LEXUS LS430 2005 Owners Manual

IN CASE OF AN EMERGENCY
402
CAUTION
Batteries contain sulfuric acid which is poisonous
and corrosive. Wear protective safety glasses when
jump starting, and avoid spilling acid on your skin,
clothing, or vehicle.
 If you should accidentally get acid on yourself or in
your eyes, remove any contaminated clothing and
flush the affected area with water immediately. Then
get immediate medical attention. If possible,
continue to apply water with a sponge or cloth while
en route to the medical office.
 The gas normally produced by a battery will explode
if a flame or spark is brought near. Use only
standardized jumper cables and do not smoke or
light a match while jump starting.
NOTICE
The battery used for boosting must be 12 V. Do not jump
start unless you are sure that the booster battery is
correct.
40L140a
 5 Discharged battery 6Booster battery
JUMP STARTING PROCEDURE
1. If the booster battery is installed in another vehicle, make
sure the vehicles are not touching. Turn off all unnecessary
lights and accessories.

IN CASE OF AN EMERGENCY
403
When boosting, use the battery of matching or higher quality.
Any other battery may be difficult to jump start with.
If jump starting is difficult, charge the battery for several
minutes.
2. If required, remove all the vent plugs from the booster
battery. Lay a cloth over
the open vents on the booster battery.
(This helps reduce the explosion hazard, personal injuries and
burns.)
If the booster battery is an extended maintenance interval
battery, it is not necessary to remove the vent plugs.
3. If the engine in the vehicle with the booster battery is not
running, start it and let it run for about 5 minutes. During jump
starting, run the engine at about 2000 rpm with the accelerator
pedal lightly depressed.
4. Locate positive (+) and negative (–) terminals of each
battery. Connect the jumper cables in the exact order (
1 2 3 4) shown in the illustration.
1 Connect a positive (red) jumper cable clamp to the
positive (+) terminal of the discharged battery.
2Connect the clamp at the other end of the positive (red)
cable to the positive (+) terminal of the booster battery.
3Connect a negative (black) cable clamp to the negative
(–) terminal of the booster battery.
4Connect the clamp at the other end of the negative (black)
cable to a solid, stationary, unpainted metallic point (such
as shown in the illustration) away from the battery. Do not
connect it to or near any part that moves when the engine
is cranked.
CAUTION
When making the connections, to avoid serious injury,
do not lean over the battery or accidentally let the
jumper cables or clamps touch anything except the
correct battery terminals or the ground.
5. Start your engine in the normal way. After starting, run it at
about 2000 rpm for several minutes with the accelerator pedal
lightly depressed.
6. Carefully disconnect the cables in the exact reverse order:
the negative cable and then the positive cable.
7. Carefully dispose of the battery cover cloths which may now
contain sulfuric acid.
8. If removed, replace all the battery vent plugs.
If the cause of your battery discharging is not apparent (for
example, lights left on), you should have it checked at your
Lexus dealer.
If the first start attempt is not successful...
Check that the clamp on the jumper cables are tight. Recharge
the discharged battery with the jumper cables connected for
several minutes and restart your engine in the normal way.
If another attempt is not successful, the battery may be
depleted. Have it checked at your Lexus dealer.

IN CASE OF AN EMERGENCY
404
IF YOU CANNOT INCREASEENGINE SPEED
If engine speed does not increase when the accelerator
pedal is depressed, there may be a problem somewhere
in the electronic throttle control system . Move the vehicle
to a safe place by means of creeping and call a Lexus
dealer for assistance:
1. Depress the brake pedal and shift to the “D” position.
2. Gradually release the brake pedal, and the vehicle starts to
move by creeping. After arriving at a safe place, stop the
vehicle and call a Lexus dealer for assistance.
CAUTION
 The above method of moving the vehicle is for
emergency. Use it only for moving minimum
distances to a safe place.
 Be especially careful to prevent erroneous pedal
operation.
IF YOUR VEHICLE OVERHEATS
If your engine coolant temperature gauge indicates
overheating, if you experience a loss of power, or if you
hear a loud knocking or pinging noise, the engine has
probably overheated.
When the engine overheats
Pull safely off the road, stop the vehicle and turn on your
emergency flashers. Put the transmission in “P” and apply the
parking brake.
A: If steam is coming from your engine:
Turn off the engine. Leave the hood closed until there is no sign
of steam or coolant. Your engine could have been seriously
damaged already. Call your Lexus dealer for assistance.
CAUTION
To help avoid personal injury, keep the hood closed until
there is no steam. Escaping steam or coolant is sign of
very high pressure.

IN CASE OF AN EMERGENCY
405
B: If no steam is coming from your engine:
Leave the engine running and turn off the air conditioning.
Check the following.

