distance after being refueled
 Elapsed time
 Average vehicle speed
 Blank

GAUGES, METERS AND SERVICE REMINDER INDICATORS
91
The displayed cruise information values indicate the general
driving
condition and may not always reflect precise and actual
conditions.
 Available driving distance
w244
When the fuel gauge is close to “F”
W25w245
When the fuel gauge is close to middle
w246
When the fuel gauge is close to “E”
The available driving distance is calculated and displayed
depending on the amount of remaining fuel.
 Average fuel consumption
W27W247
The average fuel consumption is calculated and displayed
based on the total driving distance and the total fuel
consumption with the engine running.
The value is updated every 10 seconds.
To begin recalculating, push the “RESET” button for about 1 to
2 seconds.
 Current fuel consumption
W28W248
The current fuel consumption is calculated and displayed
based on the driving distance and the fuel consumption
per 2 second interval with the engine running.
The value is updated every 2 seconds.
If you are driving at low speeds just before stopping, the
accurate figure may not be shown.
Average fuel consumption after refueling
W29W249
The average fuel consumption after refueling is
calculated and displayed based on the total driving
distance and the total fuel consumption after refueling.
The value is updated every 10 seconds.
When refueling, be sure to stop your vehicle and turn the
ignition switch off.
The average fuel consumption could not be calculated in either
of the following cases:
 Refueled by opening the fuel filler door using the manual
lever in the trunk
 Refueled with a small quantity of gasoline
To begin recalculating, push the “RESET” button for about 1 to
2 seconds.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
92The multi−
information display shows “Tank Avg –.– MPG” for
a while after refueling or pushing the “RESET” switch, and then
shows the previous average fuel consumption until you start
the vehicle.
 Driving distance after refueling
w250
The driving distance after refueling is displayed.
When refueling, be sure to stop your vehicle and turn the
ignition switch off.
The driving distance after refueling could not be calculated in
either of the following cases:
 Refueled by opening the fuel filler door using the manual
lever in the trunk
 Refueled with a small quantity of gasoline
To begin recalculating, push the “RESET” button for about 1 to
2 seconds.
 Elapsed time
W31W251
The total time that the engine has been running is
displayed.
When the engine is started again after the ignition is off, the
driving time is added to the previous value. Up to 99 hours 59
minutes can be displayed. When the driving time exceeds 99
hours 59 minutes, the display returns to 0 and recounting
starts.
To begin recalculating, push the “RESET” button for about 1 to
2 seconds.
 Average vehicle speed
w252
The average vehicle speed is calculated and displayed
based on the total driving distance and the total driving
time with the engine running.
The displayed value is updated every 10 seconds.
To begin recalculating, push the “RESET” button for about 1 to
2 seconds.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
93
(b) Graphic information
13L147
The following graphic information is shown on the
display.
Any door open
 Compass display (if equipped)
 Outside temperature display
 Lexus park assist system display (if equipped)
 Dynamic radar/laser cruise control display (if equipped)
 Blank
If any door is opened, the warning message also reminds you
to close the door. When the ignition is turned on, the previously selected display
appears. Each time you push the “DISP2” button for about 1
to 2 seconds, the display changes from compass (if the
compass is
initially displayed) to outside temperature to blank
screen, then back to compass.
For the compass, see “Compass” on page 105. For the outside
temperature display, see “Outside temperature display” on
page 117.
If you push the main switch of the Lexus park assist system or
turn the ignition on with the main switch of the Lexus park assist
system on, the Lexus park assist system screen appears for
2 seconds and then the multi −information display returns to the
previous screen.
When you push the main switch of the dynamic radar/laser
cruise control, the dynamic radar/laser cruise control screen
appears. Each time you push the “DISP2” switch for 1 to 2
seconds, the screen changes to compass, outside
temperature display, blank screen, and then back to the
dynamic radar/laser cruise control screen. When the display
shows a screen other than dynamic radar/laser cruise control,
the multi −information display returns to the dynamic
radar/laser cruise control screen after 6 seconds. For details,
see “Dynamic radar/laser cruise control” on page 329.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
94
(c) Warning messages
13L148
W40W253
When the engine oil pressure becomes too low, the
master warning light comes on, a warning tone sounds
and the above message appears.
If this message appears while you are driving, pull off the road
to a safe place and stop the engine immediately. Call a Lexus
dealer or qualified repair shop for assistance.
The message may appear when the oil level is extremely low.
It is not designed to indicate low oil level, and the oil level must
be checked using the oil level dipstick.
NOTICE
Do not drive the vehicle while this warning message is
displayed even for one block. It may ruin the engine.
W41W254
When your brake pads have worn down enough to require
replacement, the master warning light flashes and a
warning tone sounds and the above message appears.
If this message appears while you are driving, have the brake
pads checked and replaced by your Lexus dealer as soon as
possible.
W50W255
When the engine oil level is too low, the master warning
light flashes, a warning tone sounds, and the above
message appears.
Add oil as soon as possible. (For instructions, see “Checking
the engine oil level” on page 452.)
While driving on steep inclines or rough roads which causes
the vehicle to substantially sway or on curves, this message
may appear due to the movement of engine oil in the engine.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
95
In normal conditions, due to engine oil consumption, this
message may a
ppear earlier than the specified service interval
of the scheduled maintenance. This is because the engine oil
is consumed to the low level within the scheduled maintenance
interval and does not indicate a problem. (For detailed
information, see “Facts about engine oil consumption” on page
450.)
NOTICE
Continued engine operation with low engine oil will
damage the engine.
w282
This message indicates that the engine oil maintenance
data has been reset. After replacing the engine oil, be sure
to reset the maintenance data.
To reset the data, perform the following operations:
1. Push the “ODO/TRIP” button to change the display to
blank.
2. Turn the ignition switch off.
3. Turn the ignition switch to “ON” with the trip meter
“RESET” button held down.
4. Keep pushing the “RESET” button for longer than 5
seconds after the ignition is turned on.
After the above operation, the master warning light comes
on, a warning tone sounds and the above message
appears to inform you that the engine oil maintenance
data has been reset. (U.S.A. only)
