LEXUS LS430 2005 Owners Manual

ELECTRICAL COMPONENTS
502
CHECKING THE CARTRIDGE TYPEFUSES
64L201
Engine compartment
64L202
Engine compartment
omg062d
Good Blown
If the headlights or other electrical components do not
work and the blade type fuses are O.K., check the
cartridge type fuses. If any of the cartridge type fuses are
blown, they must be replaced.
If there is an overload in the circuits from the battery, the fuses
are designed to blow before the entire wiring harness is
damaged.
CAUTION
Always use a genuine Lexus fuse or equivalent for
replacement. Never install an ordinary wireeven for a
temporary fix. This may cause extensive damage and
possibly a fire.

ELECTRICAL COMPONENTS
503
NOTICE
Before replacing the fuses, have the cause of electrical
overload determined and repaired by your Lexus dealer.
ADDING WASHER FLUID
64L095b
If the washer tank becomes nearly empty, add washer
fluid.
You may use plain water as washer fluid. However, in cold
areas where temperatures range below the freezing point, use
washer fluid containing antifreeze. This product is available at
your Lexus dealer and most auto parts stores. Follow the
manufacturer’s directions for how much to mix with water.
NOTICE
Do not use engine antifreeze or any other substitute
because it may damage your vehicle’s paint.

ELECTRICAL COMPONENTS
504
CHECKING THE HEADLIGHT AIM
64L228
 1Vertical movement adjusting bolt 1
2Vertical movement adjusting bolt 2
Before checking the headlight aim:
1. Be sure that the body around the headlight is not deformed.
2. Park the vehicle on a level spot.
3. Get into the driver’s seat and put the vehicle in a state ready
for driving (with a full tank).
4. Bounce the vehicle several times.
Adjusting the vertical aiming
64L229
1. Turn the vertical movement adjusting bolt 1 in either
direction using a Phillips −head screwdriver. At this time, keep
the turning direction and number of turns in mind.

ELECTRICAL COMPONENTS
505
64L230
2. Turn the vertical movement adjusting bolt 2 the same
number of turns and in the same direction as step 1 using a
Phillips−head screwdriver.
REPLACING LIGHT BULBS
The illustrations on the following pages show the locations of
light bulbs. If it is necessary to replace a bulb, take your vehicle
to your Lexus dealer as soon as possible. Use bulbs with the
bulb numbers and wattage ratings given in the table.
The tail and stop lights consist of a number of LEDs. If any LED
burns out, we recommend you take your vehicle to your Lexus
dealer to have the light inspected as soon as possible.
CAUTION
 To prevent burning yourself, do not replace the light
bulbs while they are hot.
 Halogen bulbs have pressurized gas inside and
require special handling. They can burst or shatter if
scratched or dropped. Hold a bulb only by its plastic
or metal case. Do not touch the glass part of a bulb
with bare hands.
 Do not touch the high voltage socket when the
headlights turn on. 20000 V is momentarily
generated and may cause severe injury by an electric
shock.
 Do not disassemble, repair or take apart the headlight
bulbs, connector, power supply circuits and rotated
components. Or you may be injured by electric
shocks. Call your dealer when the headlights fail to
work or have to be replaced or disposed of.

ELECTRICAL COMPONENTS
506
NOTICE
Only use a bulb of the listed type.
The inside of the lens of exterior lights such as headlights may
temporarily fog up when the lens becomes wet in the rain or in
a car wash. This is not a pr oblem because the fogging is
caused by the temperature dif ference between the outside and
inside of the lens, just like the windshield fogs up in the rain.
However, if there is a large drop of water on the inside of the
lens, or if there is water pooled inside the light, contact your
Lexus dealer. LIGHT LOCATION
64L209
Light Bulbs
Bulb No. W Type
1 Headlight (High beam) 9005 60 A
2 Parking light −−−5D
3 Headlight (Low beam) −−−35 B
4 Front turn signal light −−−21 D
5 Front side marker light −−−5D
6 Fog light 9006 51 C

ELECTRICAL COMPONENTS
507
64L210b
Light BulbsBulb No. W Type
1 High mounted stoplight −−−21 D
2 Trunk light 194 3.8 D
3 License plate light −−−5D
4 Back− up light 921 16 D
5 Rear turn signal light −−−21 D
64L211
Light Bulbs Bulb No. W Type
1 Front personal light −−−8F
2 Front interior light −−−8E
3 Front vanity light −−−3E
4 Rear vanity light −−−3E
5 Rear interior light,
Rear personal light −−−8F
6 Door courtesy light 194 3.8 D

ELECTRICAL COMPONENTS
508A: HB3 halogen bulbs
B: D2S discharge bulbs
C: HB4 halogen bulbs
D: Wedge base bulbs
E: Double end bulbs
F: Single end bulbs

ELECTRICAL COMPONENTS
509

SECTION 6 – 5
510
SERVICE PROCEDURES AND
SPECIFICATIONS369.
Body
Specifications511
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Protecting your vehicle from corrosion 512
. . . . . . . . . . . . . . . . . . . . . .
Washing and waxing 513
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Cleaning the interior 515
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.

BODY
511
370.SPECIFICATIONS
– DIMENSIONS AND WEIGHTSOverall length
5015 mm (197.4 in.)
Overall width1830 mm (72.0 in.)
Overall height– with electronically modulated air suspension
– without electronically modulated air suspension
1470 mm (57.9 in.)*
1490 mm (58.7 in.)*
Wheelbase2925 mm (115.2 in.)
Tread
– Frontwith electronically modulated air suspension
without electronically modulated air suspension
– Rear with electronically modulated air suspension
without electronically modulated air suspension
1575 mm (62.0 in.)
1570 mm (61.8 in.)
1575 mm (62.0 in.)
1570 mm (61.8 in.)
Vehicle capacity weight (occupants + cargo)410 kg (900 lb.)
Towing capacity (trailer weight + cargo weight)907 kg (2000 lb.)
*Unladen vehicle
– FUEL TANK
Capacity
84 L (22.2 gal., 18.5 lmp.gal.)