Is the cooling fan operating?
 Is the coolant in the acceptable range?
 Is the engine drive belt O.K.?
CAUTION
When the engine is running, keep hands and clothing
away from the moving fan and engine drive belt.
 Do not attempt to remove the radiator cap when the
engine and radiator are hot. Serious injury could
result from scalding hot fluid and steam blown out
under pressure.
If the cooling fan is not operating or the coolant is not in the
acceptable range, turn off the engine and call your Lexus
dealer.
If both conditions are O.K., after the engine coolant
temperature has cooled to normal, continue driving your
vehicle.
If the engine coolant temperature does not cool down, or your
vehicle overheats again, have it checked as soon as possible
by your Lexus dealer.
IF YOU HAVE A FLAT TIRE
1. Reduce your speed gradually, keeping a straight line.
Move cautiously off the road to a safe place − well away
from the traffic. Avoid stopping on the center divider of
a highway. Park on a level spot with firm ground.
2. Stop the engine and turn on your emergency flashers.
3. Firmly set the parking brake and put the transmission
in “P”.
4. Have everyone get out of the vehicle on the side away
from traffic.
5. Read the following instructions thoroughly.
CAUTION
When jacking, be sure to observe the following to
reduce the possibility of personal injury:
 Follow jacking instructions.
 Do not put any part of your body under a vehicle
supported by a jack. Otherwise, personal injury
may occur.
 Do not start or run the engine while your vehicle
is supported by the jack.

IN CASE OF AN EMERGENCY
406
Stop the vehicle on a level firm ground, firmly
set the parking brake and put the transmission
in “P”. Block the wheel diagonally opposite to
the one being changed if necessary.
 Make sure to set the jack properly in the jack
point. Raising the vehicle with jack improperly
positioned will damage the vehicle or may allow
the vehicle to fall off the jack and cause
personal injury.
 Never get under the vehicle when the vehicle is
supported by the jack alone.
 Use the jack only for lifting your vehicle during
wheel changing.
 Do not raise the vehicle with someone in the
vehicle.
 When raising the vehicle, do not put an object
on or under the jack.
 Raise the vehicle only high enough to remove
and change the tire.
 For vehicles equipped with the height control
switch, be sure to turn the ignition switch off
before jacking. If this is not done, the vehicle
height adjustment function will operate, which
may cause an accident.NOTICE
Do not continue driving with a deflated tire.
Driving even a short distance can damage a tire
and wheel beyond repair.

IN CASE OF AN EMERGENCY
407
Access to spare tire
40L079
1. Pull up the deck board.
40L080
2. Lift up the back side of the board and secure the
board by hooking the lever at the top of the trunk lid
opening as shown.
Make sure the board is secured and does not fall down.

IN CASE OF AN EMERGENCY
408
40L081
When closing the board, replace the hook also in its
original position as shown.
NOTICE
If you close the trunk lid with the board hooked,
the hook may be damaged.
40L051b
 1Tool box
2Towing eyelet (For emergency towing)
3Jack handle 4Spare tire 5Jack
1. Get the tool, jack and spare tire.
To prepare yourself for an emergency, you should
familiarize yourself with the use of the jack and each tool,
and their storage locations.

IN CASE OF AN EMERGENCY
409
40L052
 1 Joint
2 When removing the jack, turn the joint by hand inthe “contract” direction until the jack is free.
3 When storing, turn the joint by hand in the“expand” direction until the jack is firmly secured
to prevent it from flying forward during a collision
or sudden braking.
40L160
To remove the spare tire:
1 Remove the spare tire cover.
2 Loosen the bolt and remove it.
When storing the spare tire, place it with the inner side
of the wheel facing up. Then bolt the tire in place and
install the spare tire cover to prevent the tire from flying
forward during a collision or sudden braking.

IN CASE OF AN EMERGENCY
410
40L169
2. Block the wheel diagonally opposite the flat tire to
keep the vehicle from rolling when it is jacked up.
When blocking a wheel, place a wheel block in front of
one of the front wheels or behind one of the rear wheels.
40L161
3. Loosen all the wheel nuts.
Always loosen the wheel nuts before raising the vehicle.
Turn the wheel nuts counterclockwise to loosen them.
To get maximum leverage, fit the wrench to the nut so
that the handle is on the right side, as shown above.
Grab the wrench near the end of the handle and pull up
on the handle. Be careful that the wrench does not slip
off the nut.
Do not remove the nuts yet − just unscrew them about
one−half turn.
CAUTION
Never use oil or grease on the bolts or nuts. The
nuts may loosen and the wheels may fall off, which
could cause a serious accident.

IN CASE OF AN EMERGENCY
411
40L170
4. Position the jack at the jack points as shown.
Make sure the jack is positioned on a level and solid
surface.
40L162
5. After making sure no one is in the vehicle, raise it
high enough so that the spare tire can be installed.
Allow for the fact that you need more ground clearance
when putting on the spare tire than when removing the
flat tire.
To raise the vehicle, insert the jack handle into the jack
(it is a loose fit) and turn it clockwise. As the jack touches
the vehicle and begins to lift, double −check that it is
properly positioned.
CAUTION
Never get under the vehicle when the vehicle is
supported by the jack alone.
